Side 1/14
Step 1 Verify Your Gas Installation (see section 2).
Step 2 Prepare the Area and Exhaust for Installation of New
Dryer (see section 1) .
Step 3 Check and Insure the Existing External Exhaust is
Clean (see section 1) and Meets Attached Installation
Speci ications. (see section 6)f .
Step 4 Remove the Foam Shipping Pads (see section 1).
Step Mo the Dryer to the Desired Location 5 ve .
Step 6 Level Your Dryer (see section 8).
Ste Conne the Gas Supply (see section and heck fop 7 ct 3) c r
leaks (see section 4) .
Step Connect the External Exhaust (see section 7) 8 .
Step Connect the er Supply (see section 5) 9 Pow .
Step 10 Check the Operation of the Power Supply, Gas
Connections, and Venting.
Step 11 Place the Owners Manual and the Installation
Inst uctions in Location Where They illr a W Be
Noticed By the Owner.
For Alcove or Closet Installation see section 9.
For Bathroom or Bedroom Installation see section 10.
For Mobile or Manufactured Home see section 11.
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
If you ha ve any questions, call 1- -GECARES (US)800 or 1- -561-3344 (Canada800 )
or Vis it our Web si te a t: www. c .com GEApplian es (US)
Installation
Instructions
Gas Dr rye
10
PEDESTALS FOR DRYERS
(comes with individual installation instructions)
3 models available:
500A436P010 Pub# 31-16229
In the state of Massachusetts, installation must be performed by a qualified or
licensed contractor, plumber, or gasfitter qualified or licensed by the state.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
IMPORTANT- Save these
instructions for local inspector’s use.
•
IMPORTANT- Observe
all governing codes and ordinances.
•
Note to Installer- Be sure to leave these
instructions with the customer.
•
Note to Customer- Keep these
instructions with your Use and Care Book
for future reference.
•
Before the old dryer is removed from
service or discarded, remove the dryer door.
•
Service information and the wiring diagram
are located in the control console.
•
D
o not allow children on or in the appliance.
Close supervision of children is necessary
when the appliance is used near children.
•
Install the dryer where the temperature is
above 50°F for satisfactory operation of
the dryer control system.
•
•Inspect the dryer exhaust outlet and
straighten the outlet walls if they are bent.
MATERIALS YOU WILL NEED
LEVEL
8" PIPE WRENCH
EXHAUST HOOD
FLEXIBLE GAS LINE CONNECTOR
SOAP SOLUTION
FOR LEAK DETECTION
PIPE
COMPOUND
DUCT TAPE
GLOVES
SAFETY GLASSES
4" DIAM METAL ELBOW
10" ADJUSTABLE WRENCHES
(x2)
4" DUCT CLAMPS
OR
4" SPRING CLAMPS
(x2)
(x2)
TOOLS YOU WILL NEED
SLIP JOINT PLIERS FLAT BLADE SCREWDRIVER
4" DIA. FLEXIBLE METAL (SEMI-RIGID)
UL LISTED TRANSITION DUCT
(IF NEEDED)
KIT WX08X10077 (INCLUDES 2 ELBOWS)
4" DIA. METAL DUCT
(RECOMMENDED)
4" DIA. FLEXIBLE METAL (FOIL TYPE)
UL LISTED TRANSITION DUCT
(IF NEEDED.)
To reduce the risk of severe injury or death, follow all installation instructions.
• Clothes dryer installation must be performed by a qualified installer.
• Install the clothes dryer according to these instructions and in accordance with local codes. In
the absence of local codes, installation must comply with National Fuel Gas Code,
ANSIZ223.1/NFPA 54 or the Canadian Natural Gas and Propane Installation Code, CSA B149.1.
• This dryer must be exhausted to the outdoors.
This act requires the governor of California to publish a list of substances known to the state to
cause cancer, birth defects or other reproductive harm and requires businesses to warn
customers of potential exposure to such substances. Gas appliances can cause minor
exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde and
soot, caused primarily by the incomplete combustion of natural gas or LP fuels. Properly
adjusted dryers will minimize incomplete combustion. Exposure to these substances can be
minimized further by properly venting the dryer to the outdoors.
•
California Safe Drinking Water and Toxic Enforcement Act
• Use only 4” rigid metal ducting for exhausting the clothes dryer to the outdoors.
• Do not install or store this appliance in any location where it could be exposed to water and or
weather.
• Save these instructions. (Installers: Be sure to leave these instructions with the customer).
• DO NOT install a clothes dryer with flexible plastic ducting materials. If flexible metal (semi-
rigid or foil-type) duct is installed, it must be UL-listed and installed in accordance with the
instructions found in "Connecting The Dryer To House Vent" on page 6 of this manual. Flexible
ducting materials are known to collapse, be easily crushed, and trap lint. These conditions will
obstruct dryer airflow and increase the risk of fire.
- R K F REIS O FI
WARNING
•
SBSD227F, SBSD137H
SBSD107H
