EOE6P77WX

EN Oven User Manual

7.3 Notes on: Moist Fan Baking...........17

7.4 How to set: Assisted Cooking........ 17

7.5 Assisted Cooking........................... 18

8. CLOCK FUNCTIONS.................................23

8.1 Clock functions.............................. 23

8.2 How to set: Clock functions........... 23

9. HOW TO USE: ACCESSORIES................ 25

9.1 Inserting accessories..................... 25

9.2 Food Sensor.................................. 25

10. ADDITIONAL FUNCTIONS..................... 27

10.1 Lock............................................. 27

10.2 Automatic switch-off.....................27

10.3 Cooling fan...................................28

11. HINTS AND TIPS..................................... 28

11.1 Moist Fan Baking......................... 28

11.2 Moist Fan Baking -

recommended accessories..................29

11.3 Cooking tables for test institutes..30

12. CARE AND CLEANING...........................32

12.1 Notes on cleaning........................ 32

12.2 How to remove: Shelf supports ...32

12.3 How to use: Pyrolytic Cleaning.... 33

12.4 Cleaning Reminder......................34

12.5 How to remove and install: Door..34

12.6 How to replace: Lamp..................36

13. TROUBLESHOOTING............................. 37

13.1 What to do if.................................37

13.2 Service data.................................38

14. ENERGY EFFICIENCY............................ 38

14.1 Product Information and Product

Information Sheet*...............................38

14.2 Energy saving.............................. 39

15. MENU STRUCTURE................................40

15.1 Menu............................................40

16. ENVIRONMENTAL CONCERNS.............41

My Electrolux Kitchen app

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible

3/44

SAFETY INFORMATION

3.2 Securing the oven to the cabinet

4. PRODUCT DESCRIPTION

4.1 General overview

10 8

31 42

1Control panel

2Knob for the heating functions

3Display

4Control knob

5Heating element

6Socket for the food sensor

7Lamp

8Fan

9Shelf support, removable

10 Shelf positions

11/44

PRODUCT DESCRIPTION

Countries covered by the provision of Directive 2014/53/EU: Belgium, Bulgaria, Czech

Republic, Denmark, Germany, Estonia, Ireland, Greece, Spain, France, Croatia, Italy, Cyprus,

Latvia, Lithuania, Luxembourg, Hungary, Malta, Netherlands, Northern Ireland, Austria, Poland,

Portugal, Romania, Slovenia, Slovakia, Finland, Sweden, Norway, Iceland, Liechtenstein,

Switzerland, Turkey.

6.4 Software licences

The software in this product contains components that are based on free and open source soft‐

ware. Electrolux gratefully acknowledges the contributions of the open software and robotics com‐

munities to the development project.

To access the source code of these free and open source software components whose license

conditions require publishing, and to see their full copyright information and applicable license

terms, please visit: http://electrolux.opensoftwarerepository.com (folder NIU5).

7. DAILY USE

WARNING!

Refer to Safety chapters.

7.1 How to set: Heating functions

Start cooking

Step 1 Step 2

Select a heating function.

Set the temperature.

Press

7.2 Heating functions

15/44

DAILY USE

Standard heating functions

Heating function Application

True Fan Cooking

To bake on up to three shelf positions at the same time and to dry food.

Set the temperature 20 - 40 °C lower than for Conventional Cooking.

Conventional

Cooking

To bake and roast food on one shelf position.

Frozen Foods

To make convenience food (e.g., french fries, potato wedges or spring

rolls) crispy.

Pizza Function

To bake pizza. To make intensive browning and a crispy bottom.

Bottom Heat

To bake cakes with crispy bottom and to preserve food.

Defrost

To defrost food (vegetables and fruit). The defrosting time depends on the

amount and size of the frozen food.

Moist Fan Baking

This function is designed to save energy during cooking. When you use

this function, the temperature in the cavity may differ from the set temper‐

ature. The residual heat is used. The heating power may be reduced. For

more information refer to "Daily Use" chapter, Notes on: Moist Fan Bak‐

ing.

Grill

To grill thin pieces of food and to toast bread.

Turbo Grilling

To roast large meat joints or poultry with bones on one shelf position. To

make gratins and to brown.

16/44

DAILY USE

Dish Weight Shelf level / Accessory Duration

time

P35 Wegdes 1 kg ; lined with baking pa‐3 baking tray

per

Use your favourite spices. Cut potatoes

into pieces.

35 min

P36 Grilled mixed

vegetables

1 - 1,5 kg ; lined with baking pa‐3 baking tray

per

Use your favourite spices. Cut the vege‐

tables into pieces.

30 min

P37 Croquets, fro‐

zen

0,5 kg ; 3 baking tray 25 min

P38 Pommes, fro‐

zen

0,75 kg ; 3 baking tray 25 min

Gratins, bread and pizza

P39 Meat / vegeta‐

ble lasagna

with dry noo‐

dle plates

1 - 1,5 kg ; casserole dish on 2 wire shelf 45 min

P40 Potato gratin

(raw potatoes)

1 - 1,5 kg ; casserole dish on 1 wire shelf

Rotate the dish after half of the cooking

time.

50 min

P41 Pizza fresh,

thin - ; lined with baking 2 baking tray

paper 15 min

P42 Pizza fresh,

thick - ; lined with baking 2 baking tray

paper

25 min

P43 Quiche - 2 wire shelf; baking tin on 45 min

P44 Baguette /

Ciabatta /

White bread

0,8 kg ; lined with baking3 baking tray

paper

More time needed for white bread.

30 min

22/44

DAILY USE

Produkt Specifikationer

Mærke:	Electrolux
Kategori:	Ovn
Model:	EOE6P77WX
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50-60 Hz
Bredde:	594 mm
Dybde:	568 mm
Højde:	594 mm
Produktfarve:	Rustfrit stål
Installationsrum bredde:	560 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	600 mm
Grill:	2300 W
Støjniveau:	45 dB
Energieffektivitetsklasse:	A+
Fingeraftryk resistent:	Ja
Ovn - størrelse:	Medium
Samlet indvendig ovn kapacitet:	72 L
Strøm for samtlige ovne:	3490 W
