BASSBALLS
TWIN DYNAMIC FILTERS FOR BASS GUITAR
- DESCRIPTION -
Congratulations on your purchase of the Electro Harmonix Nano Bassballs,
the first and only envelope follower of its kind, now in a compact pedal! The
vocal sound of its two sweeping filters gives bass a strong presence under
leads or a commanding quality when out front. The resonant frequencies are
engineered solidly into the full range of the bass guitar’s strongest
harmonics. The Nano Bassballs will respond to every bass note. The sweep is
widely variable and harmonic enrichment is available with the Fuzz option.
The Nano Bassballs is identical to the Bassballs but smaller.
- OPERATING INSTRUCTIONS -
Connect your instrument to the INPUT jack. Connect your amplifier to the
AMP jack.
The range of the filters’ upward frequency sweep is set by the interaction of
instrument volume and the RESPONSE control. Both stronger attacks and
higher (clockwise) settings of the RESPONSE control increase the sweep
range. Low volume and low RESPONSE settings will create little or no sweep
and the Nano Bassballs will only provide a small boost in its lowest
frequencies.
In its upward position, the FUZZ switch introduces additional harmonic
enrichment that accentuates the filters’ action. The RESPONSE control also
serves as a volume control for the FUZZ, increasing in volume in the
clockwise direction.
The Status LED will light up when the Nano Bassballs is in effect mode.
When in True Bypass mode, the LED will be off. Use the FOOTSWITCH to
toggle between effect and True Bypass mode.
- POWER -
Power from the internal 9-volt battery is activated by plugging into the
INPUT jack. The input cable should be removed when the unit is not in use
to avoid running down the battery. If a battery eliminator is used, the
Bassballs will be powered up as long as wall-wart is plugged in.
The barrel connector on the front of the Nano Bassballs is for a 9-volt
battery eliminator capable of delivering 100 mA of current. The inner ring of
the 9-volt battery eliminator must be negative, the outer ring positive. The
unit’s battery may be left in or taken out when the eliminator is in use.
To change the 9-volt battery, you must remove the 4 screws on the bottom
of the Nano Bassballs. Once the screws are removed, you can take off the
bottom plate and change the battery. Please do not touch the circuit board
while the bottom plate is off or you risk damaging a component.
The input impedance presented at the Input Jack is 200 kohms. The output
impedance at the Output Jack is 1.4 kohms.
