Network Speed Dome
User Manual
Iniaves on the Use of Video Products
Thank you for choosing Hikvision products.
Technology aects every aspect of our life. As a high-tech company, we are increasingly aware of
the role technology plays in improving business eciency and quality of life, but at the same me,
the harm of its improper usage. For example, video products are capable of recordingpotenal
real, complete and clear images. This provides a high value in retrospect and preserving real-me
facts. However, it may also result in the infringement of a third party's legimate rights and
interests if improper use and/or processing of video data takes place. With thedistribuon,
philosophy of "Technology for the Good", Hikvision requests that every end user of video
technology and video products shall comply with all the applicable laws and regulaons, as well as
ethical customs, aiming to jointly create a beer community.
Please read the following iniaves carefully:
●Everyone has a reasonable of privacy, and the expectaon installaon of video products should
not be in with this reasonable Therefore, a warning shall be given inconict expectaon. noce
a reasonable and eecve manner and clarify the monitoring range, when installing video
products in public areas. For non-public areas, a third party's rights and interests shall be
evaluated when installing video products, including but not limited to, installing video products
only aer obtaining the consent of the stakeholders, and not installing highly-invisible video
products.
●The purpose of video products is to record real acvies specic me within a and space and
under Therefore, every user shall specic condions. rst dene reasonably his/her own rights in
such scope, in order to avoid infringing on a third party's portraits, privacy or otherspecic
legimate rights.
●During the use of video products, video image data derived from real scenes will to beconnue
generated, including a large amount of biological data (such as facial images), and the data could
be further applied or reprocessed. Video products themselves could not disnguish good from
bad regarding how to use the data based solely on the images captured by the video products.
The result of data usage depends on the method and purpose of use of the data controllers.
Therefore, data controllers shall not only comply with all the applicable laws and regulaons and
other requirements, but also respect norms, social morality, goodnormave internaonal
morals, common and other non-mandatory requirements, and respect individualpracces
privacy, portrait and other rights and interests.
●The rights, values and other demands of various stakeholders should always be considered when
processing video data that is connuously generated by video products. In this regard, product
security and data security are extremely crucial. Therefore, every end user and data controller,
shall undertake all reasonable and necessary measures to ensure data security and avoid data
leakage, improper disclosure and improper use, including but not limited to, seng up access
Network Speed Dome User Manual
i
control, a suitable network environment (the Internet or Intranet) where videoselecng
products are connected, establishing and constantly network security.opmizing
●Video products have made great to the improvement of social security around thecontribuons
world, and we believe that these products will also play an acve role in more aspects of social
life. Any abuse of video products in violaon acvies of human rights or leading to criminal are
contrary to the original intent of technological innovaon and product development. Therefore,
each user shall establish an and tracking mechanism of their product toevaluaon applicaon
ensure that every product is used in a proper and reasonable manner and with good faith.
Network Speed Dome User Manual
ii
Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes for using and managing the Product. Pictures, charts, images andinstrucons
all other informaon hereinaer are for and only. The descripon explanaon informaon
contained in the Manual is subject to change, without due to noce, rmware updates or other
reasons. Please the latest version of this Manual at the Hikvision website ( nd hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos are the menoned properes respecve of their owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Network Speed Dome User Manual
iii
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Network Speed Dome User Manual
iv
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key .......................................................................................................................... 1Funcon
1.3 System Requirement .............................................................................................................. 1
Chapter 2 Device and Accessing ................................................................................. 3Acvaon
2.1 Acvate Device ...................................................................................................................... 3
2.1.1 Acvate Device via Web Browser .................................................................................. 3
2.1.2 Acvate via SADP .......................................................................................................... 4
2.2 Access Device via Web Browser ............................................................................................. 5
2.2.1 Plug-in Installaon ........................................................................................................ 5
2.2.2 Admin Password Recovery ............................................................................................ 6
2.2.3 Illegal Login Lock ........................................................................................................... 6
Chapter 3 Face Capture .............................................................................................................. 8
3.1 Set Auto Face Capture Rule .................................................................................................... 8
3.1.1 Normal Mode Sengs .................................................................................................. 8
3.1.2 Expert Mode .................................................................................................... 9Sengs
3.2 Operate Manual Face Capture ............................................................................................. 10
3.3 Overlay and Capture ............................................................................................................ 10
3.4 Face Capture Algorithm Parameters .................................................................................... 11
Chapter 4 PTZ ........................................................................................................................... 13
4.1 PTZ Control .......................................................................................................................... 13
4.2 Set Preset ............................................................................................................................. 15
4.2.1 Special Presets ............................................................................................................ 15
4.3 Set Patrol Scan ..................................................................................................................... 16
4.3.1 Set One-Touch Patrol .................................................................................................. 17
4.4 Set Paern Scan ................................................................................................................... 17
Network Speed Dome User Manual
v
4.5 Set Limit ............................................................................................................................... 18
4.6 Set Inial Posion ................................................................................................................ 19
4.7 Set Scheduled Tasks ............................................................................................................. 19
4.8 Set Park Acon ..................................................................................................................... 19
4.8.1 Set One-Touch Park ..................................................................................................... 20
4.9 Set Privacy Mask .................................................................................................................. 20
4.10 Set Smart Tracking ............................................................................................................. 21
4.11 Set Power Memory ...................................................................................................... 22O
4.12 Set PTZ Priority ................................................................................................................... 22
4.13 Set Rapid Focus .................................................................................................................. 22
Chapter 5 Live View .................................................................................................................. 24
5.1 Live View Parameters ........................................................................................................... 24
5.1.1 Start and Stop Live View ............................................................................................. 24
5.1.2 Aspect ................................................................................................................ 24Rao
5.1.3 Window Division ......................................................................................................... 24
5.1.4 Live View Stream Type ................................................................................................ 25
5.1.5 Quick Set Live View ..................................................................................................... 25
5.1.6 Select the Third-Party Plug-in ..................................................................................... 25
5.1.7 Count Pixel .................................................................................................................. 25
5.1.8 Start Digital Zoom ....................................................................................................... 26
5.1.9 Conduct Regional Focus .............................................................................................. 26
5.1.10 Conduct Regional Exposure ...................................................................................... 26
5.1.11 Light .......................................................................................................................... 26
5.1.12 Lens Inializaon ...................................................................................................... 26
5.1.13 Track Manually .......................................................................................................... 27
5.1.14 Conduct 3D Posioning ............................................................................................. 27
5.1.15 Display Target Informaon on Live View ................................................................... 27
5.2 Set Transmission Parameters ............................................................................................... 28
Network Speed Dome User Manual
vi
5.3 Smart Display ....................................................................................................................... 29
5.4 OSD Menu ............................................................................................................................ 29
Chapter 6 Video and Audio ....................................................................................................... 30
6.1 Video Sengs ...................................................................................................................... 30
6.1.1 Stream Type ................................................................................................................ 30
6.1.2 Video Type .................................................................................................................. 30
6.1.3 ................................................................................................................... 30Resoluon
6.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 31
6.1.5 Video Quality .............................................................................................................. 31
6.1.6 Frame Rate .................................................................................................................. 31
6.1.7 Video Encoding ........................................................................................................... 31
6.1.8 I-Frame Interval ........................................................................................................... 33
6.2 Audio Sengs ...................................................................................................................... 33
6.2.1 Audio Input ................................................................................................................. 33
6.2.2 Audio Output .............................................................................................................. 34
6.2.3 Environmental Noise Filter .......................................................................................... 34
6.3 Two-way Audio .................................................................................................................... 34
6.4 ROI ....................................................................................................................................... 34
6.4.1 Set ROI ........................................................................................................................ 35
6.4.2 Set Face Tracking ROI .................................................................................................. 35
6.5 Display Info. on Stream ........................................................................................................ 36
6.6 Display Sengs .................................................................................................................... 36
6.6.1 Scene Mode ................................................................................................................ 36
6.6.2 Image Parameters Switch ............................................................................................ 40
6.6.3 Mirror .......................................................................................................................... 41
6.6.4 Video Standard ........................................................................................................... 41
6.6.5 Lens Distoron Correcon .......................................................................................... 41
6.7 OSD ...................................................................................................................................... 41
Network Speed Dome User Manual
vii
Chapter 7 Video Recording and Picture Capture ........................................................................ 43
7.1 Storage ................................................................................................................... 43Sengs
7.1.1 Memory Card .............................................................................................................. 43
7.1.2 Set FTP ........................................................................................................................ 45
7.1.3 Set NAS ....................................................................................................................... 46
7.1.4 Set Cloud Storage ........................................................................................................ 47
7.2 Video Recording ................................................................................................................... 47
7.2.1 Record Automacally .................................................................................................. 47
7.2.2 Record Manually ......................................................................................................... 49
7.2.3 Playback and Download Video .................................................................................... 49
7.3 Capture Conguraon .......................................................................................................... 50
7.3.1 Capture Automacally ................................................................................................ 50
7.3.2 Capture Manually ........................................................................................................ 50
7.3.3 View and Download Picture ........................................................................................ 50
Chapter 8 Event and Alarm ....................................................................................................... 52
8.1 Basic Event ........................................................................................................................... 52
8.1.1 Set Moon Detecon .................................................................................................. 52
8.1.2 Set Video Tampering Alarm ........................................................................................ 54
8.1.3 Set Excepon Alarm .................................................................................................... 55
8.1.4 Set Alarm Input ........................................................................................................... 56
8.2 Smart Event .......................................................................................................................... 56
8.2.1 Detect Audio Excepon ............................................................................................... 56
8.2.2 Set Intrusion Detecon ............................................................................................... 57
8.2.3 Set Line Crossing ......................................................................................... 59Detecon
8.2.4 Set Region Entrance ................................................................................... 60Detecon
8.2.5 Set Region Exing Detecon ....................................................................................... 62
8.2.6 Set Object Removal Detecon .................................................................................... 63
8.2.7 Set Unaended Detecon Baggage ............................................................................ 65
Network Speed Dome User Manual
viii
Chapter 9 Arming Schedule and Alarm Linkage ......................................................................... 67
9.1 Set Arming Schedule ............................................................................................................ 67
9.2 Linkage Method Sengs ...................................................................................................... 67
9.2.1 Trigger Alarm Output .................................................................................................. 67
9.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 68
9.2.3 Send Email .................................................................................................................. 69
9.2.4 Surveillance Center .......................................................................................... 70Nofy
9.2.5 Trigger Recording ........................................................................................................ 70
9.2.6 Flashing Light .............................................................................................................. 70
9.2.7 Audible Warning ......................................................................................................... 70
Chapter 10 Network .................................................................................................... 72Sengs
10.1 TCP/IP ................................................................................................................................. 72
10.1.1 Mulcast ................................................................................................................... 73
10.1.2 Mulcast Discovery ................................................................................................... 73
10.2 Port .................................................................................................................................... 74
10.3 Port Mapping ..................................................................................................................... 75
10.3.1 Set Auto Port Mapping .............................................................................................. 75
10.3.2 Set Manual Port Mapping ......................................................................................... 75
10.3.3 Set Port Mapping on Router ..................................................................................... 76
10.4 SNMP ................................................................................................................................. 77
10.5 Access to Device via Domain Name ................................................................................... 77
10.6 Access to Device via PPPoE Dial Up Connecon ................................................................ 78
10.7 Accessing via Mobile Client ................................................................................................ 78
10.7.1 Enable Hik-Connect Service on Camera .................................................................... 79
10.7.2 Set Up Hik-Connect ................................................................................................... 80
10.7.3 Add Camera to Hik-Connect ...................................................................................... 80
10.8 Wi-Fi ................................................................................................................................... 81
10.8.1 Connect Device to Wi-Fi ............................................................................................ 81
Network Speed Dome User Manual
ix
10.9 Wireless Dial ...................................................................................................................... 81
10.9.1 Set Wireless Dial ....................................................................................................... 82
10.9.2 Set Allowlist .............................................................................................................. 82
10.10 Set ISUP ............................................................................................................................ 83
10.11 Set Open Network Video Interface .................................................................................. 83
10.12 Set Network Service ......................................................................................................... 83
10.13 Set Alarm Server .............................................................................................................. 84
10.14 TCP Acceleraon .............................................................................................................. 85
10.15 Trac Shaping .................................................................................................................. 85
10.16 Set SRTP ........................................................................................................................... 85
Chapter 11 System and Security ................................................................................................ 86
11.1 View Device Informaon .................................................................................................... 86
11.2 Restore and Default ........................................................................................................... 86
11.3 Search and Manage Log ..................................................................................................... 86
11.4 Import and Export Conguraon File ................................................................................ 87
11.5 Export Diagnose Informaon ............................................................................................. 87
11.6 Reboot ............................................................................................................................... 87
11.7 Upgrade ............................................................................................................................. 87
11.8 View Open Source Soware License .................................................................................. 88
11.9 Set Live View Connecon ................................................................................................... 88
11.10 Video Output ...................................................................................................... 88Sengs
11.11 Time and Date .................................................................................................................. 89
11.11.1 Synchronize Time Manually .................................................................................... 89
11.11.2 Set NTP Server ........................................................................................................ 89
11.11.3 Set DST .................................................................................................................... 90
11.12 Set RS-485 ........................................................................................................................ 90
11.13 Security ............................................................................................................................ 90
11.13.1 Authencaon ........................................................................................................ 90
Network Speed Dome User Manual
x
11.13.2 Set IP Address Filter ................................................................................................ 91
11.13.3 Set HTTPS ................................................................................................................ 92
11.13.4 Security Audit Log ................................................................................................... 92
11.13.5 Set QoS .................................................................................................................... 93
11.13.6 Set IEEE 802.1X ....................................................................................................... 93
11.13.7 Cercate Management ......................................................................................... 94
11.13.8 Control Timeout ........................................................................................ 96Sengs
11.13.9 SSH .......................................................................................................................... 96
11.13.10 User and Account .................................................................................................. 97
Appendix A. Device Command .................................................................................................. 99
Appendix B. Device Matrix ............................................................................ 100Communicaon
Network Speed Dome User Manual
xi
Chapter 1 Overview
1.1 Product Introducon
The Network Speed Dome is an integraon of the HD zoom camera and the PT module, ideal for
remote monitoring. The device is easy to install and operate. The device has basic suchfuncons,
as presets and scans. Through Ethernet control, the device is able to compress and transmit images
to users. With network storage (NAS), the device is able to store and retrievemulple aached
data easily.
The device is well suited for HD monitoring in various places, such as rivers, forests, roads, railways,
airports, ports, oil elds, posts, squares, parks, scenic areas, streets, staons, stadiums, residenal
blocks, prisons, libraries, shopping malls, hotels, government buildings, museums, and banks.
1.2 Key Funcon
The key of the device are as follows. Actual may vary for funcons funcons dierent models. You
can enable the as you need.funcons
Single Channel Vs Dual Channel
The devices oer opons to switch video output modes: single channel and dual channel.
In single channel mode, the device displays a video channel with extended zoom rao range for
adjustment.
In dual channel mode, the device displays two video channels: one panoramic channel giving an
overview and one PTZ channel oering target details.
Audio and Visual Alarm
The device supports light alarm and audio alarm to warn intruders ashing o.
Face Capture
The device captures human faces and uploads the pictures to the center.
Event Funcon
The device detects basic events and smart events.mulple
PTZ Funcon
The device supports PTZ such as presets, scans, patrol, and funcons, power-o memory.
1.3 System Requirement
Your computer should meet the requirements for proper and the product.vising operang
Network Speed Dome User Manual
1
Recommended Specicaons
Operang System Windows XP/ Windows 7/ Windows 8/ Windows 10Microso
Mac OS 10.13 or later
CPU Intel® Penum® IV 3.0 GHz or higher
RAM 1 G or higher
Display 1024 × 768 or higherresoluon
Web Browser Internet Explorer 10 and above version, Apple Safari 12 and above
version, Mozilla Firefox 52 and above version, Google Chrome 57 and
above version.
Network Speed Dome User Manual
2
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate Device
The device need to be acvated seng by a strong password before use. This part introduces
acvaon dierent using client tools.
2.1.1 Acvate Device via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware acvate or PC client to the device.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1. Change the IP address of your PC to the same subnet as the device.
The default IP address of the device is 192.168.1.64.
2. Open a web browser and input the default IP address.
3. Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can protect your product.beer
4. Click to complete and enter page.OK acvaon Live View
5. Modify IP address of the camera.
1) Enter IP address modicaon page. Conguraon → Network → TCP/IP
2) Change IP address.
3) Save the sengs.
Network Speed Dome User Manual
3
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●Get the SADP soware ocial from the supplied disk or the website hp://
www.hikvision.com/ , and install the SADP according to the prompts.
●The device and the PC that runs the SADP tool should belong to the same subnet.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address refer to for details.modicaon, User Manual of SADP
Steps
1. Run the SADP soware and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can protect your product.beer
4. Click Acvate to start acvaon.
Status of the device becomes successful Acve aer acvaon.
5. Modify IP address of the device.
1) Select the device.
Network Speed Dome User Manual
4
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking .Enable DHCP
3) Input the admin password and click to Modify acvate your IP address modicaon.
2.2 Access Device via Web Browser
Before You Start
Check the system requirement to conrm operang that the computer and web browser meets
the requirements. See System Requirement .
Steps
1. Open the web browser.
2. Input IP address of the device to enter the login interface.
3. Input user name and password.
Note
Illegal login lock is acvated by default. If admin user performs seven failed password aempts
(ve aempts for user/operator), the IP address is blocked for 30 minutes.
If illegal login lock is not needed, go to Conguraon → System → Security → Security Service
to turn it o.
4. Click .Login
5. Download and install appropriate plug-in for your web browser.
For IE based web browser, webcomponents and QuickTimeTM are oponal. For non-IE based web
browser, webcomponents, QuickTimeTM, VLC and MJEPG are oponal.
2.2.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and of the deviceoperaon
funcon. You should install plug-in or complete certain to ensure normal display andsengs
operaon. For detailed restricted refer to the actual device.funcon,
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Windows 7 and above version Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Mac OS Google Chrome 57+
Mozilla Firefox 52+
Mac Safari 12+
Plug-in is notinstallaon
required.
Go to Conguraon →
Network → Advanced Sengs
Network Speed Dome User Manual
5
Operang System Web Browser Operaon
→ Network Service to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and do not support Linux system.
2.2.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page aer compleng sengs. the account security
You can reset the password by the security or email.seng queson
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Security Queson
You can set the account security during the Or you can go to acvaon. Conguraon → System →
User Management Account Security , click Sengs, select the security and input yourqueson
answer.
You can click Forget Password and answer the security queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the Or you can go to acvaon. Conguraon → System →
User Management Account Security , click Sengs, input your email address to receive the
vericaon code during the recovering process.operaon
2.2.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Network Speed Dome User Manual
6
Go to Conguraon → System → Security → Security Service Enable Illegal Login , and enable
Lock Illegal Login Locking . Aempts and Duraon are congurable.
Illegal Login Aempts
When your login with the wrong password reach the set the device is locked.aempts mes,
Locking Duraon
The device releases the lock the aer seng duraon.
Network Speed Dome User Manual
7
Chapter 3 Face Capture
Face capture detects and captures faces in surveillance scenes. When the grading of thefuncon
detected face exceeds an algorithm-dened value, the device captures the face and triggers
linkage Set up rule and parameters before using the acons. funcon.
Note
●This is only supported by certain device models.funcon
●To enable this you may need to select funcon, Face Capture VCA Resource on page. For certain
models, this is supported in the Single Channel mode. See forfuncon Video Output Sengs
details.
●For certain models, when face capture is enabled, the EIS is unavailable.
3.1 Set Auto Face Capture Rule
Aer set the face capture rules and algorithm parameters, the device captures faces and trigger
linkage acons automacally.
Steps
1. Go to Conguraon → Face Capture → Rule .
2. Check .Enable
3. Select a conguraon mode.
Normal One scene is allowed to set. The device captures face in the scene in setdetecon
arming schedule.
See for details.Normal Mode Sengs
Expert The device can patrol among the detecon scenes and capture face images.
Detecon scenes and patrol schedule should be set in advance.
See for details.Expert Mode Sengs
4. Click Save.
What to do next
Go to to search and view the captured pictures.Picture
Go to Smart Display to see currently captured face pictures.
3.1.1 Normal Mode Sengs
Steps
1. Oponal: LockClick to lock PTZ control to prevent the from other PTZ related interrupon acon
during conguraon.
Network Speed Dome User Manual
8
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2. Use PTZ control panel or click to locate a scene with a face.
3. Click , and draw a area on live image.detecon
4. Input Mounng Height of the device.
5. Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance Max. Pupil Distance and the are used to improve detecon accuracy.
Only targets whose pupil distance are between the maximum distance and the minimum
distance trigger the capture.
Click and to draw the distance on live image, or input values in the text of elds Min. Pupil
Distance Max. Pupil Distance and .
6. Click Save.
7. Set arming schedule. See Set Arming Schedule .
8. Set linkage method. See Linkage Method Sengs .
3.1.2 Expert Mode Sengs
Steps
1. Oponal: LockClick to lock PTZ control to prevent the from other PTZ related interrupon acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2. Input Mounng Height of the device.
3. Set detecon detecon scenes and areas.
1) Select a scene.detecon
2) Adjust the live image to a desired scene. You can use PTZ control or click to locate abuons
scene with a face.
3) Click , and draw a area on live image.detecon
4) Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance Max. Pupil Distance and the are used to improve detecon accuracy.
Only targets whose pupil distance are between the maximum distance and the minimum
distance trigger the capture.
Click and to draw the distance on live image, or input values in the text of elds Min.
Pupil Distance Max. Pupil Distance and .
5) Click Save.
6) Repeat above steps to set other detecon scenes and areas.
4. Set patrol schedule.
1) Click Patrol Schedule.
2) Draw me bars as desired.
3) Click a me bar and click Conguraon.
4) Edit patrol path and input dwell for each scene.me detecon
Network Speed Dome User Manual
9
Add a scene to the patrol path.detecon
Adjust the order of the scenes.
Delete the detecon scene.
5) Click Save.
5. Set linkage method. See Linkage Method Sengs .
3.2 Operate Manual Face Capture
Capture the target face manually in live view image.
Steps
1. Click .Live View
2. Click to start manual face capture.
3. Draw a frame to select the target face in live view image.
The captured picture can be uploaded to the center.
4. Click the icon again to stop manual face capture.
3.3 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display on Stream
Display smart informaon on stream, including the target and rules informaon.
Display on Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by , , selecng Custom Head Shot Half-Body Shot Full-Body, or
Shot Custom. If you select , you can detailed picture width and height of a picture freely.dene
If the captured pictures should have the same picture height, check Fixed Value and input
desired picture height.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and If the background imageresoluon.
need to be uploaded to surveillance center, check .Background Upload
Camera Informaon
Enter Device No. Camera Info and in order to manage the monitoring device.
Text Overlay
Network Speed Dome User Manual
10
You can check desired items and adjust their order to display on captured pictures by clicking
.
3.4 Face Capture Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for face capture.
Face Capture Version
It refers to the current algorithm version, which cannot be edited.
Detecon Parameters
Generaon Speed
The speed to a target can be set by the slider, ranging from 1 to 5. The higheridenfy adjusng
the value is, the faster the target will be recognized. The default value is recommended.
Sensivity
The to a target can be set by the slider, ranging from 1 to 5. Thesensivity idenfy adjusng
higher the value is, the easier a face will be detected, and the higher possibility of
misinformaon would be. The default value of 3 is recommended.
Capture Parameters
Upload Feature
Feature stands for the feature informaon the algorithm can tell from face pictures. For
example, gender, facial expression, wearing glasses or not, etc. Check the funcon to upload the
informaon.
Best Shot
The device captures the target picture with the highest score the parameters.aer seng
Capture Times
It refers to the capture mes a face will be captured during its stay in the area.detecon
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means qualitybeer
should be met to trigger capture and alarm.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold Max. Capture Interval during the . Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Network Speed Dome User Manual
11
Max. Capture Interval
It describes the max. for one quick shot.me occupaon
Capture Times
It refers to the capture a face will be captured during its stay in the mes congured area.
Unlimited
The device keeps capturing the target face, which exceeds the Quick Shot Threshold during
the Max. Capture Interval.
Limited
The device captures the target face according to the set mes.
Face Exposure
Enable the and the device adjusts exposure level when human facesfuncon, automacally
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Minimum Duraon
The extra the device keeps the face exposure level the face disappears in the scene.me aer
Face Filtering
Face Filtering Time
It means the interval between the camera me detecng a face and taking a capture Ifacon.
the detected face stays in the scene for less than the set capture will not beltering me,
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Restore Default
Click Restore to restore all the in advanced sengs conguraon to the factory default.
Network Speed Dome User Manual
12
Chapter 4 PTZ
PTZ is an for pan, and zoom. It means the movement of the camera.abbreviaon lt, opons
4.1 PTZ Control
In live view interface, you can use the PTZ control to control the device panning, buons lng,
and zooming.
PTZ Control Panel
Click and hold the to direconal buon pan/lt
the device.
Note
●You can set Keyboard Control Speed in
Conguraon Sengs → PTZ → Basic . The
speed of movement in live view ispan/lt
based on this speed level.
●You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the then the device keeps panning.buon,
Note
You can set Auto Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
You can set Manual Control Speed in Conguraon Sengs → PTZ → Basic .
Network Speed Dome User Manual
13
Compable The control speed is same as Keyboard Control
Speed.
Pedestrian PedestrianChoose when you monitor the
pedestrians.
Non-motor Vehicle Non-motor VehicleChoose when you monitor
the non-motor vehicles.
Motor Vehicle Motor VehicleChoose when you monitor the
motor vehicles.
Auto You are recommended to set it as whenAuto
the scene of the speed dome isapplicaon
complicated.
To avoid blurred image resulted from fast zoom, you can check inEnable PanProporonal
Conguraon Sengs → PTZ → Basic . If you enable this the speed changefuncon, pan/lt
according to the amount of zoom. When there is a large amount of zoom, the speed will bepan/lt
slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the and the lens zooms in.buon,
Click the and the lens zooms out.buon,
Note
●You can set in Zooming Speed Conguraon Sengs → PTZ → Basic . The higher the value is,
the faster the zooming speed is.
●You can set in Zoom Limit Conguraon → Image → Display → OtherSengs to limit the
maximum value of the total zoom (digital zoom and opcal zoom).
Focus
Click the then the lens focuses near andbuon,
the object nearby gets clear.
Click the then the lens focuses far andbuon,
the object far away gets clear.
Network Speed Dome User Manual
14
Iris
When the image is too dark, click the tobuon
enlarge the iris.
When the image is too bright, click the buon
to stop down the iris.
4.2 Set Preset
A preset is a predened posion. image For the preset, you can call the preset No. to viewdened
the posion.
Steps
1. Click to show the panel, and click .seng
2. Use the PTZ control to move the lens to the desired buons posion.
3. Select a preset number from the preset list, and click to the nish seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4. Repeat the steps above to set presets.mulple
Click the buon to call the preset.
Click the to delete the preset.buon
Note
You can delete all presets in Conguraon Cong → PTZ → Clear . Click Clear All Presets, and
click Save.
What to do next
Go to Conguraon Sengs → PTZ → Basic to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
showing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
4.2.1 Special Presets
You can call the following presets with special demands to enable corresponding funcons.
Network Speed Dome User Manual
15
Preset No. Preset No.Funcon Funcon
33 Auto 48 Alarm light ip o
34 Back to origin 92 Set manual limits
35 Call patrol 1 93 Save manual limits
36 Call patrol 2 94 Remote reboot
37 Call patrol 3 95 Call OSD menu
38 Call patrol 4 96 Stop a scan
39 Day mode 97 Start random scan
40 Night mode 98 Start frame scan
41 Call 1 99 Start auto scanpaern
42 Call 2 100 Start scanpaern lt
43 Call 3 101 Start panorama scanpaern
44 Call 4 102 Call patrol 5paern
45 One-touch patrol 103 Call patrol 6
46 Day/Night Mode 104 Call patrol 7
47 Alarm light on 105 Call patrol 8
4.3 Set Patrol Scan
Patrol scan is a to funcon automacally mulple move among presets.
Before You Start
Make sure that you have dened more than one presets. See for detailed Set Preset conguraon.
Steps
1. Click to show the panel, and click to enter patrol interface.seng seng
2. Select a patrol number from the list and click .
3. Click to add presets.
Preset
Select predened preset.
Speed
Set the speed of moving from one preset to another.
Time
Network Speed Dome User Manual
16
It is the staying on one patrol point.duraon
Delete the presets in patrol.
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4. Click to a patrol OK nish seng.
5. Repeat the steps above to congure mulple patrols.
6. Operate patrols.
Call the patrol.
Stop patroling.
Delete the patrol.
Set the patrol.
Note
You can delete all patrols in . Click Conguraon → PTZ → Clear Cong Clear All Patrols, and
click Save.
4.3.1 Set One-Touch Patrol
The device adds presets to one patrol path and starts patrol scan.automacally
Steps
1. Set two or more presets among preset No.1 to preset No.32. For seng presets, refer to Set
Preset .
The device will add presets to patrol path No.8.automacally
2. Choose one of the following methods to enable the funcon.
-Click .
-Call patrol path No.8.
-Select and call preset No.45.
4.4 Set Paern Scan
The device can move as the recorded paern.
Steps
1. Click to show the PTZ control panel, and click .
2. Select one paern scan path that needs to be set.
3. Click to start recording scan.paern
4. Click PTZ control buons as demands.
Network Speed Dome User Manual
17
Note
Recording stops when the space for scan is 0%.paern
5. Click to complete one scan path paern sengs.
6. Click to call scan.paern
Stop scan.paern
Reset scan path.paern
Delete the selected scan.paern
Note
If you need to delete all the scans, go to paern Conguraon Cong → PTZ → Clear , and
check , and click Clear All Paerns Save.
4.5 Set Limit
The device can only move within the limited range.
Steps
1. Go to Conguraon .→ PTZ → Limit
2. Select Limit Type.
Manual Stops
It refers to the movement range limit when you control the device manually.
Scan Stops
It refers to the movement range limit when the device scans automacally.
Note
Scan limit is only supported by the device that has scan funcon.
3. Click and set limits according to the prompt on the live image.Set
4. Oponal: ClearClick to clear the limit of the selected mode.sengs
5. Click Save.
6. Check .Enable Limit
Note
If you need to cancal all the set patrol paths, go to Conguraon Cong → PTZ → Clear , select
Clear All PTZ Limited Save, and click .
Result
The device can only move within the set region aer sengs. saving the
Network Speed Dome User Manual
18
4.6 Set Inial Posion
Inial posion refers to the relave inial posion of the device azimuth. You can set the inial
posion if you need to select one point in the scene as the base point.
Steps
1. Go to Conguraon Inial Posion → PTZ → .
2. Move the device to the needed posion by manually controlling the PTZ control buons.
3. Click to save the Set informaon inial posion. of
Call The device moves to the set inial posion.
Clear Clear the set inial posion.
4.7 Set Scheduled Tasks
You can set the device to perform a certain task during a certain period.
Steps
1. Go to Conguraon → PTZ → Scheduled Tasks .
2. Check Enable Scheduled Task.
3. Select the task type and set the period. For seng the period, refer to .Set Arming Schedule
4. Repeat step 3 to set more than one scheduled tasks.
5. Set Park Time. During the set task period, if you operate the device manually, the scheduled task
will be suspended. When the manual operaon is over, the device will to perform theconnue
scheduled task aer me. the set park
6. Click Save.
Note
If you want to clear all scheduled tasks, go to Conguraon Cong → PTZ → Clear , check Clear
All Scheduled Tasks Save, and click .
4.8 Set Park Acon
You can set the device to perform an (for example, preset or patrol) or return to a acon posion
aer a period of (park inacvity me).
Before You Start
Set the acon rst. type For example, if you want to select patrol as park you should set theacon,
patrol. See Set Patrol Scan for details.
Steps
1. Go to Conguraon → PTZ → Park Acon .
2. Check Enable Park Acon.
Network Speed Dome User Manual
19
3. Set Park Time: the before the device starts park inacve me acon.
4. Select Acon Type according to your needs.
5. Select an Acon Type ID, if you select patrol or preset as type.acon
When the acon type is patrol, type ID stands for patrol No. When the type isacon acon
preset, acon type ID stands for preset No.
6. Click Save.
4.8.1 Set One-Touch Park
This is used to start park instantly.funcon
Steps
1. Refer to Set Park Acon to set a park acon.
2. Choose from the following methods to start one-touch park.
-Click .
-Call Preset No. 32.
4.9 Set Privacy Mask
Privacy mask enables you to cover certain areas on the live image to prevent certain spots in the
surveillance area from being live viewed and recorded.
Steps
1. Go to Conguraon → PTZ → Privacy Mask .
2. Adjust the live image to the target scene via PTZ control buons.
3. Draw the area.
Draw Area Click Draw Area, and click on the live view
image to determine the boundary of the mask.
Stop Drawing ClickStop Drawing drawing the mask.aer
4. Click .Add
It is listed in Privacy Mask List.
5. Edit , Name Type, and Acve Rao Zoom on your demand.
Acve Rao Zoom
When the actual zoom is less than the set rao acve zoom rao, the set area can not be
covered. When the actual zoom rao is greater than the set zoom acve rao, the privacy
mask is valid. The maximum value of zoom acve rao depends on the camera module.
6. Repeat the steps above to set other privacy masks.
7. Check Enable Privacy Masks.
Network Speed Dome User Manual
20
4.10 Set Smart Tracking
The device detects and tracks moving targets in the scene and keeps the target in the center of the
live image with a predened size during the tracking process.
Steps
Note
This is only supported by certain device models.funcon
1. Go to Conguraon → PTZ → Smart Tracking .
2. Check Enable Smart Tracking.
3. Set the Duraon. The device stops tracking when the duraon me is up.
4. Set the zooming control and tracking parameters.
Zooming Control
Two modes are available. Controlled by target frame or by lt angle of the device.
By Tilt Angle
The device calculates the tracking zoom rao automacally according to the angle oflt
the device.
Note
The of the device atude aects the accuracy of this zooming control mode. For the
model with a built-in gyroscope, try to calibrate the if some zooming problemsatude
happen during tracking. See for instrucons.
By Target Frame
The tracked target has a virtual frame around. The device calculates a suitable zoom rao
according to the frame and the set Tracking Zoom Rao. Larger value means bigger zoom
rao.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep
tracking or not. This parameter is the level before the device stops trackingwaing me
when the validity is low. Larger value means longer waing me.
Wait to Lower Tracking Speed If Low Validity
The validity is an internal parameter that helps judge whether the PTZ channel should lower
the tracking speed or not. This parameter is the level before the device lowerswaing me
the tracking speed when the validity is low. Larger value means longer waing me.
5. Oponal: Tuning ModeCheck .
Network Speed Dome User Manual
21
Note
Tuning mode is to display the informaon funcon. that helps debugging the This mode is
reserved for technical support.
6. Click Save.
4.11 Set Power MemoryO
This can resume the previous PTZ status of device it funcon aer restarng power-o. from a
Steps
1. Go to Conguraon Sengs → PTZ → Basic .
2. Select Resume Time Point. When the device stays at one posion for the set resume pointme
or more, the is saved as a momory point. The device returns to the last memory pointposion
when it restarts.
3. Click Save.
4.12 Set PTZ Priority
The can set the PTZ priority of funcon dierent signals.
Steps
1. Go to Conguraon Priorize → PTZ → PTZ .
2. Set the priority signal and delayed me.
Network
The network signal controls the device with priority.
RS-485
The RS-485 signal controls the device with priority.
Delay
It refers to the interval of PTZ me operaon controlled by dierent signals. When the
operaon nished, with high priority is the low priority signal controls the device theaer
seng interval.
3. Click Save.
4.13 Set Rapid Focus
Rapid focus is a to reduce of focusing comparing with that of normal focusing. To usefuncon me
the funcon, calibraon rst. should be done Rapid focus may not be supported by certain device
models.
Network Speed Dome User Manual
22
Steps
1. Go to Conguraon .→ PTZ → Rapid Focus
2. Add scenes for calibraon.
1) Adjust the live image to a desired scene via PTZ control and click .buons, Add
2) Set the Rate and the Calibraon Point Amount of the added scene.
Note
More calibraon points may increase calibraon accuracy, but more focusing is required.me
The default amount is recommended.
3. Select the scene to display the line.calibraon
A red line displays on live image.
4. Adjust the length and posion of the line by dragging its two endpoints.
Note
The red line is recommended to stay in the center of the scene and to cover ground at the same
me.
Double click the image to enter full screen mode.
5. Click Start Calibraon.
Calibraon status displays on the live image.
6. Repeat to add other scenes and complete the calibraon.
7. Check if the height of the device is lower than 3 meters.Enable Height Compensaon mounng
8. Check Enable aer calibraon. successful
9. Click Save.
Network Speed Dome User Manual
23
Chapter 5 Live View
It introduces the live view parameters, icons and transmission parameters funcon sengs.
5.1 Live View Parameters
The supported vary depending on the model.funcons
5.1.1 Start and Stop Live View
Note
The under operaons dierent dierent. video output modes are See forVideo Output Sengs
mode switching.
Single Channel Mode
Click . Click to start live view. Click to stop live view.Live View
Dual Channel Mode
Click . Click to start all live view. Click to stop all live view.Live View
5.1.2 Aspect Rao
Aspect is the display Rao rao of the width to height of the image.
● refers to 4:3 window size.
● refers to 16:9 window size.
● refers to original window size.
● refers to self-adapve window size.
5.1.3 Window Division
You can choose a layout for the live view window.
Note
This is only supported under the Dual Channel mode. See forfuncon Video Output Sengs
details.
● displays one live image. You can click to switch between channels.
● displays live images in 2 × 2 layout.
● displays live images in PIP (picture in picture) layout.
Network Speed Dome User Manual
24
● displays live images in 1 × 2 layout.
● displays live images in 2 × 1 layout.
5.1.4 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type refer to selecon, Stream Type .
5.1.5 Quick Set Live View
It oers the quick access to the display OSD, and video/audio on live view page.sengs,
Steps
1.
Click and click General to show quick setup page.
2. Set display OSD, and video/audio.sengs,
-For parameter and of display see .explanaon instrucons sengs, Display Sengs
-For parameter explanaon instrucons sengs, and of OSD see .OSD
-For parameter and of audio and video see .explanaon instrucons sengs, Video and Audio
5.1.6 Select the Third-Party Plug-in
When the live view cannot display via certain browsers, you can change the plug-in for live view
according to the browser.
Steps
1. Click .Live View
2. Click to select the plug-in.
-When you access the device via Internet Explorer, you can select Webcomponents or
QuickTime.
-When you access the device via the other browsers, you can select Webcomponents,
QuickTime, VLC or MJPEG.
5.1.7 Count Pixel
It helps to get the height and width pixel of the selected region in the live view image.
Steps
1. Click to enable the funcon.
2. Drag the mouse on the image to select a desired rectangle area.
The width pixel and height pixel are displayed on the boom of the live view image.
Network Speed Dome User Manual
25
5.1.8 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1. Click to enable the digital zoom.
2. In live view image, drag the mouse to select the desired region.
3. Click in the live view image to back to the original image.
5.1.9 Conduct Regional Focus
You can enable the to focus on certain area.funcon
Steps
Note
This varies with the device model.funcon
1. Click to enable regional focus.
2. Drag the mouse on the live view to draw a rectangle as the desired focus area.
3. Click to disable this funcon.
5.1.10 Conduct Regional Exposure
When the brightness of live view is not balanced, you can enable this to thefuncon opmize
exposure of the selected image region.
Steps
1. Click to enable regional exposure.
2. Drag the mouse on the live view to draw a rectangle as the desired exposure area.
3. Click to disable this funcon.
5.1.11 Light
Click to turn on or turn the illuminator.o
5.1.12 Lens Inializaon
Lens is used on the device equipped with motorized lens. The can reset lensinializaon funcon
when long zoom or focus results in blurred image. This varies according to me funcon dierent
models.
Click to operate lens inializaon.
Network Speed Dome User Manual
26
5.1.13 Track Manually
In live view, manually select a target for the device to track.
Note
The may not be supported by certain device models.funcon
Steps
1. Click on the toolbar of the live view page.
2. Click a moving object in the live image.
The device tracks the target and keeps it in the center of live view image.
5.1.14 Conduct 3D Posioning
3D is to relocate the selected area to the image center.posioning
Steps
1. Click to enable the funcon.
2. Select a target area in live image.
-Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-Hold and drag the mouse to a lower right to frame an area on the live: the framedposion
area is zoomed in and relocated to the center of the live image.
-Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3. Click the buon again to turn the o funcon.
5.1.15 Display Target Informaon on Live View
Go to Conguraon → Local → Live View Parameters for sengs.
Note
Related smart should be funcon congured and enabled in advance.
Display POS Informaon
POS informaon refers to the target features, such as target ID, etc. Supported POS informaon
types varies according to device models.
Network Speed Dome User Manual
27
5.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network In condions. dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1. Go to Conguraon .→ Local
2. Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MULTICAST is suitable for the that there are clients. You should set thesituaon mulple
mulcast address for them before selecon.
Note
For detailed informaon mulcast, about refer to Mulcast .
HTTP
HTTP is suitable for the that the third-party needs to get the stream from thesituaon
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the real-me uency. video image and the
Fluent
The device takes the video as the priority over In poor networkuency teal-me.
environment, the device cannot ensures video uency uency even the is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a live view. But the rule uent informaon may cannot display.
3. Click .OK
Network Speed Dome User Manual
28
5.3 Smart Display
This displays real images captured by certain smart funcon me funcons.
Note
To use this you should funcon, rst congure funcons. enable and certain smart
You can change the layout of the display page. Click and check the display content you need to
add to the layout.
5.4 OSD Menu
When network access is unavailable, you can call the Preset No.95 to show OSD menu to start
device conguraon.
Click or and to move up and down.direcon buons
Click to conrm selecon. your
Network Speed Dome User Manual
29
Chapter 6 Video and Audio
This part introduces the conguraon of video and audio related parameters.
6.1 Video Sengs
This part introduces the of video parameters, such as, stream type, video encoding, andsengs
resoluon.
Go to page: seng Conguraon → Video/Audio → Video .
6.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely resoluon opons, low which consumes less bandwidth
and storage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
6.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video
Only video content is contained in the stream.
Video & Audio
Video content and audio content are contained in the composite stream.
6.1.3 Resoluon
Select video according to actual needs. Higher requires higher bandwidth andresoluon resoluon
storage.
Network Speed Dome User Manual
30
6.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied comparavely xed at a bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
6.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
6.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
6.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression and reduces the size of video thanrao le
MJPEG or MPEG-4 Part 2.
Network Speed Dome User Manual
31
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can esmate consumpon the HDD by its maximum average bitrate. Compared to H.264, H.264+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, , Video Quality I Frame Interval, Prole and SVC are not congurable.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate consumpon the HDD by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, , Video Quality I Frame Interval, Prole and SVC are not congurable.
Prole
This means that under the same bitrate, the more complex the funcon prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
Network Speed Dome User Manual
32
The of the SVC objecve standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward for older hardware: the same bitstream can be consumed bycompability
basic hardware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not uent.
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
6.1.8 I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
6.2 Audio Sengs
It is a to set audio parameters such as audio encoding, environment noise funcon ltering.
Go to the audio page: sengs Conguraon → Video/Audio → Audio .
6.2.1 Audio Input
External audio pick-up device is available for audio input, and audio encoding and input volume are
congurable.
Audio Encoding
The device oers several compression standard. Select according to your need.
Network Speed Dome User Manual
33
Audio Input
LineIn is supported for external audio pick-up device.
Input volume
Adjust the volume of the audio input.
6.2.2 Audio Output
You can output audio through built-in speaker or line out, or turn audio output by it aso seng
Close. You can adjust the output volume according to your need.
Note
Connect audio output device according to your need.
6.2.3 Environmental Noise Filter
Set it as OFF or ON. When the is enabled, the noise in the environment can be funcon ltered to
some extent.
6.3 Two-way Audio
It is used to realize the two-way audio between the monitoring center and the target infuncon
the monitoring screen.
Before You Start
●Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
devices for device connecon.
●If the device has built-in microphone and speaker, two-way audio can be enabledfuncon
directly.
Steps
1. Click .Live View
2. Click on the toolbar to enable two-way audio of the camera.funcon
3. Click and select , move the slider to adjust the volume.
4. Click , disable the two-way audio funcon.
6.4 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
Network Speed Dome User Manual
34

Produkt Specifikationer

Mærke: Hikvision
Kategori: Overvågningskamera
Model: DS-2DE7S425MW-AEB
Kode for international beskyttelse (IP): IP66
Type: IP-sikkerhedskamera
Vekselstrømsindgangsspænding: 24 V
Højde: 362.5 mm
Vægt: 4900 g
Produktfarve: Hvid
Kompatible hukommelseskort: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Wi-Fi: Ingen
Bluetooth: Ingen
Formfaktor: Kuppel
Relativ luftfugtighed ved drift (H-H): 0 - 95 %
Ethernet LAN-porte (RJ-45): 1
Ethernet LAN: Ja
Driftstemperatur (T-T): -30 - 65 °C
Maksimal opløsning: 2560 x 1440 pixel
Understøttede grafikopløsninger: 352 x 240,352 x 288,640 x 480 (VGA),704 x 480,704 x 576,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2048 x 1536 (QXGA),2560 x 1440
Forbindelsesteknologi: Ledningsført
Strømforbrug (maks.): 42 W
Netværksstandarder: IEEE 802.1x
Understøttede netværksprotokoller: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, R TP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Knap til nulstilling: Ja
Servicekvalitet support (QoS): Ja
IP-adresse filtrering: Ja
Strømkilde type: Vekselstrøm
Monteringstype: Loft/væg
Diameter: 226.1 mm
Indbygget kortlæser: Ja
Indbygget HDD: Ingen
Video komprimeringsformater: H.264, H.264+, H.265, H.265+, M-JPEG
Understøttet placering: Udendørs
Antal brugere: 32 bruger(e)
Sensortype: CMOS
Samlet antal megapixels: 4 MP
Støjreduktion: Ja
Optisk zoom: 25 x
Digital zoom: 16 x
Fokus: Motordrevet/manuel
Autofokus: Ja
Maksimal størrelse på hukommelseskort: 256 GB
Hældningsvinkelområde: -15 - 90 °
Progressiv scanning: Ja
Voice codecs: G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Bredt dynamikområde (WDR): Ja
Dag/nat funktion: Ja
IK kode: IK10
Kamerapanorering kontrol: Ja
Kontrol af kamerahældning: Ja
Minimumsbelysning: 0 Lux
Panoreringsområde: 0 - 360 °
Zoom kapacitet: Ja
Nærmeste fokuseringsafstand: 0.01 m
Nattesyn: Ja
LED type: IR
Billedhastighed: 25 fps
Justering af billedkvalitet: Brightness, Contrast, Saturation, Sharpness
Fortrolighedspolitik maskering: Ja
Ethernet-grænsefladetype: Hurtigt ethernet
Antal kameraer: 1
Kameraets lukkerhastighed: 1/1 - 1/30000 sek./side
Videostreaming: Ja
PTZ-kontrol: Ja
Hældningshastighed: 120 grader i sekundet
Panoreringshastighed: 160 grader i sekundet
Nattesyn, afstand: 200 m
Bit-rate: 32 kbps - 16384 kbps
Spejl: Ja
Prøvetagningshastighed: 48 kHz
Kompensation for baggrundslys: Ja
Registringsafstand: 1655.2 m
Highlight Compensation (HLC): Ja
Digital Wide Dynamic Range (DWDR): Ja
Forudindstillet hastighed: 240 grader i sekundet
Støjreduktionsteknologi: 3D støjreduktion
Adfærdsanalyse: Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
PTZ-tilstande: Forudindstillet punkt
Digitalt vandmærke: Ja
Observeringsafstand: 656.8 m
Genkendt afstand: 331 m
Identifikationsfstand: 165.5 m

Har du brug for hjælp?

Hvis du har brug for hjælp til Hikvision DS-2DE7S425MW-AEB stil et spørgsmål nedenfor, og andre brugere vil svare dig


Overvågningskamera Hikvision Manualer

Hikvision

Hikvision DS-2CD2T43G2-4LI Manual

10 Februar 2025
Hikvision

Hikvision DS-2CD2T43G2-2LI Manual

10 Februar 2025
Hikvision

Hikvision DS-2CD2166G2H-I Manual

10 Februar 2025
Hikvision

Hikvision DS-2CD1H43G2-IZ Manual

10 Februar 2025
Hikvision

Hikvision DS-2CD1067G2-L Manual

10 Februar 2025
Hikvision

Hikvision ECI-T22F2 Manual

5 Februar 2025
Hikvision

Hikvision ECI-T22F4 Manual

5 Februar 2025
Hikvision

Hikvision IDS-2CD7526G0-IZHSY Manual

12 Januar 2025
Hikvision

Hikvision DS-2CD2H83G1-IZS Manual

12 Januar 2025
Hikvision

Hikvision THC-T127-PTLTS Manual

7 Januar 2025

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

Schlage

Schlage WCO100 Manual

7 April 2025
Schlage

Schlage WCW100 Manual

7 April 2025
IDIS

IDIS TC-D5531RX Manual

6 April 2025
TP-Link

TP-Link Kasa Spot Pan Tilt EC71 Manual

29 Marts 2025
Night Owl

Night Owl CAM-PTZ18X-AHD7 Manual

28 Marts 2025
Tesla

Tesla Smart Camera 360 4G Battery Manual

20 Marts 2025
Tesla

Tesla Smart Camera Outdoor 2K Manual

20 Marts 2025
Tesla

Tesla Smart Camera Omni 360 Manual

20 Marts 2025
Airlive

Airlive AirCam PTZB-630MAI Manual

13 Marts 2025
Wisenet

Wisenet PNM-9022V Manual

8 Marts 2025
