Video Matrix Platform (M60)
User’s Manual
V2.1.0
Foreword I
Foreword
General
This manual introduces function, installation, use, operation and maintenance of Video Matrix
Platform .
Model
Video Matrix Platform-12U, Video Matrix Platform- 7U
Safety Instructio ns
The following categorized signal words with dened meaning might appear in the manual.
Signal Words
Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result
in death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
TIPS
Provides methods to help you solve a problem or save you time.
NOTE
Provides additional information as the emphasis and supplement
to the text.
Revision History
Revision Content
Release Date
Baseline Revision
April 2019
First release
June 2018
Privacy Protection Notice
As the device user or data controller, you might collect personal data of others, such as face,
ngerprints, car plate number, Email address, phone number, GPS and so on. You need to be
in compliance with the local privacy protection laws and regulations to protect the legitimate
rights and interests of other people by implementing measures including but not limited to:
providing clear and visible identication to inform data subject the existence of surveillance
area and providing related contact.
Foreword II
About the Manual
The Manual is for reference only. If there is inconsistency between the manual and the
actual product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the manual.
The manual would be updated according to the latest laws and regulations of related
regions. For detailed information, see the paper manual, CD-ROM, QR code or our ocial
website. If there is inconsistency between paper manual and the electronic version, the
electronic version shall prevail.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or
errors in print. If there is any doubt or dispute, please refer to our nal explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and the company names in the manual are the
properties of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem
occurred when using the device.
If there is any uncertainty or controversy, please refer to our nal explanation.
Important Safeguards and Warnings III
Important Safeguards and Warnings
The following description is the correct application method of the device. Please read the
manual carefully before use, in order to prevent danger and property loss. Strictly conform to
the manual during application and keep it properly after reading.
Operating Requirement
Do not place or install the Device in a place exposed to sunlight or near the heat source.
Keep the Device away from dampness, dust or soot.
Keep the Device installed horizontally on the stable place to prevent it from falling.
Do not drop or splash liquid onto the Device, and make sure there is no object lled with
liquid on the Device to prevent liquid from owing into the Device.
Install the Device in a well-ventilated place, and do not block the ventilation of the Device.
Operate the device within the rated range of power input and outpu t.
Do not dissemble the Device.
Transport, use and store the Device under the allowed humidity and temperature
conditions.
Electrical Safety
Use the battery of specied manufacturer; otherwise there might result in explosion.
When replacing battery, make sure the same type is used. Improper battery use might
result in re, explosion, or inammation.
Follow the instructions to dispose of the used battery.
Use the recommended power cables in the region and conform to the rated power
specication.
Use the power adapter provided with the Device; otherwise, it might result in people
injury and device damage.
The power source shall conform to the requirement of the Safety Extra Low Voltage
(SELV) standard, and supply power with rated voltage which conforms to Limited power
Source requirement according to IEC60950-1. Please note that the power supply
requirement is subject to the device label.
Connect the device (I-type structure) to the power socket with protective earthing.
The appliance coupler is a disconnection device. When using the coupler, keep the angle
for easy operation.
Table of Contents IV
Table of Contents
Foreword ..................................................................................................................................................... I
Important Safeguards and Warnings ..................................................................................................... III
1 Overview ................................................................................................................................................. 1
1.1 Introduction .................................................................................................................................... 1
1.2 Functional Feature ......................................................................................................................... 1
1.2.1 Structural Feature ................................................................................................................ 2
1.2.2 Hardware Feature ............................................................................................................... 2
1.2.3 Software Feature ................................................................................................................. 2
1.3 Introduction to Cards in System .................................................................................................... 4
1.4 Host System .................................................................................................................................. 6
1.4.1 12U Host Case .................................................................................................................... 6
1.4.2 7U Host Case ...................................................................................................................... 7
1.4.3 Main Control Panel .............................................................................................................. 8
1.5 Function Card ................................................................................................................................ 9
1.5.1 VEC3204FB SD A/V Encoding Card ................................................................................10
1.5.2 VEC1604HS -CH HD SDI Encoding Card 16 .................................................................... 11
1.5.3 VEC0804 HD DVI Encoding Card HD ............................................................................... 12
1.5.4 VEC1604HC -CH HDCVI Encoding Card 16 ..................................................................... 13
1.5.5 VEC0804US 8- -SDI Encoding Card CH 3G ...................................................................... 14
1.5.6 VEC1605UH 16-CH UHD Encoding Card ........................................................................ 14
1.5.7 VEC0805UH 8-CH UHD Encoding Card .......................................................................... 15
1.5.8 VDC0905H 9-CH HD HDMI Decoding Card ..................................................................... 16
1.5.9 VDC1205H 12-CH HD HDMI Decoding Card ................................................................... 16
1.5.10 VDC1505H -CH HD HDMI Decoding Card 15 ................................................................. 17
1.5.11 VDC1805H 18-CH HD HDMI Decoding Card ................................................................. 17
2 Device Installation ............................................................................................................................... 19
2.1 Inspection Steps .......................................................................................................................... 19
2.2 Accompanied Assessory Bag ...................................................................................................... 19
2.3 Device Installation ....................................................................................................................... 19
2.3.1 Preparation of Installation Environment ............................................................................ 19
2.3.2 Installation Steps ............................................................................................................... 20
2.3.3 Boot- /shutdown up ............................................................................................................. 24
3 Local Interface Conguration ............................................................................................................. 25
3.1 Basic Operation of Software Interface ........................................................................................25
3.1.1 Entering System Menu ...................................................................................................... 25
3.1.2 Main Interface .................................................................................................................... 26
3.1.3 Menu Introduction ............................................................................................................. 27
3.2 Advanced Operation of Me nu...................................................................................................... 27
3.2.1 Main Menu ......................................................................................................................... 27
3.2.2 Menu Navigation ............................................................................................................... 28
Table of Contents V
3.2.3 System Setting .................................................................................................................. 28
3.2.4 System Info ....................................................................................................................... 32
3.2.5 Shutdown ..........................................................................................................................35
4 Web Operation .....................................................................................................................................37
4.1 Network Connection .................................................................................................................... 37
4.2 System Login ............................................................................................................................... 37
4.3 Screen ......................................................................................................................................... 38
4.3.1 Adding Video Wall ............................................................................................................. 40
4.3.2 Window Conguration ....................................................................................................... 40
4.3.3 Signal Conguration .......................................................................................................... 42
4.3.4 Video Wall Management ................................................................................................... 44
4.4 Preview ........................................................................................................................................ 57
4.4.1 Window Function ............................................................................................................... 58
4.4.2 Signal Conguration .......................................................................................................... 59
4.4.3 PTZ Control Panel ............................................................................................................. 60
4.5 Setup ........................................................................................................................................... 62
4.5.1 System Cong ................................................................................................................... 62
4.5.2 Network ............................................................................................................................. 74
4.5.3 Event Management ........................................................................................................... 80
4.5.4 Signal Management .......................................................................................................... 81
4.5.5 Display Management ........................................................................................................ 94
4.6 Info ............................................................................................................................................. 107
4.6.1 Device Info ...................................................................................................................... 107
4.6.2 Help ................................................................................................................................. 113
5 Platform Software Operation ............................................................................................................ 114
6 FAQ and Maintenance ....................................................................................................................... 115
6.1 FAQ ............................................................................................................................................ 115
6.2 Use and Maintenance 119................................................................................................................
Appendix 1 Mouse Operation .............................................................................................................. 120
Appendix 2 Cybersecurity Recommendations .................................................................................. 122
Overview 1
1 Overview
Introduction 1.1
Based on Advanced Telecommunications Computing Architecture (ATCA), video matrix
platform is designed as a modern telecommunication-level device which supersedes DVR,
decoder, analog matrix, and video wall controller. It is compatible with past and current network
monitoring environments.
Main Application:
Flexible equipping of function card.
Connect analog/ -SDI camera and IPCs. HD
With HDMI port, achieve matrix switch, encoding and decoding.
Support online real-time preview.
Appearance of 12U video matrix platform Figure 1-1
Appearance of 7U video matrix platform Figure 1-2
Functional Feature 1.2
This product is a digital video matrix system with functions of digital video switch, multiple
operation access, centralized management and distributed deployment.
It switches among analog signal, digital signal, HD network signal and HD digital video
signal, and mak HD image available on video walls. es
Overview 2
This platform integrates video signal encoding/decoding, centralized data storage, online
real-time preview and various networks, plan, log, user right management, device
maintenance functions and etc., allows HD video command/dispatch and video and
conference system.
1.2.1 Structural Feature
19-inch 7U and 12U standard rack case for universal uses.
Card-type ATCA structure with strong expansibility and exibility.
Seven fans in three groups for intelligent temperature controlling, stabilized air passage
with the case structure to balance internal temperature.
Dual-channel redundant power supply for continuous working of device and security of
data.
Double blade function card.
1.2.2 Hardware Feature
Intel x86 platform r device expandability and uency when system is in full load. fo
High-speed connector on compression card, x PCI-E gen2, DC 12V power supply 8 and 5
GIO, for uency of high-speed data ow.
Compression card’s hot swap button and indicator for users’ flexible extension on the
application and knowledge of compression card status.
Various ports of compression card, such as USB, serial, Internet interface, HDMI, BNC,
DVI and etc. which guarantee device functions and simplify operation and debugging done
by users and technical staffs.
With industrial embedded micro-processor, e function card works independently to ach
balance system’s work load and ensure fluency.
Duel-high-speed non-blocking design for rear panel to meet demand of large volume A/V
data transmission.
1.2.3 Software Feature
Embedded LINUX OS: safe, stable, efcient, easy development and maintenance.
A/V Encoding and Decoding
A/V encoding card supports -ch BNC, -ch -SDI, -ch optical ber32 16 HD 16 , 8-ch DVI
(support DVI, VGA, HDMI signal), and 16-ch HDCVI.
A/V decoding card supports maximum 384-ch D1 real-time decoding or 96-ch HD1080P
decoding output .
Network Function
Eight RJ45 ports, each of which supports 1000M network; 8 optical ber ports (Ethernet
port and optical ber port cannot be used at the same time).
Overview 3
Support cascading among video matrix platforms, extending the video processing and
networking abilities of video matrix platforms, and thus achieving the integration of
multi-level video surveillance system.
Support TCP/IP protocol stack, including TCP, UDP, RTP, RTSP, DHCP, DNS, DDNS, NTP,
SADP protocols.
Support management software to achieve remote switching between analog and digital
videos on video wall and control with keyboard.
Receive and congure parameter, reboot, export and import parameters remotely.
Video Management
Support HD and SD digital matrix, and direct switch as non-compression bit stream which
eliminates image quality reduction after multiple switches of video signal.
Support HD SD IPC matrix. and
Support digital video full crossing switch matrix, based on dierent applied compression
card combinations, forming digital video full crossing switch matrix with dierent
specications.
A/V decoding card supports HDMI, DVI, VGA and BNC ports; support up to 1080P
(1920*1080P) resolution output.
Allow operator to loop display dierent images on the same screen, pre-set and switch as
group.
Splicing image favorites, simplied operations on multiple video channels.
Other Functions
Operation, alarm, abnormality and log recording facilitates user and technical staff’s
maintenance.
Improve user authority management to provide more clear and orderly authorization levels.
Timely upgrade the system in local and remote online way.
Support device cascading and network storage to meet mand from medium to large de
surveillance systems.
Multiple users and clients login, convenient for users to preview and manage monitoring
whenever and wherever possible.
Overview 4
Connection diagram Figure 1-3
Introduction to Cards in System 1.3
Table 1-1 System cards
No.
Name
Model
Functional
Module
Description
Note
1
Platform
Host
M60-12U
Video matrix
platform host
One 12U host
supports function 10
cards.
One MBC0050 main
control panel.
Two built-in power
adaptors (redundant).
Standard
M60- 7U
One 7U host supports
5 function cards.
One MBC0050 main
control panel.
Two built-in power
adaptors (redundant).
2
Input
Module
VEC3204FB
SD BNC video
encoding card
32-ch video input
(BNC).
Two DVI audio input
ports (32-ch).
2-ch RS 485 port. –
Optional
Overview 5
No.
Name
Model
Functional
Module
Description
Note
VEC1604HS
HD-SDI video
encoding card
(16-ch)
16-ch HD-SDI video
input (BNC).
One DVI audio input
port (16-ch).
2-ch RS port. –485
Optional
VEC0804HD
HD DVI video
encoding card
8-ch DVI video input.
One VGA audio input
port -ch). (8
2-ch RS 485 port. –
Optional
(support
DVI,VGA,
HDMI)
VEC1604HC
16-ch HDCVI
encoding card
16-ch BNC video input
(HDCVI).
One DVI audio input
(16-ch).
2-ch RS 485 port. –
Optional
VEC0804US
HD -SDI 3G
encoding card
(8-ch)
8-ch -SDI video 3G
input (BNC).
One DVI audio input
port (8-ch).
2-ch port. RS–485
Optional
VEC1605UH
16-ch UHD
encoding card
16-ch HDMI video
input.
4-ch VGA video input.
Tw VGA audio input o
ports (16-ch).
1-ch RS 485 port. –
Optional
VEC0805UH
8-ch UHD
encoding card
8-ch HDMI video
input.
2-ch VGA video input.
One VGA audio input
port (8-ch).
1-ch RS 485 port. –
Optional
3
Output
Module
VDC0905H
9-ch HDMI
decoding card
9 HDMI video output ports
Optional
VDC1205H
12-ch HDMI
decoding card
12 HDMI video output
ports
Optional
VDC1505H
15-ch HDMI
decoding card
15 HDMI video output
ports
Optional
VDC1805H
18-ch HDMI
decoding card
18 HDMI video output
ports
Optional
Overview 6
Host System 1.4
1.4.1 12 U Host Case
Video Matrix Platform with 19-inch U structure host case includes function card slot, power 12
port and intelligent temperature-controlling fan. See Figure 1-4.
Appearance of 12U Host Case Figure 1-4
Indicator lights on the front panel display device working status. See Table 1-2.
Table 1-2 Function introduction
ON/OFF button.
Power indicator light.
Red: Not operating after plugged in.
Red-Blue: Operating.
Network indicator light.
Red: Device network is abnormal.
O: Device network is normal.
Alarm indicator light.
Red: Fault occurs.
O: Device is normal.
Temperature indicator light.
Red: Board card temperature is too high.
O: Board card temperature is normal.
Overview 7
Power module indicator light.
Red: Power module is abnormal.
O: Power module is normal.
Fan indicator light.
Red: Fan is abnormal.
O: Fan is normal.
Hardware structure is as below:
Air intake of host has a dust lter behind the plastic shell.
Three groups of intelligent temperature-controlling fans allow hot swap.
10 interface board slots of function card are labeled in sequence and used to install rear
interface board of function card.
Interface board slots of main control panel are marked to “M”.
Dual-power module supports 220V and 48V module.
1.4.2 7U Host Case
Video Matrix Platform with 19-inch 7U structure host case includes function card slot, power
port and intelligent temperature-controlling fan. See Figure 1-5.
Appearance of 7U Host Case Figure 1-5
Indicator lights on the front panel display device working status. See Table 1-3.
Table 1-3 Function introduction
Power supply indicator light. It is green after the device is power-on
normally.
Operation indicator light.
O: Not operating after plugged in.
Green: Operating.
Network indicator light.
Red: Device network is abnormal.
O: Device network is normal.
Overview 8
Alarm indicator light.
Red: Fault occurs.
O: Device is normal.
Temperature indicator light.
Red: Board card temperature is too high.
O: Board card temperature is normal.
Power module indicator light.
Red: Power module is abnormal.
O: Power module is normal.
Fan indicator light.
Red: Fan is abnormal.
O: Fan is normal.
Infrared remote control signal receiving port.
Hardware structure is as below:
Single fan , air intake of host with dust lter at side. box
Three groups of intelligent temperature-controlling fans allow hot swap.
Five interface board slots of function card are labeled in sequence and used to install rear
interface board of function card.
Interface board slots of main control panel are marke d to “M”.
Dual-power module supports 220V module.
1.4.3 Main Control Panel
MBC0050 main control panel of video matrix platform.
1.4.3.1 Port Introduction
Functional board ports of main control panel Figure 1-6
Interface board ports of main control panel Figure 1-7
Overview 9
Table 1-4 Introduction to ports of main control panel
No.
Port
Quantity
Function
1
Reset Button
One
Restor to default settings. e
2
Power Indicator of
Main Control Panel
One
Display power status of main control panel
3
Disk
Reading-writing
Status Indicator
One
Display disk reading-writing status.
4
CPU Working
Status Indicator
One
Diaplay CPU working status.
5
PCIE Working
Status Indicator
One
Display PCIE working status.
6
USB Port
Two
Connect mouse, keyboard and flash drive.
7
Gigabit RJ45 Port
Eight
Transmit network A/V data a control signal. nd
8
Gigabit SFP Port
Eight
Either Gigabit RJ45 port or Gigabit SFP port can
be used at the same time.
9
RS–232 Serial Port
One
Connect serial port device.
10
VGA
One
Local display output port. Connec LCD screen.
11
DVI
One
Local display output port. Connec LCD screen.
12
DVI
One
Decoding output port.
13
USB Port
Two
Connect mouse, keyboard, USB.
14
Audio Output
One
For audio talk.
15
Audio put In
One
For audio talk.
16
ESATA Port
One
For external storage device, data backup. and
1.4.3.2 rformance Feature Pe
High speed connector, including x80 PCIE gen2, DC 12V power, 3x10 GIO (3
GIO/operational card), IIC.
Four memory slots two channels. ,
Fan port, power/rotation rate control (CPU).
Four indicators (power indicator of main control panel, CPU failure indicator, PCIE failure
indicator and disk reading-writing indicator).
High speed connector, including p15-x8 PCIE gen2, DC 12V power 5 GIO. and
Function Card 1.5
Function card with blade modular design is mainly used for analog and digital image input,
centralized encoding compression, remote preview, network centralized storage, centralized
management and centralized decoding and so on.
Overview 10
1.5.1 VEC3204FB SD A/V Encoding Card
VEC3204FB SD A/V encoding card Figure 1-8
1.5.1.1 Main Features and Functions
Features
32-ch BNC video rt input (1.0 -p, 75 ohms). po Vp
32-ch audio input.
2-ch RS port. –485
One power button.
Five indicators (power, PCIE, PCIE failure, encoding chip operating indicator).
High speed connector, including x8 PCIE gen2,12V DC power and 5 GIO.
Functions
PAL/NTSC signal input.
H.264 video compression technology.
G711a, PCM and G711u audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rate,
bit stream rate, image quality and etc.
Each channel supports schedule and event as compression parameters.
Support composite and bit stream encoding. A/V synchronized in composite stream is
encoding.
Dual stream technology.
Picture compression and network transmission 4CIF or CIF under JPEG standard. of
Watermark technology.
1.5.1.2 Port Introduction
AIN audio input port, DB29 port.
VIN video input port, BNC port.
Overview 11
1.5.2 16 VEC1604HS -CH HD SDI Encoding Card
VEC1604HS 16-ch HD SDI encoding card Figure 1-9
1.5.2.1 Main Features and Functions
Features
16-ch -SDI video input port. HD
16-ch audio input.
2-ch port. RS–485
16 1080P, 30 fps.
One power button.
Seven indicators (power, PCIE and PCIE failure, encoding chip operating indicator).
High speed connector, including x8 PCIE gen2, DC 12V power 5 GIO. and
Functions
H.264 video compression technology.
G711a, PCM and G711u audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rate,
bit stream rate, image quality and etc.
Each channel supports schedule and event as compression parameters.
Support composite and bit stream encoding. A/V synchronized in composite stream is
encoding.
Dual stream technology.
Picture compression and network transmission 4CIF or CIF under JPEG standard. of
Watermark technology.
1.5.2.2 Port Introduction
AIN audio input port, DB29 port.
VIN video input port, BNC port.
Overview 12
1.5.3 VEC0804HD HD DVI Encoding Card
VEC0804HD HD DVI encoding card Figure 1-10
1.5.3.1 Main Features and Functions
Features
8-ch DVI-I video port input, supporting DVI, VGA and HDMI input.
8-ch audio input.
2-ch RS port. –485
One power button.
Seven indicators (power, PCIE and PCIE failure, encoding chip operating indicator).
High speed connector, including x8 PCIE gen2, DC 12V power 5 GIO. and
Functions
Support 1920×1080@60Hz, 1680×1050@60Hz, 1440×900@60Hz, 1366×768@60Hz,
1280×1024@60Hz, 1280×960@60Hz, 1280×800@60Hz, 1280×720@60Hz,
1152×864@60Hz, 1024×768@60Hz, 800×600@60Hz.
H.264 video compression technology.
G711a, PCM and G711u audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rate,
bit stream rate, image quality and etc.
Each channel supports schedule and event as compression parameters.
Support composite and bit stream encoding. A/V synchronized in composite stream is
encoding.
Dual stream technology.
Picture compression and network ansmission 4CIF or CIF under JPEG standard. tr of
Watermark technology.
1.5.3.2 Port Introduction
AIN audio input port, DB port. 15
VIN video input port, DVI-I port.
Overview 13
1.5.4 16 VEC1604HC -CH HDCVI Encoding Card
VEC1604HC 16-ch HDCVI encoding card Figure 1-11
1.5.4.1 Main Features and Functions
Features
16-ch BNC video input port. HDCVI signal input.
16-ch audio input, support external and built- . in
2-ch RS port. –485
Reverse control.
One power button.
Seven indicators (power, PCIE and PCIE failure, encoding chip operating indicator).
High speed connector, including x8 PCIE gen2, DC 12V power 5 GIO. and
Functions
Support 1080P@30Hz, 1080P@25Hz, 720P@60Hz, 720P@50Hz, 720P@30Hz,
720P@25Hz.
H.264 video compression technology.
G711a, PCM and G711u audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rate,
bit stream rate, image quality and etc.
Each channel supports schedule and event as compression parameters.
Support composite and bit stream encoding. A/V synchronized in composite stream is
encoding.
Dual stream technology.
Picture compression and network transmission 4CIF or CIF under JPEG standard. of
Watermark technology.
1.5.4.2 Port Introduction
AIN audio input port, DB29 port.
VIN video input port, BNC port.
Overview 14
1.5.5 3G VEC0804US 8-CH -SDI Encoding Card
VEC0804US 8-ch 3G-SDI encoding card Figure 1-12
1.5.5.1 Main Features and Functions
Features
8-ch -SDI video input port. 3G
8-ch audio input.
2-ch RS port. –485
Eight 1080P, 60 fps.
One power button.
Seven indicators (power, PCIE and PCIE failure, encoding chip operating indicator).
High speed connector, including p20-x8 PCIE gen2, DC 12V power 5 GIO. and
Functions
H.264 video compression technology.
G711a, PCM and G711u audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rate,
bit stream rate, image quality and etc.
Each channel supports schedule and event as compression parameters.
Support composite and bit stream encoding. A/V synchronized in composite stream is
encoding.
Dual stream technology.
Picture compression and network transmission 4CIF or CIF under JPEG standard. of
Watermark technology.
1.5.5.2 Port Introduction
AIN audio input port, DB29 port.
VIN video input port, BNC port.
1.5.6 16 VEC1605UH - UHD Encoding Card CH
VEC1605UH -ch UHD Encoding Card Figure 1- 1613
Overview 15
1.5.6.1 Main Features and Functi ons
Features
16-ch HDMI video input port, and 4-ch VGA video input port.
16-ch HDMI built-in audio input, and 16-ch external audio input port.
1-ch RS port. –485
8-ch (4096x2160@24 or 3840x2160@30) and 12-ch 1080P (1920x1080@60 4K ).
One power button.
10 indicators (power, PCIE and PCIE failure indicator, encoding chip operating indicator).
Functions
H.264/H.265 video compression technology.
PCM audio compression standard.
Video encoding parameter is adjustable in each channel, including resolution, frame rat e,
bit stream rate, image quality and etc.
Each channel supports schedule and event compression parameters.
Support composite and video stream encoding. A/V is synchronized in composite stream
encoding.
Dual stream technology.
1.5.6.2 Port Introduction
AIN audio input port, DB port. 15
VIN video input port, HDMI VGA port. and
1.5.7 VEC0805UH 8-CH UHD Encoding Card
VEC0805UH 8-ch UHD encoding card Figure 1-14
1.5.7.1 Main Features and Functions
Features
8-ch HDMI video input port, and 2-ch VGA video input port.
8-ch HDMI built-in audio input, and 8-ch external audio input port.
1-ch RS port. –485
4-ch (4096x2160@24 or 3840x2160@30) and 6-ch 1080P (1920x1080@60 4K ).
One power button.
6 indicators (power, PCIE and PCIE failure indicator, encoding chip operating indicator).

Produkt Specifikationer

Mærke: Dahua Technology
Kategori: Ikke kategoriseret
Model: M60-7U

Har du brug for hjælp?

Hvis du har brug for hjælp til Dahua Technology M60-7U stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Dahua Technology Manualer

Dahua Technology

Dahua Technology AWA6220-C Manual

28 Januar 2025
Dahua Technology

Dahua Technology PFM886-20 Manual

28 Januar 2025
Dahua Technology

Dahua Technology WBC5-45AC-03P Manual

28 Januar 2025
Dahua Technology

Dahua Technology WBC5-30AC-05P Manual

28 Januar 2025
Dahua Technology

Dahua Technology PFM880 Manual

28 Januar 2025
Dahua Technology

Dahua Technology PFM880E Manual

28 Januar 2025
Dahua Technology

Dahua Technology WB2-60N-I Manual

28 Januar 2025
Dahua Technology

Dahua Technology AWA6220-O Manual

28 Januar 2025
Dahua Technology

Dahua Technology AWA6330-C Manual

28 Januar 2025
Dahua Technology

Dahua Technology WR5210-IDC Manual

28 Januar 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Waterpik

Waterpik WP-490 Manual

10 April 2025
Daikin

Daikin EAVX16S18DA9WG Manual

10 April 2025
Daikin

Daikin RXYLQ40T7Y1B Manual

10 April 2025
Daikin

Daikin RXYLQ42T7Y1B Manual

10 April 2025
Daikin

Daikin ETVZ16S23EA6V7 Manual

10 April 2025
Daikin

Daikin FXMA200AXVMB Manual

10 April 2025
Daikin

Daikin FXZQ15A2VEB Manual

10 April 2025
Daikin

Daikin ETVZ16S18EA9W Manual

9 April 2025
Daikin

Daikin DSR1 Manual

9 April 2025
Simplified MFG

Simplified MFG SP18CAT120 Manual

9 April 2025
