Model No.:
GLR76TBKE/GLR76TS1E/GLR76TWEE
1
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
User notification s
Instructions for usage
Disconnecting the appliance
Limited warranty
Instructio n for the door closer
13
14
Maintenanc e
2
NOTICE:
When gas leaks from its container, don't pull the plug, out or in, for it may
spark and cause a fire hazard.
1.
Don't place bottled beverage in the freezer, so as to prevent breaking.
Don't splash water on the rear of the appliance, for it may cause malfunction
or electric shock.
2.
3. Don't store inflammabe materials such as ether, benzene, LP gas and glue
etc in the refrigerator.
4.
5.
The refrigerant of this product is R600a,which is inflammable. So,make sure not to
damage the cooling system during the transportation and installation.
DISPOSAL:Do not dispose this product as unsorted
municipal waste.Collection of such waste separately
for special treatment is necessary.
6.
7.
It is better not place object on the top of appliance which is magnetic, heavy, or filled
with water. Electronic components may not work steadily if water gets inside.
Do not store object which is costly or dangerous , e.g. serum, bacterin and so on.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
4
INSTR UCTION FOR USAG E
The temperature of refrigerator can be controlled manually by the knob. However,
the number shown on the knob does not directly represent the temperature. Instead,
the larger the number is, the lower the interior temperature will be. 0 stands for off. Turn
the knob to level 4 when it is normal, turn it to the level 4-7 if a lower interior temperature
is required; contrarily, lower to 4-1, when a higher one is needed.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
6
Discontinuation during vacation
Please remove the easily rotten food from the fridge before short vacation. After
confirmation, close the door firmly. For a long vacation, please remove all the food and
cut off the power. After defrosting, clean up the liner of the appliance and wipe it dry, and
leave the door open.
2.
Under gen eral condito n do not stop an d restart the appliance
frequently. After switching off the pow er, please leave at leas t 5
minutes b efore resumption.
Attention
Stop using
If the refrigerator is stopped after using for a long time, please unplug the outlet and
clean up the appliance. The door should be kept open in order to prevent unpleasant
smell caused by food remnants.
3.
USER NOTIFICATIONS
Do not splash water on the refrigerator, as it will cause oxidation and malfunction.
Electronic component such as on/off button should be wiped dry.
Cleansers such as soap powder, abrasive cleaning powder, alkali cleansers, chemical
cloth, alcohol, acid petroleum product and hot water should not be used to
clean the refrigerator as they may damage the painted cover and plastics.
Smear can damage the interior plastic component, so wipe it as soon as possible.
1.
2.
3.
Please check the points below after maintenance:
(1) Is there any damage or loss of the electronic wire ?
(2) Can the plug be put in the socket reliably and smoothly?
(3) Is the plug heating unconventionally?
4.
Please get rid of the gasket of the door before the disposal.
The disposed apparatus should be handled by professional
staff, as it may be harmful to the environment.
Warning
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
8
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
14.slightly backward the machine
against the wall.
15.Take off the 2 fixed feet
16.Take off the bottom hinge.
17.Assemble the bottom hinge in
the other side of the machine.
18.Fixed up the feet.
19.Exchange the 2 bolts and fixed
them in the other sides.
20.Remove the fixed plate of hinge
on the bottom door, and fix it on
the other side.
21.Fix up the bottom door on the
outside bolts.
22.Fix up the middle hinge on the
bottom door.
23.Put the bottom door into the left
side in correct way.
24.Close the bottom door.
12.Remove the middle hinge.
13.Use a solid plug around the hole to pull
it out.Pull out the plug ho le and save
them in some s pace.
10
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
12
INSTRUCTIONS FOR DOOR CLOSER
The left door closer The right door closer Tapping screws
1. Remove the tapping screws of the right door closer, and take out the right door closer.
2. Install the left door closer, and fix the door closer on the door through the tapping screws.
The door is set to open from the left side. If the door is switched to open from the right side,
then please follow the below instructions:
The displacement of interior light Uninstall the cover and replace the light with a
screwing light (E12 , 120V/10W)，Consult the following pictures：
2.Meanwhile take another side
as the center to rotate the lamp shade outwards.
1. Pry the bolt on the thermostat
away from the lamp shade about 2mm with the tool.
4.Rotate and take out the bulb in
counterclockwise direction.
3.Take out the lamp shade along
the direction of the arrow.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
14
800-562-0738
528429
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
3
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
5
DISCONNECTING THE APPLIANCE
Discontinuation during power failure
After power failure, do not put additional food in the appliance and reduce the frequency
of door opening.Make ice in a container if the power failure is known beforehand.
1.
After power failure, even in summer, the refrigerator can store food normally for several
hours.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
7
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
9
You can choose to open your refrigerator by the right side or the left one
To change the way of opening, please follow the below instructions
Important safety warning: before doing so please unplug and
disconnect the appliance
Except the Accessories packed, you still need：
Medium-sized cross screwdriver
Small screwdriver
A solid line
One more person who can help you
would be better.
1.Firstly, you need to check if the
power connect or not.
2.Open the upper door, and close
the bottom door.
3.Take off the protective covers on both
sides of upper cover with a Phillips
screwdriver through the back side,
and save the protective covers.
7.Slightly tilted the upper hinge in
order to remove it from the door.
8.Open the bottom door.
9.Take out the bottom door and save it.
10.Take off the 2 screws and save them.
11.Open the door in order to take
off the bottom hinge and save it.
5.Push the door and door hinge
forward,remove the door and save
it aside.
6.Take off the third shelf-tapping
screw and save it.
4.Take off the 2 shelf-tapping
screws on the left side of door hinge,
and save them.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
11
27.Fixed up the upper door in door
bolt which is near the middle
hinge.
28.Twist the upper hinge carefully
inside the blank position of the
door.
29.Fix up the upper hinge with
screw B, and fix up the
self-tapping screw A.
30.Assemble the protective box in the
upper cover of the upper door.
31.Check all parts of the door if they
are fixed up enough. You can use
a paper insert inside every parts
of the door related, see if the paper
drop down easily, make sure the
paper won't drop down.
32.If the tightness on every parts is
uniformly, you can pull the obstructions
by hand after hitting with hair-dryer in
related parts which has problem.
26
hinge on the door opening position,
but not fixed.
.Put the self-tapping screws in the
25.Take off the right closer and fix
the left closer in the other side
of the upper door.
The appliance should be maintained and cleaned frequently. For your safety,do
please pull the plug out of the socket before the cleaning.
Interior maintenance
Clean the interior of the appliance with clean water or neutral abluent.Scour it with
clean water and wipe it with a piece of dry cloth.
Maintenance of door gasket
It is easy to damage if the door gaskets are polluted by the stain like oil, sauce and
etc., so it is better to clean them carefully.
Outer maintenance
Wipe the dusty with a piece of dry cloth ,clean it with neutral abluentif necessary.
MAINTENANCE
1.
2.
3.
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
13
1.6
6.0
1.4
0.95
R600a/1.23 oz
99.21 lbs
22.36
55.59
21.61
KW.h/24h
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
Compact Refrigerator
SAVE THIS INFORMATION FOR FUTURE REFERENCE
Important notice: Pl ease keep this appliance standing upright
during transportation. If the unit must be laid on its side at any ti me,
pleas e stand the appliance up right fo r at leas t 4 hours b efore us ing.
For all consumer questions or inquiries, contact our please U.S.
800-562-0738 .
customer service line at
Refrigerator Use and Care Manual Support:800-562-0738GLR76TBKE/GLR76TS1E/GLR76TWEE
