AXBUCS-SB286V AXBUCS-SB286V
REV. 9/18/19 REV. 9/18/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
Pre-wired AXSWC harness
(AXSWC sold separately)
Retains the factory backup camera
Retains the factory AUX-IN jack
Provides NAV outputs (parking brake,
reverse, speed sense)
Includes an AXCSD-6V 12-volt
to 6-volt converter
INTERFACE COMPONENTS
AXBUCS-SB286V harness • AXCSD-6V 12-volt to 6-volt converter
Subaru 2015-Up*
Backup Camera Retention Harness with
Pre-Wired AXSWC Harness
APPLICATIONS
SUBARU
BRZ 2016-Up
Crosstrek 2016-2017
Forester 2017-2018
Impreza 2015-2016
WRX (with NAV) 2015
WRX 2016-Up
XV Crosstrek 2015
* Visit
AxxessInterfaces.com
for more detailed information about the product and up-to-date vehicle specific applications
INTERFACE FEATURES
† With Base radio, 6.2-inch screen
K PNOWLEDGE IS OWER
Enhance your inst allation and fabrication skills by
enrolling in t he most recognized and spect ed re
mobile elect nics school in our industry.ro
Log onto www.installerinstitute.com or call
800-354-6782 for mo informat ion and take st eps re
toward a bett er tomorrow.
®
Metra recommends MECP
certified technicians
Connections to be made
Connect the
Black
wire to chassis ground, and also to the
Black
wire of the AXCSD-6V.
Connect the
Red
wire labeled "Camera Power 6V" to the
Blue/Red
wire of the AXCSD-6V.
Connect the unlabeled
Red
wire to accessory power.
Connect the
Green/Purple
wire to the reverse wire of the aftermarket radio,
and also to the
Blue/White
wire of the AXCSD-6V.
To the aftermarket radio:
Connect the
Yellow
RCA jack to the backup camera input.
If retaining the factory AUX-IN jack, connect the
Red
&
White
RCA jacks to the AUX input.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires:
Connect the wire to the parking brake wire.Light Green
Connect the wire to the speed sense wire.Blue/Pink
Installing the AXBUCS-SB286V
With the key in the off position:
After the radio has been tested and working, connect the AXBUCS-SB286V harness to the vehicle,
and then into the AXSWC.
Refer to the AXSWC instructions for radio connections and programming.
Note:
Disregard the harness that comes with the AXSWC.
