AXAC-CH6
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 7/25/24 INSTAXAC-CH6
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights,
are plugged in before reconnecting the battery or
cycling the ignition to test this product.
NOTE:
Refer also to the instructions included with the
aftermarket accessory before installing this device.
INTERFACE FEATURES
TOOLS REQUIRED
INTERFACE COMPONENTS
REQUIRED ITEMS
TABLE OF CONTENTS
Introduction 2 ...........................................................
Configuration 2-4 .....................................................
Connections 5 ............................................................
Installation 6 .............................................................
Programming 6 .........................................................
Rebooting the U-Connect Radio 7 ..........................
(4) Camera inputs
Reverse signal trigger generated via CAN bus communication of
the vehicle
Turn signal trigger generated via CAN bus communication of
the vehicle
(4) Programmable camera control wires
Micro-B USB updatable
• Crimping tool and connectors, or solder gun,
solder, & heat shrink • Tape • Wire cutter • Zip
ties
• AXAC-CH6 interface
• AXAC-CH6 interface harness
• AXAC-CH6 vehicle harness
Update Cable: AXUSB-MCBL (sold separately)
Axxess Updater Program
* With 5-inch U-Connect radio
Jeep/Ram* Camera Interface With
Pre-Wired
Harness
2014-Up
APPLICATIONS
Jeep
Renegade 2015-2018 .......................................................................
Ram
Promaster 2014-Up .........................................................................
Promaster City 2015-2017 ...............................................................
Note: Only compatible with NTSC cameras.
Visit for more detailed information
AxxessInterfaces.com
about the product and up-to-date vehicle specific applications
