- General Information -

Intended use -

Private exchanges -

Disposal -

Please read these operating instructions carefully. If you

should have any questions, please contact our Service

Department on the Hotline number 0180 5 00 13 88 (costs

Telekom by printing: 12ct/min). Under no circumstances

open the unit yourself and do not try to carry out your own

repairs. For any claims under the warranty, please refer to

your dealer.

This telephone is designed for use

connected to an analogue telephone line (PSTN) in

Germany. However, due to differences in the services

provided by the various telecommunications providers, we

cannot guarantee that the telephone will work properly

when connected to all telecommunications terminal lines.

The telephone is prepared for connection to a TAE phone

jack with F/N coding and can be used together with other

equipment such as a fax, answering machine, or a

modem. Plug the connecting phone cable only into the

telephone plug socket provided for this purpose. Do not

replace the plug of the connecting phone cable.

The telephone can also be

connected to a private exchange. You can find out from

the dealer from whom the equipment was purchased

whether your telephone will work on your private

exchange without any problems. Due to the large number

of different private exchanges, it is not possible to

guarantee this function.

If the useful life of the complete equipment has

expired, please dispose of it carefully in accordance with

the statutory requirements and in a manner friendly to the

environment.

CE mark - The telephone complies with the basic

requirements of the R&TTE Directive This is confirmed by

the CE mark.

- General Information -

Temperature and ambient conditions -

Location -

Cleaning and care -

The telephone

is designed for use in protected rooms with a temperature

range of 10 °C to 30 °C. The telephone must not be

installed in damp rooms such as a bathroom or laundry

room. Avoid proximity to sources of heat such as radiators

and do not expose the unit to direct sunlight.

Do not set up the telephone in the immediate

vicinity of other electrical equipment such as microwaves

or hi-fi systems, as this may result in mutual interference.

The location has a decisive influence on the trouble-free

operation of the telephone.

Place the telephone on a flat and non-slip surface. The

feet do not normally leave any marks on the surface.

However, due to the large number of varnishes and

surfaces in use, it may not be possible to prevent marks

occurring on the surface due to the feet of the unit.

Do not use the telephone in areas where there is a risk of

an explosion.

Excessive exposure to smoke, dust, vibrations,

chemicals, moisture, heat or the direct rays of the sun

must be avoided.

The surface of the case can be

cleaned with a soft, dry, lint-free cloth. Never use cleaning

agents, particularly aggressive solvents. No attention is

necessary apart from cleaning the housing occasionally.

The rubber feet of the telephone are not resistant to all

cleaning agents. The manufacturer can therefore not

accept any liability for possible damage to furniture or the

like.

- Operational Elements -

1 Disconnect button/receiver rest

2 Save button

4 Speed dial button

7 100/300ms

Right side

Redial

R signal button

Ring tone switch

FLASH switch

Mute button

Inside the receiver

300 100 ms

ABC DEF

GHI JKL MNO

PQRS TUV WXYZ

5 64

8 9

2 31

- Operation -

Making a call

Receiving calls

Redial facility

Your telephone can be used like any conventional

telephone.

Lift the receiver and wait until you hear the dialling

tone.

Now dial the required telephone number.

To end the call, replace the receiver on the rest. You can

end the current call by using the disconnect button and

you will immediately obtain a new dialling tone.

When a call comes through, you will hear the ringing

tone. The call can now be accepted using the receiver.

If a connection that you have dialled is engaged or you

were unable to get through to anybody, simply replace

the receiver. The last number dialled remains stored in

the telephone automatically. To use the redial facility,

proceed as follows:

Lift the receiver and press the redial button The

stored redial number will now be dialled.

By means of the slide switch you can choose the

settings (loud) or (soft) to match the volume of the

ringing tone to your requirements. If at any time you do

not want to be disturbed, use the setting (off).

Adjustable ring tone

- Operation -

Muting the microphone

Saving numbers under the speed dial buttons

You can switch off the microphone during a call using the

mute button, . It is thus possible to speak without the

other party hearing you. The loudspeaker remains

switched on and you can continue to hear the other party.

To mute the microphone, press and hold the mute button

once while a call is being made.

To switch the microphone on again, release the mute

button and you will be able to continue your call as

normal.

1. Lift the receiver.

2. Press the store button .

3. Enter the required telephone number with a maximum

of digits using the number pad. 16

If you enter the wrong number, you can break

off the process at this point by replacing the receiver

on the rest.

4. Press the store button .

5. Now select a speed dial storage location by pressing a

number between 0 and 9 on the number pad.

6. Replace the receiver on the rest to complete the save

procedure.

Storage locations that have already been used cannot be

erased. Simply save a new number in the storage location

that you want to erase.

Note:

Tips on storing numbers:

- Operation -

Making a call using the speed dial buttons

Private exchanges - Setting up for T-NET

1. Lift the receiver.

2. Press the speed dial button .

3. Now press the required storage location between 0

and 9 on the keypad. The stored number will now be

dialled automatically.

4. To end the call, replace the receiver.

With your telephone you can make calling by way of the

private telephone network providers considerably easier.

Save the access numbers to the private network providers

and the actual telephone numbers separately in different

storage locations. First dial the memory location for the

private network provider and then a direct dial button or

over the speed dial button the memory location for the

required telephone number or dial the required telephone

number manually.

You can use the “R” signal button on your telephone on

private exchanges and when using DEUTSCHE

TELEKOM's T-Net functions.

If you have connected your

telephone to a private exchange, you can use all the

facilities such as call transfer, automatic recall, etc. The “R”

signal button gives you access to these facilities. The

FLASH time “100ms” will be required on a private

exchange. To make this setting, move the slide switch on

the right side to the “100ms” position. You can find out

from the dealer from whom the equipment was purchased

whether your telephone will work on your private exchange

without any problems and which other facilities you will

have access to.

Interesting note!

Private exchanges -

- Operation -

T-NET functions -

Dialling telephone numbers when using on private

exchanges

Your telephone supports the most

important DEUTSCHE TELEKOM added value services

(e.g. brokering, call waiting, three-way conferencing, etc.).

Please contact DEUTSCHE TELEKOM to gain access to

these functions (some of which are subject to charge).

When using T-NET functions, move the slide switch on the

right side to the “300ms” position.

With private exchanges, it is necessary to dial a certain

number (e.g. "9" or "0") in order to obtain a dialling tone for

an outside line on the extension. With some, older private

exchanges, it takes some time before the dialling tone can

be heard. Especially for these private exchanges, an

automatic pause can be inserted after connecting to the

outside line so that you can dial directly without waiting for

the dialling tone.

Press the redial button once between the number for

the outside line and the actual telephone number. After

connecting to an outside line your telephone will wait for 3

seconds before dialling the actual telephone number.

You can store the pause under the speed dial buttons.

- Commissioning -

General Information

Check contents of pack

Connecting the telephone

Wall mounting

NOTE! Before commissioning, it is essential that you read

the General Information at the beginning of this manual.

The following items are supplied

- one telephone with telephone connecting cable

- one instruction manual

Connect the firmly installed telephone cable to the

telephone socket.

The telephone works using the tone dialling system.

Your telephone is also suitable for wall mounting. Use two

flat head screws for fixing. Drill two holes horizontally side

by side, 83 mm apart, and leave the screws protruding

from the wall by 5mm. Now place the telephone over the

screws and push it slightly downwards.

If you are using the telephone fitted to the wall, you can

hang the receiver on the telephone without hanging up.

You will find a small hook for this purpose at the upper end

of the receiver rest.

- Important information -

Fault finding

Guarantee

Remove all extra telephone equipment and connect only

the telephone directly to the telephone socket.

If the fault is still present, connect another telephone (if

available) to the telephone socket. The results will show

you whether the fault lies with the unit or with the

telephone line.

In the case of technical problems you can also contact our

Service Department on the Hotline number

0180 5 00 13 88 (costs Telekom by printing: 12ct/min).

AUDIOLINE equipment is manufactured and tested in

accordance with the most up to date production methods.

Selected materials and highly developed technology

ensure trouble-free operation and long life. If your unit

should develop a fault within the guarantee period,

however, please contact the shop where you bought your

AUDIOLINE equipment exclusively and have your

purchase receipt available for inspection. The warranty

period is 24 months calculated from the day of purchase.

Within the guarantee period, all defects due to material or

manufacturing faults will be repaired free of charge. The

guarantee is invalidated if the equipment has been

tampered with by the purchaser or third parties. Any

damage caused by improper handling or operation, by

incorrect positioning or storage, by improper connection or

installation or by excessive force or other external

influences is not covered by the guarantee. In the case of

complaint, we reserve the right to repair or replace

defective parts or to exchange the equipment.

Warranty conditions:

- Important information -

Exchanged parts or exchanged equipment become our

property. Claims for compensation are excluded insofar as

they do not relate to criminal intent or gross negligence on

the part of the manufacturer. All guarantee claims according

to these conditions must be raised exclusively with your

dealer. Rights under the guarantee can no longer be

enforced after the expiry of 24 months from purchase and

delivery of our products. In the case of unnecessary or

unjustified demands on the customer service department,

we will levy our usual service charges for materials, time,

postage and packing. Any complaints must be reported as

soon as a problem is found. The guarantee is valid within

the German Federal Republic.

The telephone complies with the basic requirements of the

R&TTE Directive "1999/5/EEC". This is confirmed by the CE

mark.

For the complete Declaration of Conformity, please use the

free download from our web site www.audioline.de.

Declaration of Conformity/CE mark

- Notizen / Notes -

Produkt Specifikationer

Mærke:	Audioline
Kategori:	Telefon
Model:	TEL6

Har du brug for hjælp?

Hvis du har brug for hjælp til Audioline TEL6 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Telefon Audioline Manualer

Audioline Splash 100 Manual

3 Oktober 2024

Audioline DECT 7801micro Manual

2 Oktober 2024

Audioline TEL4CLIP Manual

2 Oktober 2024

Audioline TEL28 Manual

2 Oktober 2024

Audioline Euro 300 Manual

2 Oktober 2024

Audioline IP 6 Manual

2 Oktober 2024

Audioline Oslo 200 Manual

21 September 2024

Audioline Sprint 100 Manual

20 September 2024

Audioline Oslo 58-X Manual

20 September 2024

Audioline Euro 300S Manual

18 September 2024

Telefon Manualer

Nyeste Telefon Manualer

HTC Desire 19+ Manual

15 December 2024

Ranex RX 6031 Manual

15 December 2024

Vtech DS6611-2 Manual

14 December 2024

Vtech DS6771-3 Manual

14 December 2024

Vtech DS6161 Manual

14 December 2024

Vtech DS6621-2 Manual

14 December 2024

Vtech CS6114-21 Manual

14 December 2024

Panasonic KX-TGU410 Manual

14 December 2024

Vtech CS6124-21 Manual

13 December 2024

Vtech CS6929-3 Manual

13 December 2024
