INSTAX-ADXSVI-MB1
REV. 6/28/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
INSTAX-ADXSVI-MB1
1-800-221-0932 metraonline.com
REV. 6/28/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
AX-ADXSVI-MB1
Mercedes accessory and NAV output CAN Interface 2001-2004
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Used in non-amplified systems, or when bypassing an amplified system
Provides NAV outputs (parking brake, reverse, and speed sense)
Prewired ASWC-1 harness (ASWC-1 sold separately)
Retains balance and fade
Micro "B" USB updatable
Attention! This harness must be used along with the AX-ADXSVI
(sold separately)
APPLICATIONS
WIRING THE AX-ADXSVI-MB1
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the wire to the radio’s ground wire.Black
Connect the wire to the ignition wire of the aftermarket radio.Red
Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the Orange wire.
Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
Connect the wire to the left front positive speaker output of the aftermarket radioWhite
.
Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
Connect the wire to the right front positive speaker output of the aftermarket radio Gray
.
Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
MERCEDES
C Class 2001-2004
CLK Class 2004
CLK500 2003
CLK55AMG 2003
Connect the wire to the radios left rear positive speaker output.Green
Connect the wire to the radio’s left rear negative speaker output.Green/Black
Connect the wire to the radio’s right rear positive speaker output.Purple
Connect the wire to the radio’s right rear negative speaker output.Purple/Black
The following (3) wires are for the aftermarket radios that have navigation built in.
Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
INITIALIZING THE AX-ADXSVI-MB1
Attention! If the interface loses power for any reason, the following steps will need to
be performed again. Also, if installing an ASWC-1 connect it after you initialize and test
the interface/radio, with the key in the off position.
Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
Turn the key to the off position, and then to the accessory position. Test all functions
of the installation for proper operation, before reassembling the dash.
K PNOWLEDGE IS OWER
Enhance your inst allat ion and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo informat ion and t ake steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
CAUTION!
All accessories, switches, climate con-
trols panels, and especially air bag indicator lights
must be connected before cycling the ignition.
Also, do not remove the factory radio with the key
in the on position, or while the vehicle is running.
