User Manual: Windows I-Series AiO Interactive Signage
UM600086 Rev A, Page 1 of 45
USER MANUAL
Elo Touch Solutions
ESY15i2 15.6” Windows I-Series AiO Interactive Signage
ESY22i2 21.5” Windows I-Series AiO Interactive Signage
ESY15i5 15.6” Windows I-Series AiO Interactive Signage
ESY22i5 21.5” Windows I-Series AiO Interactive Signage
UM600086 Rev. A
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 2 of 45
Copyright © 2016 Elo Touch Solutions, Inc. All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language, in any form or by any means, including, but not
limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission
of Elo Touch Solutions, Inc.
Disclaimer
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its
Affiliates (collectively "Elo") makes no representations or warranties with respect to the contents
herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular
purpose. Elo reserves the right to revise this publication and to make changes from time to time in the
content hereof without obligation of Elo to notify any person of such revisions or changes.
Trademark Acknowledgments
Elo, Elo (logo), Elo Touch, Elo Touch Solutions, and TouchPro are trademarks of Elo and its Affiliates. Windows is a
trademark of Microsoft Corporation
.
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 3 of 45
Table of Contents
Read this first .......................................................................................................... 5
Product Description ............................................................................ 7
Precautions ......................................................................................... 7
I-Series Layout .................................................................................... 8
Elo Expansion Module (optional for POS capability) Layout ............... 9
Chapter 2: Getting Started ..................................................................................... 11
Unpacking the Windows I-Series AiO Interactive Signage ............... 11
General Mounting Information .......................................................... 12
Rear VESA Mount ............................................................................ 13
Chapter 3: Operation ............................................................................................. 14
General Information .......................................................................... 14
Front OSD Control Buttons ............................................................... 14
L.E.D. Functionality – POWER LED ................................................. 15
L.E.D. Functionality – Wireless LAN LED ......................................... 15
L.E.D. Functionality – Ethernet LED (i2 product shown) ................... 16
Using the Input/output Panel (i2 product shown) .............................. 16
Setting Up the Operating System ..................................................... 16
Creating the Recovery Flash Drive ................................................... 19
Recovering the Operating System .................................................... 23
Chapter 4: Options and Upgrades ....................................................................... 26
Optional Peripherals Kits .................................................................. 26
Magnetic Stripe Reader Kit (E001002) ............................................. 26
Near Field Communication Kit (E001004) ........................................ 28
Barcode Reader Kit (E093433) ......................................................... 30
I-Series 15.6” Stand Kit (E044162) ................................................... 32
I-Series 21.5” Stand Kit (E044356) ................................................... 33
I-Series Wall Mount Kit (E143088) .................................................... 34
Chapter 5: Technical Support ............................................................................... 34
Trouble Shooting for Common Problems .......................................... 35
Technical Assistance ........................................................................ 35
Chapter 6: Safety & Maintenance ........................................................................ 36
Safety ................................................................................................ 36
I-Series Care and Handling .............................................................. 37
Waste Electrical & Electronic Equipment .......................................... 38
Chapter 7: Regulatory Information ...................................................................... 39
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 4 of 45
Chapter 8: Warranty Information ......................................................................... 44
User Manual: Windows I-Series AiO Interactive Signage
UM600086 Rev A, Page 5 of 45
Read this first
Before using the I-Series for Windows, read the important safety and handling information (this
section), Safety & Maintenance (Chapter 6), Regulatory Notice (Chapter 7), and the Warranty
Information (Chapter 8) chapters in this user manual.
This section provides guidance on the safe handling and use of your I-Series for Windows.
Please read to understand all of the details.
ENERGY STAR Support information
Your touchcomputer is ENERGY STAR® qualified. Elo is a partner in the Environmental
Protection Agency’s (EPA) ENERGY STAR® Program and has designed the
computer to meet the latest ENERGY STAR® guidelines for energy efficiency.
Your touchcomputer ships with the power management options preset to a
configuration that will provide the most onment and optimum stable operating envir
system performance.
To conserve energy, your computer is set to dim the display after 5 minutes of inactivity, and
enter the low-power Sleep mode which shuts down the system after 30 minutes of inactivity. We
recommend that you leave this and other energy saving features active, so that your
touchcomputer will operate at its maximum energy efficiency. You can wake the touchcomputer
from Sleep mode by pressing the power button.
When considering additions to your business, purchase products that have earned the
ENERGY STAR® for all your equipment needs, which can save your money, save energy, and
help protect the climate.
Visit http://www.energystar.gov http://www.energystar.gov/powermanagement or for more
information regarding the ENERGY STAR® Program.
Important safety and handling information
To avoid personal injury, property damage, or accidental damage to your Elo I-Series for
Windows (hereafter referred to as the I-Series or touchcomputer), please read through all of the
information provided in this section before using the I-Series.
For detailed operating instructions, refer to the I-Series User Manual (this publication).
Protect your data and software:
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 6 of 45
Do not delete or change the name of files or directories that were not created by you; as this
may prevent the I-Series software from operating properly.
Be aware that accessing network resources can render your I-Series vulnerable to computer
viruses, hackers, spyware, and other malicious activities that might damage your I-Series,
software, or data. It is your responsibility to ensure that your I-Series has adequate protection
in the form of firewalls, antivirus software, and anti-spyware software and keep them up to
date.
Keep electrical appliances such as an electric fan, radio, high-powered speakers, air
conditioner, and microwave oven away from your I-Series because the strong magnetic fields
generated by these appliances can damage the screen and the data on the I-Series.
Take precautions with plastic bags:
The I-Series comes with plastic packaging material.
DANGER: Plastic bags can be dangerous. Keep plastic bags away from babies and
children to avoid danger of suffocation.
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 7 of 45
Chapter 1: Product Overview
This chapter provides an overview of the new Elo I-Series for Windows, including the locations
of the connectors and controls, I-Series features, accessories, specifications, and operating
environment.
Product Description
The new Elo I-Series for Windows combines Elo reliable performance with the latest
developments in touchscreen technology and display design. This combination creates a
natural flow of information between a user and the I-Series for Windows.
The I-Series for Windows provides a powerful, compact, and configurable interactive display in
two screen sizes: 15.6-inch, and 21.5-inch. These models are ruggedized and available with
our industry-leading Elo touch technology: TouchPro® PCAP (projective capacitive). Both 15"
and 22" I-Series models integrate with 1920x1080 LCD panel to provide superior display
performance for displaying images and running applications. The i2 models are fan-less —
well-suited for environments where noise may be an issue. The i5 models with the 6 th
generation Intel® CoreTM-i5 processor and HD530 graphics are fan-cooled and deliver
superior performance when needed.
The I-Series for Windows have a compact, stylish design, with a choice of configuration and
customer-installable peripheral options as well as ease of serviceability. These models support
multiple memory and storage configurations as well as optional accessories for purchase from
Elo.
Precautions
Follow all warnings, precautions and maintenance tips as recommended in this user manual to
maximize the life of your unit and prevent risks to user safety. See Chapter 6 for more
information on safety.
This manual contains information that is important for the proper setup and maintenance of the
I-Series for Windows. Before setting up and powering on your new I-Series, please read
through this manual in detail seriously and carefully.
User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 8 of 45
I-Series Layout
ESY I-Series 15.6”/21.5” Models (i2 product shown)
I-Series 15.6”/21.5” front view (left) and clerk right side view (right)
I-Series 15.6”/21.5” back view (top) and rear IO view (bottom)
1
4 6
2
5
3
789 10 11 12
