HD Turret and Bullet
Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Model
Type I Camera
HWT T120 P/HWT- - - T120
H T140 P/HWT T140WT- - -
Type CameraII
HWT T220 P- -
H T240 PWT- -
Type III Camera
HWT T120 M- -
HWT T140 M- -
Type Camera IV
HWT T220 M- -
H T240 MWT- -
Type V Camera
HWT B220 M/HWT B220- - -
HWT B240 M/HWT B240- - -
Type VI Camera
HWT B120 P/HWT B120 M- - - -
H B140 P/HWT B140 MWT- - - -
This manual may contain several technical incorrect
places or prinng errors, and the content is subject to
change without noce. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
0100001080706
Regulatory Informaon
FCC Informaon
Please take attenon that changes or modicaon not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
FCC compliance: This equipment has been tested and
found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protecon
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instrucon manual, may cause harmful interference to
radio communicaons. Operaon of this equipment in a
residenal area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
FCC Condions
This device complies with part 15 of the FCC Rules.
Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operaon.
EU Conformity Statement
This product and if applicable the - -
supplied accessories too are marked with
"CE" and comply therefore with the
applicable harmonized European
standards listed under the Low Voltage Direcve
20 /35/EU, the EMC Direcve 201 30/EU.14 4/
20 2/1 19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
equipment, or dispose of it at designated collecon
points. For more informaon see: www.recyclethis.info.
2006/66/EC (baery direcve): This product contains a
battery that cannot be disposed of as
unsorted municipal waste in the European
Union. See the product documentaon for
specic baery informaon. The baery is
marked with this symbol, which may
include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery
to your supplier or to a designated collecon point. For
more informaon see: www.recyclethis.info.
Industry Canada ICES 003 Compliance-
This device meets the CAN ICES 3 (A)/NMB 3(A) - -
standards requirements.
Safety Instrucon
These instrucons are intended to ensure that user can
use the product correctly to avoid danger or property
loss.
The precauon measure is divided into “Warnings” and
“Cauons”.
Warnings: Serious injury or death may occur if any of
the warnings are neglected.
Cauons: Injury or equipment damage may occur if any
of the cauons are neglected.
Warnings
In the use of the device, you must be in strict
compliance with the electrical safety regulaons of
the naon and region.
Input voltage should meet both the SELV (Safety Extra
Low Voltage) and the Limited Power Source with 12
VDC according to the IEC60950 1 standard. Refer to -
technical specicaons for detailed informaon.
The output current of the power adapter must be no
more than .6A
Do not connect mulple devices to one power
adapter to avoid over heang or a re hazard caused -
by overload.
Make sure that the plug is rmly connected to the
power socket.
Make sure that the device is rmly fixed if wall
mounng or ceiling mounng is adopted.
If smoke, odor or noise rise from the device, turn o
the power at once and unplug the power cord, and
then contact the service center.
Never attempt to disassemble the camera by
unprofessional personal.
Cauons
Do not drop the camera or subject it to physical
shock.
Do not place the camera in extremely hot, cold (the
operang temperature shall be °C to 60°C), dusty -40
or damp locaons, and do not expose it to high
electromagnetic radiation.
Do not touch senor modules with ngers.
If cleaning is necessary, use clean cloth with a bit of
ethanol and wipe it gently.
Do not aim the camera at the sun or extra bright
places.
The sensor may be burned out by a laser beam, so
when any laser equipment is in using, make sure that
the surface of sensor will not be exposed to the laser
beam.
Do not expose the device to high electromagnec
radiaon or extremely hot, cold, dusty or damp
environment.
Warnings Follow
these safeguards to
prevent serious injury
or death.
Cauons Follow these
precauons to prevent
potenal injury or
material damage.
To avoid heat accumulation, good venlaon is
required for the operang environment.
Keep the camera away from liquid while in use for
non water proof device.- -
While in delivery, the camera shall be packed in its
original packing, or packing of the same texture.
Mark Descripon
Table 0 1 Mark Description-
Mark
Descripon
DC Voltage
1 Introducon
1.1 Product Features
The main features are as follows:
High performance CMOS sensor
IR cut lter with auto switch
OSD menu with congurable parameters
Auto white balance
Internal synchronizaon
SMART IR mode
3 axis adjustment-
1.2 Overview
This manual applies to six types of cameras. The
overviews of each type are shown in the gures below.
1.2.1 Overview of Type Camera I
DC12VIN
Video Cable
Power Cord
12 VDC
Switch Buon Mounng Base
Main Body
Enclosure
Figure 1-1 Overview of Type I Camera
Note:
Press and hold the switch buon for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.2 Overview of Type Camera II
DC12VIN
Enclosure
Main Body
Mounng
Base Video Cable
Switch Buon
Power Cord
12 VDC
Figure 1-2 Overview of Type II Camera
Note:
Press and hold the switch buon for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.3 Overview of Type III Camera
Figure 1-3 Overview of Type III Camera
Note:
Press and hold the switch buon for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.4 Overview of Type Camera IV
DC12VIN
Mounng
Base
Enclosure
Trim Ring Main Body
Switch Buon
Video Cable
Power Cord
12 VDC
Figure 1-4 Overview of Type IV Camera
Note:
Press and hold the switch buon for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.5 Overview of Type V Camera
Video Cable
Power Cord
12 VDC
Switch Buon
Mounng Base
Main Body
Lens
Figure 1-5 Overview of Type V Camera
Note:
Press and hold the switch buon for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
4. Drill the screw holes, and the cable hole (oponal)
on the ceiling according to the drill template.
Screw
Hole
Cable
Hole
Side
Opening
Figure 2-2 Drill Template
Note:
Drill the cable hole, when adopng the ceiling outlet
to route the cable.
5. Attach the mounng base to the ceiling, and secure
them with supplied screws.
Type I Camera Type II Camera
Figure 2-3 Attach the Mounng Base to the Ceiling
Note:
The supplied screw package contains
self-tapping screws, and expansion bolts.
For cement ceiling, expansion bolts are required
to x the camera. For wooden ceiling,
self-tapping screws are required.
6. Route the cables through the cable hole, or the side
opening.
7. Align the camera with the mounng base, and
ghten the screws to secure the camera the on
mounng base.
Figure 2-4 Secure the Camera with Mounng Base
8. Connect the corresponding cables, such as power
cord, and video cable.
9. Power on the camera to check whether the image
on the monitor is goen from the opmum angle. If
not, adjust the camera according to the gure below
to get an opmum angle.
