AVR-2807

A/V Surround Receiver

The AVR-2807 is Denon's latest addition of versatile A/V Receivers,

which incorporate all current surround formats and enhanced installation

flexibility, all with great simplicity of setup and operation.

Audio section

■ Full discrete 7-channel high power amplifier

Front 110 W + 110 W (8 ohms, 20Hz - 20kHz, 0.05 % THD)

Center 110 W (8 ohms, 20Hz - 20kHz, 0.05 % THD)

Surround 110 W + 110 W (8 ohms, 20Hz - 20kHz, 0.05 % THD)

Surround back 110 W + 110 W (8 ohms, 20Hz - 20kHz, 0.05 % THD)

■ Latest 32-bit floating point DSP for the decoder

• 24-bit/192-kHz D/A converter

• 96kHz A/D converter

■ 'AL24 Processing Plus,' for high sound quality

■ Digital interface receiver supporting 24-bit/192-kHz signals

■ Large-output power amp section and power supply configuration,

for stable high-power output

■ Stable power supply for high-quality sound and picture playback

■ Pure Direct mode, for the pure enjoyment of music in high-quality sound

■ Supports the most advanced surround playback formats

• Dolby Digital EX • Dolby Digital • Dolby Pro Logic IIx

• DTS-ES • DTS 96/24 • DTS Neo:6 • DTS

■ Configurable surround back amplifiers

• Multi-zone system: a 5.1-channel theater in the main room and a stereo

environment in a second room.

• "Bi-amp" system: Front (L/R) channels are bi-wired in a 5.1-channel theater to

improve playback quality in the front for enhanced listening enjoyment.

Video section

■ HDMI digital video interface supporting high-quality video of 1080p (*1)

The AVR-2807 has HDMI digital video interface terminals (2 inputs and 1 output) that

can be switched for high-resolution 1080p video signal transmission. These HDMI

terminals also support digital input of multi-channel audio signals.

*1) Version 1.1 compliant. Since HDCP is also supported, video cannot be viewed on a non-HDCP display

connected to the AVR-2807; please connect a HDCP-compliant display when viewing video material.

■ Video Up/Down conversion capable of output to HDMI

The AVR-2807 includes a video up/down conversion function that allows the unit to be

connected to the video monitor via a single cable regardless of the video input signal's

format as follows:

1) Composite video signals are converted to HDMI (*2), component video, & S-video;

2) S-video signals are converted to HDMI (*2), component video, & composite video;

3) Component video signals are converted to HDMI (*2), composite video (*3), & S-video (*3).

*2. I/P conversion from 480i/576i to 480p/576p

*3. Down-conversion from component video to composite or S-video applies only to 480i input signals.

■ High-speed, high-accuracy 12-bit/216-MHz Video DAC

■ I/P conversion from 480i to 480p ( When a 480i/576i signal is input from a

Composite Video, S-Video, or Component terminal, it should be output from the

HDMI terminal.)

■ 3 Sets of Component Video Inputs

■ High Definition Quality Video Switching

■ Composite and S-video signal processing

The AVR-2807 uses a time base corrector (TBC) in converting composite video & S-video

signals to component video to suppress jitter in the video signal during playback.

Connectivity/ Expandability

■ Variable subwoofer crossover switching

(40/60/80/90/100/110/120/150/200/250Hz)

■ ASD-1R iPod®Control Dock (option): Supports iPod play-

back when connected to the AVR-2807

iPod (*4) playback can be enjoyed through the AVR-2807 when the

ASD-1R, Denon's original iPod Control Dock (sold separately), is

connected to the dedicated control terminal of the AVR-2807. The

iPod can also be controlled via the remote controller supplied with

the AVR-2807.

*4) Supports 3rd-generation and later iPods equipped with a Dock connector. Some functions may not work

depending on the generation of the iPod and the version of the software..

■ New Auto Set-up and Room EQ, featuring MultEQ from Audyssey,

for overall listening area support using supplied microphone

■ Room EQ Memory

Black version is also available.

Produkt Specifikationer

Mærke:	Denon
Kategori:	Modtager
Model:	AVR-2807
