AX-ALOC710
INSTALL ATION INSTRUCTI O N S
REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire Color & Function: The audio input wire colors are an EIA standard
for car stereo applications as follows.
INPUT HARNESS
= GroundBlack
Yellow - Battery +12V input
= Remote +12V outputBlue
= Left front (+) inputWhite
= Left front (-) inputWhite/Black
= Right front (+) inputGray
Gray/Black = Right front (-) input
= Reference ground (-)Brown
(Reference ground optional if noise is present)
Note:
Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the audio
source need to be connected to the corresponding positive input wires
of the AX-ALOC710. The same goes for the negative audio wires. Fail-
ure to do this will result in poor bass response and low quality audio.
Adjusting the AX-ALOC710 for maximum performance: After complet-
ing all of the necessary connections, turn the AX-ALOC710 adjustment
pots all of the way down by rotating them completely counter-clock-
wise. Now, turn the stereo system on and adjust the main volume con-
trol on the stereo to approximately 3/4 maximum volume. Select one
of the adjustment pots on the AX-ALOC710 and turn it slowly clockwise
until you notice audio distortion and then stop. Turn the remaining pot
to the same position as the previously adjusted pot. The audio set-up
of the AX-ALOC710 is now complete and ready to be enjoyed.
The AX-ALOC710 is designed to convert speaker level audio to line level
audio. This allows for the installation of line level products such as amplifiers,
EQs and crossovers on systems that do not have RCA line level outputs. In
addition this device will also detect the presence of an audio signal and then
generate a +12V output that can be used to turn-on an aftermarket amplifier.
Features:
55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly
Found On Other Brands of LOCs, 6:1 Step Down with Variable Output,
Detachable Input Plug, Gold Plated RCAs, Attractive & Durable Enclosure
2 Channel, Adjustable Line Output Converter


Produkt Specifikationer

Mærke: AXESS
Kategori: Ikke kategoriseret
Model: AX-ALOC710
