ADM-VWPS Page 1 of 12This pack contains 1 mount. Please retain this document for future reference.
REQUIRED TOOLS FOR INSTALLATION
CONTENTS
Installation Safety Notes Page 2
Interface Adaptors Page 3
Installation Instructions Page 4
Installation Options Page 9
Alternative Mounting Examples Page 10
Product Dimensions Page 11
Flathead &
Crosshead
Screwdrivers
A
Wall Mount
I
M6 x
16mm
Screw
M
M8 x
16mm
Screw
J
M6 x
25mm
Screw
N
M8 x
25mm
Screw
K
M6 x
40mm
Screw
O
M8 x
40mm
Screw
L
M6
Washer
B
Interface
Arm - Left
C
Interface
Arm - Right
D
600mm
Adaptor Arm
E
M6 x 20mm
Screw
F
M8 x 12mm
Countersunk
Screw (x4)
G
4mm Short
Allen Key
H
4mm Long
Allen Key
PencilPower
Drill
Dual-Plane
Laser Level:
Optional
Drill
Bit
Suitable for loads up to 50kg
IMPORTANT INFORMATION
! Important: Fixing screws are not included with this product.
Atdec highly recommends this product be installed by a suitably
qualified person. The installer must be satisfied that the type of
fixings used are suitable for the type of wall the product is to be
mounted to. Care must be taken as to where this product is located
as some walls are not suitable for installation. When drilling holes
knowledge must be obtained to avoid contact with any electrical
cables and/or gas and water pipes contained within the wall.
COMPONENT CHECKLIST
Display Interface
P
M8 x
5mm
Spacer
Q
M8 x
13mm
Spacer
R
M8 x
24mm
Spacer
Installation Guide
ADM-VWPS
Pop-Out Slim
Video Wall Mount
