Pro Series | DH-IPC-HDBW5442HN-ZHE
ArccPro
The Dahua ArccPro Series of extreme-environment cameras combine
temperature-tolerant components, a waterproof enclosure, and an
integrated heater to ensure awless operaon in temperatures as low as
–40° C (–40° F). For applicaons that demand high-resoluon video with
advanced features in extremely cold environments, the Dahua ArccPro
Series oers a camera to sasfy the most demanding requirements.
Enhanced Power over Ethernet (ePoE) Technology
Dahua's innovave ePoE technology oers a plug-and-play soluon to
transmit power and data over long distances via Ethernet or coaxial
cables, reducing installaon me and saving money. ePoE technology
encompasses pure IP systems
Cybersecurity
Dahua network cameras are equipped with a series of key cybersecurity
technologies including: security authencaon and authorizaon, access
control, trusted protecon, encrypted transmission, and encrypted
storage. These technologies improve the camera’s ability to prevent
malicious access and to protect data.
Environmental
The camera complies with an IK10 impact rang making it capable of
withstanding the equivalent of 5 kg (11.02 lbs) of force dropped from
a height of 40 cm (15.75 in.). Subjected to rigorous dust and water
immersion tests and cered to the IP67 Ingress Protecon rang makes
it suitable for demanding outdoor applicaons.
us.dahuasecurity.com
• 1/1.8-in. 4MP Progressive-scan CMOS Sensor
• Triple-stream Encoding
• Smart H.265+ and Smart H.264+ Dual Codec
• 4MP (2688 x 1520) at 30 fps
• Ultra Wide Dynamic Range (140 dB)
•Analytics+ Functions — Perimeter Protection, People Counting, and Smart
Motion Detection
•Starlight+ Technology for Low-light Applications
• Enhanced Power and Data Transmission Distances (ePoE)
•Maximum IR Distance 40 m (131.20 ft)
•ArcticPro Series Camera — Operational down to –40° C (–40° F)
•IP67 Ingress Protection, IK10 Vandal Resistance, NEMA 4X Enclosure Rating
•Five-year Warranty*
4MP Corrosion-resistant Network Dome Camera
ePoE Network Camera with NEMA 4X Enclosure RatingIR Vari-focal
*Warranty applies to products sold through an authorized Dahua Dealer.
System Overview
The Dahua 4MP corrosion-resistant network camera features a special
coang that makes the camera compliant to the NEMA 4X standard. The
camera oers a motorized vari-focal lens, True Wide Dynamic Range,
and Starlight technology for crisp, clear images in most applicaons.
Plus, the camera oers Smart Moon tecon d advanced De an
perimeter protection intelligence. The camera is suitable for salt-spray
and corrosive environments where rugged onditions persist. c
Funcons
People Counng
The camera uses complex real-me people counng algorithms to
deliver accurate ow stascs from two disnct people counng
funcons, Line Crossing and Regional. The line crossing funcon counts
the number of people crossing a dened line, and the regional funcon
counts the number of people in a disnct, user-dened area.
Perimeter Protecon
Dahua Analycs+ includes Tripwire and Intrusion funcons that oer
custom tripwires based on object type for automaon in limited access
areas. Perimeter Protecon requires less pixels to detect an object to
deliver improved accuracy and decreased false alarms due to lights,
weather, trees, or animals.
Starlight+
WizMind Series devices oer the full complement of Dahua Analycs+
funcons for comprehensive, human-oriented analyc soluons. WizMind
Series products deliver perimeter protecon, vehicle and crowd density
stascs, video metadata, and advanced people counng with heat map
funconality. WizMind is ideal for complex applicaons with demanding
requirements that need advanced analyc capabilies.
us.dahuasecurity.com
Pro Series | DH-IPC-HDBW5442HN-ZHE
White Balance Auto, Natural, Street Lamp, Outdoor, Manual,
Regional Custom
Gain Control Auto, Manual, Gain Priority, Shutter Priority
Noise Reduction 3D DNR
Motion Detection Off, On (4 Zones, Rectangular)
Region of Interest Off, On (4 Zones)
Advanced Features Smart IR, Defog, Electronic Image Stabilization
Flip 0°, 90°, 180°, 270°
Mirror Off, On
Privacy Masking Off, On (8 Areas, Rectangular)
Audio
Compression PCM, G.711a, G.711Mu, G.726, G.723
Network
Ethernet RJ-45 (10/100 Base-T)
Protocol
HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, SMTP,
FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS,
UPnP, NTP, ICMP, IGMP, 802.1x
Interoperability ONVIF Profile S, G, T; CGI, P2P; SDK; API
Auto Register Support
Streaming Method Unicast, Multicast
Maximum User Access 20 Users (Total Bandwidth: 80 Mbps)
Edge Storage
Network Attached Storage (NAS)
SFTP, FTP
Micro SD Slot, maximum 256 GB
Web Viewer IE (Versions 8 and later)
Chrome, Firefox
Management Software DSS, DMSS
Mobile Operating System IOS, Android
Cybersecurity
Video Encryption, Firmware Encryption,
Configuration Encryption, Digest, WSSE, Account
Lockout, Security Logs, IP/MAC Filtering, Generating
and Importing X.509 Certification, Syslog, HTTPS,
802.1x, Trusted Boot, Trusted Execution, Trusted
Upgrade
Cercaons
Safety
UL60950-1
CAN/CSA C22.2 No.60950-1-07
EN62368-1, EN60950-22
Electromagnetic Compatibility
(EMC)
CFR 47 FCC Part 15 Subpart B
Electromagnetic Compatibility Directive 2014/30/EU
Interface
Audio Input One (1) Channel
Output One (1) Channel
Alarm
Input Three (3) Channels (5 mA, 3 VDC to 5 VDC)
Output Two (2) Channels (300 mA, 12 VDC)
Electrical
Power Supply 12 VDC (±25%), 24 VAC (±30%),
PoE (IEEE 802.3af, Class 0), or ePoE
Power
Consumption
Basic
12 VDC: 3.6 W
24 VAC: 3.1 W
PoE: 4.4 W
Maximum
12 VDC: 11.7 W
24 VAC: 11.3 W
PoE: 11.9 W
Technical Specicaon
Camera
Image Sensor 1/1.8-in. 4MP CMOS
Effective Pixels 2688(H) x 1520(V)
RAM/ROM 1 GB / 128 MB
Scanning System Progressive
Electronic Shutter Speed Auto, Manual, 1/3 s to 1/100,000 s
Minimum Illumination
Color: 0.003 lux at F1.8 (30 IRE)
B/W: 0.0003 lux at F1.8 (30 IRE)
0 lux at F1.8 with IR on
S/N Ratio Greater than 56 dB
IR Illumination Distance 40.0 m (131.20 ft)
IR On/Off Control Auto, Manual
IR Illuminators Three (3)
Lens
Lens Type Motorized Vari-focal
Mount Type ø14
Focal Length 2.7 mm to 12 mm
Max. Aperture F1.8
Angle of View
Horizontal: 44° to 107°
Vertical: 29° to 69°
Diagonal: 53° to 134°
Iris Type Auto
Close Focus Distance 1.20 m (47.24 ft)
DORI
Distance¹
Lens Detect
(8 ppf)
Observe
(19 ppf)
Recognize
(38 ppf)
Identify
(76 ppf)
Wide 57.0 m
(187.0 ft)
23.0 m
(75.46 ft)
11.0 m
(36.09 ft)
5.70 m
(18.70 ft)
Tele 130.70
(428.81)
52.0
(170.60)
26.0
(85.30)
13.0
(42.65)
Installaon Angle
Range
Pan: 0° to 355°
Tilt: 0° to 80°
Rotation: 0° to 355°
Video
Compression Smart H.265+, H.265, Smart H.264+, H.264, H.264B, H.264H,
MJPEG (sub stream only)
Streaming Capability Three (3) Streams
Resolution
4MP (2688 x 1520), 2560 x 1440,
3MP (2304 x 1296), 1080p (1920 x 1080),
1.3MP (1280 x 960), 720p (1280 x 720), D1 (704 x 480),
VGA (640 x 480), CIF (352 x 240)
Frame Rate²
Main Stream: 4MP (2688 x 1520) at 30 fps or
1080p (1920 x 1080) at 60 fps
Sub Stream 1: D1 at 30 fps
Sub Stream 2: 1080p at 30 fps
Bit Rate Control CBR/VBR
Bit Rate H.264: 32 Kbps to 8192 Kbps
H.265: 32 Kbps to 8192 Kbps
Day/Night Auto (ICR), Color, B/W
BLC Mode BLC, HLC, Ultra WDR (140 dB), SSA
