Side 1/60

SEW-3042W

RealVIEW

User Manual

English

If you have additional questions or need further assistance, contact Samsung support at (877) 349-3149.

To extend your one year warranty by three months, be sure to go to www.samsungsv.com and register your product.

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 1 2016-01-07 오전 9:58:21

SPECIFY SERVICE INSTRUCTIONS AND WARRANTY

TERMS

FCC Caution :

Any Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions :

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Note :

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and monitor.

• Connect the equipment into an outlet on a circuit different from that to which the monitor is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING

• STRANGULATION HAZARD - Keep cord out of child's reach. NEVER place camera or cords

within 3 feet of crib or playpen. Never use extension cords with AC Adapters. Only use the AC

Adapters provided.

• Some adult assembly or installation required.

• This product contains small parts that may cause choking. Keep small parts away from children.

• This product is NOT intended to replace proper supervision of children. You MUST check your

child’s activity regularly, as this product will not alert parents to silent activities of a child.

• Before using this product, read and follow all instructions contained in this booklet, and read and

follow all instructions and warnings on the product.

• NEVER use the transmitter or monitor near water, including near a bathtub, sink, laundry tub, wet

basement, etc.

• This product is intended for indoor use only.

• This product is not intended for use as a medical monitor and its use should not replace adult

supervision.

• The transmitter detects normal sound levels within a range of 2 to 3 meters (6 to 10 feet) from a

child. If the child moves outside of this range, if may not be able to detect sounds from him or her.

• It is essential that you check the operating range and condition of the transmitter monitor on initial

installation, and on a regular basis after that.

• Check reception regularly. Test monitor before use and after changing camera location.

The wireless signal transfer range may be shortened if an obstacle such as a

concrete wall is in between the camera and monitor.

• To prevent overheating, keep the product and AC power adapters away from any direct sunlight

and heat sources such as radiators, heat registers, cooking devices (e.g., stoves and ovens) and

other appliances that produce heat (e.g., amplifiers, televisions and stereos).

• Ensure that the product is well ventilated during use. Avoid contact with pillows and furniture that

may block ventilation.

• Use only the AC adapters provided with the product, as other adapters may damage the product.

Plug the adapters only into standard household current (100~240 volts AC).

Place the AC adapters avoiding pinch points otherwise you can damage the adapters.

• When an AC adapter is plugged into a power source, DO NOT touch the exposed end of the AC

adapter’s cord.

• Do not use extension cords with the AC power adapters to avoid entanglement.

• This product should only be serviced by qualified and authorized Samsung service centers.

• Images and sounds are transmitted by the product over public airwaves and transmissions may

be picked up by other units. (Although the transmission distance is 100m or longer, it may vary

depending on whether there are obstacles between the camera and the monitor.)

• Caution if you use the system to watch a young child, do not place the camera where the child

can reach.

• When using the system with only battery power and the charge is low, then the picture and or

sound may affected.

• If this occurs then please connect the AC power adapter.

CAUTION

Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 3 2016-01-07 오전 9:58:22

WHAT’S INCLUDED

Package Contents ………………………………………………… 5

GETTING STARTED

Functional Description ……………………………………………… 6

Powering your monitor ……………………………………………………… 6

Operating the System ……………………………………………………… 6

VIEWING MODE DISPLAY

Indicator Description ……………………………………………… 8

How to use the indicator …………………………………………………… 8

Menu Operation …………………………………………………… 9

How to use the function tools ……………………………………………… 9

How to use the setup icon ………………………………………………… 9

OVERVIEW

Getting to know your Monitoring system ……………………… 11

Wireless Monitor …………………………………………………………… 11

Wireless Camera …………………………………………………………… 13

INSTALLATION

How to Install ……………………………………………………… 14

Wireless Monitor …………………………………………………………… 14

Wireless Camera …………………………………………………………… 14

APPENDIX

Specifications …………………………………………………… 15

Troubleshooting ………………………………………………… 16

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 4 2016-01-07 오전 9:58:22

English ·

01 What’s Included

What s ncluded’ I

The system comes with the following components:

Wireless camera Wireless monitor User Manual & Warranty Card

Camera Adapter Monitor Adapter Screws (2EA) & Plastic anchors (2EA)

Check your package to confirm that you have received the complete system, including all components shown above.

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 5 2016-01-07 오전 9:58:22

· Viewing Mode Display

How to use the indicator

a b c d ef g h i j

a Signal Indicator

The signal indicator shows the strength of the signal being received from the

camera.

The number of bars in the signal indicator shows the strength of the signal –

One or no bars indicate the signal is poor, and 5 bars indicate a strong signal.

b Digital Clock

Displays the time that is set on the monitor. It only provides AM / PM time

format and no 24hour format.

c Camera Number

Indicates which camera is being displayed on the current screen. When scan mode

is selected, this icon will flash.

d Sound level Indicator

Indicate the sound level of the Active Camera.

e x1/x1.5/x2 Zoom mode

Indicates that current screen is Zoomed in. Press [

] icon on the monitor to

zoom back out.

f Night Vision Indicator

Indicates camera night vision mode is turned on.

The screen will appear in Black/White in this mode.

g VOX On

Indicates you select Low Sound level detection or High Sound level detection in

VOX menu.

h Monitor Speaker Mute

Indicates the monitor speaker is muted. Once the monitor’s speaker is muted,

no sound from the camera is produced.

i Battery Capacity Level

Indicates remaining battery charge. Indicated in 4 levels, and one discharge

warning.

Charging

Indicates the battery is charging by DC input power. If battery nearly empty,

it will flash to alert user to charge up the unit.

Two-way talk

Press the [ ] icon while talking.

No Signal Warnings

The " " message means the monitor cannot access the camera.Out of Range

Please reposition the camera, or check the camera power.

V M dIeWInG ode Isplay

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 8 2016-01-07 오전 9:58:24

English ·

04 Overview

Wireless Monitor

After opening the box, fully charge the monitor before use. After initial charge, recharge as needed.

Front Controls

o VerVIeW

5" LCD Screen

Displays video from the camera.

Power LED

When the monitor is being recharged or monitor has low

electricity, red light flashes.

When the monitor is working, the LED becomes solid

red light.

Microphone

Transmits audio to the camera when [

] icon is

pressed down and held like a walkie talkie.

Monitor Antenna

Receives and sends signals from or to the camera.

Navigation Controls

Viewing Mode: The following controls are used while watching live video from the camera:

• Press [ ] icon to zoom in/out the screen.

While in zooming, use [

] icon to move the screen around.

Menu Mode: Press the [ ] icon to confirm the menu selection.

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 11 2016-01-07 오전 9:58:26

· Installation

CAUTION: If you use the system to watch a young child, do not place the camera in the

child's reach.

Wireless Monitor

Place the monitor in a place that will have clear

reception with your camera(s).

Pull out the stand.

`Do not pull up the stand lever with an excessive

force.

Wireless Camera

Before you install the camera, carefully plan where and how it will be positioned, and

where you will route the cable that connects the camera to the power adapter.

Before starting permanent installation, verify its performance by observing the image

on the monitor when camera is positioned in the same location/position where it will be

permanently installed and the monitor is placed in the location where it will be used

most of the time.

Installation Warnings

Aim the camera(s) to best optimize the viewing area: Select a location for the camera

that provides a clear view of the area you want to monitor, which is free from dust, and

is not in line-of-sight to a strong light source or direct sunlight.

Avoid installing the camera where there are thick walls or obstructions between the

camera and the monitor.

STRANGULATION HAZARD - Keep cord out of child's reach. NEVER place camera or

cords within 3 feet of crib or playpen. Never use extension cords with AC Adapters.

Only use the AC Adapters provided.

Carefully unpack the camera.

If you are installing cameras that did not come with the system, please see the

pairing camera section of this manual for details on installation.

Mount the camera to the wall.

Mark the position of the screw holes on the wall, and

drill holes and insert 2 screws, then firmly attach the

camera to the wall by placing the stand over the

installed screws and pushing the base downwards.

`To install on a concrete wall, drill a hole and use plastic

anchor to fix.

`Use the drilling template to drill holes on the wall for

camera installation. (Page 18)

`The camera can also be placed on a flat surface, such

as a table or shelf, and no mounting hardware is

required.

Adjust the viewing angle of the camera.

`Adjusting the camera with excessive force may

damage the unit.

InstallatIon

OFF

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 14 2016-01-07 오전 9:58:27

MeMo

PT01-004291A-SEW-3042W-ENGLISH-미주.indd 19 2016-01-07 오전 9:58:27

Produkt Specifikationer

Mærke:	Hanwha
Kategori:	Overvågningskamera
Model:	RealVIEW SEW-3042W

Har du brug for hjælp?

Hvis du har brug for hjælp til Hanwha RealVIEW SEW-3042W stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Overvågningskamera Hanwha Manualer

Hanwha PNO-A9311R Manual

24 September 2024

Hanwha ACO-8020R Manual

24 September 2024

Hanwha QNO-C8083R Manual

24 September 2024

Hanwha PNM-C34404RQPZ Manual

1 September 2024

Hanwha XNO-9083R Manual

31 August 2024

Hanwha LNO-6012R Manual

30 August 2024

Hanwha XNV-6081R Manual

30 August 2024

Hanwha QNO-7022R Manual

30 August 2024

Hanwha XNO-9082R Manual

30 August 2024

Hanwha XNV-8081RE Manual

30 August 2024

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

Schlage WCO100 Manual

7 April 2025

Schlage WCW100 Manual

7 April 2025

IDIS TC-D5531RX Manual

6 April 2025

TP-Link Kasa Spot Pan Tilt EC71 Manual

29 Marts 2025

Night Owl CAM-PTZ18X-AHD7 Manual

28 Marts 2025

Tesla Smart Camera 360 4G Battery Manual

20 Marts 2025

Tesla Smart Camera Outdoor 2K Manual

20 Marts 2025

Tesla Smart Camera Omni 360 Manual

20 Marts 2025

Airlive AirCam PTZB-630MAI Manual

13 Marts 2025

Wisenet PNM-9022V Manual

8 Marts 2025
