Dear Customer, thank you for purchasing this product. For optimum performance and safety,

please read these instructions carefully before connecting, operating or adjusting this product.

Please keep this manual for future reference.

INTENDED USE

We do not permit using the device in other ways like described in this user’s manual. Use the product

only in dry interior rooms. Not attending to these regulations and safety instruction might cause fatal

accidents, injuries, and damages to persons and property. The manufacturer/supplier assumes no

liability for damages caused by failure to comply with the intended use. To reduce risk of electric shock,

this product should ONLY be opened by an authorized technician when service is required. Disconnect

the product from mains and other equipment if a problem should occur. Do not expose the product to

water or moisture.

• Your product is not a toy and is not meant for children, because it contains small parts which can be

swallowed and can injure when used inappropriately!

• Please install the system and devices attached to it in a way that persons cannot be injured, or

objects not be damaged for example by dropping or stumbling.

• Please remove the packing materials, because children may cut themselves on them while playing.

Furthermore, there is a risk of swallowing and inhalation of incidentals and insulating material.

• Avoid places the product under the sun, rain or unventilated environment. Avoid place product with

high temperatures, or humidity, or places which might come into contact with water. Do not install

the product close to openings of air conditioners, or at places with an excessive amount of dust or

smoke. Keeps distance from ﬂammable and explosive devices.

• Do not install the product at places subject to vibration, or oscillation.

• Do not modify and alter the product and any accessories! Do not use any damaged parts.

• Keep enough space around all devices for a good ventilation and free motion and to avoid damages.

• Do not insert metal or other objects into the equipment to avoid to damage it.

• Please plug and unplug the cables gently, do not often plug, unplug or shake them.

INTRODUCTION

This HDMI wireless extender includes transmitter unit and receiver unit, allows to transmit and extend

HDMI signal up to 50 meters long away wirelessly. It has string anti-interference ability by running

at 5GHz operation frequency. Supports point to point connection. It is really a very good solution for

meeting, conference, home entertainment and multi-media education etc.

Note: Transmission distance will be different due to the environment.

Wall, brick or glass will shorten the signal cover range or cause big signal loss.

FEATURES

• Smart portable design, high performance

• HDMI video and audio transmission via wireless WIFI, up to 50 meters

• Compatible HDMI1.3 and HDCP1.2

• Supports HD video resolution up to 1920x1080p@60Hz

• Supports video compression format H.264 for effectively improve the transfer efﬁciency and ﬂuency

playback ﬂuency

• Supports point to point wireless conﬁguration

• Able to automatically identify and conﬁgure a variety of display mode

• Built-in automatic balance system, the picture is ﬂuent, clear and stable

• The built-in ESD electrostatic protection circuit, comprehensive security protection system

• Plug and play, easy installation, no need any conﬁguration

PACKAGE CONTENTS

• HDMI sender x 1pc

• HDMI receiver x 1pc

• DC 12V Power supply x 2 pcs

• User's manual x 1pc

Note: above accessories are contented in the regular package for the kit with transmitter and receiver.

If buy HDMI Extender TX or HDMI Extender RX separately, the package contents would be different.

PANEL DESCRIPTION

Transmitter

With the CE sign, Techly® ensures that the product is conformed to the basic European

standards and directives.

In compliance with EU Directive WEEE this product is marked with this symbol. It

means that used electrical and electronic products should not be mixed with general

household waste. There is a separate collections system for these products in

compliance with WEEE directive, otherwise contaminative and hazardous substances

can pollute the environment.

Receiver

CONNECTION

Point to Point connection

CONNECTION INSTRUCTION

1) Connect HDMI input with HDMI source device and connect IR blaster extension cable to IR OUT

interface of the sender (TX).

2) Connect HDMI output with HDMI display device and connect IR receiver extension cable with IR IN

interface.

3) Check that the transmitter and receiver are placed within the indicated operating range and that

there are no obstacles that could compromise the signal transmission between them

4) Power on the device (power led lights) and it works.

Note:

1) When the wireless signal transmits through wall, glass or other obstacles, it will cause signal loss.

Please install this device in good environment with few obstacles.

2) The external environment wireless signal interference the transmission, such as micro waver,

wireless mouse and keyboard, etc...

SPECIFICATION

Parameter Speciﬁcation

Video

Standard HDMI1.3; HDCP1.2

Compression format H.264

Maximum pixel clock 165MHz

Maximum data rate 6.75Gbps

Resolution 1920x1080p@60Hz

Connector HDMI-A male

Impedance 100 Ohm

Recommend HDMI maximum

input/output range

Less than 5 meters,

when 1920 x1080p@60Hz

Wireless

Radio frequency power 13dbm

Wireless standard 802.11ac

Signal direction unidirectional

Radio frequency 5.8Ghz

Transmission distance 50m

Other

Power DC 12V

Power dissipation Max 5W

Operating temperature -5°C –70°C

humidity (no condensation) 5-90%

Dimension (each unit) 120 x 73 x 22 mm

Maintenance:

Clean only with a dry cloth. Do not use cleaning solvents or abrasives.

Warranty:

No guarantee or liability can be accepted for any changes and modiﬁcations of the product or damage

caused due to incorrect use of this product.

PWR Power status ....................

STA ...................... Signal status

DC/12V.............. DC Power input port

HDMI Input ..... HDMI input port

Reset .................. Reset button

PWR Power status .......................

STA .........................Signal status

DC/12V.................DC Power input port

HDMI Output ....HDMI Output port

Reset .....................Reset button

CAUTION - RISK OF ELECTRIC SHOCK

DO NOT OPEN

EN HDMI WIRELESS EXTENDER 50M

Produkt Specifikationer

Mærke:	Techly
Kategori:	AV forlænger
Model:	IDATA HDMI-WL55
Type:	AV sender & modtager
Bredde:	120 mm
Dybde:	72 mm
Højde:	22 mm
Vægt:	679 g
Antal pr. pakke:	2 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Wi-Fi:	Ja
Understøttede videotilstande:	1080p
Relativ luftfugtighed ved drift (H-H):	5 - 90 %
HDCP:	Ja
Driftstemperatur (T-T):	-5 - 70 °C
Maksimal opløsning:	1920 x 1080 pixel
Impedens:	100 ohm (Ω)
Forbindelsesteknologi:	Kabel & trådløs
Certificering:	CE, FCC, RoHS
Strømkilde type:	DC
AC-adapter inkluderet:	Ja
Bæredygtighedscertifikater:	CE, RoHS
Emballageindhold:	1x HDMI transmitter\n1x HDMI Receiver
Maksimal overførselsafstand:	50 m
Maksimal opdateringshastighed:	60 Hz
HDMI-version:	1.3
HSMI-indgang:	1
Antal HDMI-udgange:	1
HDCP-version:	1.2
Båndbredde:	165 MHz
Driftsspænding (modtager):	12 V
Driftsspænding (sender):	12 V
Leverandørkode:	365634
Understøttelse af lyd:	Ja
