Side 1/56
183D5580P243 49-85161 01-09 JR
GEAppliances.com
Write the model and serial
numbers here:
Model # ____________________
Serial #______________________
You can find them on a label on
the front of the range behind the
storage drawer or kick panel.
Safety Instructions . . . . . .2–7
Operating Instructions
Aluminum Foil . . . . . . . . . . . . . . . .15
Clock and Timer . . . . . . . . . . .17, 18
Oven . . . . . . . . . . . . . . . . . . . . . .12–25
Baking and Roasting . . . . . . . .15
Broiling, Broiling Guide . . . . . . .16
Oven Control . . . . . . . . . . . . .12, 13
Power Outage . . . . . . . . . . .14, 18
Preheating . . . . . . . . . . . . . . . . . . .15
Sabbath Feature . . . . . . . . .21, 22
Self-Cleaning . . . . . . . . . . . . .24, 25
Special Features . . . . . . . . . . . . .20
Thermostat Adjustment . . . . .23
Timed Baking
and Roasting . . . . . . . . . . . . . . . .19
Surface Cooking . . . . . . . . . . . . .8, 9
Griddle . . . . . . . . . . . . . . . . . . .10, 11
Care and Cleaning
Burner Assembly . . . . . . . . . .27–29
Burner Grates . . . . . . . . . . . . . . . . .29
Control Panel and Knobs . . . . .32
Cooktop Surface . . . . . . . . . . . . . .29
Door Removal . . . . . . . . . . . . . . . . .30
Griddle . . . . . . . . . . . . . . . . . . . . . . . .26
Kick Panel . . . . . . . . . . . . . . . . . . . . .31
Oven Bottom . . . . . . . . . . . . . . . . .30
Oven Light Replacement . . . . . .33
Oven Vents . . . . . . . . . . . . . . . . . . .32
Self-Cleaning . . . . . . . . . . . . . .24, 25
Racks . . . . . . . . . . . . . . . . . . . . . . . . .33
Stainless Steel Surfaces . . . . . . .29
Storage Drawer . . . . . . . . . . . . . . .31
Installation
Instructions . . . . . . . . . . . .34–45
Air Adjustment . . . . . . . . . . . . . . . .44
Anti-Tip Device . . . . . . . . . . . .37, 45
Checking Burner Ignition . . . . . .43
Connecting the Range
to Gas . . . . . . . . . . . . . . . . . . . .38–40
Dimensions and Clearances . .36
Electrical Connections . . . . .41, 42
Leveling the Range . . . . . . . . . . .44
Location . . . . . . . . . . . . . . . . . . . . . .37
LP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Troubleshooting
Tips . . . . . . . . . . . . . . . . . . . . . .46–49
Accessories . . . . . . . . . . . . . . . .50
Consumer Support
Consumer
Support . . . . . . . . . . . . . .Back Cover
Ownership Registration
for Customers in
Canada only . . . . . . . . . . .51, 52
Warranty for Customers
in Canada . . . . . . . . . . . . . . . . . . . . .55
Warranty for Customers
in the U.S.A. . . . . . . . . . . . . . . . . . .54
Ranges
JGBP36
JGBP86
JGBP87
RGB735
RGB740
RGB745
RGB746
RGB790
Owner’s Manual
& Installation
Instructions
Self-Cleaning Gas
In Canada contact us at:
www.GEAppliances.ca
Consumer SupportOperating Instructions
Safety Instructions
Installation
Instructions Troubleshooting Tips
3
GEAppliances.com
WARNING!
Have the installer show you the location of the range gas shut-off valve and how to shut it off
if necessary.
■Have your range installed and properly
grounded by a qualified installer, in
accordance with the Installation Instructions.
Any adjustment and service should be
performed only by qualified gas range
installers or service technicians.
■Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other service
should be referred to a qualified technician.
■Plug your range into a 120-volt grounded
outlet only. Do not remove the round
grounding prong from the plug. If in doubt
about the grounding of the home electrical
system, it is your personal responsibility and
obligation to have an ungrounded outlet
replaced with a properly grounded,
three-prong outlet in accordance with
the National Electrical Code. Do not use
an extension cord with this appliance.
SAFETY PRECAUTIONS
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause birth defects or other reproductive harm, and
requires businesses to warn customers of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon
monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or
LP fuels. Properly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize
incomplete combustion. Exposure to these substances can be minimized by venting with an open
window or using a ventilation fan or hood.
■Locate the range out of kitchen traffic path
and out of drafty locations to prevent poor air
circulation.
■Be sure all packaging materials are removed
from the range before operating it to prevent
fire or smoke damage should the packaging
material ignite.
■Be sure your range is correctly adjusted by
a qualified service technician or installer for
the type of gas (natural or LP) that is to be
used. Your range can be converted for use
with either type of gas. See the Installation
of the range section.
■WARNING: These adjustments
must be made by a qualified service
technician in accordance with the
manufacturer’s instructions and all codes
and requirements of the authority having
jurisdiction. Failure to follow these instructions
could result in serious injury or property
damage. The qualified agency performing
this work assumes responsibility for the
conversion.
■After prolonged use of a range, high floor
temperatures may result and many floor
coverings will not withstand this kind of use.
Never install the range over vinyl tile or
linoleum that cannot withstand such type
of use. Never install it directly over interior
kitchen carpeting.
■Do not leave children alone or unattended
where a range is hot or in operation. They
could be seriously burned.
■Do not allow anyone to climb, stand or hang
on the oven door, storage drawer, warming
drawer or cooktop. They could damage the
range and even tip it over, causing severe
personal injury.
■ CAUTION: Items of interest
to children should not be stored in cabinets
above a range or on the backsplash of
a range—children climbing on the range
to reach items could be seriously injured.
■Never wear loose fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored in cabinets over the
range. Flammable material could be ignited
if brought in contact with flame or hot oven
surfaces and may cause severe burns.
■Do not store flammable materials in an oven,
a range storage drawer, a warming drawer
or near a cooktop.
■Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
■Do not let cooking grease or other flammable
materials accumulate in or near the range.
■Do not use water on grease fires. Never pick
up a flaming pan. Turn the controls off.
Smother a flaming pan on a surface burner
by covering the pan completely with a well-
fitting lid, cookie sheet or flat tray. Use a
multi-purpose dry chemical or foam-type
fire extinguisher.
■Flaming grease outside a pan can be put
out by covering it with baking soda or,
if available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■Flame in the oven can be smothered
completely by closing the oven door and
turning the control to off or by using a multi-
purpose dry chemical or foam-type
fire extinguisher.
■Let the burner grates and other surfaces cool
before touching them or leaving them where
children can reach them.
■Never block the vents (air openings) of the
range. They provide the air inlet and outlet
that are necessary for the range to operate
properly with correct combustion. Air openings
are located at the rear of the cooktop, at the
top and bottom of the oven door, and at the
bottom of the range under the kick panel or
storage drawer.
■Large scratches or impacts to glass doors can
lead to broken or shattered glass.
SAFETY PRECAUTIONS
Operating Instructions
4
Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING: NEVER use this
appliance as a space heater to heat or
warm the room. Doing so may result
in carbon monoxide poisoning and
overheating of the oven.
5
SURFACE BURNERS
Use proper pan size—avoid pans that are unstable or easily tipped. Select cookware having flat
bottoms large enough to cover burner grates. To avoid spillovers, make sure cookware is large enough
to contain the food properly. This will both save cleaning time and prevent hazardous accumulations of
food, since heavy spattering or spillovers left on range can ignite. Use pans with handles that can be
easily grasped and remain cool.
■Always use the position when igniting theLite
top burners and make sure the burners have
ignited.
■Never leave the surface burners unattended at
high flame settings. Boilovers cause smoking
and greasy spillovers that may catch on fire.
■Adjust the top burner flame size so it
does not extend beyond the edge of the
cookware. Excessive flame is hazardous.
■Use only dry pot holders—moist or damp pot
holders on hot surfaces may result in burns
from steam. Do not let pot holders come near
open flames when lifting cookware. Do not
use a towel or other bulky cloth in place
of a pot holder.
■When using glass cookware, make sure it
is designed for top-of-range cooking.
■To minimize the possibility of burns, ignition
of flammable materials and spillage, turn
cookware handles toward the side or back of
the range without extending over adjacent
burners.
■Carefully watch foods being fried at a high
flame setting.
■Always heat fat slowly, and watch as it heats.
■Do not leave any items on the cooktop. The
hot air from the vent may ignite flammable
items and will increase pressure in closed
containers, which may cause them to burst.
■If a combination of oils or fats will be used in
frying, stir together before heating or as fats
melt slowly.
■Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
■Use the least possible amount of fat for
effective shallow or deep-fat frying. Filling the
pan too full of fat can cause spillovers when
food is added.
■Do not flame foods on the cooktop. If you do
flame foods under the hood, turn the fan on.
■Do not use a wok on the cooking surface if the
wok has a round metal ring that is placed over
the burner grate to support the wok. This ring
acts as a heat trap, which may damage the
burner grate and burner head. Also, it may
cause the burner to work improperly. This may
cause a carbon monoxide level above that
allowed by current standards, resulting in a
health hazard.
■Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and over
the sides of the pan.
■Never try to move a pan of hot fat, especially
a deep fat fryer. Wait until the fat is cool.
■Do not leave plastic items on the cooktop—
they may melt if left too close to the vent.
■Keep all plastics away from the surface
burners.
■To avoid the possibility of a burn, always be
certain that the controls for all burners are at
the Off position and all grates are cool before
attempting to remove them.
■ If range is located near a window, do not hang
long curtains that could blow over the surface
burners and create a fire hazard.
■If you smell gas, turn off the gas to the range
and call a qualified service technician. Never
use an open flame to locate a leak.
■Always turn the surface burner controls off
before removing cookware.
■Do not lift the cooktop on sealed burner
models. Lifting the cooktop can lead to
damage and improper operation of the range.
Consumer SupportOperating Instructions
Safety Instructions
Installation
Instructions Troubleshooting Tips
GEAppliances.com
WARNING!
Operating Instructions
6
Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
■Do not use the oven for a storage area.
Items stored in the oven can ignite.
■Keep the oven free from grease buildup.
■Place the oven racks in the desired position
while the oven is cool.
■Pulling out the rack to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching hot
surfaces of the door or oven walls. The lowest
position is not designed to slide.
■Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
■Do not use aluminum foil anywhere in the
oven except as described in this manual.
Misuse could result in a fire hazard or damage
to the range.
■When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
■Do not use your oven to dry newspapers.
If overheated, they can catch fire.
■Use only glass cookware that is recommended
for use in gas ovens.
■Always remove any broiler pan from range
as soon as you finish broiling. Grease left in
the pan can catch fire if oven is used without
removing the grease from the broiler pan.
■When broiling, if meat is too close to the flame,
the fat may ignite. Trim excess fat to prevent
excessive flare-ups.
■Make sure any broiler pan is in place correctly
to reduce the possibility of grease fires.
■If you should have a grease fire in a broiler
pan, touch the pad, and keep Clear/Off
the oven door closed to contain fire until it
burns out.
■For safety and proper cooking performance,
always bake and broil with the oven door
closed.
Stand away from the range when opening the door of a hot oven. The hot air and steam that escape
can cause burns to hands, face and eyes.
OVEN
COOK MEAT AND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry
to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against
foodborne illness.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING: NEVER cover
any slots, holes or passages in the oven
bottom or cover an entire rack with
materials such as aluminum foil. Doing
so blocks air flow through the oven and
may cause carbon monoxide poisoning.
Aluminum foil linings may also trap
heat, causing a fire hazard.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
7
■Be sure to wipe off excess spillage before
self-cleaning operation.
■Before self-cleaning the oven, remove the
racks, any broiler pan, grid and other
cookware.
■Do not clean the door gasket. The door gasket
is essential for a good seal. Care should be
taken not to rub, damage or
move the gasket.
■Clean only parts listed in this Owner’s Manual.
■If the self-cleaning mode malfunctions,
turn the oven off and disconnect the power
supply. Have it serviced by a qualified
technician.
■Do not use oven cleaners. No commercial
oven cleaner or oven liner of any kind should
be used in or around any part of the oven.
Residue from oven cleaners will damage the
inside of the oven when the self-clean cycle
is used.
SELF-CLEANING OVEN
Consumer SupportOperating Instructions
Safety Instructions
Installation
Instructions Troubleshooting Tips
GEAppliances.com
8
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
Throughout this manual, features and appearance may vary from your model.
How to Light a Gas Surface Burner
Make sure all the surface burners are placed
in their respective positions.
Push the control knob in and turn it to the Lite
position.
You will hear a little noise—the soundclicking
of the electric spark igniting the burner.
Turn the knob to adjust the flame size. If the
knob stays at it will continue to click.Lite,
When one burner is turned to Lite, all the
burners spark. Do not attempt to disassemble
or clean around any burner while another
burner is on. An electric shock may result,
which could cause you to knock over hot
cookware.
Push the control knob in and turn
it to the Lite position.
How to Select Flame Size
For safe handling of cookware, never let the
flames extend up the sides of the cookware.
Watch the flame, not the knob, as you reduce
heat. When fast heating is desired, the flame
size on a gas burner should match the
cookware you are using.
Flames larger than the bottom of the
cookware will not result in faster heating
of the cookware and could be hazardous.
Before Lighting a Gas Burner
■Make sure all burners are in place.
■Make sure all grates on the range are
properly placed before using any burner.
After Lighting a Gas Burner
■Do not operate the burner for an extended
period of time without cookware on the
grate. The finish on the grate may chip
without cookware to absorb the heat.
■Be sure the burners and grates are cool
before you place your hand, a pot holder,
cleaning cloths or other materials on them.
Sealed Gas Burners
Your gas range cooktop, depending on model,
has either four or five sealed gas burners.
They offer convenience, cleanability and
flexibility to be used in a wide range of
cooking applications.
The smallest burner in the right rear position is
the simmer burner. This burner can be turned
down to Lo for a very low simmer setting. It
provides precise cooking performance for
delicate foods such as sauces or foods that
require low heat for a long cooking time.
The medium (left rear and, on some models,
left front) and the large (left front and, on some
models, right front) burners are the primary
burners for most cooking. These general-
purpose burners can be turned down from
Hi to Lo to suit a wide range of cooking needs.
The extra large burner (right front, on some
models) is the maximum output burner. Like
the other four burners, it can be turned down
from Hi to Lo for a wide range of cooking
applications; however, this burner is designed
to quickly bring large amounts of liquid to
a boil. It has a special Power Boil™setting
designed to be used with cookware
10 inches or larger in diameter.
The center oval burner (on some models) is
for large pots/pans or for use with the griddle.
Using the gas surface burners.
Medium Small
Large Extra
Large
Center (oval)
(on some
models)
Extra-large burner only
Medium Small
Medium Large
On some models
On some models
On some models
9
Consumer SupportOperating Instructions
Safety Instructions
Installation
Instructions Troubleshooting Tips
GEAppliances.com
Use a flat-bottomed wok.
Top-of-Range Cookware
Aluminum: Medium-weight cookware is
recommended because it heats quickly
and evenly. Most foods brown evenly in an
aluminum skillet. Use saucepans with tight-
fitting lids when cooking with minimum
amounts of water.
Cast-Iron: If heated slowly, most skillets
will give satisfactory results.
Enamelware: Under some conditions,
the enamel of some cookware may melt.
Follow cookware manufacturer’s
recommendations for cooking methods.
Glass: There are two types of glass
cookware—those for oven use only and those
for top-of-range cooking (saucepans, coffee
and teapots). Glass conducts heat very
slowly.
Heatproof Glass Ceramic: Can be used for
either surface or oven cooking. It conducts
heat very slowly and cools very slowly. Check
cookware manufacturer’s directions to be
sure it can be used on gas ranges.
Stainless Steel: This metal alone has poor
heating properties and is usually combined
with copper, aluminum or other metals for
improved heat distribution. Combination
metal skillets usually work satisfactorily if
they are used with medium heat as the
manufacturer recommends.
Stove Top Grills (on models with sealed burners)
Do not use stove top grills on your sealed gas
burners. If you use the stove top grill on the
sealed gas burner, it will cause incomplete
combustion and can result in exposure to
carbon monoxide levels above allowable
current standards.
This can be hazardous to your health.
Wok This Way (on models with sealed burners)
We recommend that you use a 14" or smaller
flat-bottomed wok. Make sure the wok bottom
sits flat on the grate. They are available at
your local retail store.
Only a flat-bottomed wok should be used.
Do not use a flat-bottomed wok on a support
ring. Placing the ring over the burner or grate
may cause the burner to work improperly,
resulting in carbon monoxide levels above
allowable standards. This could be dangerous
to your health.
In Case of Power Failure
In case of a power failure, you can light the
gas surface burners on your range with a
match. Hold a lit match to the burner, then
push in and turn the control knob to the Lite
position. Use extreme caution when lighting
burners this way.
Surface burners in use when an electrical
power failure occurs will continue to operate
normally.
10
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
Your non-stick coated griddle provides
an extra-large cooking surface for meats,
pancakes or other food usually prepared
in a frying pan or skillet.
NOTE: Your griddle will discolor over time as it
becomes seasoned with use.
How to Insert the Griddle
Using the griddle. (on some models)
CAUTION: Place and remove
the griddle only when all grates and
griddle are cool and all surface units are
turned OFF.
The griddle can only be used with the center
burner. To insert the griddle, remove the
center grate and replace with the griddle.
11
Consumer SupportOperating InstructionsSafety Instructions Installation
Instructions Troubleshooting Tips
GEAppliances.com
Most griddled foods require cooking on a
preheated surface. Preheat griddle according
to the guide below, then switch to the desired
cook setting.
IMPORTANT NOTES:
■Avoid cooking extremely greasy foods and
be careful of grease spill-over while cooking.
■Do not use oil on the griddle for extended
lengths of time. Permanent staining and/or
craze lines on the surface could result.
■Never place or store any items on the
griddle, even when it is not in use. The
griddle can become heated when using the
surrounding burners.
■Do not overheat the griddle. Leaving the
griddle burner on at HI for an extended
amount of time without food can damage
the non-stick coating.
■Avoid using metal utensils with sharp points
or rough sharp edges which might damage
the griddle surface.
■Do not cut foods on the griddle.
Using the Griddle
Type of Food Preheat Cook
Conditions Setting
Warming none 3 (MED-LOW)
Tortillas
Pancakes 7 (MED-HI) 7 (MED-HI)
3 min.
Hamburgers 7 (MED-HI) 7 (MED-HI)
5 min.
Fried Eggs HI 4 (MED)
5 min.
Bacon none 5 (MED)
Breakfast HI 5 (MED)
Sausage Links 5 min.
Hot Sandwiches HI HI
(such as 4 min.
Grilled Cheese)
NOTE: Griddle settings may need to be
adjusted if the griddle is used for an
extended time.
Operating Instructions
12
Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
Bake/Temp Recall Pad
Touch this pad to select the bake function.
Bake Light
Flashes while in edit mode—you can change the
oven temperature at this point. Glows when the
oven is in bake mode.
Start/On Pad
Must be touched to start any cooking or cleaning
function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or self-
cleaning mode and the times set for the timer
or automatic oven operations. The display will
show PRE while preheating. When the oven
reaches the selected temperature, the oven
control will beep and the display will show the
oven temperature.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function error
code.
If your oven was set for a timed oven operation and a
power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there has
been a power outage. Reset the clock.
On models with an oven door latch, if the function error
code appears during the self-cleaning cycle, check the
oven door latch. The latch handle may have been moved,
even if only slightly, from the latched position. Make sure
the latch is moved to the right as far as it will go.
Touch the Clear/Off pad. Allow the oven to cool
for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power
to the range and call for service.
Kitchen Timer On/Off Pad
Touch this pad to select the timer feature. Then
press the pads to adjust the timer.+and –
Kitchen Timer Light
Flashes while in edit mode—you can change the
set time at this point. Glows when the timer has
been activated. Flashes again when the time has
run out until the control is reset.
Clock Pad
To set the clock, press this pad twice and then
press the pads. The time of day will+and –
flash in the display when the oven is first
turned on.
Start Time Pad
Use along with the Cooking Time or Self Clean
pads to set the oven to start and stop
automatically at a time you set.
Start Time Light
Flashes while in edit mode—you can change the
start time at this point. Glows when the function
has been activated.
Cooking Time Pad
Touch this pad and then touch the + –or pads
to set the amount of time you want your food
to cook. The oven will shut off when the cooking
time has run out.
Cooking Time Light
Flashes while in edit mode—you can change the
set time at this point. Glows when the function
has been activated. Flashes again when the time
has run out until the control is reset.
Throughout this manual, features and appearance may vary from your model.
Using the oven controls.
Oven Control, Clock and Timer Features and Settings (on some models)
13
GEAppliances.com
Automatic Oven Light (on some models)
This lights anytime the oven has been
programmed using the Cooking Time or Start
Time functions.
Oven Light On/Off Pad
Touch this pad to turn the oven light on or off.
– Pad
Short taps to this pad will decrease the time or
temperature by small amounts. Touch and hold
the pad to decrease the time or temperature by
larger amounts.
+ Pad
Short taps to this pad will increase the time or
temperature by small amounts. Touch and hold
the pad to increase the time or temperature by
larger amounts.
Self Clean Pad
Touch this pad to select the self-cleaning
function. See the Using the self-cleaning oven
section.
Clean Light
Flashes while in edit mode—you can change the
length of time for the self-clean cycle at this
point. Glows when the oven is in the self-clean
cycle. After the self-clean cycle, the light will turn
off. When the light is off, slide the latch handle to
the left as far as it will go and open the door. If
your range does not have a latch, the door will
unlock automatically.
Clear/Off Pad
Touch this pad to cancel ALL oven operations
except the clock and timer.
Broil Hi/Lo Pad
Touch this pad to select the broil function.
Broil Light
Flashes while in edit mode—you can switch from
Hi to Lo Broil at this point. Glows when the oven
is in broil mode.
Indicator Lights (on some pads)
Edit mode lasts several seconds after the last
pad press. Start Time and Cooking Time will
be the only pads lit if either of these options is
selected. (Example: Start Time is selected with
Bake—the Start Time pad will remain lit until the
clock reaches the programmed time, at which
point it will turn off and the Bake/Temp Recall
pad light will light up).
Consumer SupportOperating InstructionsSafety Instructions Installation
Instructions Troubleshooting Tips
Oven Control, Clock and Timer Features and Settings(on some models)
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting TipsConsumer Support
14
To avoid possible burns, place the racks in the desired position before you turn the oven on.
Oven Vent
Your oven is vented through ducts at the rear
of the range. Do not block these ducts when
cooking in the oven—it is important that the
flow of hot air from the oven and fresh air
to the oven burner be uninterrupted. Avoid
touching the vent openings or nearby
surfaces during oven or broiler operation—
they may become hot.
■Handles of pots and pans on the cooktop
may become hot if left too close to the vent.
■Do not leave plastic or flammable items on
the cooktop—they may melt or ignite if left
too close to the vent.
■Do not leave closed containers on the
cooktop. The pressure in closed containers
may increase, which may cause them to
burst.
■Metal items will become very hot if they are
left on the cooktop, and could cause burns.
Plastic items on the cooktop may melt
if left too close to the vent.
Vent appearance and location vary.
Using the oven.
Before you begin…
The racks have stop-locks, so that when
placed correctly on the rack supports
(A through E), they will stop before coming
completely out, and will not tilt.
When placing and removing cookware,
pull the rack out to the bump on the rack
support.
To remove a rack, pull it toward you, tilt the
front end up and pull it out.
To replace, place the end of the rack (stop-
locks) on the support, tilt up the front and
push the rack in.
NOTE: The rack is not designed to slide out at
the special low rack (R) position.
The oven has 5 rack positions.
It also has a special low rack position (R)
for extra large items, such as a large
turkey.
Power Outage
CAUTION: Do not make any
attempt to operate the electric ignition oven
during an electrical power failure.
The oven or broiler cannot be lit during a
power failure. Gas will not flow unless the
glow bar is hot.
If the oven is in use when a power failure
occurs, the oven burner shuts off and cannot
be re-lit until power is restored. This is
because the flow of gas is automatically
stopped and will not resume when power
is restored until the glow bar has reached
operating temperature.
Oven Light
Touch the pad on the upperOven Light
control panel to turn the light on or off.

Produkt Specifikationer

Mærke: GE
Kategori: Komfur
Model: JGBP36SEMSS

Har du brug for hjælp?

Hvis du har brug for hjælp til GE JGBP36SEMSS stil et spørgsmål nedenfor, og andre brugere vil svare dig


Komfur GE Manualer

GE

GE JCB840 Manual

17 Januar 2025
GE

GE JGS650SEFSS Manual

24 December 2024
GE

GE PC2S930YPFS Manual

16 August 2024
GE

GE JDP36BWWH Manual

6 August 2024
GE

GE JGBS60DEKCC Manual

26 Juli 2024
GE

GE JB640DFWW Manual

27 Maj 2024
GE

GE JBS61BCAD Manual

26 Maj 2024
GE

GE EER3001LSS Manual

23 Maj 2024
GE

GE JGSP28BEKBB Manual

21 Maj 2024
GE

GE Profile JP968BCBB Manual

17 Maj 2024

Komfur Manualer

Nyeste Komfur Manualer

Hoover

Hoover HHG94K3X Manual

26 Marts 2025
PITSOS

PITSOS PAF003D20 Manual

22 Marts 2025
Equator

Equator BIC 244 CC ED Manual

20 Marts 2025
AEG

AEG I64KV301CB Manual

19 Marts 2025
Continental Edison

Continental Edison CECP9060BDD Manual

19 Marts 2025
AEG

AEG TI64IB1FIZ Manual

19 Marts 2025
Electrolux

Electrolux KCC83443CZ Manual

16 Marts 2025
BEKO

BEKO FBM62330DXS Manual

14 Marts 2025
AEG

AEG NCH84B03CB Manual

11 Marts 2025
AEG

AEG PE7000S80 Manual

11 Marts 2025
