NPort 5200 Series
Quick Installation Guide
Sixth Edition, March 2 201
1. Overview
The NPort 5200 Series of compact palm-sized device servers are
used to control RS-232 (NPort 5210/5230/5210-T/5230-T) or
RS-422/485 (NPort 5230/5232/5232I/5230-T/5232 T/5232I- -T)
serial devices over a TCP/IP- based Ethernet.
Note:
“-T” indicates an extended temperature model.
2. Package Checklist
Before installing NPort 5200, verify that the package contains the
following items:
• 1 NPort 5200 2- port Serial Device Server
• Documentation & Software CD
• NPort 5200 Series Quick Installation Guide
Optional Accessories
• DK- 35A
DIN- Rail Mounting Kit (35 mm)
• CBL- - RJ45M9 150
RJ45 (8-pin) to DB9 (M) cable, 150 cm
• CBL- - RJ45F9 150
RJ45 (8- pin) to DB9 (F) cable, 150 cm
• CBL- - RJ45M25 150
RJ45 (8-pin) to DB25 (M) cable, 150 cm
• CBL- - RJ45F25 150
RJ45 (8-pin) to DB25 (F) cable, 150 cm
• DIN-Rail Power Supply and Adapter
Notify your sales representative if any of the above items is
missing or damaged.
3. Hardware Introduction
The NPort 5200 series of device servers are used to control
RS-232/422/485 devices. NPort 5210/5210- -T has two 8 pin RJ45
ports, both for the RS-232 interface. NPort 5230/5230-T has one
10-pin terminal block, with 5 pins used for one RS-232 port, and 5
pins used for one RS-422/485 port. NPort
5232/5232I/5232 T/5232I- - -T have one 10 pin terminal block, with
5 pins used for one RS-422/485 port, and 5 pins used for another
RS-422/485 port.
Reset Button—Press the Reset button continuously for 5 sec to
load factory defaults: Use a pointed object, such as a straightened
paper clip or toothpick, to press the reset button. This will cause
the Ready LED to blink on and off. The factory defaults will be
loaded once the Ready LED stops blinking (after about 5 seconds).
At this point, you should release the reset button.
NPort 5200 LED Indicators (top panel)
LED
Name
LED
Color
LED Function
Ready
red
Steady on:
Power is on and NPort 5200 is
booting up.
Blinking:
Indicates an IP conflict, or DHCP
or BOOTP server did n
ot respond
properly.
green
Steady on:
Power is on and NPort 5200 is
functioning normally.
Blinking:
The device server has been
located by Administrator’s
Location function
off
Power is off, or power error condition exists.
Ethernet
orange
10 Mbps Ethernet connection.
green
100 Mbps Ethernet connection.
off
Ethernet cable is disconnected, or has a
short.
P1, P2
orange
Serial port is receiving data.
green
Serial port is transmitting data.
off No data is being transmitted or received
through the seri al port.
4. Hardware Installation Procedure
STEP 1: After removing NPort 5200 from the box, the first thing
you should do is connect the power adaptor. Connect the 12-30
VDC power line with NPort 5200’s terminal block, or connect the
DIN- Rail power supply with NPort 5200’s terminal block.
STEP 2: Connect NPort 5200 to a network. Use a standard
straight-through Ethernet cable to connect to a Hub or Switch.
When setting up or testing NPort 5200, you might find it
convenient to connect directly to your computer’s Ethernet port. In
this case, use a cross-over Ethernet cable.
STEP 3: Connect NPort 5200’s serial port to a serial device.
STEP 4: Placement Options
In addition to placing
NPort 5200 on a desktop
or other horizontal
surface, you may also
make use of the DIN
-
Rail
or Wall Mount options, as
illustrated here.
Wall Mount
DIN- Rail
Produkt Specifikationer
Mærke: | Moxa |
Kategori: | Server |
Model: | NPort 5210 |
Vægt: | 320 g |
Opbevaringstemperatur (T-T): | -20 - 85 °C |
Relativ luftfugtighed ved drift (H-H): | 5 - 95 % |
Relativ luftfugtighed ved opbevaring (H-H): | 5 - 95 % |
Driftstemperatur (T-T): | 0 - 55 °C |
Dimensioner (BxDxH): | 67 x 100.4 x 22 mm |
Forbindelsesteknologi: | Ledningsført |
Certificering: | EN 60601-1-2 B, EN55011 |
LED-indikatorer: | Ja |
Effektkrav: | 12/48 VDC, 305 mA |
Grænseflade: | RS-232 |
Maksimal dataoverførselshastighed: | 0.2304 Mbit/s |
Gennemsnitstid mellem fejl (MTBF): | 134850 t |
I/O-porte: | 2 x RS-232 |
Sikkerhed: | UL: UL60950-1, TÜV: EN60950-1 |
Datalink-protokol: | Ethernet, Fast Ethernet |
Elektromagnetisk udstråling: | CE: EN55022/EN55024 A, FCC: FCC 15 BA |
