Philips Comfort GC1573 Manual
Læs nedenfor 📖 manual på dansk for Philips Comfort GC1573 (2 sider) i kategorien Jern. Denne guide var nyttig for 12 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/2
General description (fig. 1)IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
ATemperature control dial
BSteam control dial
O= no steam
q= moderate steam
w= maximum steam
x= Calc-Clean function
CSpray button T
DSpray nozzle
ETemperature pilot light
FWater filling opening
GWater tank
HType plate
ICord
JExtra Steam function (press steam control dial) (type GC1580)
KAuto shut-off (type GC1580)
LRelease button for water tank
MShot of Steam function (type GC1573 and GC1575)
ImportantIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
Read these instructions for use carefully before using the appliance and save them
for future reference.
◗Check if the voltage indicated on the type plate corresponds to the local
mains voltage before you connect the appliance.
◗If the appliance is provided with an earthed plug, it must be plugged into an
earthed wall socket.
◗Do not use the appliance if the plug, the cord or the appliance itself shows
visible damage, or if the appliance has been dropped or is leaking.
◗Check the cord regularly for possible damage.
◗If the mains cord is damaged, it must be replaced by Philips, a service centre
authorised by Philips or similarly qualified persons in order to avoid a hazard.
◗Never leave the appliance unattended when it is connected to the mains.
◗Never immerse the iron and the stand, if provided, in water.
◗Keep the appliance out of the reach of children.
◗Young children should be supervised to ensure that they do not play with the
appliance.
◗This appliance is not intended for use by young children or infirm persons
without supervision.
◗The soleplate of the iron can become extremely hot and may cause burns if
touched.
◗Do not allow the cord to come into contact with the soleplate when it is hot.
◗When you have finished ironing, when you clean the appliance, when you fill
or empty the water tank and also when you leave the iron even for a short
while: set the steam control to position O, put the iron on its heel and
remove the mains plug from the wall socket.
◗Always place and use the iron and the stand, if provided, on a stable, level
and horizontal surface.
◗Do not put perfume, vinegar, starch, descaling agents, ironing aids or other
chemicals in the water tank.
◗This appliance is intended for household use only.
Before first useIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
1Remove sticker or protective foil from the soleplate if there is any.
2Heat up the iron to the maximum temperature and pass the iron over a
piece of damp cloth for several minutes to remove any residues from the
soleplate.
The iron may give off some smoke when you use it for the first time. This will cease
after a short while.
Filling the water tankIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
Never immerse the iron in water.
1Remove the mains plug from the wall socket.
2Set the steam control to position O (= no steam) (fig. 2).
3Press and hold the release button and remove the detachable water tank
(fig. 3).
4Fill the water tank with cold tap water up to the maximum level (fig. 4).
Do not fill the water tank beyond the MAX indication.
Only use water. Do not use vinegar, starch, ironing concentrates or chemically
descaled water.
If the tap water in your area is very hard, we advise you to mix it with an equal
amount of distilled water or to use distilled water only.
5Push the water tank back into the iron until you hear a ‘click’.
Setting the temperatureIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
1Put the iron on its heel.
2Check the garment label for the required ironing temperature:
1Synthetic fabrics (e.g. acrylic, viscose, polyamide, polyester)
1Silk
2Wool
3Cotton, linen
If you do not know what kind of fabric(s) a garment is made of, determine the right
ironing temperature by ironing a part that will be invisible when you wear the
garment.
Silk, woollen and synthetic materials: iron the reverse side of the fabric to prevent
shiny patches. Avoid using the spray function to prevent stains.
Start ironing the articles that require the lowest ironing temperature, such as those
made of synthetic fibres.
3Set the temperature control dial to the required ironing temperature by
turning it to the appropriate temperature indication (fig. 5).
4Put the mains plug in an earthed wall socket.
5When the temperature pilot light has gone out, wait a while before you start
ironing (fig. 6).
The pilot light will go on from time to time during ironing.
Steam ironingIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
1Make sure that there is enough water in the water tank.
2After the temperature pilot light has gone out, set the steam control to the
appropriate steam position (fig. 7).
qfor moderate steam (temperature settings 2to MAX)
wfor maximum steam (temperature settings 3to MAX)
The iron will start producing steam as soon as the set temperature has been
reached.
3Set the temperature control dial to the recommended position.
See 'Setting the temperature'.
Ironing without steamIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
1Set the steam control dial to position O (= no steam).
2Set the temperature control dial to the recommended position.
See 'Setting the temperature'.
Other featuresIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
Spray function
To remove stubborn creases at any temperature
◗Make sure there is enough water in the water tank.
1Press the spray button several times to moisten the article to be ironed
(fig. 8).
Extra Steam (type GC1580)
This function provides extra steam to remove very stubborn creases.
◗The Extra Steam function only works at temperature settings between 3
and MAX.
1Set the steam control dial to the maximum position w(fig. 9).
2Press and hold the steam control dial for maximal 5 seconds (fig. 10).
3Release the steam control dial and wait at least 1 minute before using this
function again to prevent water from dripping out of the soleplate.
Shot of steam (types GC1575 and GC1573)
A powerful shot of steam helps to remove stubborn creases.
Use the Shot-of-Steam function only at temperature settings between 3and
MAX.
1Press and release the Shot of steam button (fig. 11).
Wait for while before using the button again to avoid spluttering.
Never direct the steam towards people.
ASO - Auto shut off (type GC1580)
An electronic safety device will automatically switch off the iron if it has not been
removed for a while.
To indicate that the iron has been switched-off, the red auto-off pilot light will start
blinking (fig. 12).
- In a horizontal position, this will happen after 30 seconds.
- In a vertical position, this will happen after 8 minutes.
To heat up the iron again:
- Pick up the iron or move it slightly.
- The red auto-off pilot light will go out. The amber temperature pilot light will go
on.
- When the amber pilot light has gone out and goes on again, the iron is ready
for use.
Cleaning and maintenanceIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
Calc-Clean function
The Calc-Clean function removes scale and impurities.
Use the Calc-Clean function once every two weeks. If the water in your area is very
hard (i.e. when flakes come out of the soleplate during ironing), you should use the
Calc-Clean function more frequently.
1Set the steam control dial to position O.
2Set the temperature control dial to MAX.
3Fill the water tank to the maximum level.
Do not pour vinegar or other descaling agents into the water tank.
4Put the plug in the wall socket.
5Unplug the iron when the temperature pilot light has gone out.
6Hold the iron over the sink and set the steam control to the Calc-Clean
position •(fig. 13).
7Pull the steam control dial slightly upwards and gently shake the iron until all
water in the tank has been used up.
Steam and boiling water will come out of the soleplate, flushing out impurities and
scale.
8Press the steam control dial back to its original position and set it to position
O after having used the Calc-Clean function.
9Repeat the Calc-Clean process if the iron still contains a lot of impurities.
10 To clean the steam control needle, pull the steam control out of the
appliance (fig. 14). Use vinegar to remove scale, if any, from the needle
(fig. 15).
Do not bend or damage the steam control needle.
1Reinsert the steam control needle by placing the point of the needle exactly
in the centre of the hole and by fitting the small projection on the side of the
needle into the slot (fig. 16).
2Set the steam control to position O.
After the Calc-Clean process
1Connect the iron to the mains to let the soleplate dry.
2Unplug the iron when the pilot light has gone out.
3Move the iron gently over a piece of used cloth to remove any water stains
that may have formed on the soleplate.
4Let the iron cool down before you store it.
Cleaning after ironing
1Make sure the plug has been removed from the wall socket and the iron has
cooled down.
2Wipe scale and any other deposits off the soleplate with a damp cloth and a
non-abrasive (liquid) cleaner.
Keep the soleplate smooth: avoid contact with metal objects.
3Clean the upper part of the appliance with a damp cloth.
4Regularly rinse the water tank with water. Empty the water tank after
cleaning.
StorageIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
1Make sure the plug has been removed from the wall socket and the iron has
cooled down. Set the steam control to position O.
2Empty the water tank (fig 17).
3Wind the mains cord round the cord storage facility.
4Store the iron standing on his heel in a safe and dry place (fig. 18).
Environment.
◗Do not throw the appliance away with the normal household waste at the
end of its life, but hand it in at an official collection point for recycling.
By doing this you will help to preserve the environment (fig. 19).
Information & serviceIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
If you need information or if you have a problem, please visit the Philips Web site at
www.philips.com or contact the Philips Customer Care Centre in your country (you
will find its phone number in the worldwide guarantee leaflet). If there is no
Customer Care Centre in your country, turn to your local Philips dealer or contact
the Service Department of Philips Domestic Appliances and Personal Care BV.
TroubleshootingIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
This chapter summarises the most common problems you could encounter with
your iron. Please read the different sections for more details. If you are unable to
solve the problem, please contact the Philips Customer Care Centre in your
country. You can find its telephone number in the worldwide guarantee leaflet.
ENGLISH
Comfort
GC1580, GC1575, GC1573, GC1565
2
4
7
8
9
1
0
1
3
14
1
5
1
6
1
7
1
8
12
8
Solution(s)
Check if the plug is connected
to the wall socket properly.
Set the temperature control dial
to the required temperature.
Move the iron slightly and the
iron will start heating up again.
c
Fill the water tank (see 'Filling
the water tank').
Set the steam control dial to
position qor w(see 'Steam
ironing').
Set the temperature control dial
to a temperature suitable for
steam ironing (2to MAX).
Put the iron on its heel and wait
until the pilot light has gone out
before you start ironing.
Press and hold the steam
control dial for maximal
5 seconds.
Wait at least 1 minute before
using the Extra Steam function
again.
Set the temperature control dial
to a temperature between
3and MAX. Put the iron on
its heel and wait until the pilot
light has gone out.
Fill the water tank (see 'Filling
the water tank').
Set the temperature control dial
to a temperature between
3and MAX. Put the iron on
its heel and wait until the pilot
light has gone out.
Wait at least 1 minute before
using the Extra Steam function
again (see 'Extra Steam').
Fill the water tank (see 'Filling
the water tank').
Use the Calc-Clean function a
few times (see 'Calc-Clean').
Set the temperature control dial
to a temperature suitable for
steam ironing (2to MAX).
Put the iron on its heel and wait
until the pilot light has gone out
before you start ironing.
Empty the water tank and set
the steam control to position O
before storing the iron (see
'Storage'). Place the iron on its
heel.
Fill the water tank (see 'Filling
the water tank').
Possible cause(s)
There is a connection
problem.
The temperature
control dial has been
set to MIN.
The auto-off function is
activated.
There is not enough
water in the water tank.
The steam control dial
has been set to
position O.
The iron is not hot
enough.
The steam control dial
has not been pressed
long enough.
The Extra Steam
function has been used
too often in a short
period.
The iron is not hot
enough.
There is not enough
water in the water tank.
The iron is not hot
enough.
The Extra Steam
function has been used
too often in a short
period.
There is not enough
water in the water tank.
You have been using
hard water, which has
caused scale flakes to
develop inside the
soleplate.
The set temperature is
too low.
The iron has been put
in horizontal position
while there is still water
in the water tank.
There is not enough
water in the water tank.
Problem
The iron is plugged in
but the soleplate is
cold.
The iron does not
produce any steam.
The Extra Steam
function does not work
(type GC1580)
Water leaks from the
soleplate when I use
the Extra Steam
function (type
GC1580)
The spray function
does not work
Flakes and impurities
come out of the
soleplate during ironing.
Water leaks from the
soleplate during ironing.
Water leaks from the
soleplate while the iron
is cooling down or after
it has been stored.
The Shot of steam
function does not work
(types GC1575 and
GC1573).
19
www.philips.com
u
4239 000 52692
Produkt Specifikationer
| Mærke: | Philips |
| Kategori: | Jern |
| Model: | Comfort GC1573 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Philips Comfort GC1573 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Jern Philips Manualer
8 Oktober 2024
29 September 2024
23 September 2024
17 September 2024
11 September 2024
7 September 2024
6 September 2024
6 September 2024
6 September 2024
4 September 2024
Jern Manualer
- Jern DeLonghi
- Jern Sinbo
- Jern Bosch
- Jern SilverCrest
- Jern OBH Nordica
- Jern Sencor
- Jern Singer
- Jern Siemens
- Jern Breville
- Jern Panasonic
- Jern Gorenje
- Jern VOX
- Jern Miele
- Jern Concept
- Jern Vitek
- Jern LG
- Jern AEG
- Jern Electrolux
- Jern Shark
- Jern Elica
- Jern Braun
- Jern Hotpoint
- Jern Melissa
- Jern Hoover
- Jern Korona
- Jern ProfiCare
- Jern Grundig
- Jern Livoo
- Jern Klarstein
- Jern Tefal
- Jern Trisa
- Jern Princess
- Jern Emerio
- Jern Moulinex
- Jern Sunbeam
- Jern Westinghouse
- Jern Hyundai
- Jern Proctor Silex
- Jern Jura
- Jern Imetec
- Jern TriStar
- Jern Clas Ohlson
- Jern Adler
- Jern Black And Decker
- Jern Camry
- Jern Blaupunkt
- Jern Tomado
- Jern AEG-Electrolux
- Jern Becken
- Jern BEKO
- Jern Privileg
- Jern Alpina
- Jern Clatronic
- Jern Quigg
- Jern Hitachi
- Jern Rowenta
- Jern Fagor
- Jern Haier
- Jern AFK
- Jern Bomann
- Jern Morphy Richards
- Jern Russell Hobbs
- Jern Ariete
- Jern Innoliving
- Jern Maxim
- Jern Zelmer
- Jern Leifheit
- Jern Vivax
- Jern JML
- Jern Calor
- Jern Sunny
- Jern Telefunken
- Jern Primo
- Jern Orbegozo
- Jern Optimum
- Jern Taurus
- Jern Exquisit
- Jern Elba
- Jern MPM
- Jern Profilo
- Jern Tesla
- Jern G3 Ferrari
- Jern Domo
- Jern BEEM
- Jern GlobalTronics
- Jern Swann
- Jern Thomas
- Jern Hamilton Beach
- Jern Ambiano
- Jern Unold
- Jern Nevir
- Jern Ursus Trotter
- Jern Inventum
- Jern Cleanmaxx
- Jern Swan
- Jern Khind
- Jern Frigidaire
- Jern SVAN
- Jern Scarlett
- Jern Izzy
- Jern ECG
- Jern Nova
- Jern Saturn
- Jern Eldom
- Jern Maxwell
- Jern H.Koenig
- Jern Proline
- Jern Waves
- Jern Termozeta
- Jern Laurastar
- Jern Easy Home
- Jern Polti
- Jern Eta
- Jern Turmix
- Jern Orion
- Jern Rotel
- Jern Kalorik
- Jern Cecotec
- Jern Solac
- Jern CHI
- Jern Beper
- Jern Tower
- Jern Team
- Jern Jocca
- Jern Brentwood
- Jern Duronic
- Jern Bestron
- Jern Philco
- Jern Kunft
- Jern Arzum
- Jern LERAN
- Jern Conair
- Jern Hacienda
- Jern Andis
- Jern Oster
- Jern Jocel
- Jern Ufesa
- Jern DPM
- Jern Create
- Jern Flama
- Jern Kambrook
- Jern Jata
- Jern Aigostar
- Jern Heinner
- Jern Defy
- Jern First Austria
- Jern Drew & Cole
- Jern Qilive
- Jern Lümme
- Jern Johnson
- Jern Koblenz
- Jern Essentiel B
- Jern Gallet
- Jern Zephir
- Jern Superior
- Jern Grunkel
- Jern Coline
- Jern Elta
- Jern Imarflex
- Jern Lelit
- Jern Girmi
- Jern Zomix
- Jern Vanguard
- Jern Domena
- Jern Eudora
- Jern Elgento
- Jern High One
- Jern Lagrange
- Jern Robinhood
- Jern LAFE
- Jern Inno-Hit
- Jern Britania
- Jern Vaporella
- Jern Kleva
- Jern Steamfast
- Jern Michelini
Nyeste Jern Manualer
15 Oktober 2024
15 Oktober 2024
11 Oktober 2024
10 Oktober 2024
10 Oktober 2024
8 Oktober 2024
8 Oktober 2024
7 Oktober 2024
7 Oktober 2024
6 Oktober 2024
