Side 1/5
GENERAL SAFETY RULES - FOR ALL BATTERY OPERATED TOOLS
WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions
listed below, may result in electric shock, fire and/or serious personal injury
SAVE THESE INSTRUCTIONS
WORK AREA
• Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
• Keep bystanders, children, and visitors away while operating a power tool. Distractions can
cause you to lose control.
ELECTRICAL SAFETY
• Do not abuse the cord. Never use the cord to carry the tool. Keep cord away from heat, oil,
sharp edges or moving parts. Replace damaged cords immediately. Damaged cords may
create a fire.
• A battery operated tool with integral batteries or a separate battery pack must be recharged
only with the specified charger for the battery. A charger that may be suitable for one type of
battery may create a risk of fire when used with another battery.
• Use battery operated tool only with specifically designated battery pack. Use of any other
batteries may create a risk of fire.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use tool while tired or under the influence of drugs, alcohol, or medication. A moment
of inattention while operating power tools may result in serious personal injury,
• Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair,
clothing , and gloves away from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts.
• Avoid accidental starting. Be sure switch is in the locked or off position before inserting
battery pack. Carrying tools with your finger on the switch or inserting the battery pack into a
tool with the switch on invites accidents.
• Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left
attached to a rotating part of the tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. Proper footing and balance
enable better control of the tool in unexpected situations.
• Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes, hard hat,
or hearing protection must be used for appropriate conditions.
TOOL USE AND CARE
• Use clamps or other practical way to secure and support the workpiece to a stable platform.
Holding the work by hand or against your body is unstable and may lead to loss of control.
• Do not force tool. Use the correct tool for your application. The correct tool will do the job better
and safer at the rate for which it is designed.
• Do not use tool if switch does not turn it on or off. A tool that cannot be controlled with the
switch is dangerous and must be repaired.
• Disconnect battery pack from tool or place the switch in the locked or off position before
making any adjustments, changing accessories, or storing the tool. Such preventative safety
measures reduce the risk of starting the tool accidentally.
• Store idle tools out of reach of children and other untrained persons. Tools are dangerous in
the hands of untrained users.
• When battery pack is not in use, keep it away from other metal objects like: paper clips,
coins, keys, nails, screws or other small metal objects that can make a connection from one
terminal to another. Shorting the battery terminals together may cause sparks, burns, or a fire.
• Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools, with
sharp cutting edge are less likely to bind and are easier to control.
• Check for misalignment or binding of moving parts, breakage of parts, and any other
condition that may affect the tool’s operation. If damaged, have the tool serviced before
using. Many accidents are caused by poorly maintained tools.
• Use only accessories that are recommended by the manufacturer for your model. Accessories
that may be suitable for one tool may create a risk of injury when used on another tool.
SERVICE
• Tool service must be performed only by qualified repair personnel. Service or maintenance
performed by unqualified personnel may result in a risk of injury.
• When servicing a tool, use only identical replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized parts or failure to follow Maintenance
Instructions may create a risk of shock or injury.
SPECIFIC SAFETY RULES
• Hold tool by insulated gripping surfaces when performing an operation where the cutting tool
may contact hidden wiring or its own cord. Contact with a "live" wire will also make exposed
metal parts of the tool "live" and shock the operator.
WARNING: Use of this tool can generate dust containing chemicals known to cause cancer, birth defects
or other reproductive harm.
The label on your tool may include the following symbols.
V ..........................volts A ........................amperes
Hz ........................hertz W ......................watts
min ......................minutes ......................alternating current
....................direct current n o ......................no load speed
........................
Class II Construction ........................earthing terminal
........................safety alert symbol .../min ................revolutions or
reciprocations
per minute
Charging the Drill
Before attempting to charge your drill, thoroughly read ALL of the safety instructions. To charge
your drill, follow the steps below.
1. Remove any accessories from the chuck.
2. Plug the output cord of the charger into the socket in the drill handle.
3. Plug the charger into any standard electrical outlet.
4. Allow the tool to remain in this condition for 16 hours.
Important Charging Notes
1. After normal usage, your drill should be fully charged in 16 hours or less. Your drill was
sent from the factory in an uncharged condition. Before attempting to use it, it must be
charged for at least 16 hours.
2. DO NOT charge the batteries in an air temperature below +40°F or above +105°F. This is
important and will prevent serious damage to the batteries.
3. While charging, the charger may hum and become warm to touch. This is a normal condi-
tion and does not indicate a problem.
4. If the batteries do not charge properly – (1) Check current at receptacle by plugging in a
lamp or other appliance. (2) Check to see if the receptacle is connected to a light switch
which turns power off when you turn out the lights.
(3) Move charger and drill to a surrounding air temperature of +40°F to +105°F. (4) If the
receptacle and temperature are OK, and you do not get proper charging, take or send the
tool and charger to your local Black & Decker service center. See "Tools Electric"’ in yellow
pages.
5. The drill should be recharged when it fails to produce sufficient power on the jobs which
previously were done easily. DO NOT CONTINUE to use the drill with its battery in a
depleted condition.
6. To prolong battery life, avoid leaving the tool on charge for more than 2 days. Although
overcharging is not a safety concern, it can significantly reduce overall battery life.
7. Since the unit is designed for cordless applications, use of the unit while plugged in is of no
benefit. Batteries will still become depleted.
8. Unplug your tool’s charger from the power supply before disconnecting the charger from
the tool. Under certain conditions, with the charger plugged in to the power supply, the
exposed charging plug can be shorted by foreign material and may create a fire hazard.
Foreign materials of a conductive nature, such as but not limited to, steel wool, aluminum
foil, or any build up of metallic particles should be kept away from the charging plug.
Unplug charger before attempting to clean.
Trigger Switch & Reversing Button
The drill is turned ON and OFF by pulling and releasing the trigger switch shown in Figure 1. The
reversing button, also shown in Figure 1, switches the drill’s direction from forward to reverse.
Two Speed Operation
Your drill is equipped for two speed drilling. To operate at low speed, squeeze the trigger switch
halfway. This will produce a low speed to be used for driving screws and starting holes without a
centerpunch. Squeezing the trigger switch all the way will produce a high speed for normal
drilling operation.
NOTE: There is a slight pause between speeds. Keep squeezing the trigger, and the drill will start
again.
Screw Driving
For driving fasteners, the reversing button should be pushed to the left as shown in Figure 1.
Use reverse (button pushed to the right) for removing fasteners. When moving from forward to
reverse, or vice versa, always release the trigger switch first.
Keyless Chuck (9089KB, 9099KB)
To insert a drill bit or other accessory:
1. Grasp the rear half of the chuck with one hand and use your other hand to rotate the
front half in the counterclockwise direction, (Fig. 2).
2. Insert the bit or other accessory fully into the chuck, and tighten securely by holding the
rear half of the chuck and rotating the front portion in the clockwise direction as viewed
from the chuck end.
WARNING: Do not attempt to tighten drill bits (or any other accessory) by gripping the front
part of the chuck and turning the tool on. Damage to the chuck and personal injury may occur
when changing accessories.
Chuck & Key (9089, 9099)
Turn chuck key counterclockwise to open chuck jaws, place bit in chuck as far as it will go and
then pull it out far enough so that the chuck jaws do not touch the flutes of the bit. Tighten chuck
collar by hand. Place chuck key in each of the three holes, and tighten in clockwise direction
(Figure 3). It’s important to tighten the chuck with all three holes to prevent bit slippage. To release
bit, turn chuck key counterclockwise in just one hole, then continue to loosen chuck by hand.
CAT. NO. 9089, 9089KB, 9099, 9099KB FORM NO. 394176-00 PRINTED IN CHINA (DEC 99 -1)
KEY INFORMATION YOU SHOULD KNOW:
• Drill must be charged for 16 hours before use.
• Charger may hum; batteries or charger may become warm during charging.
VEA EL ESPAÑOL EN LA CONTRAPORTADA.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE
USAR EL PRODUCTO.
INSTRUCTION MANUAL
6
6
6
6
66
6
6
6
6
66 .
.
.
.
..
.
.
.
.
.. 0
0
0
0
00
0
0
0
0
00
a
a
a
a
aa
a
a
a
a
aa n
n
n
n
nn
n
n
n
n
nn d
d
d
d
dd
d
d
d
d
dd
7
7
7
7
77
7
7
7
7
77 .
.
.
.
..
.
.
.
.
.. 2
2
2
2
22
2
2
2
2
22
V
V
V
V
VV
V
V
V
V
VVo
o
o
o
oo
o
o
o
o
oo l
l
l
l
ll
l
l
l
l
ll t
t
t
t
tt
t
t
t
t
tt
C
C
C
C
CC
C
C
C
C
CC o
o
o
o
oo
o
o
o
o
oo r
r
r
r
rr
r
r
r
r
rr d
d
d
d
dd
d
d
d
d
ddl
l
l
l
ll
l
l
l
l
ll e
e
e
e
ee
e
e
e
e
ee s
s
s
s
ss
s
s
s
s
ss s
s
s
s
ss
s
s
s
s
ss
D
D
D
D
DD
D
D
D
D
DD r
r
r
r
rr
r
r
r
r
rr i
i
i
i
ii
i
i
i
i
ii l
l
l
l
ll
l
l
l
l
ll l
l
l
l
ll
l
l
l
l
ll s
s
s
s
ss
s
s
s
s
ss
9089, 9089KB, 9099, 9099KB
Depress for reverse (this side)
Enfoncer pour la marche arrière (de ce côté )
Oprima para reversa (desde el lado izquierdo)
Depress for forward (other side)
Enfoncer pour la marche avant (de l'autre côté )
Oprima para marcha hacia adelante (desde el lado derecho)
12
3
Produkt Specifikationer
| Mærke: | Black And Decker |
| Kategori: | Boremaskine |
| Model: | 9089 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Black And Decker 9089 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Boremaskine Black And Decker Manualer
28 Juni 2024
30 April 2024
27 April 2024
26 April 2024
18 April 2024
12 April 2024
9 April 2024
2 April 2024
30 Marts 2024
30 Marts 2024
Boremaskine Manualer
- Boremaskine Scheppach
- Boremaskine Ikea
- Boremaskine Bosch
- Boremaskine Ozito
- Boremaskine Guede
- Boremaskine Panasonic
- Boremaskine Metabo
- Boremaskine DeWalt
- Boremaskine RYOBI
- Boremaskine Silverline
- Boremaskine Skil
- Boremaskine AEG
- Boremaskine Carat
- Boremaskine Zipper
- Boremaskine Stihl
- Boremaskine Makita
- Boremaskine Worx
- Boremaskine Güde
- Boremaskine Vonroc
- Boremaskine Milwaukee
- Boremaskine Clas Ohlson
- Boremaskine Parkside
- Boremaskine Einhell
- Boremaskine Proxxon
- Boremaskine Stanley
- Boremaskine Hikoki
- Boremaskine Hilti
- Boremaskine Hitachi
- Boremaskine Alpha Tools
- Boremaskine Festool
- Boremaskine Dremel
- Boremaskine Fein
- Boremaskine Topcraft
- Boremaskine Powerfix
- Boremaskine Festo
- Boremaskine Craftsman
- Boremaskine Powerplus
- Boremaskine Malmbergs
- Boremaskine Westfalia
- Boremaskine Genesis
- Boremaskine Fieldmann
- Boremaskine Velleman
- Boremaskine Kawasaki
- Boremaskine Porter-Cable
- Boremaskine Baumr-AG
- Boremaskine Ridgid
- Boremaskine Sun Joe
- Boremaskine Cotech
- Boremaskine Hazet
- Boremaskine SKIL Masters
- Boremaskine Truper
- Boremaskine Meec Tools
- Boremaskine Brüder Mannesmann
- Boremaskine Steren
- Boremaskine Graphite
- Boremaskine Cocraft
- Boremaskine Maestro
- Boremaskine Wolfcraft
- Boremaskine Mac Tools
- Boremaskine Workzone
- Boremaskine Tryton
- Boremaskine Stalco
- Boremaskine Black Decker
- Boremaskine MSW
- Boremaskine Prowork
Nyeste Boremaskine Manualer
23 November 2024
23 November 2024
23 November 2024
23 November 2024
23 November 2024
23 November 2024
23 November 2024
23 November 2024
22 November 2024
22 November 2024
