Side 1/4

When using electrical appliances, basic safety precautions should always be followed, including

the following: PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE UNIT.

WARNING: This product contains chemicals, including lead, known to the State of California

to cause cancer, and birth defects or other reproductive harm. Wash hands after

handling.

WARNING: To reduce the risk of fire, electrical shock or injury:

■Close supervision is necessary when any appliance is used by or near children. Do not allow to

be used as a toy.

■To protect against risk of electrical shock, do not put unit or charging base in water or other liquid.

■Do not use Dustbuster®dry hand vacs to pick up liquids, toxic substances, flammable or

combustible liquids such as gasoline or use in areas where they may be present.

■Do not use wet/dry hand vacs to pick up toxic substances, flammable or combustible liquids such

as gasoline or use in areas where they may be present.

■Do not operate in the presence of explosives and/or flammable fumes or liquids.

■Do not operate any appliance with a damaged cord or charger or after the appliance

malfunctions, is left outdoors, dropped into water or is damaged in any manner. Return the

appliance to any authorized service facility.

■Do not use Dustbuster®dry hand vacs outdoors or on wet surfaces. Do not use the wet/dry hand

vacs outdoors.

■Do not abuse the cord. Never carry the charger or base by the cord or yank to disconnect from

an outlet; instead grasp the charger and pull to disconnect. Keep cord away from heated

surfaces. Do not pull cord around sharp edges or corners.

■Do not allow the cord to hang over the edge of a table or counter or touch hot surfaces. The unit

should be placed or mounted away from sinks and hot surfaces.

■Do not use an extension cord. Plug the charger directly into an electrical outlet.

■Use the charger only in a standard electrical outlet (120V/60Hz).

■Do not attempt to use the charger with any other product; do not attempt to charge this product

with any other charger. Use only the charger supplied by the manufacturer to recharge.

■Keep hair, loose clothing, and all parts of body away from openings and moving parts.

■Do not insert accessories when unit is running.

■Do not handle plug or appliance with wet hands.

■Do not put any object into unit openings. Do not use with any openings blocked; keep free of

dust, lint, hair, and anything that may reduce air flow.

■Do not operate the unit without a filter in place. Replace a damaged filter promptly.

■Do not vacuum burning or smoking materials, such as lit cigarette butts, matches or hot ashes.

■Do not use on or near hot surfaces.

■Use extra caution when cleaning on stairs.

■This appliance is intended for household use only and not for commercial or industrial use.

■Use only as described in this manual. Use only manufacturer’s recommended attachments.

■Unplug the charger from outlet before any routine cleaning or maintenance.

■This product includes rechargeable nickel cadmium batteries. Do not incinerate batteries as

they will explode at high temperatures.

■Leaks from battery cells can occur under extreme conditions. If the liquid, which is a 20-35%

solution of potassium hydroxide, gets on the skin (1) wash quickly with soap and water or (2)

neutralize with a mild acid such as lemon juice or vinegar. If the liquid gets into the eyes, flush

them immediately with clean water for a minimum of 10 minutes. Seek medical attention.

INSTALLATION INSTRUCTIONS (FIG. B)

Fix the charging base within reach of an electrical outlet, as illustrated, using the screws and plugs

supplied. Plug in and place the product in position. The charging base can also be fixed, or simply

placed, in a convenient horizontal position.

NOTE: Avoid damaging the cord while fixing the base to the wall or when removing or replacing the

product from the base.

RECHARGING (FIG. C)

From new, the rechargable cells of the product need a minimum charge time of 16 hours to ensure full

power. We suggest you fully discharge the product when it is used for the first time as this will help the

cells recharge faster. The switch must be in the off (“O”) position, the product will not charge if it is in

any other position. While charging, the product may get warm, this is perfectly normal and safe. It can

remain on charge indefinitely without damage or danger. It is not possible to “overcharge” the battery

cells with the charger provided.

OPERATION (FIG. D)

This product is for dry pick-up only.

To start, slide the On/Off switch forward (i.e. “O”= Off, “I” = On). To stop, slide the switch back.

9.6 volt units: To start, slide the power switch forward to on (1) position for longest run time. Slide

switch to second position (2) for extra power when cleaning larger messes and debris.

Always return the product to the charging base immediately after use so that it will be ready and fully

charged for the next use. Ensure that the product is fully engaged on the charging base.

CLEANING THE PRODUCT (FIGS . E-I)

WARNING:Never use the Dustbuster without its filters.

NOTE: The filters are re-usable, do not confuse them with disposable dust bags, and do not throw

them away when the product is emptied. We recommend that you replace the filters every 6-9 months.

FIG. E ■Remove the dust bowl by pressing the dust bowl release button and pulling the bowl

down and out. To replace the bowl, place it back onto the handle and click firmly into

position.

FIG. F ■Empty the dust from the bowl and wash if necessary (see Fig. H).

FIG. G ■To remove the filter twist it in a clockwise direction. Shake or lightly brush any loose

dust off the filter.

FIG. H ■Wash the filter regularly using warm, soapy water and ensure that it is completely dry

before using it again. The cleaner the filters are, the better the product will perform. It is

very important that the filter is correctly in position before use. The dust bowl can also be

washed in warm soapy water. Ensure that it is dry before re-attaching.

IMPORTANT: Maximum dust collection will only be obtained with clean filters and an empty dust

bowl. If dust begins to fall back out of the product after it is switched off, this indicates that the bowl

is full and requires emptying.

FIG. I ■Never immerse the product in water. A damp cloth and soapy water should be used to

clean the exterior of the motor section. Always ensure the product is completely dry

before re-use or storing.

ECONOMIC USAGE

■Your product is very economical to charge. While it is charging it uses less than half the amount of

electricity used by a light bulb.

■When fully charged, the average effective usage times are between 8-10 minutes.

Catalog Nos. V1200, V1210, V1220, V4800, V4810, V4820, V7200, V7210, V7220, V7260, V8460, V9600, V9610,

V9620, V9650, V9660, FVE1210, FVE9610

FORM NO. 571908-02 REV. 4 PRINTED IN CHINA FEB. ‘03

VEA EL ESPAÑOL EN LA CONTRAPORTADA.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.

ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.

INSTRUCTION MANUAL

IMPORTANT SAFEGUARDS

How To Use

1-800-54-HOW-TO

1-800-54-HOW-TO1-800-54-HOW-TO

BEFORE RETURNING THIS PRODUCT

BEFORE RETURNING THIS PRODUCT BEFORE RETURNING THIS PRODUCT

FOR ANY REASON PLEASE CALL

FOR ANY REASON PLEASE CALLFOR ANY REASON PLEASE CALL

IF YOU SHOULD EXPERIENCE A PROBLEM

WITH YOUR PURCHASE,BLACK & DECKER

CALL .1-800-54-HOW-TO (1-800-544-6986)

IN MOST CASES, A BLACK & DECKER REPRESENTATIVE

CAN RESOLVE YOUR PROBLEM OVER THE PHONE.

IF YOU HAVE A SUGGESTION OR COMMENT,

GIVE US A CALL. YOUR FEEDBACK IS VITAL

TO THE SUCCESS OF BLACK & DECKER'S QUALITY

IMPROVEMENT PROGRAM.

(544-6986)

AVANT DE RETOURNER LE PRODUIT, PEU IMPORTE

LA RAISON PRIÈRE DE COMPOSER 1 800 544-6986

ANTES DE DEVOLVER ESTE PRODUCTO POR CUALQUIER RAZON POR

FAVOR LLAME (Únicamente para propósitos de México) (55)5326-7100

Catalog Nos. V1200, V1210, V1220, V4800, V4810, V4820, V7200,

V7210, V7220, V7260, V8460, V9600, V9610, V9620, V9650, V9660,

FVE1210, FVE9610

SAVE THESE INSTRUCTIONS

Product Features (Fig. A)

1. On/Off slide switch (3 Position switch (9.6 volt units only))

2. Release button

3. Dust bowl

4. Wall mountable charging base

5. Charger

A B C

D E F

9.6V

4.8V

7.2V

12.0V

Produkt Specifikationer

Mærke:	Black And Decker
Kategori:	Støvsuger
Model:	Dustbuster V9620
