Side 1/8

AXSSO-FD

I N S T A L L A T I O N I N S T R U C T I O N S

Patent #10844821, 11459994, 11493012

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Zip ties • Cutters (for zip ties)

• USB Micro-B cable

(Axxess part number )AXUSB-MCBL

TABLE OF CONTENTS

Programming 2 .........................................................

Connections 3 ............................................................

Operation................................................................4

Ford Stop/Start Override Interface 2015-Up

APPLICATIONS

• Allows the override of the STOP/START engine feature

• The factory STOP/START button can resume the STOP/START feature

• Can be used with either a factory or aftermarket radio

•

Vehicle type configured through the Axxess Updater software program

• Simple plug n’ play installation, no wiring required

The is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been AXSSO-FD

cycled. The will work with either an aftermarket radio, or a factory radio. A simple plug n’ play installation is all that is required to install AXSSO-FD

the device in the vehicle, and programming through a Windows 10 computer via the software program.

Axxess Updater

Ford

Bronco 2022 .............................................................

Edge 2015-2020 .......................................................

Escape 2017-Up .......................................................

F-150.......................................................... 2015-Up

Focus 2016-Up .........................................................

Fusion 2015-Up .......................................................

• AXSSO-FD interface

• AXSSO-FD harness (qty. 2)
