Hoover LiNX BH50020 Manual

Hoover Støvsuger LiNX BH50020

Læs nedenfor 📖 manual på dansk for Hoover LiNX BH50020 (2 sider) i kategorien Støvsuger. Denne guide var nyttig for 26 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/2

Battery Fuel Gauge: Battery Capacity Indicator Information

All three LEDS will momentarily light when the product’s power switch is turned on. Then the Battery Fuel Gauge will

indicate the pack’s remaining capacity as noted below. NOTE: Unit and lights will turn off when battery is fully discharged.

Once battery is fully discharged return switch to off position.

3 LEDs lit Remaining battery capacity > 75%

2 LEDs lit Remaining battery capacity > 50%

1. FEATURES 3. MAINTENANCE

2. HOW TO OPERATE

For filter replacement, please call 1-800-944-9200 or visit our website at www.hoover.com to locate

a dealer nearest you. Filter Service Part # 410044001.

For belt replacement, please call 1-800-944-9200 or visit our website at www.hoover.com to locate

a dealer nearest you. Belt Service Part # 001942002

ANY SERVICING SHOULD BE DONE BY AN

AUTHORIZED SERVICE REPRESENTATIVE

Call 1-800-944-9200 USA & Canada

In the event that further assistance is required, see your Yellow Pages for an authorized HOOVER® Dealer or visit

www.hoover.com. Costs of any transportation to and from any place of repair are to be paid by the owner. The

service parts used in this unit are easily replaced and readily available from an authorized HOOVER® Dealer or

retailer. Always identify your product by the model number and manufacturing code when requesting information

or ordering replacement parts. (The model number appears behind the dirt cup of the product.)

5. TROUBLESHOOTING

4. BATTERY FUEL GAUGE, DISPOSAL & SERVICE

Battery Disposal

WARNING: RISK OF EXPLOSION OR

EXPOSURE TO TOXIC MATERIAL

CAUTION: The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not

disassemble, heat above manufacturer’s maximum temperature limit (60˚C/140˚F), or incinerate. Replace battery

with HOOVER®® battery Part # BH50000 REV B only. Use of another battery may present a risk of fire or explosion.

Dispose of used battery promptly. Keep away from children. Do not disassemble and do not dispose of in fire.

Do not attempt to disassemble the battery or remove any component projecting from the battery terminals. The

battery and charger have no user serviceable parts. Fire or injury may result. Prior to disposal, protect exposed

terminals with heavy insulating tape to prevent shorting.

Lithium-ion Batteries

The battery must be collected, recycled or disposed of in an environmentally sound manner. The EPA certified RBRC

Battery Recycling Seal on the lithium-ion (Li-ion) battery indicates Techtronic Industries, a corporate affiliate of Hoover,

Inc., is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful

life, when taken out of service in the United States or Canada. The RBRC program provides a convenient alternative

to placing used Li-ion batteries into the trash or the municipal waste stream, which may be illegal in your area.

Please visit www.rbrc.org/call2recycle/ for information on Li-ion battery recycling and disposal bans/restrictions in

your area. Hoover, Inc., involvement in this program is part of our commitment to preserving our environment and

conserving our natural resources.

(continued)

1 LED lit Remaining battery capacity > 25%

1 LED blinking Remaining battery capacity < 25%

Instructions d’Utilisation et d’Entretien

Veuillez lire attentivement ces instructions avant d’utiliser votre aspirateur vertical HOOVERMD.

N’oubliez pas d’enregistrer votre produit en ligne, à l’adresse Hoover.com, ou par téléphone,

au 1-800-944-9200.

Operating and Servicing Instructions

Please read these instructions carefully before using your HOOVER® Stick Vac.

Be sure to register your product online at Hoover.com or call 1-800-944-9200 to register by phone.

Instrucciones de Funcionamiento y Mantenimiento

Lea atentamente estas instrucciones antes de usar su Barredora de succión HOOVER®.

Inscriba su producto en línea en Hoover.com, o llame al 1-800-944-9200 si preﬁere hacerlo por teléfono.

OWNER’S MANUAL

GUIDE D’UTILISATION • MANUAL DEL USUARIO

THIS VACUUM IS INTENDED FOR HOUSEHOLD USE ONLY.

IMPORTANT SAFETY INSTRUCTIONS

WARNING:

CLEANER ASSEMBLY MAY INCLUDE SMALL PARTS. SMALL PARTS CAN

PRESENT A CHOKING HAZARD.

When using an electrical appliance, basic precautions should always be

followed, including the following:

• READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.

• ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS.

• SEE SEPARATE MANUAL PERTAINING TO BATTERY AND CHARGING

OPERATION.

• DO NOT LEAVE VACUUM CLEANER UNATTENDED.

• WARNING: FULLY ASSEMBLE VACUUM CLEANER BEFORE OPERATING.

• WARNING: THIS PRODUCT CONTAINS CHEMICALS KNOWN TO THE STATE OF

CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR REPRODUCTIVE HARM.

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:

• Do not use the unit, store, or charge battery outdoors or on wet surfaces. Do not allow to get wet.

• Do not allow to be used as a toy. Close attention is necessary when used by or near children.

• Use only as described in this manual. Use only manufacturer’s recommended attachments.

• Do not use charger with damaged cord or plug. If vacuum or charger is not working as it should,

has been dropped, damaged, left outdoors, or dropped into water, return it to a service center for

inspection. return it to an authorized Hoover Dealer for inspection.

• Do not pull or carry by charger cord, use cord as a handle, close a door on cord, or pull cord around

sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.

• Do not unplug charger by pulling on cord. To unplug charger, grasp the plug, not the cord.

• Do not handle charger (including charger plug and terminals), battery, or appliance with wet hands.

• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.

• Do not use the vacuum cleaner without filter and dirt cup in place.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible liquids such as gasoline, or use in areas where they

may be present.

• Leaks from battery cells can occur under extreme conditions. If any liquid gets on the skin wash

quickly with soap and water. If any liquid gets into the eyes, do not rub eyes, immediately flush them

with clean water continuously for a minimum of 15 minutes. Seek medical attention immediately.

• Use only the charger (Hoover Part# BH50005) supplied by the manufacturer to recharge.

• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent tripping

accidents.

• Use only battery (Hoover Part # BH50000 REV B) supplied by manufacturer to operate this product.

• Always turn off and remove battery before connecting or disconnecting optional motorized power

brush, or before servicing.

• Do not dispose of battery in a fire or trash compactor. See battery disposal section at end of this

manual for directions.

• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair,

and anything that may reduce air flow.

• Do not incinerate the charger, battery, or appliance even if it is severely damaged. The batteries can

explode in a fire.

SAVE THESE INSTRUCTIONS

Assembly

Line up nozzle with main body

and firmly push nozzle into

body of unit until nozzle locks

into place. NOTE: To remove,

push release button and pull

the nozzle away from the body

of the unit.

FRONT

1. On/Off Switch (0=OFF,

I=Suction ON,

I I )=Suction and Brush ON

2. Fuel Gauge

3. Battery Cavity

4. Dirt Cup

5. Large Debris Opening

6. Bottom Nozzle Cover

(underneath nozzle)

BACK

11. Handle

12. Dirt Cup Release

Button

13. Carry Handle

14. Nozzle Release

Button

DIRT CUP AND FILTER

7. Filter Cap

8. Filter (inside filter cap)

9. Baffle Tube

10. Bottom Empty

Release Button

1.1

Insert handle into body.

NOTE: Ensure handle faces

proper direction.

Insert screw and tighten until

secure.

NOTE: DO NOT over tighten

screw.

Charge battery fully before

first use. Fully discharged

battery will take up to 3 hours

to charge. NOTE: See battery

and charging manual for

battery charging instructions.

Use only manufacturer’s

supplied or recommended

battery and charger.

2.1 2.2 2.3

2.4 2.5 2.6

2.7 2.8

Insert charged battery into

battery cavity until latch is

locked into place. NOTE:

When inserting and removing

battery, ensure the switch is in

the off position marked “O”.

Hold down nozzle with foot and

tilt back to reclining position.

To turn vacuum on, roll button

forward.

PUSH DIAL:

O - OFF

I - Suction ON

- Recommended for use on hard

floors.

II - Suction and Brushroll ON

- Recommended for use on carpet.

To remove and charge

battery, turn switch to off

position. Pull on release lever

located on end of battery and

pull out gently.

Dirt Cup & Filter Removal & Replacement

IMPORTANT: For best results, clean after each use.

REGULAR MAINTENANCE: Each time the dirt cup is emptied, the filter should be cleaned (Filter will be

discolored after use. This will not affect the filter’s performance.)

Dirt Cup Removal and Cleaning

Bafﬂe Tube Removal and Replacement

Filter Removal and Cleaning

Belt and Brushroll Replacement

To Remove dirt cup, depress

the dirt cup release button

located on the top of the dirt

cup and tip away from the

body of the unit.

REMOVAL

Hold dirt cup right side up and

press bottom release button to

open trap door.

Press dirt cup empty button over trash can to release debris.

Push door closed until latch clicks.

Turn baffle tube counter

clockwise until it stops. Pull out

baffle tube, hold over trash can

and shake free debris.

REPLACEMENT

To replace baffle tube, insert

back into dirt cup, align slots

and twist clockwise till tube

locks in place.

3.1

3.11

3.2

3.12

3.3

3.13

WARNING: Always dry filter

for 24 hours before replacing.

WARNING: Do not use

detergent or hot water to clean

filter.

3.6

3.14

3.7

Dirt Cup and Filter Replacement

REPLACEMENT

Insert filter into filter cap.

Insert filter cap into dirt cup. Place bottom of dirt cup onto

housing and pivot into place until

dirt cup release button locks.

3.8 3.9 3.10

Service

PROBLEM POSSIBLE SOLUTIONPOSSIBLE REASON

Product does not turn on 1. Battery is not in product. 1. Insert battery into product.

2. Battery is not inserted properly. 2. Make sure battery is fully seated in battery cavity.

3. Battery is not charged. 3. Remove and charge battery or replace with second charged battery.

4. Battery is too hot. 4. Remove battery and let cool for 30 minutes, replace battery and retry or replace

with second charged battery.

5. Internal component damage. 5. Call for service: 1-800-944-9200

Product turns off while

in use

1. Battery is fully discharged. 1. Remove and charge battery or replace with second charged battery.

2. Battery is too hot. 2. Remove battery and let cool for 30 minutes, replace battery and retry or replace

with second charged battery.

Product does not pick

up dirt

3. Internal component damage. 3. Call for service: 1-800-944-9200

1. Dirt cup may be full. 1. Empty dirt cup.

2. Filter may be dirty. 2. Clean and/or wash filter.

3. Baffle tube may be dirty. 3. Remove and clean.

4. Airpath may be clogged. 4. Make sure the battery is removed and the product is off. Remove nozzle by pressing

the nozzle release button and pulling the nozzle in a downward motion. Remove any

debris clogged in the nozzle airpath. Reassemble nozzle to the product.

5. Internal component damage. 5. Call for service: 1-800-944-9200

Brushroll will not turn Brushroll may have an obstruction. 1. Make sure the battery is removed and the product is turned off. Remove nozzle by 1. pressing the nozzle release button and pulling the nozzle in a downward motion.

Remove any debris clogged in the nozzle airpath. Reassemble nozzle to the product.

2. Motor protection device tripped. 2. Turn product to off position, product will reset in approximately 30 minutes.

3. Broken belt. 3.Make sure the battery is removed and the product is off. Remove nozzle cover replace

with recommended belt and replace nozzle cover.

4. Internal component damage. 4. Call for service: 1-800-944-9200

Pull out filter cap. Pull out filter and brush clean. Rinse under cold water

as needed.

WARNING: Remove battery before servicing.

Turn vacuum nozzle over. Remove screws indicated by arrows on

bottom nozzle plate. Lift plate off nozzle bottom to access brush, belt

and nozzle.

After replacement turn brushroll making sure belt turns freely.

Return nozzle plate and screws.

CET ASPIRATEUR A ÉTÉ CONÇU POUR USAGE DOMESTIQUE SEULEMENT.

CONSIGNES DE SÉCURITÉ IMPORTANTES

AVERTISSEMENT :

L’ASSEMBLAGE DE L’APPAREIL COMPREND DES PETITES PIÈCES. CES DERNIÈRES

PRÉSENTENT UN DANGER D’ÉTOUFFEMENT.

Pendant l’utilisation d’un appareil électrique, toujours prendre des précautions élémentaires, notamment :

• LIRE TOUTES LES INSTRUCTIONS AVANT D’UTILISER CET APPAREIL.

• TOUJOURS SUIVRE CES CONSIGNES DE SÉCURITÉ.

• POUR CONNAÎTRE LES INSTRUCTIONS RELATIVES À LA CHARGE DE LA PILE, CONSULTER

LE GUIDE D’UTILISATION DE LA PILE ET DU CHARGEUR (GUIDE SÉPARÉ).

• NE PAS LAISSER L’ASPIRATEUR SANS SURVEILLANCE.

• AVERTISSEMENT : ASSEMBLER ENTIÈREMENT L’ASPIRATEUR AVANT DE L’UTILISER.

• MISE EN GARDE : CE PRODUIT CONTIENT DES SUBSTANCES CHIMIQUES

RECONNUES PAR L’ÉTAT DE LA CALIFORNIE COMME CAUSANT LE CANCER,

DES ANOMALIES CONGÉNITALES OU DES PROBLÈMES DE REPRODUCTION.

AVERTISSEMENT :

AFIN DE RÉDUIRE LES RISQUES D’INCENDIE, DE

CHOC ÉLECTRIQUE OU DE BLESSURES :

• Ne pas utiliser l’appareil, ranger le chargeur ou recharger la pile à l’extérieur ou sur une surface mouillée.

Garder au sec.

• Ne pas permettre que l’appareil soit utilisé comme un jouet. Être particulièrement vigilant lorsque l’appareil est

utilisé par des enfants ou à proximité d’enfants.

• Utiliser cet appareil uniquement de la façon décrite dans ce guide. Utiliser uniquement les accessoires

recommandés par le fabriquant.

• Ne pas utiliser le chargeur si la fiche ou le cordon sont endommagés. Si l’aspirateur ou le chargeur fonctionne

mal, s’il est tombé ou a été endommagé ou laissé à l’extérieur, ou s’il est tombé dans l’eau, il doit être apporté

à un Centre de service pour y être inspectél’, expédier à un centre de réparation pour qu’il soit vérifié.

• Ne pas tirer sur le cordon du chargeur ni utiliser le cordon du chargeur pour transporter l’appareil, utiliser le

cordon comme une poignée, fermer une porte sur le cordon ou tirer le cordon autour de coins ou d’arêtes vives.

Ne pas faire passer l’appareil sur le cordon. Garder le cordon éloigné de toute surface chauffée.

• Ne pas tirer sur le cordon pour débrancher le chargeur. Saisir la fiche et non le cordon pour débrancher le

chargeur.

• Ne pas manipuler le chargeur (y compris la fiche et les bornes), la pile ou l’appareil avec les mains mouillées.

• Garder les cheveux, les vêtements amples, les doigts et toute autre partie du corps à bonne distance des

ouvertures et des pièces mobiles de l’appareil.

FRANÇAIS

If you need assistance:

Visit our website at hoover.com. Follow the authorized dealer locator link to find the Hoover® authorized dealer nearest you or

call 1-800-944-9200 for an automated referral of Hoover® authorized dealer locations (U.S. only) or to speak with a customer

service representative; Mon- Fri 8am- 7pm EST.

PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.

Limited TWO Year Warranty

(Domestic Use)

WHAT THIS WARRANTY COVERS

When used and maintained in normal household use and in accordance with the Owner’s Manual, your HOOVER

product is warranted against original

defects in material and workmanship for a full two year from date of purchase (the “Warranty Period”). During the Warranty Period, Hoover

will provide

labor and parts, at no cost to you, to correct any such defect in products purchased in the United States, U.S. Military Exchanges and Canada.

HOW TO MAKE A WARRANTY CLAIM

If this product is not as warranted, take or send the product to a Hoover

Authorized Warranty Service Dealer along with proof of purchase. For an

automated referral to authorized service outlets in the U.S.A., phone: 1-800-944-9200 OR visit Hoover

online at www.hoover.com.

WHAT THIS WARRANTY DOES NOT COVER

This Warranty does not cover: use of the product in a commercial operation (such as maid, janitorial and equipment rental services), brushroll, belt, improper

maintenance of the product, damage due to misuse, acts of God, nature, vandalism or other acts beyond the control of Hoover®, owner’s acts or omissions, use

outside the country in which the product was initially purchased and resales of the product by the original owner. This warranty does not cover pick up, delivery,

transportation or house calls. However, if you mail your product to a Hoover® Authorized Warranty Service Dealer, cost of shipping will be paid one way.

This warranty does not apply to products purchased outside the United States, including its territories and possessions, outside a U.S. Military Exchange

and outside of Canada. This warranty does not cover products purchased from a party that is not an authorized retailer, dealer, or distributor of Hoover®

products.

OTHER IMPORTANT TERMS

This Warranty is not transferable and may not be assigned. This Warranty shall be governed and construed under the laws of the state of Ohio. The Warranty

Period will not be extended by any replacement or repair performed under this Warranty.

THIS WARRANTY IS THE EXCLUSIVE WARRANTY AND REMEDY PROVIDED BY HOOVER

. ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, ARE DISCLAIMED. IN NO EVENT WILL HOOVER

BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE TO OWNER OR ANY PARTY

CLAIMING THROUGH OWNER, WHETHER BASED IN CONTRACT, NEGLIGENCE, TORT OR STRICT PRODUCTS LIABILITY OR ARISING FROM

ANY CAUSE WHATSOEVER. Some states do not allow the exclusion of consequential damages, so the above exclusion may not apply to you. This

warranty gives you speciﬁc rights; you may also have others that vary from state to state.

Nozzle

Release

Button

If a minor problem develops, it usually can be remedied quite easily when the cause is identified by using the

checklist below.

Any other servicing should be done by an authorized service representative.

WARNING: To reduce risk of personal injury - unplug vacuum before servicing.

In order to maintain optimum performance of your cleaner, each time

the dirt cup is removed for emptying it is recommended to check if there

is any debris trapped in the dirt tube (A). If so, remove the debris before

re-attaching the dirt cup to the cleaner.

If you still are experiencing reduced suction/performance, detach

the nozzle base from the main unit (press button on back of nozzle

to release, B) and inspect both openings of the nozzle base (C) for

any trapped debris. Remove any debris that may be present before

re-attaching the nozzle base to the main body of the cleaner.

Dirt Cup Debris and Clog Removal 3.4

3.5

Produkt Specifikationer

Mærke:	Hoover
Kategori:	Støvsuger
Model:	LiNX BH50020

Har du brug for hjælp?

Hvis du har brug for hjælp til Hoover LiNX BH50020 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Støvsuger Hoover Manualer

Hoover Sensory TC5235 019 Manual

6 December 2024

Hoover HP330ALG 021 Manual

6 December 2024

Hoover TXL10HM 011 Manual

6 December 2024

Hoover KHROSS KS35PAR 011 Manual

12 Oktober 2024

Hoover Air Cordless Manual

12 Oktober 2024

Hoover Capture TCP2105 011 Manual

11 Oktober 2024

Hoover Purepower TPP 2010 Manual

9 Oktober 2024

Hoover Alyx TC 1202 Manual

7 Oktober 2024

Hoover Clik Manual

6 Oktober 2024

Hoover Athen ATN 264 R Manual

5 Oktober 2024

Støvsuger Manualer

Nyeste Støvsuger Manualer

Electrolux Pure Q9 PQ91-3EB Manual

21 December 2024

Electrolux Ergorapido ZB3104 Manual

21 December 2024

Electrolux ZAP9910 Manual

21 December 2024

Electrolux Pure I9 PI91-5SGM Manual

21 December 2024

Philips 3000 Series XD3010 Manual

21 December 2024

Panasonic MC-YL669 Manual

21 December 2024

Livoo DOH143 Manual

20 December 2024

Kogan Z12 Pro Manual

19 December 2024

Kogan Mighty Cyclonic KAVACBA22WA Manual

19 December 2024

Philips Universe FC9009 Manual

19 December 2024
