DAIKIN ROOM AIR CONDITIONER
OPERATION MANUAL
EnglishFrançaisEspañol
MODELS
CTXS07JVJU
CTXS09HVJU
CTXS12HVJU
5
English
Outdoor Unit
Open the front panel
Appearance of the outdoor unit may differ from some models.•
Air fi lter
Air-purifying fi lter
with photocatalytic
deodorizing function
Refrigerant piping and
inter-unit wiring
Ground terminal
Inside of this cover.•
Drain hose
Air inlet (back and side)
Air outlet
6
Name of Parts
Remote Controller: ARC452A9
Signal transmitter
Receiver
To use the remote controller, aim the •
transmitter at the indoor unit. If there
is anything to block signals between
the unit and the remote controller,
such as a curtain, the unit will not
operate.
Do not drop the remote controller. Do •
not get it wet.
The maximum distance for •
communication is approximately
23ft. (7m).
FAN setting button
Selects the airfl ow rate setting.•
Page 11
POWERFUL button
POWERFUL operation. • Page 16
Display (LCD)
Displays the current settings.•
(In this illustration, each section is
shown with its displays on for the
purpose of explanation.)
TEMPERATURE
adjustment buttons
Changes the temperature setting.•
Page 10
ON/OFF button
Press this button once to start •
operation.
Press once again to stop it. Page 10
Front cover
Open the front cover. • Page 7
12
Adjusting the Airfl ow Direction
You can adjust the airfl ow direction to increase your comfort.
Adjusting the upper and lower airfl ow direction
To adjust the louvers (horizontal blades)
Press 1. .
“• ” is displayed on the LCD and the louvers will begin to swing.
When the louvers have reached the desired 2.
position, press once more.
The louvers will stop moving.•
“• ” is no longer displayed on the LCD.
Adjusting the right and left airfl ow direction
To adjust the
fi
ns (vertical blades)
Press 3. .
“• ” is displayed on the LCD.
When the
fi
ns have reached the desired position, 4. press once more.
The fi ns will stop moving.•
“• ” is no longer displayed on the LCD.
14
INTELLIGENT EYE Operation
“INTELLIGENT EYE” is the infrared sensor which detects the human movement.
To start INTELLIGENT EYE operation
Press 1. .
“ • ” is displayed on the LCD.
To cancel INTELLIGENT EYE operation
Press 2. again.
“ • ” is no longer displayed on the LCD.
[Example]
Somebody back in the room
• Back to normal operation.
The air conditioner will return to
normal operation when the sensor
detects the movement of people
again.
When somebody in the room
• Normal operation
The air conditioner is in normal
operation while the sensor is
detecting the movement of people.
When nobody in the room
• 20 minutes after, start
energy saving operation.
The set temperature is shifted in
±3.6ºF (±2ºC) steps.
15
English
“INTELLIGENT EYE” is useful for energy saving
Energy saving operation
Change the temperature –3.6°F (–2°C) in HEAT / +3.6°F (+2°C) in COOL / +1.8°F (+1°C) in DRY operation from set temperature.•
Decrease the air
fl
ow rate slightly in FAN operation only.• If no presence detected in the room for 20 minutes.•
NOTE
Notes on INTELLIGENT EYE operation
Application range is as follows.•
90°
55°
23ft.
(7m)
55°
23ft. (7m)
Vertical angle 90°
(Side view)
Horizontal angle 110°
(Top view)
Sensor may not detect moving objects further than 23ft. (7m) away. (Check the application range.)•
Sensor detection sensitivity changes according to indoor unit location, the speed of passersby, temperature range, etc.•
The sensor also mistakenly detects pets, sunlight, fl uttering curtains and light refl ected off of mirrors as passersby.•
INTELLIGENT EYE operation will not go on during POWERFUL operation.•
NIGHT SET mode • Page 20 will not go on during use of INTELLIGENT EYE operation.
CAUTION
Do not place large objects near the sensor.•
Also keep heating units or humidifi ers outside the sensor’s detection area. This sensor can detect undesirable objects.
Do not hit or forcefully push the INTELLIGENT EYE sensor. This can lead to damage and malfunction.
•
16
POWERFUL Operation
POWERFUL operation quickly maximizes the cooling (heating) effect in any
operation mode. You can get the maximum capacity.
To start POWERFUL operation
Press during operation.
POWERFUL operation ends in 20 minutes. Then the system automatically operates again with •
the previous settings which were used before POWERFUL operation.
“• ” is displayed on the LCD.
When using POWERFUL operation, there are some functions which are not available.•
To cancel POWERFUL operation
Press again.
“• ” is no longer displayed on the LCD.
NOTE
Notes on POWERFUL operation
POWERFUL operation cannot be used together with QUIET operation.•
Priority is given to the function of whichever button is pressed last.
In COOL and HEAT operation•
To maximize the cooling (heating) effect, the capacity of outdoor unit must be increased and the airfl ow rate be fi xed to the maximum setting.
The temperature and airfl ow settings are not variable.
In DRY operation•
The temperature setting is lowered by 4.5°F (2.5°C) and the airfl ow rate is slightly increased.
In FAN operation•
The airfl ow rate is fi xed to the maximum setting.
In AUTO operation•
To maximize the cooling (heating) effect, the capacity of outdoor unit must be increased and the airfl ow rate be fi xed to the maximum setting.
POWERFUL operation will not increase the capacity of the air conditioner if the air conditioner is already in operation with its maximum capacity
•
demonstrated.
22
Note for Multi System
What is a multi system?
This system has one outdoor unit connected to multiple
indoor units.
Selecting the operation mode
With the priority room setting present but1.
inactive or not present.
When more than one indoor unit is operating, priority is
given to the fi rst unit that was turned on.
In this case, set the units that are turned on later to the
same operation mode (*1) as the fi rst unit.
Otherwise, they will enter the standby state, and the
OPERATION lamp will fl ash: this does not indicate malfunction.
(*1)
COOL, DRY and FAN operation may be used at the same time.•
AUTO operation automatically selects COOL operation or HEAT operation based on the room temperature.•
Therefore, AUTO operation is available when selecting the same operation mode as that of the room with the fi rst unit to be
turned on.
CAUTION
Normally, the operation mode in the room where the unit is
fi
rst run is given priority, but the following situations are exceptions, so please •
keep this in mind.
If the operation mode of the fi rst room is FAN operation, then using HEAT operation in any room after this will give priority to HEAT operation.
In this situation, the air conditioner running in FAN operation will go on standby, and the OPERATION lamp will fl ash.
With the priority room setting active.2.
See priority room setting on the next page.
B
room
A
room
Outdoor
unit
NIGHT QUIET mode (Available only for COOL operation)
NIGHT QUIET mode requires initial programming during installation. Please consult your retailer or dealer for assistance.
NIGHT QUIET mode reduces the operation noise of the outdoor unit during the nighttime hours to prevent annoyance to neighbors.
The NIGHT QUIET mode is activated when the temperature drops 9°F (5°C) or more below the highest temperature recorded •
that day. Therefore, when the temperature difference is less than 9°F (5°C), this function will not be activated.
NIGHT QUIET mode reduces slightly the cooling effi ciency of the unit.•
