Side 1/10

Programme selector for switching the

machine on and off and for selecting the

programme. Can be rotated in either

direction.

Detailed programme overview. Page 7/8a

Detergent drawer with

compartments I, II, ~

Sort and load the laundry (drying)

Only dry laundry that is labelled with the following care symbols:

( = tumble-dry at normal heat setting ( ) .Normaltrocknen

'c= tumble-dry at low heat setting ( ).Schontrocknen

The following textiles should not be tumble-dried:

) = do not tumble-dry care symbol.

 Woollens or items containing wool. Risk of shrinking!

 Delicate fabric (silk, synthetic net curtain). Risk of creasing!

 Items containing foam rubber or similar material.

 Items which have been treated with flammable solvents, such as stain

removers, petrol, paint thinners. Explosion hazard!

 Items still containing hair lacquer or similar substances.

Dangerous vapours!

Do not exceed the maximum drying load. aPage 7

Display panel/

Option buttons/

Additional functions

Sort and load the laundry

 Observe the care information provided by the manufacturer.

 Sort according to the information on the care labels.

 Sort according to type, colour, soiling and temperature.

 Remove any foreign objects  risk of rusting.

 Do not exceed the maximum load. aPage 7

 If drying programme selected. aPage 4: Sort and load the laundry (drying)

 Observe the instructions in the Important information section. aPage 6

 Load both large and small items of washing.

 Close the washer dryer door. Take care not to trap any items of clothing between

the loading door and rubber seal.

Add detergent and care product

 Add the appropriate dose according to: Amount of washing, soiling, water hardness

(ask your water supply company) and manufacturers instructions.

 Models without insert for liquid detergent: pour liquid detergent into an appropriate

dispenser and place in the drum.

 Use commercially available low foam detergents for washer dryer only.

 During operation: close the detergent drawer!

Correct installation according to separate Installation

and maintenance instructions.

Check the machine

 Never switch on a damaged machine!

 Inform your customer service!

Insert mains plug

With dry hands only!

Take hold of the plug only!

Turn on the tap

 At the end of the drying programme there is an

automatic cleaning fluff process, turn on the water

tap even if a drying programme is selected.

Provide good ventilation

Good ventilation is required to extract air produced

during drying.

 Keep the installation room well ventilated.

 Clean the air inlet filter regularly.

 Do not block the air inlet and/or air outlet.

Compartment II: Detergent for the main wash, water softener,

bleach, stain remover

Your washer dryer Preparation

Before using for the first time Page 6a

The washer dryer was tested before leaving the factory.

To remove any water left over from testing procedures, the â

first cycle should be carried out without any laundry with

Flusen spülen (Fluff Clean) programme. aPage 6: Before

using for the first time

Set and adjust the programme

 Turn the programme selector to desired washing

programme. aPage 7: Programme overview

Use option buttons and additional functions. aPage 9/10

All buttons are sensitive and a gentle touch is adequate!

If you press and hold the °C (Temp.), (Finish in) or c(Spin) option buttons,

the setting options automatically scroll through.

If washing and drying without interruption is desired (only possible for Koch/Bunt

(Cottons), (Cottons Eco), , (Easy-Care) and ):Bunt Eco Mix Pflegeleicht PowerWash 60

 Activate auto drying function by touching button.{( )Dry aPage 10.

 Do not exceed the maximum load for the drying function. aPage 7

 Select maximun selectable spin speed of washing programme to ensure the drying

result.

Select Start/Reload

... Washing/Washing + Drying

Compartment ~: Fabric softener

Compartment I: Detergent for pre-wash

Intended use

ʋFor domestic use only.

ʋFor the washing of machine-washable fabrics in a detergent

solution.

ʋTo be operated with cold mains water and commercially available

low foam detergents and care products which are suitable for use

in front loaded washer dryer.

 Do not leave children unattended near the washer dryer.

 Keep pets away from the washer dryer!

 The washer dryer is not to be used by children or persons

not familiar with the operating instructions.

 Install and operate the washer dryer in a room with a drain.

 In order to ensure your safety, you must plug the cable into

a socket which has a reliable earth connection.

Removing laundry

Open washer dryer door and remove laundry.

Leave the washer dryer door and detergent drawer open so that any residual

water can evaporate!

Turn off the tap

Not required for Aqua-Stop models. Installation maintenance instructions, a

Page 9

Switch off

 Set programme selector to (Off).ÂAus

... Drying

Drying

Washing

Washing + Drying without interruption

Set and adjust the drying programme

 Turn the programme selector to (Intensive Dry) or Normaltrocknen

Schontrocknen (Gentle Dry). a Page 7: Programme overview

Select Start/Reload

Programme selector

Programme ended when ...

... Start/Reload indicator light goes out and or (if was selected, 

no final spin/drain) appears on the display field, the buzzer sounds. Set volume

of buzzer. âaPage 10

If was selected, and is displayed, touch the /Nachlegen button.Start 

 The programme continues with draining the water and spinning the laundry

(the default spin speed can be changed in advance).

 If you only want to drain the water, touch the / button again Start Nachlegen

when the spinning starts. The programme is paused and the door lock is

released. You can remove the laundry.

If appears and drying symbol flashes on the display field c7 a high drum

temperature. Cool-down programme is running until drum is cooled down.

If and   appears alternately.aPage 11: Information on the display

Change the programme ...

If you have selected the wrong programme by mistake:

 Reselect the washing/drying programme.

 If required, adjust the programme setting and/or select additional functions.

aPage 9/10

 Select Start/Nachlegen.

Pause the programme ...

 Touch the / button. Start Nachlegen

 Follow the instructions in the display field: when lights up and 

appears in the display, the door can be opened. If required, add/remove

a laundry item; If and are displayed alternately, the door cannot â

be opened due to a high water level in drum or a high temperature.

 Touch Start/Nachlegen button to continue the programme.

 The pause function cannot be activated during drying phase.

... or terminate the programme

Washing programmes with high temperature:

 Cool down laundry: Select (Rinse), touch /Nachlegen.Spülen Start

Washing programmes at lower temperature:

 Select (Spin), touch Schleudern Start/Nachlegen.

Drying programme:

 Select Normaltrocknen Schontrocknen (Intensive Dry) or (Gentle Dry) ,

touch option button, set 15 minutes drying time, then touch /{c(Dry) âStart

Nachlegen button.



Important information





Washing drying preparing/Protecting the laundry and the machine

 Empty pockets.

 Look out for metal items (paperclips, etc.).

 Trousers, knitwear and knitted textiles, e.g. Jersey garments, T-shirts or sweatshirts should

be turned inside out.

 Ensure that underwired bras are machine washable.

 Wash delicates in a net/bag (tights, curtains, underwired bras).

 Fasten zips, do up any buttons.

 Brush sand out of pockets and collars.

 Remove curtain hooks or place curtains in a net/bag.

 Use only tumble-dry textiles if you select drying.

 Before tumble-drying, handwash items should be spun using the appropriate spin speed.

 Remove as much water as possible before tumble-drying. Recommended spin speed for

cottons is more than 1000 rpm; for easy-care is more than 800 rpm.

 In order to ensure uniform drying, sort the items according to fabric type and degree

of drying required.â

 Items which require ironing do not have to be ironed immediately after being tumble-dried.

It is a good idea to fold or roll them together for a while, so that any remaining moisture

is evenly distributed.â

 To achieve good drying performance, dry quilt covers, terry towels or other large textile

items individually. Terry towels not more than 4 pieces (or 3 kg).

Before using for the first time

Do not put any laundry in the washer dryer. Turn on the tap, pour ½ measuring cup

of detergent into dispenser . Set the (Fluff Clean) programme II Flusen spülen 40 °C

and select Start /Nachlegen.

At the end of the programme, set the programme selector to (Off).ÂAus

Laundry with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select Bunt Eco (Cottons Eco)

programme or additional function.â(intensive)

Heavy Load less laundry. Prewash.

If required, pretreat stains. Select Bunt Eco (Cottons Eco)

programme or additional function.( ) intensive

Soaking Load laundry of the same colour

Pour soaking agent/detergent into dispenser according to the manufacturer's instructions. II

Set (Cottons) Koch/Bunt 30 °C Start programme and select /Nachlegen.

After approx. 10 minutes, select Start /Nachlegen. After the required soaking time, reselect

Start /Nachlegen if the programme is to be continued or change the programme.

Starching Laundry must not be treated with fabric softener

Starching is possible in all wash programmes using liquid starch. Pour the starch into the

fabric softener compartment according to the manufacturer's instructions (if necessary clean

it first).

Dyeing/bleaching

Dye should only be used in normal household quantities. Salt may damage stainless steel.

Always follow the dye manufacturer's instructions. bleach laundry in the washing Do not

machine.

Start/

Reload

Door handle

Service flap

Drum

Air inlet

Air outlet (rear side)

Protection of the environment/

Conservation tips

 Load the maximum amount of laundry to wash or dry for the

particular programme. aPage 7: Programme overview

 Wash normally soiled laundry without prewash.

 Select (Cottons Eco) and additional Bunt Eco 60°C

â(Intensive) function to obtain good cleaning results with

significantly lower energy consumption.

 Dose the detergent according to the manufacturers

instructions and water hardness.

 If the laundry is then to be dried in the appliance, select the

highest selectable spin speed  because the more water that

is spun out of the appliance, the less time and energy is

ârequired to dry it.

 Keep the installation room well ventilated, clean the air inlet

filter regularly.

Installation and maintenance instructions. aPage 9

 Please do not dry dripping-wet laundry.

Waste of time and energy!

Congratulations  You have opted for a modern, high-quality

domestic appliance manufactured by BOSCH. The washer dryer

is distinguished by its economical use of water and energy. â

Each appliance which leaves our factory is inspected thoroughly

to ensure that it functions properly and is in perfect condition.â

For further information about products, accessories, spare parts and

services visit our web site: www.bosch-home.com or contact our after-

sales service centres.

The default drying mode is , in this mode the drying time is â

automatically adjusted to the load amount to obtain cupboard dried

laundry ready to fold and stack in the cupboard. You can change

the drying mode to in order to obtain extra dry laundry, or

time dry and define the drying time by touching the { (Dry) button,

to estimate or select drying duration. aPage 8: Drying table

All buttons are sensitive and a gentle touch is adequate!

If you press and hold the option buttons, Finish in 

the setting options automatically scroll through. â

Control panel

Contents

 

ʋIntended use........................................................................................ 1

ʋPreparation ...................................................................................... 1/2

ʋPreparation Washing or Washing + Drying ...........................2/3/4

ʋPreparation Drying .....................................................................2/3/4

ʋSet and adjust the programme ................................................3/4/5

ʋAfter washing/drying.......................................................................... 5

ʋImportant information.........................................................................6

ʋProgramme overview ......................................................................... 7

ʋDrying table ......................................................................................... 8

ʋConsumption values .......................................................................... 8

ʋDisplay and Option buttons .............................................................. 9

ʋAdditional functions and Individual settings ................................10

ʋInformation on the display ..............................................................11

ʋSafety instructions ............................................................................11

ʋWhat to do if ............................................................................... 12/13

ʋEmergency release ..........................................................................13

1 2 3 4 5 6

Programme overview (see also the information on page 9,10)



Programmes C°max. load

(kg)* Type of laundry  Additional functions; information

Koch/Bunt :  90 7.0/4.0** Hard-wearing textiles, heat-resistant textiles made of cotton or linen 7 =Prewash,Water plus,S Less Iron, Intensive

Bunt Eco :  60 Hard-wearing textiles made of cotton or linen

Sensitive :  60 7.0 Hard-wearing fabrics made of cotton or linen

7 =Prewash,Water plus,S Less Iron, Intensive

for particularly sensitive skin, longer washing at the selected

temperature, higher water level, extra rinse

PowerWash 60 :  60 4.0/4.0** Hard-wearing textiles made of cotton or blended fabric Time-controlled programme, 60 minutes.

Short programme for normally soiled laundry.

Pflegeleicht :  60

3.5/ 2.5**

Easy-Care textiles made of cotton, linen, synthetic fibres or blended

fabrics 7 =Prewash,Water plus Less Iron, S

Mix :  60 Textiles made of cotton and easy-care textiles 7 =Prewash,Water plus,S Less Iron, Intensive

different types of textiles which can be washed together

Fein/Seide

:  40 2.0

For delicate, washable textiles, e.g.made of silk, satin, synthetic

fibres or blended fabrics

7 =Prewash,Water plus Less Iron, S

gentle spin between the rinse cycles only

:üWolle Hand or machine washable wool or rich-wool textiles

particularly gentle wash programme to prevent

shrinkage of laundry, longer breaks during the

programme (fabrics rest in the detergent solution)

Extra Kurz 15 Easy-Care textiles made of cotton, linen, synthetic fibres or blended

fabrics

short programme, approx. 15 minutes, suitable for lightly

soiled laundry

Flusen spülen : , 40, 90 0 Drum clean programme. 90°= antibacterial programme, pour no detergent; 40°= antibacterial programme for use with special

washing machine cleaning detergent; = fluff rinsing programme to remove fluff accumulated in the tub during tumble drying.:

Spülen

7.0

= Water plus ,SLess Iron

Schleudern Washable textiles SLess Iron

Abpumpen

Normaltrocknen 4.0 Cotton/coloureds textiles, dry at normal heat setting

Schontrocknen 2.5 Easy care textiles, dry at low heat setting

 The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. .(Intensive)

* Max. load according to EN50229. Values in red: Max load for drying; Values in black: Max load for washing.

** If washing and drying without interruption is desired. The subsequent auto dry programme for , and is Intensive Dry, Koch/Bunt Bunt Eco PowerWash 60

for and is Gentle Dry.Pflegeleicht Mix

For further information and a selection of our products

go to our web site: www.bosch-home.com

or contact our customer service centres

Robert Bosch Hausgeräte GmbH

Carl -Wery-Str.34

D-81739 Munich/Germany

WVH28440 9000536281

0710

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Vaskemaskine
Model:	Avantixx 7 WVH28440
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	590 mm
Højde:	842 mm
Vægt:	85000 g
Produktfarve:	Hvid
Kontroltype:	Buttons,Rotary
Skærmtype:	LED
Strøm:	10 A
Ledningslængde:	0.21 m
Pakkevægt:	89000 g
Energieffektivitetsklasse (gammel):	B
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Tilsluttet belastning:	2200 W
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	5
Støjniveau (centrifugering):	73 dB
Støjniveau (vask):	54 dB
Forsinket start-timer:	Ja
Børnesikring:	Ja
Energiforbrug ved vask:	1.19 kWh
Årligt energiforbrug vask:	238 kWh
Tromlemateriale:	Rustfrit stål
Tromle volumen:	56 L
Certificering:	CE, VDE
Balance system:	Ja
Skum kontrol system:	Ja
Vaskeklasse:	A
Årligt vandforbrug vask:	10200 L
Forsinket start (maks.):	1 t
AquaStop funktion:	Ja
Indikator for resterende tid:	Ja
Justerbar centrifugeringshastighed:	Ja
Tørreevne:	4 kg
Vaske kapacitet:	7 kg
Støjniveau (tørring):	62 dB
Årligt energiforbrug ved vask og tørring:	1134 kWh
Årligt vandforbrug ved vask og tørring:	11400 L
Vandforbrug pr. vask:	51 L
Energiforbrug pr. vask og tørring:	5.67 kWh
Vandforbrug pr. vask og tørring:	57 L
Anti-krølle funktion:	Ja
Minimum centrifugeringshastighed:	1400 rpm
