E 116 PARTS LIST
2 x T-Bars
4 x Side Mount T-Collars
1 x Center “I” Support Bar
2 x Center Posts for Tri-Pod Stands
2 x 5” Truss I-Beam Sections w/Spigot
2 x 9” Tri-Pod Stands
6 x Safety Pins
1 Hexagon Allen Wrench
(Inserted in 5” Truss End)
E 116
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
PORTABLE TRUSSING SYSTEM
INSTRUCTIONS FOR ASSEMBLING YOUR E 116™:
Everything is included to assemble your E 116™.
1. Open up the two Tri-Pod Stands. There are two Center posts which are packed in the
E 116™ that need to be inserted into each Tri-pod stand. Tighten tri-pod knobs, leaving
inserted post exposed enough to mount Truss to top of bar.
2. Connect the two 5 ft. sections of Truss together using the spigots (flanges), mounting
screws and wing nuts attached to interconnect the two. There is a center support Bar that
has two T-collars attached to each end. This connects between the two 5 ft. sections. The
spigots fit inside of this. Remove the two screws and wing nuts and fit center support bar
onto the truss section with the spigots attached. Connect the other 5 ft. truss section and
insert screws and wing nuts. Tighten allen screws in the center support bar with the allen
wrench supplied.
3. Next, mount two Side mount T-Collars to each end of the 10 ft. truss assembly. Slide the
fully assembled truss piece onto each tri-pod center post. We suggest doing this on the
floor before standing up completed truss system: tighten all allen screws, knobs, and insert
safety pins. Once complete, stand system up on tri-pod legs extending them out so that the
lower tri-pod leg support bars are parallel to the ground.
4. Connect two T-bars at the top of each T-collar. Make sure there is enough room on the
center post above the T-collar to mount the T-bars.
5. We suggest setting the E 116™ at the desired height before mounting any fixtures to it.
Be sure to insert the three safety pins into each tri-pod.
Specifications: E 116™
Weight: 42 lbs.
System Capacity: 200 lbs.
Aluminum Diameter: 1 1/2
Warranty: 1 Year Limited Warranty
