MICRO Q-TRON
Envelope Controlled Filter
Congratulations on your purchase of the Micro Q-Tron envelope controlled filter! The
Micro Q-Tron is identical to our Mini Q-Tron but in a compact pedal. The envelope
controlled filter is a unique type of sound modifier in which the user’s playing style
controls the effect. The volume of the input signal (also called the envelope) controls
the cutoff frequency or center frequency of a swept filter. As your instrument’s
volume increases or decreases, so does the pitch of the filter.
-CONTROLS-
DRIVE CONTROL – This is the filter sweep sensitivity control. Turning the DRIVE
control clockwise will cause the filter to react more to your playing. The more you
turn up the DRIVE control, the higher in frequency the filter will jump when you play
a note. When first plugging into the Micro Q-Tron, start with this control at 12
o’clock.
Q CONTROL – Determines the peak bandwidth of the filter. As the Q control is turned
clockwise, the filter will sound increasingly narrow with a more obvious peak, making
the effect more dramatic. Start with Q set to about 2 o’clock.
MODE ROTARY SWITCH (LP BP HP) – Determines what frequency range the filter will
pass. Emphasizes lows in LP mode (Low Pass), midrange in BP mode (Band Pass) and
highs in HP mode (High Pass).
STATUS LED – When the LED is lit, the Micro Q-Tron is in effect mode. When the LED
is off, the Micro Q-Tron is True Bypass mode.
FOOTSWITCH – Toggles the Micro Q-Tron between effect and True Bypass modes.
CONNECTIONS – Connect your instrument to the INPUT Jack. Connect your amplifier
to the AMP Jack.
-POWER-
POWER – Power, from the internal 9-volt battery or external battery eliminator, is
activated by plugging into the Input jack. The input cable should be removed when-
the unit is not in use to avoid running down the battery. The barrel connector on the
front of the Micro Q-Tron is for a 9-volt battery eliminator capable of delivering 100
mA of current. The inner ring of the 9-volt battery eliminator must be negative, the
outer ring positive. The unit’s battery may be left in or taken out when the eliminator
is in use.
BATTERY – The Micro Q-Tron can run off of a 9V battery. To change the 9-volt
battery, you must remove the 4 screws on the bottom of the Micro Q-Tron. Once the
screws are removed, you can take off the bottom plate and change the battery.
Please do not touch the circuit board while the bottom plate is off or you risk
damaging a component.
-PLAYING THE MICRO Q-TRON-
The Micro Q-Tron’s effect is controlled by the musician’s playing dynamics: a stronger
attack or louder note will yield a more dramatic effect, while softer playing will
produce more subtle effects. Use the full range of control settings in combination
with different playing techniques to obtain a number of different and unique effects
combinations. You might find that the DRIVE and Q controls work best when they are
in the middle of their range rather than maximized.
When you play a note into the Micro Q-Tron, its filter will jump up to a high
frequency and then slowly descend in frequency according to the envelope of the
notes you play. The louder your note, the higher in frequency the filter jumps.
