The connection should be carried out by a qualified electrician.
SAVE THESE INSTRUCTIONS
INSTALLATION AND OPERATION:
1. Slide output diffuser (C) on round opening on lower portion of skimmer body (B).
2. Thread and secure electrical cord with cord clip (F).
3. Position surface skimmer in an area of the aquarium with the least flow.
4. Position surface skimmer within aquarium below water level, while ensuring the neck of
the floating intake assembly (A) extends above skimmer body by approximately 1” / 2.5 cm.
The floating intake assembly is self-levelling and will adjust as water evaporates. Once in
position, secure surface skimmer to interior aquarium wall using the 3 suction cups provided.
5. To avoid levelling issues, ensure electrical cord and floating intake assembly do not
come into contact with each other.
6. Plug in power cord to begin surface skimmer operation.
7. Adjust skimming intensity by turning intake regulator dial (D).
8. Regulate flow strength by adjusting the flow control slider (E).
MAINTENANCE:
1. CAUTION: Unplug all appliances in the aquarium before carrying out maintenance.
2. Remove surface skimmer from aquarium.
3. Detach skimmer body from motor, remove and rinse sponge (every few weeks).
Rinse more frequently in aquariums with heavier surface film accumulation.
4. Impeller should be cleaned monthly to ensure optimal functionality.
Yearly replacement is recommended (Item #A16685).
5. Calcium build-up on surface skimmer parts may be removed by adding a mix of
water and vinegar into a bucket and soaking components. Never submerge electrical plug.
6. Rinse components thoroughly with fresh water.
7. Once maintenance is completed, reassemble surface skimmer and reinstall
using instructions above.
FOR AUTHORIZED GUARANTEE REPAIR SERVICE:
For Authorized Warranty Service please return (well packaged and by registered post) to
the address below enclosing dated receipt and reason for return. If you have any queries or
comments about the operation of this product, please let us try to help you before you return
the product to your retailer. Most queries can be handled promptly with a phone call. When you
call (or write), please have all relevant information ready, such as model number, age of product,
details of aquarium set-up, as well as the nature of the problem.
CANADA: Rolf C. Hagen Inc., Consumer Repair, 20500 Trans Canada Hwy,
Baie-D’Urfé QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind Est.,
Castleford West Yorkshire WF10 5QH
CALL US ON OUR TOLL-FREE NUMBER:
Canada only: 1-800-554-2436 between 9:00 a.m. and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. only: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. only: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM,
Monday to Thursday and 9:00 AM and 4:00 PM on Friday (excluding Bank Holidays).
Instruction Manual
Mode d’emploi
Manual de instrucciones
ENGLISH
CONGRATULATIONS! Thank you for purchasing the Fluval SK400 Surface Skimmer. For a complete
understanding of the Surface Skimmer’s operation and capabilities, please read and follow these instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING - To guard against injury, basic safety precautions should be observed,
including the following:
1.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
and all important notices on the appliance before using. Failure to do so may result
in damage to the unit.
2. DANGER - To avoid possible electric shock, special care should be taken since water
is employed in the use of aquarium equipment. For each of the following situations,
do not attempt repairs yourself; return the appliance to an authorized service facility
for service or discard the appliance.
A. If the appliance shows any sign of abnormal water leakage or if RCD (or GFCI-
Ground Fault Current Interrupter) switches off, disconnect the power supply
cord from mains and remove the skimmer from the water.
B. Carefully examine the appliance after installation. It should not be plugged if there is
water on parts not intended to be wet.
C. Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning
or it is dropped or damaged in any manner. The power cord of this appliance cannot
be replaced; if the cord is damaged, the appliance should be discarded. Never cut the cord.
D. WARNING: To avoid the possibility of the appliance plug or receptacle getting
wet, position the appliance to one side of a wall mounted receptacle to prevent water
from dripping onto the receptacle or plug. A “drip loop”
should be arranged by the user for the cord connecting appliance
to a receptacle. The is that part of the cord below “drip loop”
the level of the receptacle or the connector if an extension cord
is used, to prevent water from travelling along the cord and
coming in contact with the receptacle. If the plug or receptacle
does get wet, unplug the cord. Disconnect the fuse or DON’T
circuit breaker that supplies power to the appliance. Then unplug
and examine for presence of water in receptacle.
3. WARNING: This appliance can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of appliance in a safe way
and understand the hazards involved. Children shall not play with the appliance.
Close supervision is necessary when any appliance is used by or near children.
Cleaning and user maintenance shall not be made by children without supervision.
4. To avoid injury, do not touch moving parts or hot parts.
5. CAUTION: Always unplug or disconnect all appliances in the aquarium from
electricity supply before placing hands in water, before putting on or taking off parts
and whilst the equipment is being installed, maintained or handled. When inserting
or removing the skimmer from the water, always pull out the main electricity plug.
Never yank cord to pull plug from outlet. Grasp the plug and pull to disconnect.
Always unplug an appliance from an outlet when not in use.
6. This is an aquarium skimmer. Do not use this skimmer for other than intended use
(i.e.: do not use in swimming pools, bathrooms, etc.). The use of attachments not
recommended or sold by the appliance manufacturer may cause an unsafe condition.
• This skimmer is suitable for use in water temperatures up to 35 °C.
• Do not use this skimmer with flammable or drinkable liquids.
7. This skimmer is suitable for use only. Do not install or store the INDOOR/HOUSEHOLD
appliance where it will be exposed to the weather or to temperatures below freezing.
8. Make sure that the skimmer is securely installed before operating it. Do not allow
skimmer to run dry. The skimmer must be immersed in water completely. This
skimmer must never operate outside of water.
9. WARNING: For North American market only. This appliance has a polarized plug
(one blade is wider than the other). As a safety feature, this plug will fit in a polarized
socket only one way. If the plug does not fit fully in the socket, reverse the plug. If it
still does not fit, contact a qualified electrician. Never use with an extension cord
unless plug can be fully inserted. Do not attempt to defeat this safety feature.
10. If an extension cord is necessary, a cord with proper rating should be used.
A cord rated for less amperes or watts than the appliance rating may overheat.
Care should be taken to arrange the cord so that it will not be tripped over or pulled.
A
D
B
C
E
F
DRIP LOOP
AQUARIUM
TANK
FRANÇAIS
FÉLICITATIONS. Merci d’avoir acheté l’écumeur de surface SK400 Fluval. Pour profiter pleinement
de cet appareil et en comprendre entièrement les fonctions et l’usage, veuillez lire et suivre
les présentes directives.
MESURES DE SÉCURITÉ IMPORTANTES
MISE EN GARDE - Pour éviter toute blessure, il faut observer des précautions
élémentaires de sécurité, notamment celles qui suivent :
1.
LIRE ET RESPECTER TOUTES LES MESURES
DE SÉCURITÉ
et tous les avis importants indiqués sur l’appareil
avant de l’utiliser. Le non-respect de ces instructions peut entraîner des dommages
à l’appareil.
2. DANGER - Pour éviter tout risque de choc électrique, il faut faire preuve de la plus
grande prudence, puisque de l’eau est utilisée avec l’équipement pour aquariums.
Dans chacune des situations suivantes, ne pas essayer de réparer l’appareil
soi-même; le retourner plutôt à un service de réparations autorisé ou le jeter.
A. Si l’appareil montre un signe de fuite d’eau anormale ou si le dispositif
différentiel (ou disjoncteur de fuite de terre) s’éteint, débrancher le cordon
de la prise murale et retirer ensuite l’appareil de l’eau.
B. Examiner attentivement l’appareil après l’installation. Ne pas le brancher s’il y a
de l’eau sur des pièces qui ne doivent pas être mouillées.
C. Ne pas utiliser un appareil dont la fiche ou le cordon sont endommagés, qui ne
fonctionne pas bien ou qui est tombé ou qui a été endommagé de quelque manière
que ce soit. Le cordon d’alimentation de cet appareil ne peut pas être remplacé;
si le cordon est endommagé, il faut jeter l’appareil. Ne jamais couper le cordon.
D. AVERTISSEMENT : Pour éviter toute possibilité que la fiche
de l’appareil ou la prise soient mouillées, placer l’appareil
près d’une prise de courant murale afin d’empêcher l’eau
de s’écouler dans la prise. L’utilisateur doit former une
« boucle d’égouttement » avec chaque cordon
d’alimentation qui relie un appareil à la prise. La « boucle
d’égouttement » est la partie courbée du cordon d’alimentation
qui se trouve sous la prise, ou le raccord si une rallonge est
utilisée, afin d’éviter que l’eau s’écoule le long du cordon et
entre en contact avec la prise. Si la fiche ou la prise de courant sont mouillées,
NE PAS débrancher le cordon. Mettre d’abord hors circuit le fusible ou le disjoncteur
qui fournit l’électricité à la prise, puis débrancher l’appareil. Vérifier qu’il n’y a pas
d’eau dans la prise.
3. AVERTISSEMENT : Cet appareil peut être utilisé par des personnes aux
capacités physiques, sensorielles ou mentales réduites, ou qui manquent
d’expérience et de connaissances, si elles sont sous la surveillance d’une
personne responsable de leur sécurité ou qu’elles ont reçu les directives nécessaires
à l’utilisation de cet équipement. Toujours surveiller les enfants pour les empêcher
de jouer avec l’appareil. Une surveillance étroite doit être exercée lorsque l’appareil
est utilisé par ou près des enfants. Le nettoyage et l’entretien ne doivent pas être
effectués par des enfants sans surveillance.
4. Afin d’éviter les blessures, ne pas toucher de pièces mobiles ou chaudes.
5. ATTENTION : Toujours débrancher tous les appareils à l’intérieur de l’aquarium de
la prise de courant avant de se mettre les mains dans l’eau, d’insérer ou de retirer
des pièces et avant d’installer, d’entretenir ou de manipuler l’équipement.
Lorsqu’on insère ou retire l’écumeur de surface de l’eau, toujours le débrancher
de la source principale de courant. Ne jamais tirer sur le cordon d’alimentation
pour débrancher l’appareil. Prendre plutôt la fiche entre les doigts, puis la tirer.
Toujours débrancher les appareils de la prise de courant quand ils ne sont pas utilisés.
6. Cet appareil est un écumeur pour aquariums. Ne pas utiliser cet écumeur pour un
usage autre que celui pour lequel il a été prévu (c.-à-d. ne pas l’utiliser dans des piscines,
des baignoires, etc.). L’utilisation d’accessoires ni recommandés ni vendus par le
fabricant de l’appareil peut être source de situations dangereuses.
• Cet appareil convient à des aquariums dont la température de l’eau est d’au plus 35 °C.
• Ne pas utiliser l’écumeur avec des liquides inflammables ou potables.
BOUCLE
D’ÉGOUTTEMENT
BAC DE
L’AQUARIUM
2 YEAR STANDARD WARRANTY
The Fluval SK400 Surface Skimmer is guaranteed for defective parts and workmanship for a period of two years
from the date of purchase. This guarantee is valid with proof of purchase only. The guarantee is limited to repair
or replacement only and does not cover consequential loss, loss or damage to livestock and personal property or
damage to animate or inanimate objects, irrespective of the cause thereof. This guarantee is valid only under normal
operating conditions for which the unit is intended. It excludes any damage caused by unreasonable use, negligence,
improper installation, tampering, abuse or commercial use. The warranty does not cover wear and tear or parts
which have not been adequately or correctly maintained. THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
BONUS +1 YEAR
LIMITED TIME OFFER!
Register this product online within 30 days of purchase and Fluval will extend your
current warranty at no charge. The extended warranty is subject to provisions outlined within the standard Fluval
warranty. Complete details and registration available at:
EXTENDED
WARRANTY
FluvalAquatics.com/warranty
Flow Rate Aquarium
Capacity
Input
Voltage Wattage Dimensions
NA
105 US GPH
400 LPH
105 US Gal
400 L
120v/60Hz 3.3W 1.7" L x 2.7" W x 5.8" H
4.3 x 6.8 x 14.7 cm
EU
380 LPH 400 L 220-240v/50Hz 2.8W 4.3 L x 6.8 W x 14.7 cm H

Produkt Specifikationer

Mærke: Fluval
Kategori: Ikke kategoriseret
Model: SK400

Har du brug for hjælp?

Hvis du har brug for hjælp til Fluval SK400 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Fluval Manualer

Fluval

Fluval SK400 Manual

7 November 2024
Fluval

Fluval P10 Manual

30 August 2024
Fluval

Fluval P25 Manual

30 August 2024
Fluval

Fluval ProVac Manual

13 Juli 2024
Fluval

Fluval Bio-CO2 Pro Manual

13 Juli 2024
Fluval

Fluval PF2 Manual

10 Juli 2024
Fluval

Fluval CO2 Manual

10 Juli 2024
Fluval

Fluval Aquasky Manual

16 Juni 2024
Fluval

Fluval Sea Manual

16 Juni 2024
Fluval

Fluval Plant Spectrum LED Manual

16 Juni 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Elektron

Elektron Overbridge Manual

26 November 2024
Elektron

Elektron Sidstation Manual

26 November 2024
SKROSS

SKROSS World Adapter Pro+ Manual

26 November 2024
SKROSS

SKROSS PRO – World & USB Manual

26 November 2024
SoundTube

SoundTube IPD-RS82-EZ Manual

26 November 2024
Kramer

Kramer 4x1VB Manual

26 November 2024
Kramer

Kramer RC-63A Manual

26 November 2024
SoundTube

SoundTube IPD-HP82-EZ Manual

26 November 2024
Kramer

Kramer RK-KVM-1U-PP3 Manual

26 November 2024
Gioteck

Gioteck VX-2 (PS3) Manual

26 November 2024
