USER

MANUAL

EN User Manual

Dishwasher

FSE74747P

of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be

kept away from the appliance unless continuously

supervised.

•Children of less than 3 years of age should be kept

away from the appliance unless continuously

supervised.

•Children should be supervised to ensure that they do

not play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•This appliance is for cleaning household-type dishes

and tableware only.

•This appliance is designed for single household

domestic use in an indoor environment.

•This appliance may be used in, offices, hotel guest

rooms, bed & breakfast guest rooms, farm guest

houses and other similar accommodation where such

use does not exceed (average) domestic usage levels.

•Do not change the specification of this appliance.

ENGLISH 3

•The operating water pressure (minimum and

maximum) must be between 0.5 (0.05) / 10 (1.0) bar

(MPa)

•Follow the maximum number of 15 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•WARNING: Knives and other utensils with sharp

points must be loaded in the basket with their points

down or placed in a horizontal position.

•Do not leave the appliance with the open door

unattended to avoid stepping accidentally onto it.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•If the appliance has ventilation openings in the base,

they must not be covered e.g. by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must

install this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not use the appliance before

installing it in the built-in structure due

to safety manner.

• Follow the installation instructions

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use the appliance

where the temperature is less than

0 °C.

• Install the appliance in a safe and

suitable place that meets installation

requirements.

www.youtube.com/electrolux

www.youtube.com/aeg

How to install your 60 cm

Dishwasher Sliding Hinge

2.2 Electrical connection

WARNING!

Risk of fire and electric

shock.

• Warning: this appliance is designed to

be installed / connected to a

grounding connection in the building.

www.aeg.com4

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance is fitted with a 13 A

mains plug. If it is necessary to

change the mains plug fuse, use only

a 13 A ASTA (BS 1362) fuse (UK and

Ireland only).

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

• The water inlet hose has a safety

valve and a sheath with an inner

mains cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately close the water tap and

disconnect the mains plug from the

mains socket. Contact the Authorised

Service Centre to replace the water

inlet hose.

2.4 Use

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Dishwasher detergents are

dangerous. Follow the safety

instructions on the detergent

packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

complete. Some detergent may

remain on the dishes.

• Do not store items or apply pressure

on the open door of the appliance.

• The appliance can release hot steam

if you open the door while a

programme operates.

2.5 Service

• To repair the appliance contact the

Authorised Service Centre. Use

original spare parts only.

• Please note that self-repair or non-

professional repair can have safety

consequences and might void the

guarantee.

• The following spare parts will be

available for 7 years after the model

has been discontinued: motor,

circulation and drain pump, heaters

and heating elements, including heat

pumps, piping and related equipment

including hoses, valves, filters and

aquastops, structural and interior

parts related to door assemblies,

printed circuit boards, electronic

displays, pressure switches,

thermostats and sensors, software

and firmware including reset software.

Please note that some of these spare

parts are only available to

professional repairers, and that not all

spare parts are relevant for all

models.

• The following spare parts will be

available for 10 years after the model

ENGLISH 5

has been discontinued: door hinge

and seals, other seals, spray arms,

drain filters, interior racks and plastic

peripherals such as baskets and lids.

• Concerning the lamp(s) inside this

product and spare part lamps sold

separately: These lamps are intended

to withstand extreme physical

conditions in household appliances,

such as temperature, vibration,

humidity, or are intended to signal

information about the operational

status of the appliance. They are not

intended to be used in other

applications and are not suitable for

household room illumination.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

5 410 9 67

2 31

1Ceiling spray arm

2Upper spray arm

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Lower basket

11 Upper basket

12 Cutlery drawer

3.1 Beam-on-Floor

The Beam-on-Floor is a light that is

displayed on the floor below the

appliance door.

• A red light comes on when a

programme starts. It remains on for

the duration of the programme.

• A green light comes on when the

programme is complete.

www.aeg.com6

• The red light flashes when the

appliance has a malfunction. The Beam-on-Floor is off

when the appliance is

deactivated.

4. CONTROL PANEL

1 2 3 4 5 6

1On/Off button / Reset button

2Delay Start button

3Display

4MY TIME selection bar

5EXTRAS buttons

6AUTO Sense program button

4.1 Display

CB B

A. ECOMETER

B. Indicators

C. Time indicator

4.2 ECOMETER

The ECOMETER indicates how the

programme selection impacts energy

and water consumption. The more bars

are on, the lower the consumption is.

indicates the most

environmentally friendly programme

selection for a normally soiled

dishwashing load.

4.3 Indicators

Indicator Description

Rinse aid indicator. It is on when the rinse aid dispenser needs refilling.

Refer to ."Before first use"

Salt indicator. It is on when the salt container needs refilling. Refer to "Be‐

fore first use".

Machine Care indicator. It is on when the appliance needs internal clean‐

ing with the Machine Care programme. Refer to ."Care and cleaning"

ENGLISH 7

5.4 Programmes overview

Programme Dishwasher

load

Degree of soil Programme phases EXTRAS

Quick Crockery,

cutlery

Fresh • Dishwashing 50 °C

• Intermediate rinse

• Final rinse 45 °C

• AirDry 1)

• ExtraPower

• GlassCare

1h Crockery,

cutlery

Fresh, lightly

dried-on

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 50 °C

• AirDry 1)

• ExtraPower

• GlassCare

1h 30min Crockery,

cutlery, pots,

pans

Normal, lightly

dried-on

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 55 °C

• Drying

• AirDry 1)

• ExtraPower

• GlassCare

2h 40min Crockery,

cutlery, pots,

pans

Normal to

heavy, dried-

• Prewash

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 60 °C

• Drying

• AirDry 1)

• ExtraPower

• GlassCare

ECO Crockery,

cutlery, pots,

pans

Normal, lightly

dried-on

• Prewash

• Dishwashing 50 °C

• Intermediate rinse

• Final rinse 55 °C

• Drying

• AirDry 1)

• ExtraPower

• GlassCare

• ExtraSilent

AUTO Sense Crockery,

cutlery, pots,

pans

All • Prewash

• Dishwashing 50 -

60 °C

• Intermediate rinse

• Final rinse 60 °C

• Drying

• AirDry 1)

Not applicable

Machine

Care

For cleaning the appliance in‐

terior. Refer to "Care and

Cleaning".

• Cleaning 70 °C

• Intermediate rinse

• Final rinse

• AirDry 1)

Not applicable

1) Automatic door opening during the drying phase. Refer to "Basic settings".

ENGLISH 9

Consumption values

Programme 1)2) Water (l) Energy (kWh) Duration (min)

Quick 10.9 0.610 30

1h 11.8 0.880 60

1h 30min 11.9 0.970 90

2h 40min 12.2 1.140 160

ECO 11.0 0.757 240

AUTO Sense 12.2 1.140 170

Machine Care 10.5 0.590 60

1) The pressure and the temperature of the water, the variations of the mains supply, the options, the

quantity of dishes and the degree of soil can change the values.

2) The values for programmes other than ECO are indicative only.

Information for test institutes

To receive the necessary information for

conducting performance tests (e.g.

according to: BS EN60436 ), send an

email to:

info.test@dishwasher-production.com

In your request, include the product

number code (PNC) from the rating plate.

For any other questions regarding your

dishwasher, refer to the service book

provided with your appliance.

6. BASIC SETTINGS

You can configure the appliance by

changing basic settings according to

your needs.

Number Setting Values Description1)

1Water hardness From level 1L to

level 10L (de‐

fault: 5L)

Adjust the level of the water softener ac‐

cording to the water hardness in your area.

2Rinse aid level From level 0A to

level 6A (de‐

fault: 4A)

Adjust the level of the rinse aid according

to the necessary dosage.

3End sound On

Off (default)

Activate or deactivate the acoustic signal

for the end of a programme.

4Auto door open On (default)

Off

Activate or deactivate the AirDry.

5Key tones On (default)

Off

Activate or deactivate the sound of the but‐

tons when pressed.

www.aeg.com10

Number Setting Values Description1)

6Latest pro‐

gramme selec‐

tion

Off (default)

Enable or disable the automatic selection

of the most recently used programme and

options.

1) For more details, refer to the information provided in this chapter.

You can change the basic settings in

setting mode.

When the appliance is in setting mode,

the bars of the ECOMETER represent

available settings. For each setting, a

dedicated bar of the ECOMETER

flashes.

The order of the basic settings presented

in the table is also the order of the

settings on the ECOMETER:

1 2 3 4 5 6

6.1 Setting mode

How to navigate in setting

mode

You can navigate in setting mode using

MY TIME selection bar.

BA C

A. buttonPrevious

B. buttonOK

C. buttonNext

Use and to switchPrevious Next

between the basic settings and to

change their value.

Use to enter the selected setting andOK

to confirm changing its value.

How to enter setting mode

You can enter setting mode before

starting a programme. You cannot enter

setting mode while the programme is

running.

To enter setting mode, press and hold

simultaneously and for

about 3 seconds.

The lights related to the , Previous OK

and are on.Next

How to change a setting

Make sure the appliance is in setting

mode.

1. Use or to select thePrevious Next

bar of the ECOMETER dedicated to

the desired setting.

• The bar of the ECOMETER

dedicated to the chosen setting

flashes.

• The display shows the current

setting value.

2. Press to enter the setting.OK

• The bar of the ECOMETER

dedicated to the chosen setting is

on. The other bars are off.

• The current setting value flashes.

3. Press or to changePrevious Next

the value.

4. Press to confirm the setting.OK

• The new setting is saved.

• The appliance returns to the basic

settings list.

5. Press and hold simultaneously

and for about 3

seconds to exit setting mode.

The appliance returns to the programme

selection.

The saved settings remain valid until you

change them again.

ENGLISH 11

6.2 The water softener

The water softener removes minerals

from the water supply, which would have

a negative effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water

in your area. Set the right level of the

water softener to assure good washing

results.

Water hardness

German de‐

grees (°dH)

French de‐

grees (°fH)

mmol/l mg/l (ppm) Clarke

degrees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 835 - 904 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 645 - 754 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 505 - 644 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 395 - 504 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 325 - 394 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 255 - 324 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 185 - 254 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 70 - 184 5 - 12 2

<4 <7 <0.7 <70 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

Regardless of the type of detergent

used, set the proper water hardness

level to keep the salt refill indicator

active.

Multi-tabs containing salt are

not effective enough to

soften hard water.

Regeneration process

For the correct water softener operation,

the resin of the softener device needs to

be regenerated regularly. This process is

automatic and is the part of the normal

dishwasher operation.

When the prescribed quantity of water

(see values in the table) has been used

since the previous regeneration process,

a new regeneration process will be

initiated between the final rinse and the

programme end.

Water softener lev‐

Amount of water

(l)

1 250

2 100

3 62

4 47

5 25

6 17

7 10

8 5

9 3

www.aeg.com12

Water softener lev‐

Amount of water

(l)

10 3

In case of the high water softener setting,

it may occur also in the middle of the

programme, before the rinse (twice

during a programme). Regeneration

initiation has no impact on the cycle

duration, unless it occurs in the middle of

a programme or at the end of a

programme with a short drying phase. In

such cases, the regeneration prolongs

the total duration of a programme by

additional 5 minutes.

Subsequently, the rinsing of the water

softener that lasts 5 minutes may begin

in the same cycle or at the beginning of

the next programme. This activity

increases the total water consumption of

a programme by additional 4 litres and

the total energy consumption of a

programme by additional 2 Wh. The

rinsing of the softener ends with a

complete drain.

Each performed softener rinse (possible

more than one in the same cycle) may

prolong the programme duration by

another 5 minutes when it occurs at any

point at the beginning or in the middle of

a programme.

All the consumption values

mentioned in this section are

determined in line with the

currently applicable standard

in laboratory conditions with

water hardness 2.5mmol/L

(water softener: level 3)

according to the regulation:

UK Ecodesign 2021/745.

The pressure and the

temperature of water as well

as the variations of the

mains supply can change

the values.

6.3 The rinse aid level

The rinse aid helps to dry the dishes

without streaks and stains. It is

automatically released during the hot

rinse phase. It is possible to set the

released quantity of rinse aid.

When rinse aid chamber is empty, the

rinse aid indicator is on notifying to refill

rinse aid. If the drying results are

satisfactory while using multi-tablets only,

it is possible to deactivate the dispenser

and the indicator. However, for best

drying performance, always use rinse aid

and keep the rinse aid indicator active.

To deactivate the rinse aid dispenser and

indicator, set the level of rinse aid to 0A.

6.4 End sound

You can activate an acoustic signal that

sounds when the programme is

completed.

Acoustic signals sound also

when a malfunction of the

appliance occurs. It is not

possible to deactivate these

signals.

6.5 AirDry

AirDry improves the drying results. The

appliance door opens automatically

during the drying phase and remains

ajar.

AirDry is automatically activated with all

programmes.

The duration of the drying phase and the

door opening time vary depending on the

selected programme and options.

When AirDry opens the door, the display

shows the remaining time of the running

programme.

ENGLISH 13

6. Turn the cap of the salt container

clockwise to close the salt container.

CAUTION!

Water and salt can come out

of the salt container when

you fill it. After you fill the

salt container, immediately

start the shortest programme

to prevent corrosion. Do not

put dishes in the baskets.

7.2 How to fill the rinse aid

dispenser

A B

CAUTION!

The compartment ( ) is forB

rinse aid only. Do not fill it

with detergent.

CAUTION!

Only use rinse aid designed

specifically for dishwashers.

1. Open the lid ( ).C

2. Fill the dispenser ( ) until the rinseB

aid reaches the marking ''MAX''.

3. Remove the spilled rinse aid with an

absorbent cloth to prevent excessive

foam formation.

4. Close the lid. Make sure that the lid

locks into position.

Fill the rinse aid dispenser

when the indicator ( ) isA

clear.

8. DAILY USE

1. Open the water tap.

2. Press and hold until the appliance

is activated.

3. Fill the salt container if it is empty.

4. Fill the rinse aid dispenser if it is

empty.

5. Load the baskets.

6. Add the detergent.

7. Select and start a programme.

8. Close the water tap when the

programme is complete.

ENGLISH 15

8.1 Using the detergent

A B

CAUTION!

Only use detergent

specifically designed for

dishwashers.

1. Press the release button ( ) to openA

the lid ( ).C

2. Put the detergent (gel, powder or

tablets) in the compartment ( ).B

3. If the programme has a prewash

phase, put a small quantity of

detergent on the inner part of the

appliance door.

4. Close the lid. Make sure that the lid

locks into position.

For information about the

detergent dosage, refer to

the manufacturer's

instructions on the

packaging of the product.

Usually, 20 - 25 ml of gel

detergent is adequate for

washing a load with normal

soil.

The upper ends of the two

vertical ribs inside the

compartment ( ) indicateB

the maximum level for filling

the dispenser with gel (max.

30ml).

8.2 How to select and start a

programme using MY TIME

selection bar

1. Slide your finger across MY TIME

selection bar to choose a suitable

programme.

• The light related to the selected

programme is on.

• The ECOMETER indicates the

level of energy and water

consumption.

• The display shows the

programme duration.

2. Activate applicable EXTRAS if

desired.

3. Close the appliance door to start the

programme.

8.3 How to activate EXTRAS

1. Select a programme using MY TIME

selection bar.

2. Press the button dedicated to the

option you want to activate.

• The light related to the button is

on.

• The display shows the updated

programme duration.

• The ECOMETER indicates the

updated level of energy and water

consumption.

By default, options must be

activated every time before

you start a programme.

If the latest programme

selection is enabled, the

saved options are activated

automatically along with the

programme.

It is not possible to activate

or deactivate options while a

programme is running.

Not all options are

compatible with each other.

Activating options often

increases the water and

energy consumption as well

as the programme duration.

www.aeg.com16

8.4 How to start the AUTO

Sense program

1. Press .

• The light related to the button is

on.

• The display shows the longest

possible program duration.

2. Close the appliance door to start the

program.

The appliance senses the type of load

and adjusts a suitable wash cycle.

During the cycle, the sensors operate

several times and the initial program

duration can decrease.

8.5 How to delay the start of a

programme

1. Select a programme.

2. Press repeatedly until the display

shows the desired delay time (from 1

to 24 hours).

The light related to the button is on.

3. Close the appliance door to start the

countdown.

During the countdown, you cannot

change the delay time and the

programme selection.

When the countdown is complete, the

programme starts.

8.6 How to cancel the delay

start while the countdown

operates

Press and hold for about 3 seconds.

The appliance returns to the programme

selection.

If you cancel the delay start,

you have to select the

programme again.

8.7 How to cancel a running

programme

Press and hold for about 3 seconds.

The appliance returns to the programme

selection.

Make sure that there is

detergent in the detergent

dispenser before you start a

new programme.

8.8 Opening the door while

the appliance operates

Opening the door while a programme is

running pauses the wash cycle. The

display shows the remaining duration of

the programme. After closing the door,

the wash cycle resumes from the point of

interruption.

If you open the door during the delay

start countdown, the countdown is

paused. The display shows the current

countdown status. After closing the door,

the countdown resumes.

Opening the door while the

appliance operates may

affect the energy

consumption and the

programme duration.

If the door is opened for

more than 30 seconds

during the drying phase, the

running programme ends. It

does not happen if the door

is opened by the AirDry

function.

8.9 The Auto Off function

This function saves energy by switching

the appliance off when it is not operating.

The function comes into operation

automatically:

• When the programme is completed.

• After 5 minutes if a programme was

not started.

8.10 End of the programme

When the programme is complete, the

display shows .0:00

The Auto Off function switches the

appliance off automatically.

All buttons are inactive except for the

on/off button.

ENGLISH 17

9. HINTS AND TIPS

9.1 General

Follow the hints below to ensure optimal

cleaning and drying results in daily use

and to protect the environment.

• Washing dishes in the dishwasher as

instructed in the user manual usually

consumes less water and energy than

washing dishes by hand.

• Load the dishwasher to its full

capacity to save water and energy.

For best cleaning results, arrange

items in the baskets as instructed in

the user manual and do not overload

the baskets.

• Do not pre-rinse dishes by hand. It

increases the water and energy

consumption. When needed, select a

programme with a prewash phase.

• Remove larger residues of food from

the dishes and empty cups and

glasses before putting them inside the

appliance.

• Soak or slightly scour cookware with

firmly cooked-on or baked-on food

before washing it in the appliance.

• Make sure that items in the baskets

do not touch or cover each other.

Only then can the water completely

reach and wash the dishes.

• You can use dishwasher detergent,

rinse aid and salt separately or you

can use the multi-tablets (e.g. ''All in

1''). Follow the instructions on the

packaging.

• Select a programme according to the

type of load and the degree of soil.

ECO offers the most efficient use of

water and energy consumption.

• To prevent limescale buildup inside

the appliance:

– Refill the salt container whenever

necessary.

– Use the recommended dosage of

the detergent and rinse aid.

– Make sure that the current level of

the water softener agrees with the

hardness of the water supply.

– Follow the instructions in the

chapter ."Care and cleaning"

9.2 Using salt, rinse aid and

detergent

• Only use salt, rinse aid and detergent

designed for dishwasher. Other

products can cause damage to the

appliance.

• In areas with hard and very hard

water, we recommend to use basic

dishwasher detergent (powder, gel,

tablets containing no additional

agents), rinse aid and salt separately

for optimal cleaning and drying

results.

• Detergent tablets do not fully dissolve

with short programmes. To prevent

detergent residues on the tableware,

we recommend that you use tablets

with long programmes.

• Always use the correct quantity of

detergent. Insufficient dosage of

detergent can result in poor cleaning

results and hard-water filming or

spotting on the items. Using too much

detergent with soft or softened water

results in detergent residues on the

dishes. Adjust the amount of

detergent based on the water

hardness. Refer to the instructions on

the detergent packaging.

• Always use the correct quantity of

rinse aid. Insufficient dosage of rinse

aid decreases the drying results.

Using too much rinse aid results in

bluish layers on the items.

• Make sure that the water softener

level is correct. If the level is too high,

the increased quantity of salt in the

water might result in rust on cutlery.

9.3 What to do if you want to

stop using multi-tablets

Before you start using separately

detergent, salt and rinse aid, complete

the following steps:

1. Set the highest level of the water

softener.

2. Make sure that the salt and rinse aid

containers are full.

3. Start the Quick programme. Do not

add detergent and do not put dishes

in the baskets.

www.aeg.com18

1. Use a descaler or a cleaning product

designed specifically for

dishwashers. Follow the instructions

on the packaging. Do not put dishes

in the baskets.

2. Press and hold simultaneously

and for about 3 seconds.

The indicators and flash. The

display shows the programme duration.

3. Close the appliance door to start the

programme.

When the programme is complete, the

indicator is off.

10.2 Internal cleaning

• Clean the appliance interior with a soft

damp cloth.

• Do not use abrasive products,

abrasive cleaning pads, sharp tools,

strong chemicals, scourer or solvents.

• Wipe clean the door, including the

rubber gasket, once a week.

• To maintain the performance of your

appliance, use a cleaning product

designed specifically for dishwashers

at least once every two months.

Carefully follow the instructions on the

packaging of the product.

• For optimal cleaning results, start the

programme Machine Care.

10.3 Removal of foreign

objects

Check the filters and the sump after each

use of the dishwasher. Foreign objects

(e.g. pieces of glass, plastic, bones or

toothpicks, etc) decrease the cleaning

performance and can cause damage to

the drain pump.

CAUTION!

If unable to remove the

foreign objects, contact an

Authorised Service Centre.

1. Disassemble the filters system as

instructed in this chapter.

2. Remove any foreign objects

manually.

3. Reassemble the filters as instructed

in this chapter.

10.4 External cleaning

• Clean the appliance with a moist soft

cloth.

• Only use neutral detergents.

• Do not use abrasive products,

abrasive cleaning pads or solvents.

10.5 Cleaning the filters

The filter system is made of 3 parts.

1. Turn the filter ( ) counterclockwiseB

and remove it.

2. Remove the filter ( ) out of filter ( ). C B

3. Remove the flat filter ( ).A

www.aeg.com20

4. Wash the filters.

5. Make sure that there are no residues

of food or soil in or around the edge

of the sump.

6. Put back in place the flat filter ( ).A

Make sure that it is correctly

positioned under the 2 guides.

7. Reassemble the filters ( ) and ( ).B C

8. Put back the filter ( ) in the flat filterB

( ). Turn it clockwise until it locks.A

CAUTION!

An incorrect position of the

filters can cause bad

washing results and damage

to the appliance.

10.6 Cleaning the lower spray

arm

We recommend to clean the lower spray

arm regularly to prevent soil from

clogging the holes.

Clogged holes can cause unsatisfactory

washing results.

1. To remove the lower spray arm, pull

it upwards.

2. Wash the spray arm under running

water. Use a thin pointed tool, e.g. a

toothpick, to remove particles of soil

from the holes.

ENGLISH 21

3. To install the spray arm back, press it

downwards.

10.7 Cleaning the upper

spray arm

We recommend to clean the upper spray

arm regularly to prevent soil from

clogging the holes.

Clogged holes can cause unsatisfactory

washing results.

1. Pull out the upper basket.

2. To detach the spray arm from the

basket, press the spray arm upwards

and simultaneously turn it clockwise.

3. Wash the spray arm under running

water. Use a thin pointed tool, e.g. a

toothpick, to remove particles of soil

from the holes.

4. To install the spray arm back, press

the spray arm upwards and

simultaneously turn it

counterclockwise until it locks into

place.

10.8 Cleaning the ceiling

spray arm

We recommend to clean the ceiling spray

arm regularly to prevent soil from

clogging the holes. Clogged holes can

cause unsatisfactory washing results.

The ceiling spray arm is placed on the

ceiling of the appliance. The spray arm

( ) is installed in the delivery tube ( )C A

with the mounting element ( ).B

www.aeg.com22

1. Release the stoppers on the sides of

the sliding rails of the cutlery drawer

and pull the drawer out.

2. Move the upper basket to the lowest

level to reach the spray arm more

easily.

3. To detach the spray arm ( ) from theC

delivery tube ( ), turn the mountingA

element ( ) counterclockwise andB

pull the spray arm downwards.

4. Wash the spray arm under running

water. Use a thin pointed tool, e.g. a

toothpick, to remove particles of soil

from the holes. Run the water

through the holes to wash soil

particles away from the inside.

5. To install the spray arm ( ) back,C

insert the mounting element ( ) inB

the spray arm and fix it in the delivery

tube ( ) by turning it clockwise. MakeA

sure that the mounting element locks

into place.

6. Install the cutlery drawer on the

sliding rails and block the stoppers.

11. TROUBLESHOOTING

WARNING!

Improper repair of the

appliance may pose a

danger to the safety of the

user. Any repairs must be

performed by qualified

personnel.

The majority of problems that may

occur can be solved without the need

to contact an Authorised Service

Centre.

Refer to the below table for information

on possible problems.

With some problems, the display shows

an alarm code.

ENGLISH 23

Problem and alarm code Possible cause and solution

The level of water inside the

appliance is too high.

The display shows .iF1

• Switch the appliance off and on.

• Make sure that the filters are clean.

• Make sure that the outlet hose is installed at the right

height above the floor. Refer to the installation instruc‐

tions.

The appliance stops and

starts more times during op‐

eration.

• It is normal. It provides optimal cleaning results and en‐

ergy savings.

The programme lasts too

long.

• If the delay start option is set, cancel the delay setting or

wait for the end of the countdown.

• Activating options increases the programme duration.

The displayed programme

duration is different than the

duration in the consumption

values table.

• Refer to the consumption values table in the chapter

"Programme selection".

The remaining time in the

display increases and skips

nearly to the end of the pro‐

gramme duration.

• This is not a defect. The appliance is working correctly.

Small leak from the appli‐

ance door.

• The appliance is not levelled. Loosen or tighten the ad‐

justable feet (if applicable).

• The appliance door is not centred on the tub. Adjust the

rear foot (if applicable).

The appliance door is diffi‐

cult to close.

• The appliance is not levelled. Loosen or tighten the ad‐

justable feet (if applicable).

• Parts of the tableware are protruding from the baskets.

The appliance door opens

during the wash cycle.

• The AirDry function is activated. You can deactivate the

function. Refer to ."Basic settings"

Rattling or knocking sounds

from the inside of the appli‐

ance.

• The tableware is not properly arranged in the baskets.

Refer to basket loading leaflet.

• Make sure that the spray arms can rotate freely.

The appliance trips the cir‐

cuit-beaker.

• The amperage is insufficient to supply simultaneously all

the appliances in use. Check the socket amperage and

the capacity of the meter or turn off one of the applian‐

ces in use.

• Internal electrical fault of the appliance. Contact an Au‐

thorised Service Centre.

Once you have checked the appliance,

deactivate and activate the appliance. If

the problem occurs again, contact an

Authorised Service Centre.

For alarm codes not described in the

table, contact an Authorised Service

Centre.

ENGLISH 25

12. TECHNICAL INFORMATION

Dimensions Width / height / depth (mm) 596 / 818 - 898 / 550

Electrical connection

1) Voltage (V) 220 - 240

Frequency (Hz) 50

Water supply pressure bar (minimum and maximum) 0.5 - 10

MPa (minimum and maximum) 0.05 - 1.0

Water supply Cold water or hot water 2) max 60 °C

Capacity Place settings 15

1) Refer to the rating plate for other values.

2) If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply

to decrease energy consumption.

12.1 Link to the product

information sheet

The QR code on the energy label

supplied with the appliance provides a

web link to the product information sheet.

Keep the energy label for reference

together with the user manual and all

Produkt Specifikationer

Mærke:	AEG
Kategori:	Opvaskemaskine
Model:	FSE74747P
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	596 mm
Dybde:	550 mm
Højde:	818 mm
Vægt:	38390 g
Kontroltype:	Berøring
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1.6 m
Pakkevægt:	40100 g
Pakkedybde:	680 mm
Pakkebredde:	635 mm
Pakkehøjde:	870 mm
Placering af apparat:	Fuldt indbygget
Indvendig belysning:	Ingen
Dørhængsel:	Glidende
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	550 mm
Tilsluttet belastning:	1950 W
Støjniveau:	44 dB
Tilløbsslange, længde:	1.8 m
Antal vaskeprogrammer:	7
Forsinket start-timer:	Ja
Børnesikring:	Ingen
Justerbare fødder:	Ja
Dør farve:	Hvid
Balje materiale:	Rustfrit stål
Vandforbrug pr. cyklus:	11 L
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Sort
Antal kuverter:	15 kuverter
Cyklustid:	240 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	60min,90min,160min,Eco,Quick
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.757 kWh
Energieffektivitetsskala:	A til G
Antal temperaturindstillinger:	4
Glasbeskyttelse:	Ja
Indikator for resterende tid:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.8 m
Produktstørrelse:	Fuld størrelse (60 cm)
Wi-Fi kontrolleret:	Ingen
Vandpåfyldning:	Kold
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	76 kWh
Brugerdefineret panel klar:	Ja
Cyklustid (hurtigt vaskeprogram):	30 min.
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Øvre
Selvrensende filter:	Ingen
Oprindelsesland:	Italien
Tørresystem:	AirDry
Strømstiktype:	Type G
Automatisk belastningsgenkendelse:	Ja
Lydalarm:	Ja
Maksimal skål størrelse (øverste kurv):	165 mm
Maksimal skål størrelse (nederste kurv):	310 mm
Automatisk døråbning:	Ja
Kode i den britiske toldtarif:	84221100
Gulvindikatorlys:	Ja
Øverste trådkurv:	Sammenfoldelig
Nederste trådkurv:	Sammenfoldelig
Intrastat kode:	84221100
Garantiperiode:	2 År
Vægt af papemballage:	210 g
Emballagevægt af polystyren (EPS/EPP):	920 g
Emballagevægt af polyethylen (PE):	283.5 g
Polypropylen (PP) emballagevægt:	40 g
3:	10.5 g
Vægt på gummiemballage:	2 g
