Side 1/4
2 Before use
DVM2028C User’s manual
(For use with DVM2028)
3 Positioning the baby monitor
Caution
• The open box volume of your
parent unit is level , and the 3
maximum volume is level . If 5
you experience feedback noise
from your baby monitor while
positioning:
- Make sure your baby unit and
parent unit are more than 1 meter
apart, OR
- Lower the volume of your parent
unit.
1 Connect and power on the baby unit
Quick start guide
What’s in the box
Kabel minima al 1 meter rwijderd ve
houden van baby.
Garder une dista nce minima l d’un mèt re
du bébé.
Das Kabel ist mindestens 1 Mete von r,
dem Ba , ent t z u halten.by f ern
Keep ca e at leas t 1m from babbl awa y y.
Mantenga el ca e al menos 1 met ro de bl
dista ncia del bebé
V1.1
1. Connect the power adaptor
to the baby unit and a power
supply.
2. Slide the ON/OFF switch to
power on or off your baby unit.
DVM2028C
Commaxx B.V.
Wiebachstraat 37,
6466 NG Kerkrade
The Netherlands,
support.alectobaby.nl
Video baby monitor
Baby unit
V1.0
ATTENTION
Before you start using the set, please remove any
protective foil from the parent unit and baby unit.
Specications
Range:
up to 50 metres indoors
up to 300 metres outdoors
Baby unit power:
5VDC 1000mA power adaptor (incl.)
Model: VT05EEU05100
Frequency: 2405-2475 MHz
Modulation: FSK
RF-power: <20 dBm
Declaration of conformity
Hereby, Commaxx declares that the radio equip-
ment type Alecto DVM2028C is in compliance with
directive 2014/53/EU. The full text of the EU dec-
laration of conformity is available at the following
Internet address: https://commaxx-certificates.com/
doc/DVM2028C_doc
Use of this equipment is allowed in all countries
of the EU. In France, Italy, Russia and Ukraine, only
indoor use is allowed.
Information power adaptor baby unit:
Manufacturers name and address:
Vtech Telecommunications LTD, 23/F.,
Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road,
Tai Po, Hong Kong.
Model Identifier: VT05EEU05100
Input voltage: 100 - 240V~
Input AC frequency: 50/60 Hz
Output voltage: 5.0V DC
Output current: 1.0 A
Output Power: 5.0 W
Average active efficiency: 74.0 %
Efficiency at low 10% load: -
No load Power consumption: 0.07 W
Important safety instructions
The applied nameplate is located at the bottom of
the baby unit’s base.
1. CAUTION: Do not install the baby unit at a
height above 2 metres.
2. Use and store the product at a temperature
between 0
oC and 40oC.
Pair a new baby unit
Each newly purchased baby unit ( ) must be paired to your system ( ).DVM2028C DVM2028
NOTESNOTE
• You can pair an additional baby unit to your parent unit. New baby unit must be paired to the
parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Turn on your parent unit and baby unit.
2. Press when the parent unit is idle.
3. Go to > , select .
4. Press and hold the PAIR key for 3 seconds until you hear a “beep”.
5. When the baby unit is successfully paired with your parent unit, the parent unit
displays and the live video.
Overview - Baby unit
1Light sensor
2Baby unit
3Infrared LEDs
4Microphone
5Stand
6 Night light switch
7Temperature sensor
8Pair key hole
• Press and hold for 3 seconds to enter
paring mode.
9Night light
10 Speaker
11 ON/OFF switch
• Slide to turn on or off the baby unit.
12 POWER LED light
• On when the baby unit is turned on
and is paired to the parent unit.
• Flashes when the baby unit is not
being viewed; or when the link to the
parent unit has lost.
13 Power jack
14 Wall mount holes
11
1
2
3
4
5
6
12
13
10
7
8
9
14
NOTESNOTE
• Use only the power adaptor supplied with this product.
• Make sure the the baby unit are not connected to an electronically/timer controlled electric power outlet.
• Connect the power adaptor in a vertical or floor mount position only. The adaptor prongs are not
designed to hold the weight of the baby unit. Otherwise, the adaptor may not properly connect to the
outlets.
• Make sure the the baby unit and the power adaptor cords are out of reach of children.
