Integrated Amplifier I - 0 3
Highly rigid, chassis construction that
inherits the K series engineering concept
*MSW= Master Sound Works
High sound quality structure from a multiple chassis design
Each circuit block is placed in a dedicated compartment. The
compartments are assembled three-dimensionally to minimize
interference between circuits and use the shortest signal paths.
The internal chassis is divided into five parts, with two separate
preamplifier boards for each channel mounted in dedicated
compartments closest to the rear connectors. This design
keeps the audio signal path short and direct. Two Esoteric MSW
power amplifier blocks are connected from the preamplifier
using the shortest signal path. These blocks are assembled in
dedicated compartments on both sides of the chassis and
mounted via aluminum plates on both side panels. Using the
side panels as heat sinks, this integrated amplifier efficiently
discharges heat without compromising its sleek form.
High-capacity power transformer and power section layout
for highest quality sound
The heavy-duty class, high-capacity power transformer is
installed in the center and fixed with a 5-mm thick steel base
plate on the bottom chassis. Also, the entire body is supported
at three points on Esoteric original pinpoint feet* to reduce
vibration and maximize high rigidity. Each component of this
integrated amplifier incorporates the housing design and
know-how applied for the K series (Super Audio CD/CD Player
K-01 and K-03). Esoteric has meticulously pursued high sound
quality and functionality up to the point of the placement of each
component. Esoteric has paid a lot of attention to details, even
in the unseen inner portions of this amazingly heavyweight, 31
kg (68.3 lbs.) integrated amplifier model I-03.
* Patent 4075477
Bold and delicately sleek round body form
Like the K series, this integrated
amplifier has inherited the round form
design of Esoteric flagship models.
Thick aluminum material has been used
for the front, top, side panels and front
corners. The preamplifier volume
control and input selector have been
machined from large-size aluminum
blocks. Precisely tooled, rounded ergonomic design offer both a
sleek appearance combined with an ideal balance of opera-
tional control.
ESOTERIC COMPANY
1-47 Ochiai, Tama-shi, Tokyo 206-8530, Japan
Fax: (042)356-9240
www.esoteric.jp
www.esoteric.teac.com/
Please note that Esoteric products are available at limited distributors in respective countries．
ESOTERIC is a trademark of TEAC Corporation, registered in the U.S. and other countries. Other company names, product name and logos are the trademarks or
registered trademarks of their respective owners.
©2011 TEAC Corporation. All Rights Reserved．All text, images, graphics and other materials on this catalogue are subject to the copyright and other intellectual
property rights of TEAC Corporation．These materials shall not directly or indirectly be published, reproduced, modified or distributed in any medium．
Design and specifications are subject to change without notice．
PRINTED IN JAPAN 0511T03•TECD-0133
Specifications
Speaker Outputs
Rated output power 180 W + 180 W (1 kHz, 8 Ω)
240 W + 240 W (1 kHz, 6 Ω)
300 W + 300 W (1 kHz, 4 Ω)
Maximum output power 250 W + 250 W (1 kHz, 0.1 %, 8 Ω)
320 W + 320 W (1 kHz, 0.1 %, 6 Ω)
380 W + 380 W (1 kHz, 0.1 %, 4 Ω)
Total harmonic distortion 0.03 % (1 kHz, 6 Ω)
Frequency response 5 Hz - 70 kHz (+1 dB, –3 dB, 6 Ω)
Signal-to-noise ratio (S/N) 110 dB (JEITA)
Minimum required impedance
4 Ω
Speaker output terminals Binding posts x 1 stereo
Analog audio inputs
Jacks RCA jacks x 3 stereo
RCA2: can be connected to an AV-amplifer’s pre-output
RCA3: can be switched among LINE, PHONO MM and PHONO MC
XLR jacks x 2 stereo
Input impedance LINE: 100 kΩ / PHONO MM: 47 kΩ / PHONO MC: 100 Ω
Analog audio outputs
Jacks RCA jacks x 1 stereo
Output impedance 470 Ω
General
Power supply AC 230V 50Hz / AC 120V 60Hz / AC 220V 60Hz
Power consumption 280 W
External dimensions (W x H x D) 445 x 162 x 468 mm (17 1/2” x 6 3/8” x 18 3/8” )
( including protrusions )
Weight 31 kg (68 lb)
- This product is available in three different power supply variations shown
in the chart above. Make sure that the voltage shown on the rear panel
matches the AC line voltage in your area.
- The shape of the AC inlet and plug of the supplied power cord depends
on the voltage rating and destination country.
