THANK YOU for purchasing this high-quality product. If you should experience a problem not covered in TROUBLESHOOTING,

please visit our website at www.amana.com for additional information. If you still need assistance, call us at 1-800-843-0304.

In Canada, visit our website at www.amanacanada.ca or call us at 1-800-807-6777.

You will need your model and serial number, located on the inside wall of the refrigerator compartment.

REFRIGERATOR SAFETY

Table of Contents / Índice / Table des matières

REFRIGERATOR SAFETY ...............................1

INSTALLATION INSTRUCTIONS....................2

REFRIGERATOR USE....................................11

REFRIGERATOR CARE .................................13

TROUBLESHOOTING ....................................14

WATER FILTER CERTIFICATIONS...............16

PERFORMANCE DATA SHEETS..................17

WARRANTY ....................................................19

SEGURIDAD DEL REFRIGERADOR.............20

INSTRUCCIONES DE INSTALACIÓN...........21

USO DE SU REFRIGERADOR.......................30

CUIDADO DE SU REFRIGERADOR ............. 33

SOLUCIÓN DE PROBLEMAS .......................34

HOJA DE DATOS DEL RENDIMIENTO........37

GARANTÍA ......................................................39

SÉCURITÉ DU RÉFRIGÉRATEUR ................41

INSTRUCTIONS D’INSTALLATION ..............42

UTILISATION DU RÉFRIGÉRATEUR............ 52

ENTRETIEN DU RÉFRIGÉRATEUR..............54

DÉPANNAGE ..................................................55

FEUILLES DE DONNÉES

SUR LA PERFORMANCE..............................58

GARANTIE ......................................................60

REFRIGERATOR USER INSTRUCTIONS

W10366213A

You can be killed or seriously injured if you don't immediately

You can be killed or seriously injured if you don't follow

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety

messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

follow instructions.

instructions.

DANGER

WARNING

Proper Disposal of Your Old Refrigerator

IMPORTANT: Child entrapment and suffocation are not problems

of the past. Junked or abandoned refrigerators are still dangerous

– even if they will sit for “just a few days.” If you are getting rid of

your old refrigerator, please follow these instructions to help

prevent accidents.

Before You Throw Away Your Old Refrigerator or Freezer:

■Take off the doors.

■Leave the shelves in place so that children may not easily

climb inside.

INSTALLATION INSTRUCTIONS

Unpack the Refrigerator

Remove the Packaging

■Remove tape and glue residue from surfaces before turning

on the refrigerator. Rub a small amount of liquid dish soap

over the adhesive with your fingers. Wipe with warm water

and dry.

■Do not use sharp instruments, rubbing alcohol, flammable

fluids, or abrasive cleaners to remove tape or glue. These

products can damage the surface of your refrigerator. For

more information, see “Refrigerator Safety.”

■Dispose of/recycle all packaging materials.

IMPORTANT SAFETY INSTRUCTIONS

WARNING:

To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:

SAVE THESE INSTRUCTIONS

■

Plug into a grounded 3 prong outlet.

■

Do not remove ground prong.

■

Do not use an adapter.

■

Do not use an extension cord.

■

Disconnect power before servicing.

■

Replace all parts and panels before operating.

■

Remove doors from your old refrigerator.

■

Use nonflammable cleaner.

■

Keep flammable materials and vapors, such as gasoline,

away from refrigerator.

■

Use two or more people to move and install refrigerator.

■

Disconnect power before installing ice maker (on ice maker

kit ready models only).

■

Use a sturdy glass when dispensing ice (on some models).

■

Do not hit the refrigerator glass doors (on some models).

WARNING

Suffocation Hazard

Remove doors from your old refrigerator.

Failure to do so can result in death or brain damage.

Important information to know about disposal of

refrigerants:

Dispose of refrigerator in accordance with Federal and Local

regulations. Refrigerants must be evacuated by a licensed,

EPA certified refrigerant technician in accordance with

established procedures.

WARNING

Excessive Weight Hazard

Use two or more people to move and install

refrigerator.

Failure to do so can result in back or other injury. When Moving Your Refrigerator:

Your refrigerator is heavy. When moving the refrigerator for

cleaning or service, be sure to cover the floor with

cardboard or hardboard to avoid floor damage. Always pull

the refrigerator straight out when moving it. Do not wiggle or

“walk” the refrigerator when trying to move it, as floor

damage could occur.

Water Supply Requirements

Gather the required tools and parts before starting installation.

Read and follow the instructions provided with any tools listed

here.

TOOLS NEEDED:

IMPORTANT:

■All installations must meet local plumbing code requirements.

■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve

which reduces water flow and clogs more easily.

■Use copper tubing and check for leaks. Install copper tubing

only in areas where the household temperatures will remain

above freezing.

■For models with water filters, the disposable water filter

should be replaced at least every 6 months.

Water Pressure

A cold water supply with water pressure of between 35 and

120 psi (241 and 827 kPa) is required to operate the water

dispenser and ice maker. If you have questions about your water

pressure, call a licensed, qualified plumber.

Reverse Osmosis Water Supply

IMPORTANT: The pressure of the water supply coming out of a

reverse osmosis system going to the water inlet valve of the

refrigerator needs to be between 35 and 120 psi (241 and

827 kPa).

If a reverse osmosis water filtration system is connected to your

cold water supply, the water pressure to the reverse osmosis

system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).

If the water pressure to the reverse osmosis system is less than

40 to 60 psi (276 to 414 kPa):

■Check to see whether the sediment filter in the reverse

osmosis system is blocked. Replace the filter if necessary.

■Allow the storage tank on the reverse osmosis system to refill

after heavy usage.

■If your refrigerator has a water filter, it may further reduce the

water pressure when used in conjunction with a reverse

osmosis system. Remove the water filter. See “Water Filtration

System.”

If you have questions about your water pressure, call a licensed,

qualified plumber.

Connect the Water Supply

Read all directions before you begin.

IMPORTANT: If you turn on the refrigerator before the water line is

connected, turn off the ice maker to avoid excessive noise or

damage to the water valve.

Connect to Water Line

1. Unplug refrigerator or disconnect power.

2. Turn OFF main water supply. Turn ON nearest faucet long

enough to clear line of water.

3. Find a ¹⁄₂ ¹⁄₄" to 1 " (12.7 mm to 31.8 mm) vertical cold water

pipe near the refrigerator.

IMPORTANT:

■Make sure it is a cold water pipe.

■Horizontal pipe will work, but the following procedure

must be followed: Drill on the top side of the pipe, not the

bottom. This will help keep water away from the drill. This

also keeps normal sediment from collecting in the valve.

4. Determine the length of copper tubing you need. Measure

from the connection on the lower right rear of the refrigerator

to the water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use

¹⁄₄" (6.35 mm) O.D. (outside diameter) copper tubing. Be sure

both ends of copper tubing are cut square.

5. Using a cordless drill, drill a ¹⁄₄" hole in the cold water pipe you

have selected.

6. Fasten the shutoff valve to the cold water pipe with the pipe

clamp. Be sure the outlet end is solidly in the ¹⁄₄" drilled hole in

the water pipe and that the washer is under the pipe clamp.

Tighten the packing nut. Tighten the pipe clamp screws slowly

and evenly so the washer makes a watertight seal. Do not

overtighten.

7. Slip the compression sleeve and compression nut on the

copper tubing as shown. Insert the end of the tubing into the

outlet end squarely as far as it will go. Screw compression nut

onto outlet end with adjustable wrench. Do not overtighten or

you may crush the copper tubing.

8. Place the free end of the tubing in a container or sink, and turn

ON the main water supply. Flush the tubing until water is clear.

Turn OFF the shutoff valve on the water pipe.

■Flat-blade screwdriver

■⁷⁄₁₆" and ¹⁄₂" Open-end or two

adjustable wrenches

■¹⁄₄" Nut driver

■¹⁄₄" Drill bit

■Cordless drill

A. Cold water pipe

B. Pipe clamp

C. Copper tubing

D. Compression nut

E. Compression sleeve

F. Shutoff valve

G. Packing nut

Refrigerator Door(s) and Drawer

TOOLS NEEDED: ⁵⁄₁₆", ³⁄₈", ¹⁄₄" hex head socket wrench, a Torx®†

T20 screwdriver, a #2 Phillips screwdriver, and a flat-blade

screwdriver.

IMPORTANT:

■Your refrigerator may have a standard reversible refrigerator

door with either a freezer door or freezer drawer, or French

doors. Follow the instructions specific to the door style of your

model.

■All graphics referenced in the following instructions are

included later in this section after “Final Steps.” The graphics

shown for the standard door are for a right-hand swing

refrigerator (hinges factory installed on the right).

■If you only want to remove and replace the doors, see

“Remove Door(s) and Hinges” and “Replace Door(s) and

Hinges.”

■Before you begin, turn the refrigerator control OFF, and

remove food and adjustable door or utility bins from the doors.

Remove and Replace Refrigerator Door Handles

Standard Door

■To remove the handle, remove the screw attaching the trim to

the upper end of the handle. Using a flat-blade screwdriver

wrapped in masking tape, pry the trim piece from the lower

end of the handle. Then, remove the screws attaching the

handle to the door. See Graphic 2.

■To replace handle, reverse directions.

French Doors

Style 1 Handles

■Using a ³⁄₃₂" or ¹⁄₈" hex key, loosen the two setscrews located

on the side of each handle. Pull the handle straight out from

the door. Make sure you keep the screws for reattaching the

handles. See Style 1 Handle, graphic 1.

■To replace the handles, reverse the directions.

Style 2 Handles

■To remove the handle, grasp the lower part of the handle

firmly, slide the handle up and pull the handle straight out from

the door. See Style 2 Handle, graphic 1.

■To replace the handle, position the handle so that the large

holes in the mounting clips are down and align the holes with

the door studs. Rotate the handle so that the mounting clips

are flat against the door and slide the handle down to engage.

See Style 2 Handle, graphic 1.

Remove Door and Hinges

Standard Door

Freezer drawer models

1. Unplug refrigerator or disconnect power.

2. Keep the refrigerator door closed until you are ready to lift it

free from the cabinet.

NOTE: Provide additional support for the door while the

hinges are being moved. Do not depend on the door gasket

magnets to hold the door in place while you are working.

3. Remove the parts for the top hinge as shown in Top Hinge

graphic. Lift the refrigerator door free from the cabinet.

4. Remove the parts for the bottom hinge as shown in Bottom

Hinge graphic.

Freezer door models

1. Unplug refrigerator or disconnect power.

2. Keep the freezer door closed until you are ready to lift it free

from the cabinet.

NOTE: Provide additional support for the door while the

hinges are being moved. Do not depend on the door gasket

magnets to hold the door in place while you are working.

3. Remove the parts for the top hinge as shown in Top Hinge

graphic. Lift the refrigerator door free from the cabinet.

4. Remove the center hinge pin and remove the hinge screws as

shown in the Center Hinge graphic. Lift the freezer door free

from the cabinet.

5. Remove the base grille by grasping the grille firmly with both

hands and pulling it toward you.

6. Remove the parts for the bottom hinge as shown in Bottom

Hinge graphic.

French Doors

1. Unplug refrigerator or disconnect power.

2. Keep the refrigerator doors closed until you are ready to lift

them free from the cabinet.

NOTE: Provide additional support for the refrigerator door

while the hinges are being removed. Do not depend on the

door gasket magnets to hold the door in place while you are

working.

†®TORX is a registered trademark of Saturn Fasteners, Inc.

⁵⁄₁₆

" Hex-Head Top Hinge Screw

WARNING

Electrical Shock Hazard

Disconnect power before removing doors.

Failure to do so can result in death or electrical shock.

Remove and Replace Freezer Drawer

IMPORTANT:

■Two people may be required to remove and replace the freezer

drawer.

■All graphics are included later in this section after “Final

Steps.”

Remove and Replace Drawer Handle

Style 1 Handle

■Using a ³⁄₃₂" or ¹⁄₈" hex key, loosen the two setscrews located

on the side of each handle. Pull the handle straight out from

the drawer. Make sure you keep the screws for reattaching the

handles. See Style 1 Handle, graphic 2.

■To replace the handle, reverse the directions.

Style 2 Handle

■To remove the handle, grasp the handle firmly, slide the handle

to the left and pull the handle straight out from the drawer. See

Style 2 Handle, graphic 2.

■To replace the handle, position the handle so that the large

holes in the mounting clips are to the right and align the holes

with the door studs. Rotate the handle so that the mounting

clips are flat against the drawer and slide the handle to the

right to engage. See Style 2 Handle, graphic 2.

Remove Drawer Front

1. Open the freezer drawer to full extension.

2. Loosen the four screws attaching the drawer glides to the

drawer front. See Drawer Front Removal graphic.

NOTE: Loosen screws three to four turns. Keep the screws in

the drawer front.

3. Lift drawer front upward and off the screws. See Drawer Front

Removal graphic.

Replace Drawer Front

1. Slide the drawer glides out of the freezer compartment. Insert

the screws in the top of the drawer front into the slots in the

drawer brackets. See Drawer Front Replacement graphic.

2. Pull the drawer brackets toward you to insert the two screws

in the bottom of the drawer front into the brackets. See

Drawer Front Replacement graphic.

3. Completely tighten the four screws.

Final Steps

1. Check all holes to make sure that hole plugs and screws are in

place. Reinstall top hinge cover as shown in Top Hinge

graphic.

2. Plug into a grounded 3 prong outlet.

3. Return all removable door parts to door and food to

refrigerator.

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Standard Door

Door Removal &

Replacement

B. Bottom Hinge

A. Hinge Pin Shim

C. Hinge Plate

D. Roller Bracket

E. ³⁄₈" Hex-Head Hinge Screws

Bottom Hinge

Top Hinge

A. Hinge Pin Cover

C. Hinge Screws

B. Center Hinge

A. Hinge Cover Screw

B. Top Hinge Cover

" Hex-Head Hinge Screws

D. Top Hinge

Center Hinge

Door Swing Reversal (optional)

A. Door Hinge Hole Plug

A. Cabinet Hinge Hole Plugs

1-2

A. Door Stop Screws

B. Door Stop

Side ViewFront View

A B

1-1

⁵⁄₁₆

" Hex-Head Hinge Screws

Door Handle

Seal Screw

Front

B. Handle Screws

C. Top Trim

D. Bottom Trim

A. Trim Screw

A. Door Hinge Hole Plugs

5-2

5-1

A. Flat-Head Handle Screws

Some Standard Door

models have French

Door Style 2 handles.

See French Doors

graphic.

B. Bottom Hinge

A. Hinge Pin Shim

C. Hinge Plate

D. Roller Bracket

E. ³⁄₈" Hex-Head Hinge Screws

French Doors

WARNING

Electrical Shock Hazard

Disconnect power before removing doors.

Failure to do so can result in death or electrical shock.

Door Removal and Replacement

A. ³⁄₃₂" or ¹⁄₈" Setscrew

Style 1 - Handle

Style 1 - Handle Style 2 - Handle

Style 2 - Handle

Top Hinges

A. Hinge Cover Screw

B. Top Hinge Cover

" Hex Head Hinge Screws

D. Top Hinge

A. Hinge Pin Cover

C. Hinge Screws

B. Bottom Hinge

Bottom Hinges

Wiring Plug

Drawer Front Removal

A. Loosen 4 Door Bracket Screws

Drawer Front Replacement

A. ³⁄₃₂" or ¹⁄₈" Setscrew

Door Closing and Door Alignment

The base grille covers the leveling screws and roller assemblies

located at the bottom of the refrigerator cabinet below the freezer

door or drawer. Before making adjustments, remove the base

grille and move the refrigerator to its final location.

1. Remove the base grille. Grasp the grille firmly and pull it

toward you.

2. Move the refrigerator to its final location.

NOTE: To allow the refrigerator to roll easier, raise the leveling

legs off the floor by turning the leveling screws

counterclockwise. The front rollers will be touching the floor.

3. So the doors will close easier, use a ¹⁄₄" hex driver to turn both

leveling screws clockwise. This will raise the front of the

refrigerator tilting it slightly downward to the rear. Turn both

leveling screws the same amount.

NOTE: Having someone push against the top of the

refrigerator takes some weight off the leveling screws. This

makes it easier to turn the screws.

4. Open and close the doors to make sure they close as easily as

you like. If not, increase the tilt by turning both leveling screws

clockwise. It may take several turns of the leveling screw to

allow the doors to close easier.

5. Check for door alignment. If one door is lower than the other,

adjust the leveling screw, on the lower side of the refrigerator.

Using a ¹⁄₄" hex driver, turn the screw clockwise to raise that

side of the refrigerator until the doors are aligned. It may take

several turns of the leveling screw to raise the refrigerator.

NOTE: Having someone push against the top of the

refrigerator takes some weight off the leveling screws. This

makes it easier to turn the screws.

6. Make sure the refrigerator is steady. If the refrigerator seems

unsteady or rolls forward when the door or drawer is opened

adjust the leveling screws. Using a ¹⁄₄" hex driver, turn the

leveling screw on each side clockwise until the rollers are up

and the leveling feet are firmly against the floor.

NOTE: Having someone push against the top of the

refrigerator takes some weight off the leveling screws. This

makes it easier to turn the screws.

7. Replace the base grille by aligning the ends of the grille with

the leveling assemblies on each side and snapping the grille

into place.

REFRIGERATOR USE

Opening and Closing Doors

(French door models)

There are two refrigerator compartment doors. The doors can be

opened and closed either separately or together.

There is a vertically-hinged seal on the left refrigerator door.

■When the left side door is opened, the hinged seal

automatically folds inward so that it is out of the way.

■When both doors are closed, the hinged seal automatically

forms a seal between the two doors.

A. Leveling screw

¹⁄₄"

A. Hinged seal

¹⁄₄"

Using the Controls

The temperature controls are located at the top front of the

refrigerator or freezer compartments.

Temperature Controls

For your convenience, the temperature controls are preset at the

factory. When you first install your refrigerator, make sure the

controls are still set to the recommended setting as shown.

Recommended Setting “4”

IMPORTANT:

■The recommended setting should be correct for normal

household refrigerator use. The controls are set correctly

when milk or juice is as cold as you like and when ice cream is

firm.

■Wait 24 hours for your refrigerator to cool completely before

adding food. If you add food before the refrigerator has cooled

completely, your food may spoil.

NOTE: Adjusting the refrigerator and freezer temperature

controls to a colder than recommended setting will not cool

the compartments any faster.

■If the temperature is too warm or too cold in the refrigerator or

freezer, first check the air vents to be sure they are not

blocked before adjusting the controls.

To Turn Off/On:

■Press the freezer down arrow touch pad until a dash (-)

appears in both the refrigerator and freezer displays. Neither

compartment will cool when cooling is off.

Humidity Control (on some models)

The humidity control turns on a heater to help reduce moisture on

the door hinge seal. Use in humid environments or when you

notice moisture on the door hinge seal. The refrigerator uses more

energy when Humidity Control is on.

■Press the control to ON when the environment is warm and

more humid, or if you notice moisture on the door hinge seal.

■Press the control to OFF to save energy when the environment

is less humid.

Adjusting Controls

If you need to adjust the temperature in either the refrigerator or

freezer compartment, use the settings listed in the chart below as

a guide.

■Press the up or down arrow touch pads to adjust the

temperature. Except when starting the refrigerator, do not

adjust either control more than one setting at a time. Wait

24 hours between adjustments for the temperature to

stabilize.

Crisper Humidity Control

You can control the amount of humidity in the moisture-sealed

crisper. Depending on your model, adjust the control to any

setting between FRUIT and VEGETABLES or LOW and HIGH.

FRUIT/LOW (open) for best storage of fruits and vegetables with

skins.

VEGETABLES/HIGH (closed) for best storage of fresh, leafy

vegetables.

Ice Maker

(on some models)

IMPORTANT: Flush the water system before turning on the ice

maker. See “Water Dispenser.”

Turning the Ice Maker On/Off

To turn the ice maker ON, simply lower the wire shutoff arm.

To manually turn the ice maker OFF, lift the wire shutoff arm to the

OFF (arm up) position and listen for the click.

NOTE: Your ice maker has an automatic shutoff. As ice is made,

the ice cubes will fill the ice storage bin and the ice cubes will

raise the wire shutoff arm to the OFF (arm up) position. Do not

force the wire shutoff arm up or down.

NOTE: Turn off the ice maker before removing the ice storage bin

to serve ice or to clean the bin. This will keep the ice cubes from

dropping out of the ice maker and into the freezer compartment.

After replacing the ice storage bin, turn on the ice maker.

CONDITION/REASON: ADJUSTMENT:

REFRIGERATOR too warm REFRIGERATOR Control

one setting higher

FREEZER too warm/too little ice FREEZER Control one

setting higher

REFRIGERATOR too cold REFRIGERATOR Control

one setting lower

FREEZER too cold FREEZER Control one

setting lower

Ice Production Rate

■The ice maker should produce a complete batch of ice

approximately every 3 hours.

■To increase ice production, lower the freezer and refrigerator

temperature. See “Using the Controls.” Wait 24 hours

between adjustments.

Remember

■Allow 24 hours to produce the first batch of ice. Allow 3 days

to completely fill the ice storage bin. Discard the first three

batches of ice produced.

■The quality of your ice will be only as good as the quality of the

water supplied to your ice maker. Avoid connecting the ice

maker to a softened water supply. Water softener chemicals

(such as salt) can damage parts of the ice maker and lead to

poor quality ice. If a softened water supply cannot be avoided,

make sure the water softener is operating properly and is well

maintained.

■Do not store anything on top of the ice maker or in the ice

storage bin.

Water Dispenser

(on some models)

IMPORTANT:

■After connecting the refrigerator to a water source or replacing

the water filter, flush the water system. Use a sturdy container

to depress and hold the water dispenser lever for 5 seconds,

then release it for 5 seconds. Repeat until water begins to

flow. Once water begins to flow, continue depressing and

releasing the dispenser lever (5 seconds on, 5 seconds off)

until a total of 4 gal. (15 L) has been dispensed. This will flush

air from the filter and water dispensing system, and prepare

the water filter for use. Additional flushing may be required in

some households. As air is cleared from the system, water

may spurt out of the dispenser.

NOTE: After 5 minutes of continuous dispensing, the

dispenser will stop dispensing water to avoid flooding. To

continue dispensing, press the dispenser button again.

■Allow 24 hours for the refrigerator to cool down and chill

water. Dispense enough water every week to maintain a fresh

supply.

Dispensing Water

1. Hold a container under the dispenser while pressing the

button.

2. Release the button to stop dispensing.

Water Filtration System

The water filter is located in the upper right-hand corner of the

refrigerator compartment.

IMPORTANT: The disposable water filter should be replaced at

least every 6 months. If the water flow to the water dispenser or

ice maker decreases noticeably before 6 months have passed,

replace the water filter more often.

Replacing the Water Filter

To purchase a replacement water filter, model UKF8001AXX-750

or UKF8001AXX-200, contact your dealer or call 1-800-843-0304

U.S.A. or 1-800-807-6777 Canada.

IMPORTANT: Air trapped in the water system may cause water

and filter to eject. Always dispense water for at least 2 minutes

before removing the filter or blue bypass cap.

1. Turn filter counterclockwise to remove.

2. Remove sealing label from replacement filter and insert the

filter end into the filter head.

3. Turn the filter clockwise until it stops. Snap the filter cover

closed.

4. Flush the water system. See “Water Dispenser.”

NOTE: The dispenser feature may be used without a water filter

installed. Your water will not be filtered. If this option is chosen,

replace the filter with the blue bypass cap.

REFRIGERATOR CARE

Cleaning

Both the refrigerator and freezer sections defrost automatically.

However, clean both compartments about once a month to avoid

buildup of odors. Wipe up spills immediately.

IMPORTANT:

■Because air circulates between both sections, any odors

formed in one section will transfer to the other. You must

thoroughly clean both sections to eliminate odors. To avoid

odor transfer and drying out of food, wrap or cover foods

tightly.

■For stainless steel models, stainless steel is corrosion-

resistant and not corrosion-proof. To help avoid corrosion of

your stainless steel, keep your surfaces clean by using the

following cleaning instructions.

Do not use with water that is microbiologically unsafe or

of unknown quality without adequate disinfection before

or after the system. Systems certified for cyst reduction

may be used on disinfected waters that may contain

filterable cysts.

WARNING

Explosion Hazard

Use nonflammable cleaner.

Failure to do so can result in death, explosion, or fire.

To Clean Your Refrigerator:

NOTE: Do not use abrasive or harsh cleaners such as window

sprays, scouring cleansers, flammable fluids, muriatic acid,

cleaning waxes, concentrated detergents, bleaches or cleansers

containing petroleum products on exterior surfaces (doors and

cabinet), plastic parts, interior and door liners or gaskets. Do not

use paper towels, scouring pads, or other harsh cleaning tools.

1. Unplug refrigerator or disconnect power.

2. Hand wash, rinse, and dry removable parts and interior

surfaces thoroughly. Use a clean sponge or soft cloth and a

mild detergent in warm water.

3. Clean the exterior surfaces.

Painted metal: Wash painted metal exteriors with a clean,

soft cloth or sponge and a mild detergent in warm water.

Rinse surfaces with clean, warm water and dry immediately to

avoid water spots.

Stainless steel: Wash stainless steel surfaces with a clean,

soft cloth or sponge and a mild detergent in warm water.

Rinse surfaces with clean, warm water and dry immediately to

avoid water spots.

NOTE: When cleaning stainless steel, always wipe with the

grain to avoid cross-grain scratching.

4. Clean the condenser coils regularly. Coils may need to be

cleaned as often as every other month. This may help save

energy.

■Pull refrigerator out away from the wall. See “Unpack the

Refrigerator.”

■Vacuum coils when they are dusty or dirty.

■Roll refrigerator back into place. Make sure to leave

1" (2.5 cm) between the cabinet back and the wall.

■Check to see that the refrigerator is level.

5. Plug in refrigerator or reconnect power.

Changing the Light Bulb

NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to

replace the bulb with an appliance bulb of the same size, shape,

and wattage (no greater than 40 watts).

1. Unplug the refrigerator or disconnect power.

2. Remove the light shield (on some models).

■Top of the refrigerator compartment - Slide the light shield

toward the back of the compartment to release it from the

light assembly.

3. Replace the burned-out bulb(s) with an appliance bulb(s) no

greater than 40 watts.

4. Replace the light shield.

5. Plug in refrigerator or reconnect power.

TROUBLESHOOTING

First try the solutions suggested here or visit our website and reference FAQs (Frequently Asked Questions)

to possibly avoid the cost of a service call.

In the U.S.A., www.amana.com In Canada, www.amanacanada.ca

Refrigerator Operation

The refrigerator will not operate

■Power cord unplugged? Plug into a grounded 3 prong outlet.

■Is outlet working? Plug in a lamp to see if the outlet is

working.

■Household fuse blown or circuit breaker tripped? Replace

the fuse or reset the circuit breaker. If the problem continues,

call an electrician.

■Are controls on? Make sure the refrigerator controls are on.

See “Using the Control(s).”

■New installation? Allow 24 hours following installation for the

refrigerator to cool completely.

NOTE: Adjusting the temperature controls to coldest setting

will not cool either compartment more quickly.

The motor seems to run too much

Your new refrigerator may run longer than your old one due to its

high-efficiency compressor and fans. The unit may run even

longer if the room is warm, a large food load is added, doors are

opened often, or if the doors have been left open.

The refrigerator seems noisy

Refrigerator noise has been reduced over the years. Due to this

reduction, you may hear intermittent noises from your new

refrigerator that you did not notice from your old model. Below are

listed some normal sounds with explanations.

■Buzzing - heard when the water valve opens to fill the ice

maker

■Pulsating - fans/compressor adjusting to optimize

performance

■Hissing/Rattling - flow of refrigerant, movement of water

lines, or from items placed on top of the refrigerator

■Sizzling/Gurgling - water dripping on the heater during

defrost cycle

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

PERFORMANCE DATA SHEETS

Interior Water Filtration System

Model UKF8001AXX-750 Capacity 750 Gallons (2839 Liters)

This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The

concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the

permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.

Test Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.78 gpm (2.9 Lpm). Pressure = 60 psig (413.7 kPa). Temp. = 68°F ± 5°F

(20°C ± 3°C).

■It is essential that operational, maintenance, and filter

replacement requirements be carried out for the product to

perform as advertised.

■The disposable water filter should be replaced at least every

6 months.

■The filter monitor system measures the amount of water that

passes through the filter and alerts you to replace the filter.

When 90% of the filter’s rated life is used, the yellow (Order)

light comes on. When 100% of the filter’s rated life is used, the

red (Replace) light comes on, and it is recommended that you

replace the filter. For models without filter status lights,

replace the filter every 6 months. Use replacement filter

model UKF8001AXX-750. 2011 suggested retail price of

$44.99 U.S.A./$49.95 Canada. Prices are subject to change

without notice.

■The product is for cold water use only.

■Do not use with water that is microbiologically unsafe or of

unknown quality without adequate disinfection before or after

the system. Systems certified for cyst reduction may be used

on disinfected waters that may contain filterable cysts.

■Refer to the “Water Filtration System” section for the

Manufacturer’s name and telephone number.

■Refer to the “Warranty” section for the Manufacturer’s limited

warranty.

Application Guidelines/Water Supply Parameters

System tested and certified by NSF International against NSF/ANSI Standard 42 for the

reduction of Chlorine Taste and Odor, Particulate Class I*; and against NSF/ANSI

Standard 53 for the reduction of Lead, Mercury, Atrazine, Benzene, p-Dichlorobenzene,

Carbofuran, Toxaphene, Cysts, Turbidity, Asbestos, Tetrachloroethylene and Lindane.

Substance Reduction

Aesthetic Effects

NSF Reduction

Requirements

Average

Influent

Influent Challenge

Concentration

Maximum

Effluent

Average

Effluent

Minimum%

Reduction

Average%

Reduction

Chlorine Taste/Odor

Particulate Class I*50% reduction

85% reduction 2.00 mg/L

14,000,000 #/mL 2.0 mg/L ± 10%

At least 10,000

particles/mL

0.06 mg/L

370,000 #/mL** 0.050625 mg/L

196,666 #/mL 97.00%

97.40% 97.52%

99.00%

Contaminant

Reduction

NSF Reduction

Requirements

Average

Influent

Influent Challenge

Concentration

Maximum

Effluent

Average

Effluent

Minimum%

Reduction

Average%

Reduction

Lead: @ pH 6.5

Lead: @ pH 8.5 0.010 mg/L

0.010 mg/L 0.150 mg/L†

0.150 mg/L†

0.15 mg/L ± 10%

0.15 mg/L ± 10% < 0.001 mg/L

< 0.001 mg/L < 0.001 mg/L

< 0.001 mg/L >99.30%

>99.30% >99.30%

>99.30%

Mercury: @ pH 6.5

Mercury: @ pH 8.5 0.002 mg/L

0.002 mg/L 0.006 mg/L

0.0059 mg/L 0.006 mg/L ± 10%

0.006 mg/L ± 10% 0.0005 mg/L

0.0018 mg/L 0.0003 mg/L

0.00073 mg/L 91.70%

69.20% 95.00%

88.10%

Benzene 0.005 mg/L 0.0133 mg/L 0.015 mg/L ± 10% 0.0005 mg/L 0.0005 mg/L 96.10% 96.30%

p-Dichlorobenzene 0.075 mg/L 0.210 mg/L 0.225 mg/L ± 10% < 0.0005 mg/L < 0.0005 mg/L >99.80% >99.80%

Carbofuran 0.040 mg/L 0.0753 mg/L 0.08 mg/L ± 10% 0.027 mg/L 0.008 mg/L 64.60% 73.45%

Toxaphene 0.003 mg/L 0.015 mg/L 0.015 ± 10% < 0.001 mg/L < 0.001 mg/L >93.3% >93.3%

Atrazine 0.003 mg/L 0.0102 mg/L 0.009 mg/L ± 10% 0.0027 mg/L 0.00105 mg/L 76.30% 89.40%

Asbestos >99% 126.5 MF/L 107 to 108 fibers/L†† < 0.17 MF/L < 0.17 MF/L >99.99% >99.99%

Live Cysts‡

Turbidity >99.95%

0.5 NTU 122,500 #/L

10.5 NTU 50,000/L min.

11 ± 1 NTU < 1 #/L‡

0.30 NTU < 1 #/L‡

0.125 NTU >99.99%

97.30% >99.99%

98.80%

Lindane 0.0002 mg/L 0.0019 mg/L 0.002 ± 10% < 0.00016 mg/L 0.000035 mg/L 91.80% 97.90%

Tetrachloroethylene 0.005 mg/L 0.015 mg/L 0.015 mg/L ± 10% < 0.0005 mg/L < 0.0005 mg/L >96.6% >96.6%

Water Supply

Water Pressure

Water Temperature

Service Flow Rate

City or Well

35 - 120 psi (241 - 827 kPa)

33° - 100°F (1° - 38°C)

0.78 gpm (2.9 L/min.) @ 60 psi

†

††

‡

Class I particle size: >0.5 to <1 um

Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.

These contaminants are not necessarily in your water supply. Performance may vary based on local water conditions.

Fibers greater than 10 um in length

Based on the use of Cryptosporidium parvum oocysts

® NSF is a registered trademark of NSF International.

AMANA

MAJOR APPLIANCE WARRANTY

LIMITED WARRANTY

For one year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or

furnished with the product, Amana brand of Whirlpool Corporation or Whirlpool Canada LP (hereafter “Amana”) will pay for factory

specified parts and repair labor to correct defects in materials or workmanship that existed when this major appliance was purchased.

Service must be provided by an Amana designated service company. YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED

WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. This limited warranty is valid only in the United States or Canada

and applies only when the major appliance is used in the country in which it was purchased. Proof of original purchase date is required

to obtain service under this limited warranty.

ITEMS EXCLUDED FROM WARRANTY

This limited warranty does not cover:

1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is

used in a manner that is inconsistent to published user or operator instructions and/or installation instructions.

2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or

repair house fuses, or to correct house wiring or plumbing.

3. Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty

coverage.

4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in

accordance with electrical or plumbing codes, or use of products not approved by Amana.

5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage

results from defects in materials or workmanship and is reported to Amana within 30 days from the date of purchase.

6. Any food or medicine loss due to refrigerator or freezer product failures.

7. Pickup and delivery. This major appliance is intended to be repaired in your home.

8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.

9. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an

authorized Amana servicer is not available.

10. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance

with Amana's published installation instructions.

11. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered or

cannot be easily determined.

12. Any damage or discoloration of dry-erase door surface caused by markers other than dry-erase markers in the recommended

colors listed in the Use and Care Guide.

13. Any damage or discoloration caused by any e not designated as dry-erase surfaces. marker to refrigerator surfaces that ar

14. Discoloration, rust, or oxidation of stainless steel surfaces.

DISCLAIMER OF IMPLIED WARRANTIES

IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR

A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces

do not allow limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This

warranty gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.

LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES

YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.

AMANA SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the

exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty

gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.

If outside the 50 United States and Canada, contact your authorized Amana dealer to determine if another warranty applies. 6/08

For additional product information, in the U.S.A., visit www.amana.com

In Canada, visit www.amanacanada.ca

If you do not have access to the Internet and you need assistance using your product or you would like to schedule service, you may

contact Amana at the number below.

Have your complete model number ready. You can find your model number and serial number on the label, located on the inside wall of

the refrigerator compartment.

For assistance or service in the U.S.A., call 1-800-843-0304. In Canada, call 1-800-807-6777.

If you need further assistance, you can write to Amana with any questions or concerns at the address below:

In the U.S.A.:

Amana Brand Home Appliances

Customer eXperience Center

553 Benson Road

Benton Harbor, MI 49022-2692

In Canada:

Amana Brand Home Appliances

Customer eXperience Centre

200 – 6750 Century Ave.

Mississauga, Ontario L5N 0B7

Please include a daytime phone number in your correspondence.

Please keep these User Instructions and the model number information for future reference.

LE AGRADECEMOS la compra de este producto de alta calidad. Si usted experimenta un problema que no se haya cubierto en

SOLUCIÓN DE PROBLEMAS, visite nuestro sitio de internet en www.amana.com para obtener información adicional. Si

considera que aún necesita ayuda, llámenos al 1-800-843-0304. En Canadá, visite nuestro sitio de internet en

www.amanacanada.ca o llámenos al 1-800-807-6777.

Necesitará tener a mano su número de modelo y de serie ubicados en la pared interior del compartimiento del refrigerador.

SEGURIDAD DEL REFRIGERADOR

INSTRUCCIONES PARA EL USUARIO DEL

REFRIGERADOR

Si no sigue las instrucciones de inmediato, usted puede

morir o sufrir una lesión grave.

Si no sigue las instrucciones, usted puede morir o sufrir

una lesión grave.

Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que

puede suceder si no se siguen las instrucciones.

Su seguridad y la seguridad de los demás es muy importante.

Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre

todos los mensajes de seguridad.

ADVERTENCIA

PELIGRO

Este es el símbolo de advertencia de seguridad.

Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a

usted y a los demás.

Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra

“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:

Para reducir el riesgo de incendio, choque eléctrico, o lesiones personales al usar su refrigerador siga

estas precauciones básicas:

ADVERTENCIA:

INSTRUCCIONES IMPORTANTES DE SEGURIDAD

CONSERVAR ESTAS INSTRUCCIONES

■ Conecte a un contacto de pared de conexión a tierra de

3 terminales.

■ No use un adaptador.

■ No quite la terminal de conexión a tierra.

■ No use un cable eléctrico de extensión.

■ Desconecte el suministro de energía antes de darle servicio.

■ Vuelva a colocar todos los componentes y paneles antes de

hacerlo funcionar.

■ Remueva las puertas de su refrigerador viejo.

■ Use un limpiador no inflamable.

■ Mantenga los materiales y vapores inflamables, tales como

gasolina, alejados del refrigerador.

■ Use dos o más personas para mover e instalar el

refrigerador.

■ Desconecte el suministro de energía antes de instalar la

fábrica de hielo (en aquellos modelos que incluyen el juego

de instalación de la fábrica de hielo).

■ Use un vaso resistente para recibir hielo del despachador

(en algunos modelos).

■ No golpee las puertas de vidrio del refrigerador (en algunos

modelos).

Produkt Specifikationer

Mærke:	Amana
Kategori:	Køleskab
Model:	ABB1924BRW

Har du brug for hjælp?

Hvis du har brug for hjælp til Amana ABB1924BRW stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Køleskab Amana Manualer

Amana ART106TFDB Manual

21 Februar 2025

Amana ASI2275FRS Manual

20 Februar 2025

Amana ABB2224BR Manual

12 Januar 2025

Amana ABB1924BR Manual

12 Januar 2025

Amana A1RXNGFYW Manual

11 Januar 2025

Amana ABB1924WES Manual

11 Januar 2025

Amana SXD520 Manual

21 August 2024

Amana ART318FFDB Manual

19 August 2024

Amana A9RXNGFYW Manual

18 August 2024

Amana A8RXCGFXS Manual

16 August 2024

Køleskab Manualer

Nyeste Køleskab Manualer

Whirlpool ARG 746/A+/5 Manual

25 Marts 2025

Bosch KTR15NWEAG Manual

22 Marts 2025

Caple RBL6 Manual

21 Marts 2025

FrigeluX CBNF177BI Manual

20 Marts 2025

Café CWE19SP2NS1 Manual

16 Marts 2025

Bosch B36FD30ENS Manual

15 Marts 2025

Bosch KTR15NWECG Manual

13 Marts 2025

Hisense HRBF126 Manual

13 Marts 2025

Hotpoint HTSD184011A1 Manual

12 Marts 2025

Hotpoint HTSD18A011A1 Manual

12 Marts 2025
