DS-PWA32-HR

Wireless Security Control Panel UD11744B

Diagram References

E N G L I S H

Control Panel x 1 Power Adapter x 1 Screw x 4IC Card in Special Shapes x 5 Quick Start Guide x1Baery x 1

Components

Appearance

Installaon

Set up via APP

Log Into the Web Client

Set Up

Set up via Web Client

AC Power Power On

System Fault

No Fault

Panel is added to

Hik-connect account

Panel is not added to

Hik-connect account

Armed

Disarmed

Alarm Occurred

Device Tampered

No Alarm

Power Oﬀ

Fault

Link

Arm

/Disarm

Alarm

Note: Remove the rear cover, and some of the components and interfaces are on the rear panel.

1. Loosen the screw on the rear cover. Slide down the rear cover and remove it from the

control panel.

2. Insert a SIM card into the SIM card slot.

3. Connect the baery to the control panel.

4. Connect the power adapter to the control panel and a power outlet. The power indicator

turns green about 30s later, which means that the device is powered on.

Note: The condion of no SIM card, no baery, AC power oﬀ, or network disconnected, will cause Control Panel Fault.

5. Connect the Ethernet cable to an internet outlet. While the device is added to a Hik-Connect

account, the link indicator turns green.

6. Secure the rear cover in the installaon posion with the supplied screws. Aach the

control panel on the rear cover, and ghten the rear cover screw to complete the installaon.

Side Opening

If you need to route the cable though the boon of the panel, remove the sheet of the side

opening.

1. Log into the App Store or Google Play and input Hik-Connect to search and install the

mobile client.

2. Log into the APP with Hi-Connect account.

3. Tap Add Device. Scan the device QR code on the rear panel(on the lable).

4. Tap Connect to a Network. Select Wireless Connecon (AP) as the connecon mode.

5. Push the AP/STA mode switch to the AP posion, tab Conﬁrm.

6. Tap Connect to Wi-Fi on the promt-up window. Select and connect to a stable Wi-Fi , and

click Next.

7. Create a password to acvate the device.

8. Push the AP/STA mode switch to the STA posion.

Note: You need to enter the Veriﬁcaon Code (on the device lable which is pasted on the rear panel) before

acvaon if you add the device by entering the device serial No.(SN).

SIM Card Slot

Baery Connector

Network Interface

Power Interface

Reset Buon

AP&STA Switch

Tamper Spring

212

211

210

Note: The funcon of GPRS or 3/4G(implemented with build-in SIM card slot) depends on the model of the device.

TAMPER Screw

It is compulsory to secure the TAMPER screw.

Specification

Alarm Input 32

Alarm Output 32

Siren 2

Keyfob 8

Par on 1

Interac onAudio Output 1, 1.5W

RF Frequency 868MHz

RF Modula on 2GFSK

RF Distance 800m Open Area（）

Wired Network Ethernet 10M/100M Self-adap ve

Cellular Network GPRS, 3/4G

upports report push-no ca on to ARC & Cloud, text ﬁ 

o ca on via SMS, and audio no ca on via phone callﬁ  ﬁ 

Standard 802.11b/g/n

Encryp on Supported

Channel 2.4G

Applica on iVMS-4200, and mobile APP

Protocol SIA - Contact ID

IC Card 12

User 13 (1 Installer, 1 Administrator, and 11 General User)

Power

5 VDC 10W，

Consump on (without HDD) <5.6W

Opera on Temperature –10 to 55℃ ℃

Opera on Humidity 10% to 90%

Shell Material PC+ABS

Dimension(WxHxD) 155 x155x35mm

Wireless Device

Connec on

Applica on & 

Protocol

User

Others

Wi-Fi

Add Peripheral Device

While the control panel is not in the conﬁguraon mode, press the funcon buon on the

side of the control panel once and trigger a peripheral device.

Check RF Signal

While the control panel is not in the conﬁguraon mode, double press the funcon buon,

and you can check the RF signal strength on the peripheral device .

Set up via 4200 Client

Add a Camera for the Zone

Conﬁgure Video-Push

1. Download and install the iVMS-4200 client.

Note: Get the client soware from the oﬃcial website:www.hikvision.com.

2. Enter Device Management page, select the device in the Online Device List, click Edit

Network Sengs, change the port as 80, and click Add to Client.

Note: You should acvate the device for the ﬁrst usage.

1. Click System-Network Camera, and you can add two cameras for the control panel.

2. Click Wireless Device-Zone, select a zone, click the Sengs icon, and select a camera to link

with the zone.

You can also link a camera with the zone via APP, refer to the Wireless Security Control Panel

User Manual for details.

Funcon Buon Operaon

Input the device IP address in the address bar of the web browser. Create a password to

acvate the device and log into the web client.

Default IP Address when using mobile broswer in the AP mode:192.168.8.1. The device must be in the AP mode.

Default IP Address when connecing the network cable with computer directly :192.0.0.64

Note: Keyfobs cannot be added by funcon buon operaon.

You can view the alarm video via APP and email. For detailed sengs, refer to Security

Control Panel User Manual.

For mul-language switch , refer to Security Control Panel User Manual (scan the QR code) for details.

Note: Add card or keyfob via the web client before adding peripheral device for clearing tampering alarm.

2 4 2

Tear oﬀ

Cable Pipe

Cable Pipe Cable Pipe

22232425

Any and all informaon, including, among others, wordings, pictures, graphs are the properes of Hangzhou Hikvision Digital

Technology Co., Ltd. or its subsidiaries (hereinaer referred to be “Hikvision”). This user manual (hereinaer referred to be “the

Manual”) cannot be reproduced, changed, translated, or distributed, parally or wholly, by any means, without the prior wrien

permission of Hikvision. Unless otherwise spulated, Hikvision does not make any warranes, guarantees or representaons,

express or implied, regarding to the Manual.

About this Manual

This Manual is applicable to the Axiom Security Control Panel Kit.

The Manual includes instrucons for using and managing the product. Pictures, charts, images and all other informaon hereinaer

are for descripon and explanaon only. The informaon contained in the Manual is subject to change, without noce, due to

ﬁrmware updates or other reasons. Please ﬁnd the latest version in the company website (hp://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement and other Hikvision’s trademarks and logos are the properes of Hikvision in

various jurisdicons. Other trademarks and logos menoned below are the properes of their respecve owners.

Product Informaon

210

211

212

222

Produkt Specifikationer

Mærke:	Hikvision
Kategori:	Ikke kategoriseret
Model:	DS-PWA32-HGR
Bredde:	155 mm
Dybde:	35 mm
Højde:	155 mm
Produktfarve:	Sort
Batterispænding:	3.8 V
Batterikapacitet:	4520 mAh
Datanetværk:	GPRS
Batteriteknologi:	Lithium-Ion (Li-Ion)
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Ethernet LAN:	Ja
Driftstemperatur (T-T):	-10 - 55 °C
Ethernet LAN-datahastigheder:	10,100 Mbit/s
Husmateriale:	Acrylonitrilbutadienstyren
LED-indikatorer:	Ja
Strømkilde type:	Battery,DC
Indgangsspænding:	5 V
RF-transmissionsfrekvens:	868 Mhz
Mængde af sammenkoblede alarmer (maks):	32
RF-transmissionsområde:	800 m
Grænsefladetype:	LAN, Wi-Fi, GPRS
Indbygget batteri:	Ja
Backup strøm:	Ja
