Dear Friend,

At the outset, we at Haier thank you for your interest in our range of products. A unique and

international range of appliances designed solely with the purpose of making modern life

simpler. And how! The entire Haier range of appliances, ranging from refrigerators, televisions,

was hi n g mach in e s, ai rc o nd it io n er s, mi c rowave ove ns, di sh was h er s an d

wine-coolers, combines the best of technology, features, performance and styling. All, a result

of our perfect understanding of your lifestyle and your needs.

But what is a great product without great service? Leaving no stone unturned in giving you the

best of service, we have also established an extensive network of authorised dealers and

authorised service centres, so that you get a lifetime of great and timely service for your Haier

appliance.

It has been an honour and a pleasure bringing these hi-tech products to you and we hope that

you get as much happiness using them as we have got, creating them for you.

Happy Inspired Living!

Thanking you,

CONTENTS

NAMES OF THE PARTS 1

SAFETY PRECAUTIONS 2

INSTALLATION AND ADJUSTMENT 4

PREPARATION BEFORE WASHING 7

THE MANDATORIES FOR WASHING 8

USAGE OF THE DETERGENT 8

WASHING SEQUENCE 9

TROUBLE-SHOOTING 13

PACKING LIST & SPECIFICATIONS 15

Please check if the power receptacle is in good earthing condition

before use, to guarantee your safety.

Buzzer

Water-inlet

Water inlet selector handle

Wash selector

Wash/Soak timer

Control panel

Overflow filter

Quick water-filling entrance

Drain hose hook

Water level adjusting lever

Lint filter(Installed by user)

Drain hose

Wash tub cover

Outer cover of the spin tub

Inner cover of the spin tub

Spin timer

Spin tub frame

Spin tub

Cabinet

Base frame

Wash tub

Pulsator

MEANING AND DESCRIPTION OF THE SYMBOLS

Contents marked with that symbol are related to the safety of

the product and personal safety of the users. Please operate

in strict conformity to the contents, otherwise it may cause

damage to the machine or injure the personal safety of the

user.

Forbidding sign Contents marked with that symbol are for actions forbidden

to perform. Performing of those actions may result in

damage of the machine or injure the personal safety of the

user.

Warning sign

NAMES OF THE PARTS

INSTALLING THE WATER INLET HOSE;

SELECT THE WATER LEVEL

Insert the water inlet hose into the water-filling entrance on the control panel directly (Pull it

out to dismantle it).

Select water level according to the quantity of the laundry.

Set the water level adjusting lever to the required line.

Use the new water inlet hose provided with the machine to connect to the water faucet. Old

hose sets should not be reused.

You can fill water into the wash tub directly through this entrance. It can reduce the

humidity inside the control panel significantly and prolong the operating life of the

components.

Insert the water inlet hose into the water-filling entrance, then push the water-filling jointer

into the quick water-filling entrance. (To dismantle the water inlet pipe, just push the control

handle as indicated in the figure and pull it out.)

QUICK WATER-FILLING ENTRANCE

Water inlet hose

Water inlet

Maximum Max.

Minimum Min

Medium Med

Water level

indicator

Quick water-filling entrance

Water inlet hose

Water inlet jointer

Control handle

Push

Quick water-filling entrance

HOW TO CHANGE THE DIRECTION OF THE

DRAIN HOSE

• Figure 1 indicates the ex-factory installation

position of the drain hose.

EXTEND THE DRAIN HOSE FROM THE

SIDE OF SPIN TUB

Take off the drain hose from the hanging hole

of the cabinet. Pull the drain hose fixing hook

outwards gently to take out the drain hose from

the two fixing hooks. (As per Figure 2)

Rotate the drain hose fixing hook by 90 to take

it out from the installation hole. (As per

Figure 3).

Install the two drain hose fixing hooks taken

out into the installation hole at the other side of

the base frame (to aim at the installation hole

accurately you can lean the washing machine

forward slightly). Then rotate 90 (As per Figure

4).

Pull the fixing hook outwards slightly. Inlay the

drain hose into the fixing hooks reliably along

the groove at spin tub side, and make it extend

towards the spin tub side.

Then hang the drain hose into the hanging hole

at the spin tub side. (As per Figure 5).

EXTEND THE DRAIN HOS E FROM

THE REAR SIDE

Take out the drain hose from the fixing hook. Extend it from the rear side (When the drain

hose is extended from the rear side, it can be hung on the point for drain hose, at the two

sides of the cabinet.) (See Figure 6).

Figure 1 Drain hose

fixing hook

Figure 2

Drain hose

fixing hook

Pull outwards

slightly

Side sectional view

Fixing hook

installation hole

Drain hose

Take off

the drain hose

Figure 3

Take off the fi xing

hoo k down war ds

Rotate the fixing

hook for 90

Figure 4

Insert the fixin g hook into the

ins tallation hole upward s

Rotate the fixing

hook for 90

to fix it

Figure 5

Figure 6

SAFETY PRECAUTIONS

Do not put the machine at a damp place

like the bathroom. Never wash it with

water. Do not place wet laundry on the

control panel.

Do not use water hotter than 50 C.

For washing machines with ventilation

openings at the base, make sure that a

carpet does not obstruct the openings.

Venti lat ion

hole at the

bott om of

the washing

machine

Do not wash water-proof laundry like

raincoat, bike covers etc. to avoid

abnormal vibrations in spinning.

• Do not let the machine share one

receptacle with other electrical

appliances.

• If the power plug is damaged, or the

plugging into the receptacle is loose,

do not use the plug anymore.

When the machine is being used normally,

please put the power plug at the location easy to

be inserted and extracted by hand. Be sure to

pull the plug off when there is power failure or

the machine is being moved, cleaned or when it

is idle.

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a

similarly qualified person in order to prevent a mishap.

Please insert the power cord into special

receptacle with rated voltage. Be sure to use

single-phase three pin receptacle. The earthing

terminal of the receptacle must be earthed

reliably. If possible, please adopt electric

leakage protector.

PREPARATION BEFORE WASHING

PREPARATION BEFORE

WASHING

1. Connect the water inlet hose.

2. Confirm that the washing machine

is earthed reliably. Then insert the

power plug into the receptacle. Do

not connect the earth terminal to

the gas pipe and tap water pipe.

3. Put down the drain hose.

4. Slanting or uneven ground may

result in unstable working or

abnormal noise. Please make the

machine stand horizontally.

PAY ATTENTION TO THE FOLLOWING BEFORE WASHING

THE LAUNDRY

a. Check if the laundry is compatible to washing in machines.

b. Divide the laundry in which colour runs and wash separately.

c. Soak the laundry which absorbs water with difficulty by hand.

d. For the heavily soiled laundry, first remove dirt like mud or dust. Please apply

detergent on the soiled parts in advance. This makes it easier for the stain to clean.

e. For laundry which may get stuck in lint ball or with fur, please turn the cloth over

before putting in the machine.

f. Do not put laundry polluted by chemicals into the washing machine directly.

Check if the

laundry

has special

requirement

for

washing.

Clear the

pocket. Take

out the coins,

sand, hairpins

etc.

The quantity

of the laundry

should not be

too large.

Stretch and

loosen the

laundry

before putting

it in the

tub.

When the

pulsator is

running, the

buttons

of the laundry

may make noise.

For the sake

of discretion,

please put the

laundry with

buttons

separately.

Tie the long

strips, fasten

the buttons,

close zippers.

SAFETY PRECAUTIONS

Do not stretch hands into the machine

when it is switched ON. It is dangerous

even if the rotation is slow. Take special

care of children.

Do not dismantle, repair or alter the

machine by yourself.

Do not put any hot or heavy items (such

as a kettle with hot water) on the washing

machine.

Do not wash laundry with volatile materials

(such as thinner, petrol etc.).

Petrol

Thi

nner

Handicapped or children without

supervision must not use the machine.

Keep the machine away from direct

sunlight and heat source like heater.

• To protect your laundry and washing

machine, please take out all coins,

buttons, sand, hairpins and other

foreign materials from the clothes

before washing.

• Please check if the water faucet is

open, and the connection of the water

inlet pipe is proper.

• It is suggested to use foamless

washing powder.

HOW TO USE WHITENER

• Fill water to the decided level. Dilute

whitener with container. Pour it slowly

into the washing tub.

• Avoid using whitener on laundry with

colours or patterns as they are prone

to losing colour.

• The whitener should not touch the

laundry directly.

• Refer to the user's manual for the

usage and quantity of the whitener to

be used.

• Please dissolve whitener before using.

• The capacity of washing and spinning

of the machine refer to the largest

weight of the standard laundry under

dry conditions that can be washed or

spinned at one time. Laundry quantity

in one washing cycle should be less

than the rated capacity if washing and

spinning at the same time.

• The thickness, size, type of cloth will

influence the actual washing capacity.

It is suitable to put in reasonable

amount of laundry and the laundry can

be turned round in washing for one

time washing.

• Do not select "Maximum" water level

for laundry less than 2.4 kg. to avoid

splashing of water.

• It is suggested not to use high sudsing

detergent.

HOW TO USE WASHING POWDER

• To directly dissolve it in the machine:

1. Fill small quantity of water.

2. Add the powder to it. Run for 3

seconds to dissolve it completely.

3. Put in the laundry. Select the

suitable water level.

• For instant dissolving of the washing

powder:

1. Prepare warm water of 30 C and

pour into a container.

2. Add the powder and keep stirring

to fully dissolve it.

• The powder is more prone to polluting

the laundry than the detergent.

Therefore please use in with proper

quantities.

• Dosage of different washing powders

is different. Please refer to the

instructions of the washing powder

for the detailed dosage.

THE MANDATORIES FOR WASHING

USAGE OF DETERGENT

INSTALLATION AND ADJUSTMENT

INSTALLING THE LINT FILTER

Overflow filter

Lint filter

Please install and adjust the machine according to the requirements mentioned in the

manual. It is very important for your security and correct operation of the machine.

After opening the package, please take out the lint filter

from the document bag, and install it to the overflow

filter of the wash tub. (See figure)

USAGE OF THE DRAIN HOSE

T H E D R A I NA G E S HO U L D BE

SMOOTH WITH THE DRAIN HOSE.

1. The height of the drain hose should be

less than 10cm else the drainage will not

be smooth and will be incomplete.

2. Do not tramp on or press the drain hose.

3. If the drain hose is too long, cut it at mid

point. For smooth drainage, cut the front

end of the hose at a slant.

4. If extra drain hose is needed, please make

a separate purchase. The inner diameter

of the extra hose should not be less than

30mm, and the length should not exceed

1.5m.

If the extra hose is too long, cut it either at

point A or B. (See figure)

<10cm

> 30mm

<1.5m

WASHING SEQUENCE

Overfilling sign

Water-filling selector handle

Wash/Soak timer Wash selector Buzzer

Water inlet

(To set to below 2 minutes,

first set to 5 minutes then

turn it back. It increases

the life of the timer).

(Strong speed,

Standard speed)

(The buzzer will ring

when the washing cycle

finishes)

Spin timer

(To set to below 1 minute,

first set to 2 minutes then

turn it back. It increases

the life of the timer).

OFF

DRAIN

STRONG

STANDARD

MAX

SPIN TIMERWASH/SOAK TIMER WASH SELECTOR

BUZZER

OF F

WASH

1. Water-filling selector

(1) Set the water-filling selector to the

"WASH" side. (Figure 1)

(2) Set the water level adjusting lever to

the desired line.

2. Fill the water and add the dissolved

washing powder to make the water level

reach the preset position. (Figure 2)

Run washing program for some time to

stir and dissolve the powder completely.

3. Put in the laundry. If the water quantity is

insufficient, please add more water.

4. Select the speed.

Select the strength of the speed

according to the laundry. (Figure 3)

5. Select the washing time.

Select the washing time according to the

laundry. (Figure 4)

6. After the washing cycle finishes, the

buzzer will ring. Set the "WASH

SELECTOR" at "DRAIN". (Figure 5).

DRAIN

STRONG

STANDARD

WASH SELECTOR

OFF

* WASH TIMER

Figure 3

DRAIN

STRONG

STANDARD

WASH SELECTOR

Figure 4

Figure 5

Figure 2

Figure 1

SPINWASH

* For model with Wash Timer

For model with Soak Timer

OFF

# SOAK TIMER

Produkt Specifikationer

Mærke:	Haier
Kategori:	Vaskemaskine
Model:	XBP65-116S

Har du brug for hjælp?

Hvis du har brug for hjælp til Haier XBP65-116S stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Vaskemaskine Haier Manualer

Haier HW80-BP14929AS6 Manual

11 November 2024

Haier HW90-B16939S8 Manual

6 November 2024

Haier HWD90-B14959S8NU1 Manual

3 November 2024

Haier THASNQ286TM5-S Manual

3 November 2024

Haier HWF5S1214 Manual

19 Oktober 2024

Haier HW-C1270TVE Manual

14 Oktober 2024

Haier HWM80-316BK Manual

24 September 2024

Haier HMS1002AA Manual

23 September 2024

Haier HWF85DW1 Manual

23 September 2024

Haier HWM180-1701D Manual

22 September 2024

Vaskemaskine Manualer

Nyeste Vaskemaskine Manualer

Faure FWF1422A32 Manual

22 November 2024

Electrolux EWDK0846B Manual

22 November 2024

Nabo WM 1600 Manual

21 November 2024

Otsein LB LTO129A Manual

20 November 2024

SanGiorgio ST6512EL Manual

20 November 2024

SanGiorgio FS614D9 Manual

20 November 2024

SanGiorgio PROGETTO F4 Manual

20 November 2024

SanGiorgio SG710 Manual

20 November 2024

SanGiorgio F814DIBC Manual

20 November 2024

SanGiorgio F812D Manual

20 November 2024
