SMALL STONE
PHASE SHIFTER
Congratulations on your purchase of the Electro-Harmonix Nano Stone! The Nano
Stone is identical to the Electro-Harmonix Small Stone, just smaller. The Small Stone
was first manufactured back in the early 70’s making it one of the first compact
phase shifters on the market. To this day, the Small Stone is still the pedal to use
when musicians want a fat, warm analog phase shifter.
- OPERATING INSTRUCTIONS -
Connect your instrument to the INPUT jack. Connect your amplifier to the AMP jack.
Please note that whenever a plug is inserted into the INPUT jack, the Nano Stone is
ON and it is draining current from the battery.
The STATUS LED will light up when the Nano Stone is in effect mode. When in True
Bypass mode, the LED will be off. Use the FOOTSWITCH to toggle between effect
and True Bypass mode.
The RATE control adjusts the speed of the phasing sweep, turn RATE clockwise for a
faster sweep.
The COLOR Switch changes the sound of the phase shift between a full and robust
phase shift in the DOWN position to a more pronounced instance phase shift in the
UP position. When in the UP position, notice how the Nano Stone carves into the
frequency spectrum hollowing out the sound. Fundamentals and harmonics glide in
and out for an extremely pronounced shifting effect. Return the COLOR switch to the
down position and notice the fullness.
- POWER -
Power from the internal 9-volt battery is activated by plugging into the INPUT jack.
The input cable should be removed when the unit is not in use to avoid running down
the battery. If a battery eliminator is used, the Nano Stone will be powered up as
long as a wall-wart is plugged into the wall.
The barrel connector on the front of the Nano Stone is for a 9-volt battery eliminator
capable of delivering 100 mA of current. The inner ring of the 9-volt battery
eliminator must be negative, the outer ring positive. The unit’s battery may be left in
or taken out when the eliminator is in use.
To change the 9-volt battery, you must remove the 4 screws on the bottom of the
Nano Stone. Once the screws are removed, you can take off the bottom plate and
change the battery. Please do not touch the circuit board while the bottom plate is off
or you risk damaging a component.
The input impedance presented at the Input Jack is 100 k-ohms. The output
impedance at the Output Jack is 15 k-ohms.
