CL-S700 Series
Thermal Transfer Barcode & Label Printer
U MSER'S ANUAL
CL-S700
CL-S703 CL-S700R
2
CONTENTS
Before Operation
INTRODUCTION -------------------------------------------------------------------- 3
COMPLIANCE STATEMENT FOR EUROPEAN USERS ----------------------------- 4
FCC COMPLIANCE STATEMENT FOR AMERICAN USERS ----------------------- 4
EMI COMPLIANCE STATEMENT FOR CANADIAN USERS------------------------ 5
ETAT DE CONFORMITE EMI A L’USAGE DES UTILISATEURS CANADIENS ----- 5
IMPORTANT SAFETY INSTRUCTIONS--------------------------------------------- 6
NOTICE ------------------------------------------------------------------------------- 7
SAFETY INSTRUCTIONS ------------------------------------------------------------ 8
Chapter 1 Setup
Confirmation of Carton Contents -------------------------------------------------10
Part Names and Functions---------------------------------------------------------- 11
Connection to Power ---------------------------------------------------------------18
Driver Installation ------------------------------------------------------------------- 18
Connection to a Computer --------------------------------------------------------19
Chapter 2 Printer Operation
Power ON/OFF --------------------------------------------------------------------- 20
Normal Operating Mode ---------------------------------------------------------- 21
Setting the Media ------------------------------------------------------------------ 23
Setting the Ribbon ----------------------------------------------------------------- 32
Mode Settings ---------------------------------------------------------------------- 35
Quick Setup of the Print Method ------------------------------------------------- 51
Emulation Auto-Detection -------------------------------------------------------- 52
Setting the menu for the Rewinder (CL-S700R only) --------------------------- 53
Chapter 3 Printer Adjustments
Sensor Adjustments and Calibration --------------------------------------------- 54
Media Thickness Adjustment ----------------------------------------------------- 57
Media Width Adjustment ---------------------------------------------------------- 58
Adjusting the Ribbon -------------------------------------------------------------- 59
Moving the Adjustable Sensor ---------------------------------------------------- 61
Cleaning ---------------------------------------------------------------------------- 62
Chapter 4 Troubleshooting --------------------- 64
Appendixes
Specifications ---------------------------------------------------------------------- 66
Interfaces --------------------------------------------------------------------------- 70
Replacing the Interface Board ---------------------------------------------------- 76
4
COMPLIANCE STATEMENT
FOR EUROPEAN USERS
CE marking shows conformity to the following criteria and provisions:
Low Voltage Directive (73/23/EEC)/EN60950-1
EMC Directive (2004/108/EC, formerly 89/336/EEC)/EN55022, EN55024, EN61000-3-2 &
EN61000-3-3
This product has been tested under EN ISO 7779 and has an acoustic level output no higher than
55db(A).
This device is not intended for use at a video workstation in compliance with Bildscharb V.
FCC COMPLIANCE STATEMENT
FOR AMERICAN USERS
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
