Side 1/2
Este conmutador activa la cuenta e impresión del número de ítems hasta 999.
<Contador de Entradas>
Cuando el contador de n de entradas está situado en n+, la calculadora
contará el n de veces que las teclas + y – se presionan. Cuando el
contador de n de entradas está situado en n+/– la calculadora contará el n de
veces que se presiona la tecla + y restará del total el n de veces que se
presiona la tecla – .
<Contador de entradas de memoria>
Cuando el contador de n de entradas está situado en n+, la calculadora
contará el n de veces que las teclas y se presionan. Cuando el
contador de n de entradas está situado en n+/– la calculadora contará el n de
veces que se presiona la tecla y restará del total el n de veces que se
presiona la tecla .
<Impresión de la cuenta de ítems>
Cuando el interruptor de impresión “PRINT” se posiciona en ON, y el interruptor
de cuenta de entradas (ITEM) está en la posición n+ o n+/–, puede imprimirse
el número de entradas registradas por el contador, hasta tres dígitos, en la
izquierda del papel, presionando la tecla o la tecla para la cuenta de
entradas y la tecla o la tecla para la memoria de cuenta de entradas.
Cuando el poder está en "ON" y la calculadora no se utiliza durante aprox.
7 minutos. La calculadora cambiará al modo ahorro de energía automáticamente
con la luz LED naranja. Pulse la calculadora volve al modo de
lculo normal.
Used for designating the decimal point position (+ 0 2 3 4 6 F)
for calculated results.
+ (Add-Mode) – Addition and subtraction functions are performed with
an automatic 2-digit decimal. It is convenient for currency calculations.
F (Floating Decimal Point) All effective numbers up to 12 digits are
printed or displayed.
COMO CAMBIAR LA CINTA
PRINTED IN CHINA
INSTRUCTIONS
INSTRUCCIONES
INSTALLING PRINTING PAPER
REPLACING BACKUP BATTERY
Memory backup battery retains the tax rate, calendar and clock setting, when the
power is off or even when the AC cord is disconnected.
Battery : 1 Lithium battery (Type : CR2032)
Battery life : Backup time 2000 hours
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instruction.
ESPAÑOLA
REPLACING THE INK RIBBON
ESPECIFICACIONES
ANTES DE EMPEZAR
INSTALANDO PAPEL DE IMPRESIÓN
DECIMAL POINT SELECTOR SWITCH
ROUNDING SWITCH
CONMUTADOR DE REDONDEO
GRAND TOTAL / RATE SET SWITCH
TECLA DE GRAN TOTAL / RATE SET
Note: Turn the power off.
1) Remove the cover and lift up the paper arm.
2) Lift ribbon spools off the shafts. Discard the old ribbon and spools.
3) Place the ribbon spool on the left spool pin and push it down until it clicks.
4) Thread the ribbon along the outer edge of the side guide, making sure
that the black half of the ribbon is still on the top.
5) Place the ribbon between the printing ring and printing roller. Thread the
ribbon along the outer edge of the left side guide.
6) Place the other ribbon spool on another spool pin.
7) Push the spool down until it clicks.
8) Take up any ribbon slack by rotating the left spool counterclockwise.
9) Replace the printer cover.
IMPORTANT: Use only the same type of ribbon spools.
BEFORE STARTING
ENGLISH – Used for round-up [ ] , round-off [5/4], or round-down [ ]to the
pre-selected decimal digits in the result.
– When the calculations are performed with the GT switch set to "ON",
the total(s) are accumulated in the grand total memory. Each time
is pressed, the subtotal number is printed with the symbols G+.
When is pressed, the intermediate grand total is printed with the
symbols G . Press successively to get the grand total followed by
the symbols G .
– Set switch to "TAX RATE SET" for setting or recalling the TAX rate.
GRAND TOTAL
TAX RATE SET
AUTO POWER SAVE
In the following cases, when "E" is displayed, "ERR" is printed, the keyboard is
electronically locked, and further operation is impossible.
Press to clear the overflow. The overflow occurs when:
1. The result or the memory content exceeds 12 digits to the left of the decimal point.
2. Dividing by "0".
3. The sequential operation speed is faster than the calculation processing speed.
(Buffer Register Overflow)
Electromagnetic interference or electrostatic discharge may cause the display to
malfunction or the memory, currency rate and tax rate to be lost or
altered. Should this occur, use the tip of a ballpoint pen
(or similar sharp object) to press the [RESET] button on
the back of the calculator. After resetting be sure to set
the calendar, clock and tax rate again.
Power Source: AC120V, 60Hz
Operation Temperature: 0°C to 40°C (32°F to 104°F)
Calculating Capacity: 12 digits maximum
Dimension: 320mm (L) x 193 mm (W) x 71mm (H) /
12-39/64" (L) x 7-39/64" (W) x 2-51/64" (H)
Weight: 1,812 g (4 lbs)
(Subject to change without notice)
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
For CA, USA Only
Included battery contains perchlorate material - special handling may apply.
See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ for detail.
The bottom case and printer cover in this product are made from recycled Canon
copier plastic.
OVERFLOW
SPECIFICATION
REEMPLAZO DE LA BATERÍA DE RESPALDO
FUNCIÓN DE REBOSE
AUTO AHORRO DE ENERGIA
“ERR”
La toma de corriente debe instalarse cerca del equipo y debe ser
fácilmente accesible.
Para el Ca, los E.E.U.U. Solamente
La batería incluida contiene el material del perclorato - El manejo especial debe ser aplicado.
Para el detalle, por favor ver http://www.dtsc.ca.gov/hazardouswaste/perchlorate
AC120V, 60Hz
Peso: 1,812 g (4 lbs)
320mm (An) x 193 mm (Pr) x 71mm (Al) /
12-39/64" (An) x 7-39/64" (Pr) x 2-51/64" (Al)
MP27-MG
When the power is turned "ON" and the calculator is not being used for approx. 7
minutes. The calculator will switch to power save mode automatically with orange
LED light-up. Press key the calculator will return to normal calculation mode.
At "n+" or "n+/–" position, the calculator counts and print the number of
calculation items up to 999.
<ITEM COUNT>
When the "ITEM" switch is set at "n+", the calculator counts the number of
times the + and keys are pressed.
When the switch is set at "n+/–", the calculator counts the number of times the
+ key is pressed and subtracts from the total numbers of times the key is
pressed.
<MEMORY ITEM COUNT>
When the "ITEM" switch is set at "n+", the calculator counts number of
times and keys are pressed.
When the switch is set at "n+/–", the calculator counts the number of times
the key is pressed and subtracts from the total number of times the key
is pressed.
<PRINTOUT OF ITEM COUNT>
When the PRINT switch is turned "ON", and the "ITEM" switch is at the "n+" or
"n+/–" position, the number of items recorded by the counter can print up to
three digits on the left-hand side of the paper by pressing either the key or
the key for item count and key or key for memory item count.
ITEM COUNT SWITCH
Print Off – Entries and results will appear on the display, but will not be
printed out.
Print On Entries and results will appear on the display and will be
printed out.
PRINT ON/OFF SWITCH
IMPRESIÓN / RECUENTO ITEM
INTERRUPTOR SELECTOR DE PUNTO DECIMAL
CONMUTADOR CONTADOR DE ENTRADAS
1) Remove the insulation tape at the back of calculator. (Figure )
2) Remove the tape on the ink ribbon of calculator. (Figure , )
3) Plug in AC power cord. (Figure )
4) Turn the power switch on. (Figure )
5) Press [RESET] key before use. (Figure )
a
b c
d
e
f
ef
b ca
d
Note : Turn the power off
1) Remove the printer cover (Figure ) and lift up the paper arm (Figure ).
2) Replace the printer cover (Figure ).
• When inserting the paper, cut the edge of the paper as shown (Figure ).
3) Turn the power switch on (Figure ).
4) Place the new paper roll on the arm. The edge of the paper should be
positioned as shown (Figure ).
• Suitable paper roll -- Width : 57mm (2-1/4”) / Diameter: 86mm (3-3/8”)
5) Press the paper feed key to advance the paper (Figure ).
ef
b ca
d
E-IM-2474
