Side 1/66
NETWORK CAMERA
User Manual
QNO-6010R
Copyright
©2016 Hanwha Techwin Co., Ltd. All rights reserved.
Trademark
Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their
respective company.
Restriction
Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without
formal authorization.
Disclaimer
Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be
provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the
right to change the contents of this document without prior notice.
Design and specications are subject to change without prior notice.
The initial administrator ID is “admin” and the password should be set when logging in for the rst time.
Please change your password every three months to safely protect personal information and to prevent the damage of the information
theft.
Please, take note that it’s a user’s responsibility for the security and any other problems caused by mismanaging a password.
Network Camera
User Manual
English _3
●●overview
important Safety inStructionS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.
(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents
as they may deform or cause damage to the product.)
7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated
from 12 Vdc, min. current for each product.
warninG
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE
VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance
with the installation instructions.
caution
caution
riSK of eLectric SHocK.
Do not open
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
eXpLanation of GrapHicaL SymBoLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the product.
overview
overview
4_ overview
Class construction
An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a
protective earthing connection.
Battery
Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in
your location.
When used outside of the U.S., it may be used HAR code with fittings of an approved
agency is employed.
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than that contained in
the operating instructions unless you are qualified to do so.
Please use the input power with just one camera and other devices must not be connected.
The ITE is to be connected only to PoE networks without routing to the outside plant.
Please read the following recommended safety precautions carefully.
yDo not place this apparatus on an uneven surface.
yDo not install on a surface where it is exposed to direct sunlight, near heating equipment or
heavy cold area.
yDo not place this apparatus near conductive material.
yDo not attempt to service this apparatus yourself.
yDo not place a glass of water on the product.
yDo not install near any magnetic sources.
yDo not block any ventilation openings.
yDo not place heavy items on the product.
yPlease wear protective gloves when installing/removing the camera.
The high temperature of the product surface may cause a burn.
User’s Manual is a guidance book for how to use the products.
The meaning of the symbols are shown below.
yReference : In case of providing information for helping of product’s usages
yNotice : If there’s any possibility to occur any damages for the goods and human caused by
not following the instruction
Please read this manual for the safety before using of goods and keep it in the safe place.
English _5
●●overview
contentS
overview
3
3 Important Safety Instructions
6 Product Features
6 Recommended PC Specifications
6 Recommended Micro SD/SDHC/SDXC
Memory Card Specifications
6 NAS recommended specs
7 What’s Included
8 At a Glance
installation & connection
9
9 Installation
10 Inserting/Removing a Micro SD Memory
Card
11 Memory Card Information (Not Included)
11 Connecting with other Device
network connection and
setup
14
14 Connecting the Camera Directly to Local
Area Networking
14 Connecting the Camera Directly to a DHCP
Based DSL/Cable Modem
15 Connecting the Camera Directly to a
PPPoE Modem
15 Connecting the Camera to a Broadband
Router with the PPPoE/Cable Modem
16 Buttons used in IP Installer
16 Static IP Setup
18 Dynamic IP Setup
18 Port Range Forward (Port Mapping) Setup
19 Connecting to the Camera from a Shared
Local PC
19 Connecting to the Camera from a Remote
PC via the Internet
web viewer
20
20 Connecting to the Camera
21 Password setting
21 Login
21 Plug-in support specifications for each
browser
22 Installing WebViewer Plugin
22 Using a Plug-in Free Webviewer
22 Using the Live Screen (Plug-in Free
Webviewer)
23 Using the Live Screen (Plug-in Webviewer)
25 Playing the recorded video (Plug-in Free
Webviewer)
27 Playing the recorded video (Plug-in
Webviewer)
setup screen
30
30 Setup
30 Basic Setup
34 Audio & Video setup
39 Network Setup
42 Event Setup
44 NAS (Network Attached Storage) guide
49 System Setup
appendix
51
51 Specification
53 Product Overview
53 Troubleshooting
55 Open Source Announcement
English _7
●● overview
wHat’S incLuDeD
Please check if your camera and accessories are all included in the product package.
(As for each sales country, accessories are not the same.)
Appearance DescriptionItem Name Quantity
Camera
1
Instruction book,
Installer S/W CD
1
Quick Guide
(Optional)
1
Warranty card
(Optional)
1
Template
1
Product installation guide
L Wrench
1
Used to control the direction of the camera
Tapping Screw 3 Used for installation on the wall or ceiling
RJ45 waterproof accessory
1
Used to install in humid places
Sunshield
1
It protects the camera from the direct sunlight.
Appearance DescriptionItem Name Quantity
Sunshield Hold
1
It fixes the sunshield with the camera.
Card-type moisture absorbent
3
Attached when installed.
Options (not included)
Pole mount bracket Cylindrical pole mounting bracket
overview
8_ overview
Components
Item Description
a
Power Port Used to plug the power cable.
b
Alarm I/O Port
ARM-OUT Used to connect the alarm output signal.
GND These are common ports to connect alarm input/output signals.
ARM-IN Used to connect the alarm input sensor or external day/night sensor.
c
Network Port Used to connect the PoE or Ethernet cable for network connection.
d
Audio In Jack Used to connect to a microphone.
CA UT IO N:Be w are of th e
Ra ted Volta ge and Pola rity
of the p ower conn ection.
a
b
c
d
AT A GLANCE
Appearance
Item Description
a
Micro SD card slot (Internal space of the product) This is a slot in which you can insert a Micro SD card.
b
Reset Button
The button restores all camera settings to the factory default.
Press and hold for about 5 seconds to reboot the system.
J
If you reset the camera, the network settings will be adjusted so that DHCP can be
enabled. If there is no DHCP server in the network, you must run the IP Installer
program to change the basic network settings such as IP address, Subnet mask,
Gateway, etc., before you can connect to the network.
c
Sunshield Hold It fixes the sunshield with the camera.
d
Sunshield It protects the camera from the direct sunlight.
RESET
b ca
d
