Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5

ʋButton signals . . . . . . . . . . . . . . . . . . . . . 5

ʋImportant Information . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection / Transport. . . . . . . . . . . 8

ʋCleaning and care . . . . . . . . . . . . . . . . . . 9

ʋTechnical data . . . . . . . . . . . . . . . . . . . 10

ʋOptional accessories . . . . . . . . . . . . . . . 10

ʋNormal noises . . . . . . . . . . . . . . . . . . . . 11

ʋWhat to do if... / After-sales service . . . . 12

ʋSafety instructions . . . . . . . . . . . . . . . . 13

... and adapt to individual requirements

Never operate the dryer if it is damaged.

Inform your after-sales service. Inspecting the

dryer

Sorting and loading laundry

Remove all objects from pockets.

Pay particular attention to cigarette lighters.

The drum must be empty before filling.

See programme overview on page 7.

See also separate instructions for “basket for woollens”

(depending on the model)

Your new dryer Intended use Preparing for installation, see Page 8

Selecting and adjusting the programme

Select the drying programme ...

Press the Start/Stop button

Only if your hands are dry.

Only hold the plug by the plug

casing.

Connecting the

mains plug

All buttons are sensitive and only need to

be touched lightly.

ʋonly for domestic use.

ʋonly to be used for drying fabrics that have been

washed with water.

Do not leave children

unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

Drying

Condensate container with filter

Control panel

Air inlet

Two-part

fluff filter

Drum

Only use the dryer with the fluff filter

inserted!

Congratulations! - You have chosen a modern, high-quality domestic

appliance from Bosch.

The condensation dryer with heat pump and automatic cleaning of the

heat exchanger is outstanding in terms of efficient energy

consumption and low maintenance requirements .apage 6

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased

to help.

Environmentally responsible disposal

Dispose of packaging in an environmentally-responsible manner.

This appliance is designated according to European directive

2002/96/EC which governs waste electrical and electronic

equipment (WEEE).

The directive provides an EU-wide framework for the return and

recycling of used appliances.

For further information about our products, accessories, spare parts

and services, please visit: www.bosch-home.com

Do not pull out/empty

the condensate container when drying is in progress

Drum interior

light

The programme has ended when lights up in the display panel.\

Interrupt programme removing or adding laundry.

The drying cycle can be interrupted for a brief period so that laundry may be added or removed.

The selected programme must then be continued until it is finished.

Never switch the dryer off before the drying process has ended.

1. Open the door. The drying cycle is interrupted.

2. Remove or add laundry and close the door.

3. If required, select a new programme and additional functions.

4. Press the /Stop button. The remaining time is updated after a few minutesStart

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

(cDrying at normal temperature. 'cDrying at low temperature also select aLow Heat

)cDo not machine dry.

Always observe the safety instructions on page 13!

Do not tumble-dry the following fabrics for example:

– Airtight fabrics (e.g. rubber-coated fabrics).

– Delicate materials (silk, curtains made from synthetic material) they may crease.a

– Oil-stained laundry.

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with

large items of laundry (e.g. hand towels).

– Close zips, hooks and eyes, and do up any buttons.

Tie belts, apron strings etc. together.

– Do not overdry easy-care laundry risk of creasinga

Allow laundry to finish drying in the air.

– Do not dry woollens in the dryer. They may, however, be refreshed apage 7

Wool Finish programme .(depending on the model)

– Do not iron laundry immediately after drying, fold items up and leave for a while the a

remaining moisture will then be distributed evenly.

– The drying result depends on the type of water used during washing. aFine adjustment of

the drying result Page 1/2a.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not select the programme.Very Dry

– Starched laundry is not always suitable for dryers starch leaves behind a coating that a

adversely affects the drying operation.

– When washing laundry that is to be tumble-dried afterwards, use the correct amount of fabric

softener according to the manufacturer's instructions.

– Use the Zeitprogramm (Timed programme) for small loads a this improves the drying result.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine the higher the spin a

speed, the shorter the drying time will be, thus consuming less energy. Also spin easy-care

laundry.

– Use the maximum recommended capacity, but do not exceed it

a a “Programme overview” Page 7.

– Ensure the room is well ventilated during drying.

– Do not cover or seal the air inlet.

Button signals

Setting the volume for button signals

Selectable values: 0 (off), 1 (quiet), 2 (normal), 3 (loud).

1 x to the

right

Press and hold ÷Low heat

and turn 2 x to the right

Press /Stop until the re-Start

quired volume is reached

Turn to

Off

Turn to

Off

Emptying condensation

Empty the container drying cycle, not during drying!after each

1. Remove the condensate container and hold it level.

2. Pour out the condensation.

3. Always push the container fully back in until it locks in place.

If the indicator lamp is flashing ācContainer a page 9.

Cleaning the fluff filter

The fluff filter consists of two parts. Clean the inner

and outer filter drying cycle: after every

1. Open the door. Remove fluff from the door/door area.

2. Pull out both parts of the fluff filter.

3. Remove fluff from the edge of the shaft. Fluff should not fall

into the open shaft.

4. Open the filter and remove all the fluff.

5. Rinse both parts under running water and dry thoroughly.

6. Close the inner and outer filter, put them back together

and reinsert them into the appliance.

Switching off the dryer

Turn the programme selector to .Off

Do not leave laundry in the dryer.

Removing the laundry

Your dryer is equipped with an automatic anti-crease function. The drum is moved at specific time intervals

for 30 minutes once the programme has ended. The laundry stays loose and fluffy (60 or 120 minutes if

the additional function is selected).ccReduced Ironing

ˎMenu For selecting the settings.

ˎ-/+ (Change) To change all settings in the display panel.

 Electronic start

timer

End of the programme following... (depending on the programme selected,

e.g. duration 1:54h 2h; the nearest whole hour is always selected).a

1 -24 hrs

3Signal 0, 1, 2, 3, 4Signal volume selectable in four stages: 0 (off), 1 (quiet), 2 (normal), 3 (loud), 4 (very loud).

# Appliance lock Protection against accidental adjustment of functions that have been set (hold menu button down for

5 seconds).

On-Off

9Fine adjustment

of the drying result

The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for the

LCottons Easy-Care Mixed Load Super Quick 40’, , 1and  programmes presetting = 0. a

After one of these programmes has been finely adjusted, the setting is retained for the others.

0, 1, 2, 3

 Spin speed Speed at which the washing machine was spun;

only used if the anticipated drying time needs to be displayed more accurately.

600-1800

Additional

functions Display panel Programme selector

Reduces creasing and extends the anti-creasing phase once the

program has ended; two settings available.

ˎcc Reduced

Ironing

Reduced temperature for delicate fabrics ' that require a longer drying

time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎ÷Low Heat

Programme sequence displays:

drying, iron dry, cupboard dry, slackening/ready.

Status indicators

Ic+c\

Rinse the fluff filter under running water .aPage 4

Empty the condensate container.

If necessary, clean the filter in the condensate container .aPage 9

Service displays

4cFluff filter

ācContainer

Read these instructions and the separate Energy-saving

mode instructions before operating the dryer.

Observe the safety instructions on page 13.

Important Information

Your dryer is designed to be particularly energy-saving and its technical features include

a refrigeration circuit that uses energy efficiently, in a similar way to a refrigerator.

The dryer's heat exchanger is cleaned automatically during drying.

The fluff filters and filter in the condensate must be cleaned regularly.container

Never operate the dryer without the fluff filters and without filter in condensate container.

ʑFluff filter

During drying, fluff and hairs from the laundry are trapped in the fluff filter. A blocked fluff filter

may impair the heat exchange process.

The fluff filter should therefore be cleaned after every drying cycle.

Rinse the filter regularly under running water .aPage 4

ʑFilter in the condensate container

The filter in the condensate container cleans the condensation. This condensation is required

for the automatic cleaning process. The filter must be cleaned regularly under running water.

Empty the condensate before cleaning the filter .container aPage 9

ʑFabrics

Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:

e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent. etc.

Empty all pockets.

Do not dry airtight fabrics.

Avoid drying fabrics that produce a lot of fluff.

Woollens should be refreshed only using the woollens programme.

Clean fluff filters reduce energy consumption.

Programme overview see also page 5

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying... c @c ciron laundry lightly iron laundrydo not iron laundry mangle laundry

PROGRAMMES TEXTILE TYPE AND INFORMATION

** CottonsLmax. 7 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.

** Easy-Caremax. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.

** MIxed Load1max. 3 kg Mixed items of laundry madeof cotton and synthetics (Mix).

Iron Dry c @c ÷ Fabrics suitable for ironing (iron fabrics in order to avoid creasing).

Cupboard Dry @Single-layer fabrics.

*Cupboard Dry Plus/

Very Dry @Fabrics made of thick, multilayered items of clothing.

*Very Dry @Fabrics made of very thick, multi-layered items of clothing which need to be dried longer.

 Shirts/Blouses max. 3 kg For cotton or linen fabrics that are still damp and easy-care fabrics. Creasing in fabrics is reduced. Fabrics are not dried

completely. Laundry ready for ironing and/or hanging up!

$ Sportswear max. 1.5 kg Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with

removable internal lining separately).

Wool finish max. 3 kg Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.

Remove fabrics once the programme has ended and allow to dry.

 Super Quick 40’ max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may

differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the

fabric and loading capacity.

 Timed Programme warm max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.

Also for subsequent drying.

 Timed Programme cold max. 3 kg All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

*for LCottons Easy-Care and programmes only

**Dryness levels can be selected individually Very Dry, Cupboard Dry Plus/Very Dry, Cupboard Dry and Iron Dry .a (depending on the model)

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

9308 / 9000907242

*907242* Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

D-81739 München/Deutschland

WTW86562GB

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Tørretumbler
Model:	EcoLogixx 7S WTW8656ECO
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	636 mm
Højde:	842 mm
Vægt:	53000 g
Produktfarve:	Hvid
Kontroltype:	Buttons,Rotary,Touch
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	10 A
Ledningslængde:	1.45 m
Årligt energiforbrug:	212 kWh
Strømforbrug (slukket):	0.1 W
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	100 W
Støjniveau:	65 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	7 kg
Forsinket start-timer:	Ja
Børnesikring:	Ja
Understøttede scanningstilstande:	1060 mm
Døråbningsvinkel:	180 °
Tromle volumen:	112 L
Certificering:	CE, VDE
Indikator for LED-programfase:	Ja
Cyklustid:	178 min.
Forsinket start (maks.):	24 t
Tørringsklasse:	A
Selvrensende:	Ja
Energieffektivitetsklasse:	A++
Tørreprogrammer:	Wool,Mix,Sport,Timed,Blouse/shirt,Cotton
Tørresystem:	Kondensering
Anti-krølle funktion:	Ja
Anti-krølle cyklus:	120 min.
Tromle indvendigt lys:	Ja
Nominel strømstyrke:	10 A
Energiforbrug:	1.65 kWh
