Side 1/4

AXSSO-FD2

I N S T A L L A T I O N I N S T R U C T I O N S

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

NOTE: Refer to the instructions included with

the aftermarket radio.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Zip ties • Cutters (for zip ties)

• USB Micro-B cable

(Axxess part number AXUSB-MCBL)

TABLE OF CONTENTS

Programming .........................................................2

Connections ............................................................3

Operation ................................................................4

Ford Stop/Start Override Interface 2019-Up

APPLICATIONS

• Allows the override of the STOP/START engine feature

• The factory STOP/START button can resume the STOP/START feature

• Can be used with either a factory or aftermarket radio

•

Vehicle type conﬁgured through the Axxess Updater software program

• Simple plug n’ play installation, no wiring required

The is designed to disengage the STOP/START feature of the vehicle and keep that feature disengaged, even after the key has been AXSSO-FD2

cycled. The AXSSO-FD2 will work with either an aftermarket radio or a factory radio. A simple plug n’ play installation is all that is required to install

the device in the vehicle. Programming will be enabled through a Windows 10 computer via the Axxess Updater software program.

Ford

Bronco Sport 2021

Escape 2020-2021

Explorer 2020-2021

Ranger 2019-2021

Transit 2020-2021

Transit Connect 2019-2021

• AXSSO-FD2 interface

• AXSSO-FD2 harness

Product Info

INTRODUCTION
