myQ® SMART LED GARAGE LIGHT
Model MYQLED2
Installation
The myQ Smart LED Garage Light is designed to plug directly into a standard 120V outlet.
Select an appropriate location on the ceiling or wall to mount the light within 6 feet
(1.83 m) of an electrical outlet so that the cord and light are away from moving parts.
NOTE: If installing light on drywall and a ceiling joist cannot be located, use the drywall anchors
provided. No pilot hole is required for drywall anchors.
1. With the smart light lens open, hold the device up to the surface of the desired mounting
location within 6 ft. from the electrical outlet. Mark screw hole locations on the mounting
surface with a pen or pencil (Figure 1).
2. If mounting to a wooden joist, use a 1/8” bit to drill pilot holes at marked locations. OR
Screw in the provided drywall anchors at marked mounting locations.
3. Determine the length of power cord needed to reach the nearest outlet. Wind any
excess cord around cord retainer on the top side of the smart light base. Route the cord through
the channel so that the light is flush when mounted.
4. Line up the smart light’s screw holes with the marked mounting locations, insert
the provided screws into the mounting guide holes, and screw in the smart light.
5. Close the smart light lens.
6. Plug in the smart light to the outlet. NOTE: The LED light is very bright and will blink while
programming. DO NOT stare at the light while on a ladder.
Programming
PROGRAM A DOOR OPENER/OPERATOR TO THE myQ SMART LED GARAGE LIGHT
1. Press the LEARN button on the smart light until the green LED turns ON (Figure 2).
2. Do one of the following operations (Figure 3):
• Press the LEARN button on the door opener/operator. OR
• Press the LEARN button on the door control twice. OR
• On an LCD Smart Control Panel
®, go to Menu > Program> myQDevice. OR
• Using the myQ App, go to Menu > Program > myQ Device.
1. Open myQ app
2. Press your myQ account (icon at upper left screen) to open account settings.
3. Press “Device Management” to display the provisioned GDOs.
4. Press your GDO (under “Hubs”) to pair to your Smart LED Garage Light.
5. Press “Add New” (under Devices/Sensors paired to this Hub”) to see list of device list.
6. Press “Smart LED Garage Light” to add this new device and follow the steps to pair the
Smart LED Garage Light.
7. After pressing the learn button on the Smart LED Garage Light, Press “Next” to finish.
The Smart LED Garage Light will blink once to confirm that it was successfully paired.
The device has been learned when the smart light blinks once.
Once paired, the Smart LED Garage Light is added to your myQ account as an accessory.
PROGRAM A SECURITY+ 2.0 ® REMOTE CONTROL TO THE myQ SMART LED GARAGE LIGHT
1. Press the LEARN button on the smart light until the green LED turns ON (Figure 2).
2. Press the button on the remote control that you wish to operate the smart light (Figure 4).
NOTE: Be sure not to select a button that is currently learned. (e.g. to a Garage Door Opener).
3. The device has been learned when the smart light blinks once.
To program the smart light with another accessory, refer to the manual for your accessory.
TO ERASE ALL PROGRAMMING FROM THE SMART LED GARAGE LIGHTmyQ
Press and hold the LEARN button on the smart light until the green LED turns off (6-10 seconds).
All programming is now erased.
Maintenance
• Unplug the smart light before cleaning.
• Use a lightly dampened cloth for cleaning.
• DO NOT use liquid cleaners on the light lens.
• Light is intended for indoor ceiling or wall mount applications ONLY.
• In the instance of a MYQLED2 being used with RJO models RJO20/C and 8500/C,
it is required to install a LiftMaster 889LMMC Wall Control (sold separately).
WARNING: This product can expose you to chemicals including
lead, which are known to the State of California to cause cancer or
birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
NOTICE: This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This device must be installed to ensure a minimum 20 cm (8 in.) distance is maintained between users/
bystanders and device.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules and Industry Canada ICES standard. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Operation of this equipment is subject to the following two conditions: (1) This equipment or device may not cause
harmful interference, and (2) This equipment or device must accept any interference, including that which may
cause undesired operation.
Door
Opener/Operator
LEARN Button
LEARN Button
OR
LEARN Button
LCD Smart
Control Panel
Figure 2
Figure 4
The Chamberlain Group LLC (“Seller”) warrants to the first consumer purchaser of this product that it is free from
defect in materials and/or worksmanship for a period of 1 year from the date of purchase.
Because Seller cannot control the quality of products sold by unauthorized sellers, this limited warranty applies
only to Products that were purchased from Seller or an authorized reseller in the United States or Canada, unless
otherwise prohibited by law. Seller reserves the right to reject warranty claims from purchasers for Products
purchased from unauthorized sellers, including unauthorized Internet sites.
Screws
Light Lens
Drywall
Anchors
Cord Retainer
Channel
Figure 1
Figure 3
