Side 1/2
CU
WARNING: This product can expose you to Lead
which is known to the state of California to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65Warnings.ca.gov
installed by a licensed electrician
in accordance with the National
All electrical components must be
Electric Code and the appropriate
local electrical codes.
How to install
You will need 24- Medium Base Bulb
40 Watts Recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE
THE FIXTURE IS DAMP RATED
Crystal Key
DETAILED ILLUSTRATION
L
Ø25X7+Ø22X5+Ø20X3+Ø18X3 132 sets
Ø25X6+Ø22X6+Ø18X4+Ø14X4 96 sets
Ø25X4+Ø22X5+Ø18X3+Ø14X3+Ø10X4 60 sets
Ø22X7 25 sets
Ø22X7+Ø80X1 1setA=
B=
C=
D=
E=
ASSEMBLY INSTRUCTION MODEL #618-GA
1 Pass the wire and safety cable through the downrod.
and insert it into the coupler on the top of the frame.
Align the hole on the downrod with the hole on the
coupler and secure it using the set screw.
2.Take one decorative chain and hook one end of it onto
. the loop on the frame using the quick link Hook the
end of it onto the hook on the top of the other
downrod Repeat for other chains. .
3. Screw the bottom ring kit onto the coupler on the
bottom of frame .
4. Attach one end of the IPS threaded pipe onto 1/4 the
5. , , Assemble the screw collar loop nipple hex nut and
hickey to 1/4 the IPS threaded pipe and adjust overall
length to allow the collar ring to hold the canopy flush
to ceiling .
6. Attach the chain to . the fixture loop Position the screw
7.Weave the fixture wires ground wires and safety cable,
ceiling joist and secure with hex nut The other end of .
the threaded pipe should protrude through the outlet box .
collar ring over the upper end of the chain Open the .
end of the quick link and attach one end to the screw
collar ring and the other end to the fixture loop Secure .
the links .
through the chain and screw collar loop exiting through
the side of Hickey Proceed with the wire connections . .
Wrap the safety cable around the chain .
A
B
C
D
E
①
③
④
②
Canopy(W7",H0.79")
154.90”
77”
60"
A=
B=
C=
D=
E=
Crystorama.comCrystorama.com
8.Press the end of the steel strand to form a hook.
9 Dress the bead strands as illustrated. .
