Side 1/24

Gigaset A400/A400A

Ð ±V

INT 1

11.12. 11:56

ÞMenu

1 Charge status of

the batteries

(¢ page 6)

2 Answering ma-

chine icon (A400A

only)

3 Signal strength (¢ page 6)

4 Internal number of the handset

5 Using the display keys

6 Control key (p)

t: Open the menu for setting

the volume (¢ page 17)

s: Open the directory

(¢ page 8)

u: Display the list of registered

handsets

v: Microphone off (¢ page 7)

7 Accept/speaker key (¢ page 7)

8 End call key and On/Off key

9 Ringer melody on/off

(press and hold in idle status)

10 Keypad lock on/off

(press and hold in idle status)

11 Message key (¢ page 9)

12 Microphone

13 Recall key

- Recall (flash)

- Dialling pause (press and hold)

The handset at a glance

Display keys on handset:

Pressing a key launches the func-

tion that appears above that key in

the display.

Other icons in the top display line:

Dis-

play

Function when pressed

ÞOpen redial list ¢ page 8.

Menu Open main/submenu (see

menu tree ¢ page 17).

“Go back one menu level.

UScroll up/down or adjust

volume with q.

TMove cursor to left/right

with r.

˜Backspace deletes one

character at a time from

right to left.

OK Confirm menu function or

save entry.

ÚRinger melody off

ØKeypad locked

½Eco Mode+ activated

(¢ page 2)

Please note

To change the display language, proceed as described on page 12.

The base at a glance

Base A400A

Base A400

1 Registration/paging key:

Search for handsets (press briefly, paging ¢

page 11).

2 On/Off key: switch answering machine on and off.

Lights up:

answering machine is activated.

Flashes: message is being recorded.

3 Volume keys: (– = quieter; + = louder)

During message playback: adjust the speaker volume.

While phone is ringing: adjust ringer melody volume.

4 Play/Stop key:

Play back new messages from answering machine (press briefly), play

back all messages (press and hold), cancel playback.

Flashes: at least one new message is present.

Flashes very quickly: memory is full.

During message playback:

5 Skip to the start of the current message (press once) or go to the pre-

vious message (press twice).

6 Go to the next message.

7 Delete current message.

Produkt Specifikationer

Mærke:	Gigaset
Kategori:	Telefon
Model:	A400 Trio
Type:	DECT telefon
Produktfarve:	Sort, sølv
Indbygget skærm:	Ja
Skærm diagonal:	1.7 "
Skærmopløsning:	96 x 64 pixel
Håndsæt:	3
Taletid:	20 t
Standby tid:	220 t
Antal melodier:	20
Telefonsvarer:	Ingen
Kapacitet for telefonbog:	80 entries
Nummervisning:	Ja
Knapper med baggrundsbelysning:	Ja
Kan monteres på væggen:	Ja
Monteringstype:	Bord/Væg
Batteritype:	AAA
Maksimal indendørs rækkevidde:	50 m
Maksimal udendørsinterval:	300 m
Vækkeur:	Ja
Mulighed for flere håndsæt:	4
Trådløs forbindelse:	Ja
Håndsæt dimensioner (BxDxH):	48 x 27 x 153 mm
Mac kompabilitet:	Ingen
Antal understøttede batterier:	2
Antal håndsæt inkluderet:	3
Tekstlinjer:	4 Linier
Opkaldslistekapacitet:	10
Ur med kalender:	Ingen
Basisdimensioner:	104 x 32 x 122 mm
Vis antal farver:	Monokrom
Vis nummer (CLIP):	Ja
Navigeringstast:	Ja
Plug and play:	Ja
Indikator for batteriopladning:	Ja
VIP-gruppe med egen melodi:	Ingen
Stemmeopkald:	Ingen
Opkaldsstyring:	Ja
