TO REDUCE RISK OF INJURY:
• Before any use, be sure everyone using this product reads and understands all safety instructions and
other information contained in this manual.
• Save these instructions and review frequently prior to use and in instructing others.
• DO NOT point tool exhaust at self, bystanders and animals.
WARNING: When using a vac, basic safety precautions should always be followed to reduce risk of
fire, electric shock, and personal injury, including the following.
WARNING: To reduce the risk of electrical shock; do not expose to rain.
WARNING: Some dust created by this product contains chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• compounds in fertilizers
• compounds in insecticides, herbicides and pesticides
• arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, wear approved safety equipment such as dust masks that are
specially designed to filter out microscopic particles.
WARNING: This product contains chemicals, including lead, known to the State of California to cause
cancer, and birth defects or other reproductive harm. Wash hands after handling.
CAUTION: Wear appropriate personal hearing protection during use. Under some conditions and
duration of use, noise from this product may contribute to hearing loss.
When using a vac, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING YOUR WET/DRY VAC.
In the following text, the words Danger, Warning, and Caution are used to emphasize important safety information.
The word: DANGER means that severe injury or death will result from failure to follow instructions.
WARNING means that severe injury or death can result from failure to follow instructions.
CAUTION means that property damage or injury can result from failure to follow instructions.
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY:
1. DO NOT use to pick up flammable or combustible liquids such as gasoline, or use in areas where they are present.
2. DO NOT use in areas where explosive vapors may be present.
3. DO NOT use to pick up explosive dust, or in areas where air contains explosive dust such as coal, grain, or
other combustible materials.
4. DO NOT use to pick up hazardous waste such as asbestos or fertilizers.
5. DO NOT pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
6. KEEP HAIR, loose clothing, fingers and all parts of the body away from openings and moving parts.
7. DO NOT leave the machine unattended when plugged in. Unplug when not in use and before servicing.
8. TO AVOID electric shock, do not expose to rain. Store indoors.
9. DO NOT allow to be used as a toy. Close attention is necessary when used near children.
10.
USE ONLY as described in this manual. Use only manufacturer’s
recommended attachments.
11. DO NOT use with damaged cord or plug. If machine is not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a Black & Decker Authorized dealer for service.
12. DO NOT pull or carry by cord, use cord as a handle, close a door on cord or pull cord around sharp edges or
corners. DO NOT
run machine over cord. Keep cord away from hot surfaces.
13. DO NOT unplug by pulling on cord. To unplug, grasp the plug, not the cord.
14. DO NOT touch plug or machine with wet hands.
15. DO NOT put any object into openings. Do not use with any opening blocked. Keep openings free of dust, lint,
hair or anything that might reduce air flow.
16. DO NOT sit or stand on the machine.
17. TURN OFF power switch before unplugging machine.
18. USE EXTRA care when cleaning on stairs.
19. CONNECT TO a properly grounded outlet only. See grounding instructions.
20. DO NOT use without proper filters in place.
21. STORE IDLE vac. When not in use, the vac should be stored in a dry, high or locked up place - - out of reach of
children.
22. DO NOT attempt to repair the vac. To assure product safety and reliability, repairs, maintenance, and
adjustments should be performed by Authorized Black & Decker Service Centers.
23. DO NOT pick up wood or coal ash, soot, cement, plaster or drywall dust without filter bag in place.
24. TO AVOID spontaneous combustion, empty tank after each use.
25. THE BLOWER operation of a utility vac can result in foreign objects being blown into eyes, which can result in
eye damage. Always wear safety goggles when using blower feature.
26. DO NOT place outlet of vacuum near eyes or ears when operating.
27.
FOR household use only. SAVE THESE INSTRUCTIONS.
EITHER
O
OU
Fig. 1 A B
KEY INFORMATION YOU SHOULD KNOW:
• To protect the motor and other moving parts— feature will Automatic Suction Shut-off
activate when the tank becomes filled. When this happens:
- unplug machine
- remove power head
- empty tank
-
replace power head and resume operation
•
Power Head is made to fit in one direction only. Ensure exhaust port is facing opposite suction hose
and that the Power Head is pushed securely down and latched. Attempting to force Power Head in
wrong direction can cause damage.
• This vac is equipped with a blower feature. Remove hose (complete with inlet tube) from tank.
Insert accessory end of hose into exhaust port. (This is helpful if hose should become clogged.)
SAVE THIS MANUAL FOR FUTURE REFERENCE.
INSTRUCTION MANUAL
Catalog Number UV200
Form No. 244109-00 REV. 2 Cat. #UV200 (NOV. ‘02)
Copyright © 2002 Black & Decker Printed in Mexico
W
W
W
W
W
W
W
W
W
We
e
e
e
e
e
e
e
e
et
t
t
t
t
t
t
t
t
t
&
&
&
&
&
&
&
&
&
&
D
D
D
D
D
D
D
D
D
Dr
r
r
r
r
r
r
r
r
ry
y
y
y
y
y
y
y
y
y
U
U
U
U
U
U
U
U
U
Ut
t
t
t
t
t
t
t
t
ti
i
i
i
i
i
i
i
i
il
l
l
l
l
l
l
l
l
li
i
i
i
i
i
i
i
i
it
t
t
t
t
t
t
t
t
ty
y
y
y
y
y
y
y
y
y
V
V
V
V
V
V
V
V
V
Va
a
a
a
a
a
a
a
a
ac
c
c
c
c
c
c
c
c
cu
u
u
u
u
u
u
u
u
uu
u
u
u
u
u
u
u
u
um
m
m
m
m
m
m
m
m
m
Date Code
IMPORTANT:
MUST INSTALL PAPER BAG FILTER
BEFORE DRY PICK-UP.
IMPORTANTE:
INSTALAR EL FILTRO DE BOLSA DE PAPEL
ANTES DE ASPIRAR MATERIALES SECOS.
IMPORTANT :
IL FAUT INSTALLER LE FILTRE EN PAPIER
AVANT DE RAMASSER DES DÉCHETS SECS.
WARNING: IMPORTANT SAFETY WARNINGS AND INSTRUCTIONS
GROUNDING INSTRUCTIONS
This machine must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce risk of electric shock. This machine is equipped with a cord having an
equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
DANGER
Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a
qualified electrician or service person if you are in doubt as to whether
the outlet is properly grounded. Do not
modify the plug provided
with the appliance - if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
GROUNDED
OUTLET
ADAPTER
METAL
SCREW
GROUND DEVICE
GROUNDING
PIN
OR
THE USE OF A TEMPORARY ADAPTER IS NOT PERMITTED BY THE CANADIAN ELECTRICAL CODE.
This machine is for use on a nominal 120 volt AC circuit, and has a grounding plug that looks like the plug
illustrated in (Fig. 1A). A temporary adapter that looks like the adapter illustrated in (Fig. 1B) may be used
to connect this plug to a 2-pole receptacle as shown in (Fig. 1B) if a properly grounded outlet is not
available. The temporary adapter should be used only until a properly grounded outlet (Fig. 1A) can be
installed by a qualified electrician. The green colored rigid ear, lug, or the like extending from the adapter
must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the
adapter is used, it must be held in place by a metal screw.
NOTICE:
GENERAL SAFETY WARNINGS AND INSTRUCTIONS FOR ALL TOOLS
EXHAUST PORT
ORIFICE D'ÉVACUATION
PUERTO DE ESCAPE
HOSE ASSEMBLY
BOYAU
SUBENSAMBLE DE TUBO
EXTENSION WAND
RALLONGE
TUBO PARA EXTENSIÓN
INLET TUBE
TUBE D'ADMISSION
TUBO DE ENTRADA
1-800-54-HOW-TO
1-800-54-HOW-TO
1-800-54-HOW-TO
1-800-54-HOW-TO1-800-54-HOW-TO
BEFORE RETURNING THIS PRODUCT
BEFORE RETURNING THIS PRODUCT
BEFORE RETURNING THIS PRODUCT
BEFORE RETURNING THIS PRODUCT BEFORE RETURNING THIS PRODUCT
FOR ANY REASON PLEASE CALL
FOR ANY REASON PLEASE CALL
FOR ANY REASON PLEASE CALL
FOR ANY REASON PLEASE CALLFOR ANY REASON PLEASE CALL
IF YOU SHOULD EXPERIENCE A PROBLEM
WITH YOUR BLACK & DECKER PRODUCT,
CALL .1-800-54-HOW-TO (544-6986)
BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION
AVAILABLE, CATALOG NO., TYPE NO., AND DATE CODE.
IN MOST CASES, A BLACK & DECKER REPRESENTATIVE CAN RESOLVE
YOUR PROBLEM OVER THE PHONE. IF YOU HAVE A SUGGESTION OR
COMMENT, GIVE US A CALL. YOUR FEEDBACK IS VITAL TO THE
SUCCESS OF BLACK & DECKER'S QUALITY IMPROVEMENT PROGRAM.
(544-6986)
ADVERTENCIA: Desconecte la almentación eléctrica de la aspiradora antes de abrirla.
PRECAUCIÓN: Nunca haga funcionar una aspiradora para uso en mojado/seco si no tiene un filtro instalado.
AVERTISSEMENT :
Débrancher l’aspirateur avant de l’ouvrir.
MISE EN GARDE : Ne jamais utiliser un aspirateur pour déchets secs ou humides sans un filtre en place.
WARNING: Disconnect power from vac before opening.
CAUTION: Never operate any wet/dry vac without a filter in place.
Your new Wet/Dry Vac is a high performance machine. Make sure that you use the correct filter for the job.
Keep your filters clean.
• WET PICKUP — Use the foam filter sleeve.
• DRY PICKUP — Use the foam filter and paper filter bag combination, replace as required when clogged.
If you do not use the proper filter, you may damage your new machine and you will void the warranty.
MAINTENANCE
NOTE: There are no user serviceable parts other than the filters. Do not oil the motor.
1. Disconnect Power from Vac before opening.
2. Remove the Power Head from the Tank. Empty, rinse, and dry tank, hose and accessories after wet pick-up.
After pick-up of wet and sticky spills, it is advisable to clean the Tank and Accessories with warm soapy water.
3. Clean Filters improve performance.
• Periodically replace the Disposable Filter Bag.
• Wash dirt from Foam Filter with warm soapy water.
• Be sure all filters that have become wet are allowed to dry before using for dry pick up.
TO CLEAN FOAM FILTER:
1. Remove filter by sliding it up and off the lid cage.
2. Shake excess dust off filter with a rapid up and down movement.
3. Hold filter under running water for a minute or two, rinsing from the inside. A water wash is not always
required, depending on the condition of the sleeve.
4. Gently wring out excess water, blot sleeve with a clean towel, and allow to dry.
POWER HEAD
TÊTE D’ALIMENTATION
CAJA DE CONTROL
ACCESSORY END OF HOSE
EXTRÉMITÉ POUR ACCESSOIRE
PUNTA PARA ACCESORIOS
BLOWER FEATURE
Remove vacuum hose by pushing down in direction shown in
“A”. The vacuum can be used as a powerful blower by inserting
the hose into the top exhaust port as shown in “B”. This feature
is especially useful for blowing out debris from behind small
spaces, helping dry a damp floor, blowing grass clippings or
leaves from an outside walk, patio, etc.
AB
EXTENSION CORDS
If the unit is to be used with an extension cord, the cord must be UL Listed/Certified, No. 16AWG,
SJTW-A/SJT 3 Conductor, marked on flag label “Suitable for Outdoor Applications, Store Indoors.” Not to
exceed 50 feet.
OPERATION / FONCTIONNEMENT / OPERACION
FILTER REPLACEMENT / REMPLACEMENT DU FILTRE / FILTRO REEMPLAZAR
PAPER BAG FILTER
FILTRE EN PAPIER
FILTRO DE BOLSA DE
PAPEL
FOAM FILTER
FILTRE EN MOUSSE
FILTRO DE ESPONJA

Produkt Specifikationer

Mærke: Black And Decker
Kategori: Støvsuger
Model: UV200

Har du brug for hjælp?

Hvis du har brug for hjælp til Black And Decker UV200 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Støvsuger Black And Decker Manualer

Black And Decker

Black And Decker VCBD8530 Manual

13 Oktober 2024
Black And Decker

Black And Decker BLB1401 Manual

4 Oktober 2024
Black And Decker

Black And Decker Dustbuster VP302 Manual

4 Oktober 2024
Black And Decker

Black And Decker HSVJ415JMBF71 Manual

3 Oktober 2024
Black And Decker

Black And Decker PV1205B Manual

30 September 2024
Black And Decker

Black And Decker ScumBuster S100 Manual

24 September 2024
Black And Decker

Black And Decker HHS315J22 Manual

14 September 2024
Black And Decker

Black And Decker CHV1210 Manual

11 September 2024
Black And Decker

Black And Decker HNV220B Manual

8 September 2024
Black And Decker

Black And Decker PKS160 Manual

2 September 2024

Støvsuger Manualer

Nyeste Støvsuger Manualer

Livoo

Livoo DOH142 Manual

3 December 2024
Sencor

Sencor SVW 5010WH Manual

3 December 2024
DeWalt

DeWalt DXV09P Manual

3 December 2024
Bosch

Bosch BGC05A220A Manual

29 November 2024
Einhell

Einhell RT-VC 1500 Manual

24 November 2024
Einhell

Einhell RT-VC 1600 E Manual

24 November 2024
Einhell

Einhell RT-VC 1630 SA Manual

24 November 2024
Einhell

Einhell RT-VC 1525 SA Manual

24 November 2024
Einhell

Einhell BT-VC 1250 Manual

24 November 2024
Einhell

Einhell BT-VC 1250 SA Manual

24 November 2024
