Getting Started Guide

The only warranties for Hewlett-Packard products and services are set forth in the express
statements accompanying such products and services. Nothing herein should be construed
as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
HP assumes no responsibility for the use or reliability of its software on equipment that is
not furnished by HP.
This document contains proprietary information that is protected by copyright. No part of
this document may be photocopied, reproduced, or translated to another language
without the prior written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
Copyright © 2000–2005 Hewlett-Packard Development Company, L.P.
This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright-protection technology must be
authorized by Macrovision Corporation and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited. Apparatus Claims of U.S. Patent
Nos. 4,631,603, 4,577,216, 4,819,098, and 4,907,093 licensed for limited viewing
uses only.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
HP supports lawful use of technology and does not endorse or encourage the use of our
products for purposes other than those permitted by copyright law.
The information in this document is subject to change without notice.

Table of Contents iii
Table of Contents
Setting Up Your PC ......................................................................... 1
Putting Your PC Together............................................................................... 1
Placing your PC in the proper location ....................................................... 1
Using surge protection ............................................................................. 2
Connecting to the PC ................................. ...................... 2........................
Storing documentation and recovery discs .................................................. 5
Turning On Your PC for the First Time ............................................................. 5
Setting Up and Connecting to the Internet........................................................ 6
Configuring and Registering Norton Internet Security Software........................... 7
Using the PC with Safety and Comfort............................................................. 8
Signing Up for Software Updates ...................................................................8
Setting Up Accounts on Your New PC............................................................. 9
Creating user accounts............................... ...................... 9........................
Creating passwords................................... .................... 10........................
Guidelines for Installing Software and Hardware Devices................................ 10
Using HP Products ......................................................................................11
Transferring Files and Settings from Your Old PC to Your New PC.................... 11
Using HP Organize Software....................................................................... 11
Using the Keyboard ..................................................................... 13
Customizing the keyboard buttons ........................................................... 15
Using Your PC Top ........................................................................ 17
Using Your Docking Bay.............................................................................. 17
Configuring Speaker and Sound Options...................................... 21
Sound Connector Types .............................................................................. 21
Speaker Configurations............................................................................... 24
Speaker types ........................................... .................... 25........................
Connecting 2.1 (2 speakers and a subwoofer) audio speakers ................... 25
Connecting 4.1 (4 speakers and a subwoofer) audio speakers ................... 26
Connecting 5.1 (5 speakers and a subwoofer) audio speakers ................... 28
Connecting 7.1 (7 speakers and a subwoofer) audio speakers ................... 29

iv Getting Started Guide
Connecting the PC to a Home Audio System.................................................. 31
2 or 2.1 home stereo installation............................................................. 32
5.1 (5 speakers and a subwoofer) home audio installation......................... 33
5.1 (5 speakers and a subwoofer) home audio installation procedure.......... 34
Connecting Digital Audio............................................................................ 35
Configuring Audio Output ........................................................................... 36
Configuring Audio Output with Multi-channel Sound Manager......................... 37
Enabling digital audio output with Multi-channel
Sound Manager (optional)...................................................................... 38
Configuring Audio Output with Sound Effect Manager.................................... 38
Using the Audio Wizard in the Sound Effect Manager ............................... 39
Retasking front-panel connectors.............................................................. 40
Disabling digital audio output with Sound Effect Manager (optional) ........... 40
Configuring Audio Output with Realtek HD Sound Effect Manager ................... 41
Configuring the Realtek HD Sound Effect Manager .................................... 42
Configuring sound for recording with the Realtek HD
Sound Effect Manager ........................................................................... 42
Retasking front panel audio connectors .................................................... 43
Configuring Multi-streaming Audio ............................................................... 43
Audio output overview ........................................................................... 43
Audio input overview............................................................................. 44
When to use multi-streaming audio.......................................................... 44
Setting up multi-streaming audio.............................................................. 45
Configuring Audio for WinDVD Player.......................................................... 47
Using Headphones..................................................................................... 47
Using a 2.1 speaker system with headphones........................................... 47
Using a 5.1 to 7.1 speaker system with headphones ................................. 48
Selecting recording devices .................................................................... 48
Resolving Sound Issues................................. ....................... 48........................
Using the Memory Card Reader ................................................... 49
Using the Memory Card Reader................................................................... 50
Media Insertion Guide................................. ....................... 51........................
Using the HP Personal Media Drive .............................................. 53
Connecting the Drive .................................................................................. 54
Inserting the Drive ....................................... ....................... 55........................
Locating the Drive and Assigning a Drive Letter.............................................. 56
Using the Drive ........................................... ....................... 57........................
Disconnecting the Drive............................................................................... 58
Working with Digital Images........................................................ 59
Using HP Image Zone................................................................................. 60

Table of Contents v
Playing CDs and DVDs ................................................................. 63
Playing Music CDs ..................................................................................... 63
Playing CDs and DVDs with Windows Media Player ...................................... 63
Playing DVD Movies with InterVideo WinDVD ............................................... 64
Using country/region codes.................................................................... 65
Playing Video CDs (VCD) with InterVideo WinDVD ........................................ 66
Playing Video CDs (VCD) with Windows Media Player................................... 66
Creating Audio and Data Discs ..................................................... 67
Erasing Rewritable Discs Before Recording .................................................... 68
Working with Audio CDs ............................................................................ 68
Verifying audio disc recorded without errors ............................................. 69
Audio CD tips ........................................... .................... 69........................
Creating audio CDs................................... .................... 70........................
Creating jukebox discs........................................................................... 70
Working with Data DVDs and CDs............................................................... 71
Verifying data disc recorded without errors............................................... 71
Data disc tips........................................................................................ 71
Creating data discs................................................................................ 72
Copying a DVD or CD .................................... .................... 73........................
Archiving Files on a CD or DVD ................................................................... 73
Working with Image Files............................................................................ 74
Creating an image file ........................................................................... 74
Burning from an image file ..................................................................... 74
Disc Labeling with LightScribe...................................................................... 75
LightScribe requirements......................................................................... 75
Burning a LightScribe label with Sonic Express Labeler............................... 75
Using adhesive disc labels...................................................................... 76
Compatibility Information ............................................................................ 76
Disc Features and Compatibility Table .......................................................... 77
Optical Drive Quick Reference Table ............................................................ 78
Software Quick Reference Table................................................................... 79
Creating Video Discs and Movies.................................................. 81
Before You Begin Capturing Video ............................................................... 81
Sonic MyDVD Video Projects ........................... .................... 82........................
Creating a Video Project ............................................................................. 83
Adding files to a video project ................................................................ 83
Capturing video to a video project .......................................................... 84
Adding slideshows to a video project....................................................... 85
Adding submenus to a video project ........................................................ 85
Editing the style of a video project ........................................................... 86
Editing movie files.................................................................................. 86
Burning a video project to disc................................................................ 87

vi Getting Started Guide
Creating a Video Project With the Direct-to-Disc Wizards................................ 88
Video Quality and Disc Size......................... ....................... 89........................
DVD Recording Time .................................................................................. 90
Creating Movies Using muvee autoProducer................................. 91
Basic Steps to Make a Movie....................................................................... 91
Locating muvee autoProducer.................................................................. 92
Using muvee autoProducer .......................................................................... 93
Getting started ...................................................................................... 93
Capturing video from a DV camcorder..................................................... 94
Adding videos ...................................................................................... 95
Adding pictures..................................................................................... 96
Adding music ....................................................................................... 97
Selecting the style.................................................................................. 97
Changing the settings ............................................................................ 97
Adding an opening title and closing credits.............................................. 98
Making the movie.................................................................................. 99
Saving the movie project........................... .................. 100.........................
Recording the movie project to disc ....................................................... 100
Getting Help .............................................................................. 101
Finding Onscreen Guides.......................................................................... 101
Finding Guides on the Web ...................................................................... 101
Using the Onscreen Help and Support Center.............................................. 102
Using PC Help & Tools.............................................................................. 102
Using Updates from HP............................................................................. 102
Getting messages................................................................................ 103
Turning off messages ................................ .................. 103.........................
Reactivating messages .............................. .................. 104.........................
Index ......................................................................................... 105

Setting Up Your PC 1
Setting Up Your PC
Putting Your PC Together
Follow the steps on the setup poster to set up your PC.
Look in the PC box for printed details or updates regarding your model PC.
Placing your PC in the proper location
When setting up your new PC, place it where ventilation openings are unobstructed.
Make sure all connections are secure and all cabling is out of the way of walkways
and will not be stepped on or run over by furniture.
WARNING: The power supply is preset for the country/region in
which you purchased your PC. If you move, please check the voltage
requirements before plugging your PC into an AC power outlet.
WARNING: Please read “Safety Information” in the Warranty
and Support Guide before installing and connecting your PC to
the electrical power system.

2Getting Started Guide
Using surge protection
Help protect your monitor, PC, and accessories by connecting all power cords for
your PC and peripheral devices (such as a monitor, printer, or scanner) to a
surge-protection device such as a power strip with surge protection or
uninterruptible power supply (UPS). Many surge protection devices have
surge-protection inputs and outputs for modem/phone lines. Phone lines are a
common path for lightning spikes to get into your system. Some surge protection
devices also have surge protection for television cable connections as well: use
those if your PC has a television tuner installed.
Not all power strips provide surge protection; the power strip must be specifically
labeled as having this ability. Use a power strip whose manufacturer offers a
damage replacement policy so you can replace your equipment if surge protection
fails.
Connecting to the PC
Connect your main hardware devices such as the monitor, keyboard, and mouse to
the back of the PC. Other peripheral devices such as a printer, scanner, or camera
also plug into connectors on the back of your computer. Some PC models also have
connectors on the front of the PC. The table does not show all connectors.
Connector
Connector
symbol Description
Mouse (PS/2 connector)
Keyboard (PS/2 connector)
Universal Serial Bus (USB) for mouse,
keyboard, digital cameras, or other devices
with USB connectors
NOTE: Your PC
f
eatures
and location, availability,
and number of connectors
may vary.

Setting Up Your PC 3
Printer (parallel)
Monitor
Serial
Serial port for some digital cameras or
other serial devices
Audio Line Out (powered speakers)
Audio Line In
Headphones
Microphone
Connector
Connector
symbol Description
OUT
IN

4Getting Started Guide
FireWire® (IEEE 1394) for video cameras
or other devices with very fast transfer rates
S/PDIF In and S/PDIF Out
Side speaker out
Rear speaker out
Center/subwoofer
Connector
Connector
symbol Description
rear

Setting Up Your PC 5
Storing documentation and recovery discs
Store all PC user manuals and warranty information in an easy-to-find, safe location.
It is a good idea to store your system recovery discs with your documentation. This
will allow easy access to all important PC documents and files in one place.
Turning On Your PC for the First Time
After you have completed the steps on the quick setup poster, you are ready to turn
on your PC.
1Press the Power button on the monitor.
2Press the On button on the front of the PC.
3Turn on the speakers, if they are present.
4Click an option to select your language (if applicable for your model). Click
OK, and then confirm your selection by clicking Yes. Wait until the PC makes
preparations. (It may take up to 30 minutes for this one-time language setup on
the PC.)
5Set up Microsoft® Windows® by following the onscreen instructions.
6(Select models only) Follow the Easy Internet Sign-up or Internet Services wizard
to set up an Internet connection. If you do not wish to set up an Internet
connection at this time, Easy Internet Sign-up or Internet Services can be
manually started at a later time. See “Setting Up and Connecting to the
Internet” on page 6.
7(Select models only) Follow the Easy Setup wizard to update the PC security
tools, register the PC and finish PC setup. If you decide to finish setup at a later
time, the wizard can be started by double-clicking the Easy Setup icon on the
desktop.

Setting Up Your PC 7
Configuring and Registering Norton
Internet Security Software
Norton Internet Security software is preinstalled on your PC and includes a
complimentary 60-day subscription to protection updates. You can enable
Symantec’s LiveUpdate™ to obtain protection updates automatically whenever you
are online.
When you first set up the PC, the Norton Internet Security Information Wizard helps
you to configure and register your copy of Norton Internet Security.
Be sure to set up Norton Internet Security before you start surfing the Internet. Just
click on the Norton Internet Security icon after you’ve established an Internet
service account, and a wizard will guide you through the simple setup process.
1Double click the Norton Internet Security icon in the system tray to
launch the Configuration Wizard.
2Click Next and follow the instructions to:
•Complete registration
•Schedule post-installation tasks including running LiveUpdate™, scanning
for viruses, and scheduling weekly scans of local hard drives.
3On the Summary page, click Finish.
When registration and initial setup is finished, Norton Internet Security
automatically begins the post-installation tasks you selected.
For information about using and updating the Norton Internet Security software,
click Start, , All Programs Norton Internet Security, and then click Help
and Support.

8Getting Started Guide
Using the PC with Safety and Comfort
Before you begin using the PC, arrange the PC and your work area to maintain your
comfort and productivity. Refer to the Safety & Comfort Guide for important
ergonomic information:
•Click Start, choose All Programs, choose User’s Guides, and then click
Safety & Comfort Guide.
Or
•Type
http://www.hp.com/ergo/
into your Web browser address box, and then press Enter on the keyboard.
Signing Up for Software Updates
Microsoft continually updates the Windows operating system. It is recommended
that you check for, download, and install these updates at least monthly. Take
advantage of the Automatic Updates feature, a convenient way to keep the
operating system up to date. When you are connected to the Internet, Windows
Update automatically notifies you through a pop-up message or icon in the
notification area when critical updates are available. When you see the Windows
Update message, allow the updates to download to the system. If you update the
system weekly, or at least monthly, the time required for download is minimal.
To configure Automatic Updates:
Click Start, Control Panel, Other ,Control Panel Options and then
Automatic Updates.
In the Automatic Updates window, select the desired configuration:
• Automatic (recommended) — This is the default setting, and it allows you to
specify a day and time to automatically download and install recommended
updates.
•Download updates for me, but let me choose when to install them.
•Notify me but don’t automatically download or install them.
The Turn off Automatic Updates option makes the PC more vulnerable and is
not recommended.
WARNING: To reduce the risk of serious injury, read the Safety &
Comfort Guide. It describes proper workstation setup, posture, and
health and work habits for PC users. It also provides important
electrical and mechanical safety information.

Setting Up Your PC 9
Setting Up Accounts on Your New PC
User accounts allow you to set the privileges for each user of your PC. For example,
you can set the software programs that each user is allowed to access. Follow the
simple steps in this section when setting up your PC to create user accounts.
Creating user accounts
The information below describes the different account types in Windows XP and
explains how to change account types.
Creating multiple user accounts on the same PC has certain advantages as well as
some drawbacks.
•Advantages to multiple user accounts:
•Ability to create individual user settings
•Ability to limit access to software for certain users
•Drawbacks to multiple user accounts:
•More memory (RAM) usage
•Multiple Temporary Internet Files folders to remove during Disk Cleanup
•More data to back up
•Longer time to complete virus scan
Windows XP provides three types of user accounts:
•Administrative
Allowed to change account types for other users, change passwords, change
system-wide settings, and install Windows XP-compatible software and drivers.
•Limited
Not allowed to change other user settings, or passwords. Limited account may
not be able to install or run some software.
Allowed to change the limited account picture, and create, edit, or delete the
account password.
•Guest
Not allowed to change other user settings or passwords.
Users who log on to the PC using the guest account do not have access to
password-protected files, folders, and settings.

10 Getting Started Guide
Creating passwords
Passwords help protect your PC and information from unauthorized access and help
ensure that information on the PC stays private and secure. Use the following list as
a basic guide when choosing your password:
•Choose a password that is easy for you to remember but difficult for others to
guess.
•Choose a long password (minimum of 6 characters).
•Use a combination of upper and lower-case letters, numbers, and symbols.
•Don’t use personal information that others can easily figure out, such as your
birthday, child’s name, or phone number.
•Don’t write down your password.
Guidelines for Installing Software and
Hardware Devices
After you set up the PC, you may wish to install additional software programs or
hardware devices. Keep in mind these important guidelines:
•Before installation, make a restore point using the Microsoft System Restore
program.
Click Start, , All Programs PC Help & Tools System Restore, and then .
The restore point is a snapshot of your PC configuration. By using System
Restore, you ensure that you have a point to return to before an issue occurred.
For information about System Restore, refer to the Microsoft Web site at:
http://www.microsoft.com/worldwide
•Choose software that is compatible with your PC — check the operating system,
memory, and other requirements listed for the new software for compatibility
with your PC.
•Install the new software according to the directions provided by the software
manufacturer. Check the manufacturer’s documentation or customer service
information for help if you need it.
•For antivirus software, uninstall the existing software program before
reinstalling it or installing a new antivirus program.
NOTE: Only use licensed original software. Installing copied software may be
illegal, may result in an unstable installation, or may infect your PC with a virus.

12 Getting Started Guide

Using the Keyboard 13
Using the Keyboard
Your keyboard has an arrangement of standard keys, indicator lights, and special
buttons (select models only).
Identifying Special Keyboard Buttons
There are special buttons (select models only) at the top of the keyboard. (Some
models have some of these special buttons on the left side of the main keys.) These
buttons operate a CD or DVD player, connect you to the Internet, or provide quick
access to specific functions.
NOTE: The number, location, and labeling of buttons vary by keyboard model.
Icon Feature Description
Standby Puts PC into power-saving mode (screen is
blank but PC is still on). To make the screen
reappear, press the Esc key, or press
Standby again. May take 10–30 seconds
before the screen reappears.
User Switches between the PC users.
hp or
HP Links to an HP Web site.
or
Help Opens the Help and Support Center.
or Pictures
(Photos)
Opens an imaging software program. Can
be reconfigured.
or
Music Opens music software program. Can be
reconfigured.
Video Opens video software program. Can be
reconfigured.

14 Getting Started Guide
or
Shopping
or
Sports
or
Finance
or
Connect to
Internet
or
Search Goes to popular Web sites. Can be
reconfigured to open a site or software
program.
or
Chat
E-Mail
A
B
C
D
E
F
Media
controls (CD/
DVD/MP3)
Operates a disc player.
A Open and close disc tray
B Record
C Play or pause
D Stop
E Skip to the previous track
F Skip to the next track
or
or
– +
Volume
control
(Volume knob
or Volume Up
and Volume
Down
buttons)
Volume knob: Increases speaker volume
when turned clockwise and decreases
volume when turned counterclockwise. It
can be turned indefinitely, even after
maximum sound has been reached.
Volume Up and Down buttons: Press the
Volume Up button to increase volume and
the Volume Down button to decrease
volume.
or
Mute Turns speaker sound on and off.
NOTE: The number, location, and labeling of buttons vary by keyboard model.
Icon Feature Description

Using the Keyboard 15
Customizing the keyboard buttons
You can customize some of the special buttons on the keyboard (select models only)
to open different programs or files or to connect to favorite Web sites:
1 Click Start on the taskbar.
2 Choose Control Panel.
3 Click Printers and Other Hardware, if it is present.
4 Double-click Keyboard.
5 On the Buttons tab, double-click the button you want to change.
6 For the Button configuration, click the Down arrow to the right of the list and
choose the button capability, such as Complex remote page with label or
Simple local file with label.
7 Enter a display label and the address information. For a Web page, enter
the URL.
8 Click OK.
9 On the Buttons tab, click Apply.
10 Repeat steps 5 through 9 for each button you want to customize.
11 Click OK to finish.
NOTE: Clicking the Restore Defaults button on the Button tab restores all of the
Internet buttons to the factory settings.

16 Getting Started Guide

Using Your PC Top 17
Using Your PC Top
Your PC may have a storage area or docking bay (select models only) on the top of
the PC chassis.
Using Your Docking Bay
You can use the docking bay to:
• Store CDs, DVDs, or memory cards.
• Dock a peripheral device in the bay, such as a digital camera docking station.
• Install a special cover (optional) and an HP camera and HP camera docking
station. (Both the camera and the docking station are sold separately.)
The bay design allows you to place a device and thread the USB or FireWire
(IEEE 1394) data cable and the power cord underneath the rear top cover to the
connectors on the back of the PC.
Your PC may look different from the one shown here. Components and location,
availability, and number of connectors may vary.

18 Getting Started Guide
To store CDs, DVDs, or memory cards:
Gently press down on the bay lid and slide it open.
To install a peripheral device or an HP camera and HP camera
docking station:
1 Gently press down on the bay lid and slide it open.
2 APlace the peripheral device or the camera docking station ( ) on the top of
the PC.
3 BFor a camera, place the camera cradle ( ) that came with the digital camera
on the camera docking station. The cradle clips onto the camera docking
station.
A
B

Using Your PC Top 19
4 Thread the cables that came with your peripheral devices or camera docking
station through the cable tunnel (C). Starting from the back of the PC, thread
them to the front of the PC. Pull the cables to the center and connect them to the
peripheral or the docking station (D).
5 EConnect the cables to the back of the PC or to a power outlet ( ).
For a peripheral, refer to the instructions that came with your peripheral device.
D
E
C

20 Getting Started Guide
For an HP camera docking station:
•Plug the USB cable into the back of the PC.
•Plug the power cord into a power outlet.
Optionally, if you want to view the camera images on a TV, plug the red and
yellow connectors (not shown) into the TV.
Refer to the instructions that came with the HP camera docking station.
6 FPlace the correct camera docking station lid ( ) on top of the PC. Gently guide
the edge of the lid into the top of the PC.
7 GWhen you want to use it, place the HP digital camera ( ) into the docking
station.
8 Follow the instructions that came with your peripheral or docking station.
F
G

Configuring Speaker and Sound Options 21
Configuring Speaker and Sound
Options
HP PCs support many different audio options, sound connections, and speaker
configurations. You may set up your PC for two stereo speakers or for multichannel
audio speaker systems. Connect your speaker system to the PC, and then configure
the audio software for sound output. For more details about connecting stereo
speakers to the PC, see the setup poster.
This chapter describes the most typical options. Your system may have different
components.
Sound Connector Types
Your model may include one of three analog sound connector types on the back of
your PC:
• Three connectors
• Six connectors
• Sound card
Your system may also have a separate Digital Out connection (select models only).
NOTE: For additional information on connecting the speakers, refer to the setup
poster that came with the PC and the documentation that came with your speakers.

22 Getting Started Guide
Software configuration is different for each connector type, as noted in the
instructions.
Use the sound connectors that match your PC model when installing cables, as
shown in the installation procedure steps.
Connector Description Illustration Type
Three
connectors
Your PC model may include
three sound connectors. You
can connect up to a 5.1 audio
system to the PC. If you want to
connect multichannel audio,
follow the instructions carefully.
3
Six
connectors
Your PC model may include six
sound connectors on the back
of your PC. You can connect
up to a 7.1 audio system to
the PC.
6
Sound card
connector
Your PC may include a sound
card. You can connect up to a
5.1 audio system (7.1 audio
system for select models) or
digital speakers to the sound
card on the PC.
See below. S
NOTE:
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
OUT
IN

Configuring Speaker and Sound Options 23
The following table shows the sound connectors on the back panel of PC systems.
Sound connector
Description
3 6 S
Line Side (gray) for side speakers in an eight-
speaker system (7.1).
Line C/Sub (gold) for center/subwoofer speakers
in a multichannel audio configuration.
Line Rear (black) for rear speakers in a
multichannel audio configuration.
Line Out (lime-green) for front speakers.
Mic (pink) connects to microphone.
(Type 3 also functions as center/subwoofer Line
Out when a multichannel audio configuration is
activated.)
Line In (light blue) connects to an analog audio
device such as a CD player for input into PC.
(Type 3 also functions as rear Line Out when a
multichannel audio configuration is activated.)
Digital Out (orange) connects to a digital audio
device with digital input (such as a home audio
receiver/amplifier) or digital speakers (select
models only).
NOTE:
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
OUT IN
DIGITAL
AUDIO OUT
DIGITAL
AUDIO OUT

24 Getting Started Guide
Speaker Configurations
You may set up your PC for the following supported configurations:
Name Speaker system See
Headphones None, muted. “Using Headphones” on
page 47.
2 (stereo) Left speaker, right speaker. “Connecting 2.1
(2 speakers and a
subwoofer) audio speakers”
on page 25.
2.1 Left speaker, right speaker, and
a subwoofer.
“Connecting 2.1
(2 speakers and a
subwoofer) audio speakers”
on page 25.
4.1 Two front speakers, two rear
speakers, and a subwoofer.
“Connecting 4.1
(4 speakers and a
subwoofer) audio speakers”
on page 26.
6/5.1 Two front speakers, two rear
speakers, a center speaker,
and a subwoofer.
“Connecting 5.1
(5 speakers and a
subwoofer) audio speakers”
on page 28.
8/7.1 Two front speakers, two rear
speakers, two side speakers, a
center speaker, and a
subwoofer (select models only).
“Connecting 7.1
(7 speakers and a
subwoofer) audio speakers”
on page 29.
Home audio
system
Home stereo or home theater
audio system with passive
speakers.
“Connecting the PC to a
Home Audio System” on
page 31.
Digital audio Digital speakers or digital input
connector on audio system.
“Connecting Digital Audio”
on page 35.
Multi-streaming
audio
Two front speakers, two rear
speakers, two side speakers,
a center speaker, and a
subwoofer (select models only).
“Configuring Multi-
streaming Audio” on
page 43.

Configuring Speaker and Sound Options 25
Speaker types
Speakers may be included with the monitor (select models only) or are sold
separately. Refer to the product documentation for your speakers.
Your PC supports only an active (powered) speaker system. An active speaker
system must have its own power cord. A home audio system does not require active
speakers because the receiver provides amplification.
A stereo speaker set is a left-right, two-channel speaker system. A multichannel
audio speaker system has a left-right front and left-right rear channel, and it may
include a subwoofer and a center speaker. Side speakers are included in more
advanced systems. A subwoofer provides enhanced bass sounds.
“.1” indicates a subwoofer. For example, 7.1 channels refers to an eight-speaker
mode and uses two front speakers (left-right), two side speakers (left-right), two rear
speakers (left-right), a center speaker, and a subwoofer.
Connecting 2.1 (2 speakers and a subwoofer)
audio speakers
To connect simple left/right stereo active speakers or two speakers and a subwoofer
for 2.1 speaker output:
1Turn off the PC.
2Connect the speaker cable to the lime-green Audio Line Out connector that
matches the back of your PC.
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
3Connect the cable to the audio system.
4For 2.1 speakers that were shipped with your PC (select models only), connect
the Audio Line Out connector to the subwoofer.
5Connect the left and right speakers to the subwoofer. Refer to the speaker
documentation.
6Turn on the PC.
NOTE: Always turn on the PC before you turn on the speaker system.
OUT
36S

26 Getting Started Guide
7Plug in the speaker system power.
8Turn on the speaker system.
Step 8 is optional for a two-speaker setup.
9After the speakers are connected to the PC, configure the audio software for
sound output for your PC model:
•Type 3 connectors: See “Configuring Audio Output with Multi-channel
Sound Manager” on page 37.
•Type 6 connectors: See “Configuring Audio Output with Sound Effect
Manager” on page 38.
The following diagram shows a typical 2.1 audio installation:
Connecting 4.1 (4 speakers and a subwoofer)
audio speakers
To connect two front speakers, two rear speakers, and a subwoofer for four-channel
(4.1 speaker) output:
1Turn off the PC.
.
2Connect the front speaker cable to the lime-green Audio Line Out connector that
matches the back of your PC.
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
OUT
OUT
36S

Configuring Speaker and Sound Options 27
3Connect the rear speaker cable to the black connector that matches the back of
your PC.
For type 3 connectors, the blue Audio Line In connector functions as a rear line
out when a multichannel audio configuration is activated.
4Connect the cables to the audio system.
5Connect the front and rear speakers to the subwoofer. Refer to the speaker
documentation.
6Turn on the PC.
7Plug in the speaker system power.
8Turn on the speaker system.
9After the speakers are connected to the PC, configure the audio software for
sound output for your PC model:
•Type 3 connectors: See “Configuring Audio Output with Multi-channel
Sound Manager” on page 37.
•Type 6 connectors: See “Configuring Audio Output with Sound Effect
Manager” on page 38.
The following diagram shows a typical 4.1 audio installation:
NOTE: Always turn on the PC before you turn on the speaker system.
IN
36S
OUT IN

28 Getting Started Guide
Connecting 5.1 (5 speakers and a subwoofer)
audio speakers
To connect two front speakers, two rear speakers, a center speaker, and a
subwoofer for six-channel (5.1 speaker) output:
1Turn off the PC.
.
2Connect the front speaker cable to the lime-green Audio Line Out connector that
matches the back of your PC.
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
3Connect the rear speaker cable to the black connector that matches the back of
your PC.
For type 3 connectors, the blue Audio Line In connector functions as a rear line
out when a multichannel audio configuration is activated.
4Connect the center/subwoofer speaker cable to the gold (or pink Mic)
connector that matches the back of your PC.
For type 3 connectors, the pink Mic connector functions as a center/subwoofer
speaker Line Out when a multichannel audio configuration is activated.
5Connect the cables to the audio system.
6Connect the front, rear, and center speakers to the subwoofer. Refer to the
speaker documentation.
7Turn on the PC.
NOTE: Always turn on the PC before you turn on the speaker system.
OUT
36S
IN
36S
36S

Configuring Speaker and Sound Options 29
8Plug in the speaker system power.
9Turn on the speaker system.
10 After the speakers are connected to the PC, configure the audio software for
sound output for your PC model:
•Type 3 connectors: See “Configuring Audio Output with Multi-channel
Sound Manager” on page 37.
•Type 6 connectors: See “Configuring Audio Output with Sound Effect
Manager” on page 38.
•Type 6 connectors — multi-streaming: See “Configuring Audio Output with
Realtek HD Sound Effect Manager” on page 41.
The following diagram shows a typical 5.1 audio installation:
Connecting 7.1 (7 speakers and a subwoofer)
audio speakers
To connect two front speakers, two side speakers, two rear speakers, a center
speaker, and a subwoofer for eight-channel (7.1 speaker) output:
1Turn off the PC.
.
2Connect the front speaker cable to the lime--green Audio Line Out connector on
the back of your PC.
3Connect the rear speaker cable to the black connector on the back of your PC.
OUT IN

Configuring Speaker and Sound Options 31
Connecting the PC to a Home Audio
System
You can connect your PC to your home stereo or home theater multichannel audio
receiver/amplifiers using your existing speakers.
For example, see “2 or 2.1 home stereo installation” on page 32, or “5.1 (5
speakers and a subwoofer) home audio installation” on page 33.
Y adapter cables
Most home receiver/amplifiers have RCA-type connectors. You may need
to connect Y adapter cables between your PC and your receiver/
amplifier. Y adapter cables have one 1/8-inch (3.5 mm) stereo mini-jack
on one end and two RCA connectors on the other end. These cables are
purchased separately.
The number of Y adapter cables you need to connect to your home stereo
system depends on the number of speakers you install:
•2/2.1 speaker system: 1 Y adapter cable
•4/4.1 speaker system: 2 Y adapter cables
•5.1 speaker system: 3 Y adapter cables
•7.1 speaker system: 4 Y adapter cables
Connecting a home stereo to a PC typically requires audio cables that are long
enough to connect from the PC to the stereo. You may also need to purchase RCA or
mini-extension cables.
NOTE: Y adapter and extension cables are purchased separately.

Configuring Speaker and Sound Options 33
5.1 (5 speakers and a subwoofer) home audio
installation
The following diagram shows a typical advanced home theater audio 5.1 speaker
installation that requires multichannel inputs on a receiver/amplifier.
This is only a suggested configuration. Your system may be different.
PC to 5.1 multichannel audio system connection
A
PC back-panel
connectors
(type 3, type 6,
or sound card)
BY adapter cables
CReceiver/amplifier
DSubwoofer
ECenter speaker
FFront speakers
(left and right)
GRear speakers
(left and right)
OUT
IN
A
B
C
D E F G

34 Getting Started Guide
5.1 (5 speakers and a subwoofer) home audio
installation procedure
To connect a six-channel (5.1 speaker) home audio system to the PC:
1Turn off the PC.
2Turn off the receiver/amplifier.
3Connect the front stereo mini-jack end of a Y adapter cable into the lime-green
Audio Line Out connector that matches the back of your PC:
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
Connect the left and right ends of the Y adapter cable into the front left (L) and
right (R) inputs on the back of the receiver/amplifier.
4If you have rear speakers, connect the rear stereo mini-jack end of a Y adapter
cable into the Audio Line In (blue) or the rear speaker out (black) connector that
matches the back of your PC.
Connect the left and right ends of the Y adapter cable into the rear left (L) and
right (R) inputs on the back of the receiver/amplifier.
NOTE: Receiver/amplifier input connectors may be labeled Surround, 5.1, or
6 Channel inputs, CD, DVD, or DVD In.
OUT
36S
IN
36S

Configuring Speaker and Sound Options 35
5Connect the stereo mini-jack of a Y adapter cable into the microphone (pink)
connector or the center speaker/subwoofer (gold) connector that matches the
back of your PC.
•Connect the left and right ends of the Y adapter cable into the center/
subwoofer inputs on the back of the receiver/amplifier (5.1 or higher
channel system).
•Plug the Y adapter cable into the subwoofer connector on the back of the
receiver even if a subwoofer is not used.
6Turn on the receiver/amplifier.
7Select the receiver/amplifier input that the Y adapter cables are plugged into.
8Turn on the PC.
9After the audio system is connected to the PC, configure the audio software for
sound output for your PC model:
•Type 3 connectors: See “Configuring Audio Output with Multi-channel
Sound Manager” on page 37.
•Type 6 connectors: See “Configuring Audio Output with Sound Effect
Manager” on page 38.
Connecting Digital Audio
(Select models only)
If you have a sound card and you are connecting your home stereo
AV receiver via Digital Out, plug the 3.5-mm stereo plug into the Digital
Out connector on the sound card. Connect the red RCA stereo plug in
the 3.5-mm Y cable to the AV receiver’s digital input connector. If the red
RCA stereo plug does not work, try the white stereo plug. One of the
connectors is not used.
To connect digital audio, your PC must include a digital out connector on
the sound card or on the back panel. You do not need to connect
multichannel speaker outputs if you connect the digital output.
NOTE: Always turn on the PC before you turn on the speaker system.
36S

36 Getting Started Guide
To connect digital audio speakers:
1Turn off the PC.
2Connect the digital input (S/PDIF) on the digital speakers or a digital audio
system to the orange digital out connector that matches the back of your PC:
•Type 3 is three connectors
•Type 6 is six connectors
•Type S is sound card
3Turn on the PC.
4Plug in the speaker system power.
5Turn on the speaker system.
6After the speakers are connected to the PC, configure the audio software for
sound output for your PC model:
•Audio card with digital output and type 3 connectors: See “Configuring
Audio Output with Multi-channel Sound Manager” on page 37. Follow the
instructions to enable digital audio output.
•Audio card with digital output and type 6 connectors: See “Configuring
Audio Output with Sound Effect Manager” on page 38. Digital audio
output is already enabled as the default.
Configuring Audio Output
You can configure your speaker’s audio output with the following software. Use the
software that applies to your PC model:
•WinDVD Player
•Multi-channel Sound Manager (type 3 connectors)
•Sound Effect Manager (type 6 connectors)
•Realtek HD Sound Effect Manager (multi-streaming audio)
NOTE: Always turn on the PC before you turn on the speaker system.
DIGITAL
AUDIO OUT
36S
DIGITAL
AUDIO OUT

Configuring Speaker and Sound Options 37
Configuring Audio Output with Multi-
channel Sound Manager
If your PC model has type 3 connectors, follow these steps after you have installed
and connected your speakers.
To configure multichannel audio output for PCs with Multi-channel Sound Manager:
1Click Start on the taskbar.
2Choose All Programs.
3Click Multi-channel Sound Manager. The Multi-channel Audio
Configuration window opens with one of five control screens.
•Sound Effect — Select the environment settings.
•Equalizer — Equalize the audio frequencies.
•Speaker Configuration — Select the number of speakers. The Audio
Connector Switch indicates the speaker configuration.
•Speaker Test — Test all connected speakers for correct configuration.
•General — View driver and audio information.
4Click the Speaker Configuration tab near the top of the window to open
the control screens. (Your speakers may need to be plugged in to see this tab.)
5Select the option describing the number of speakers in your system, in a range
from 2/2.1 speaker mode to 5.1 speaker mode.
6Enable digital audio if you want digital audio output. See “Enabling digital
audio output with Multi-channel Sound Manager (optional)” on page 38.

38 Getting Started Guide
7Click OK.
8Test the speakers. Click the Speaker Test tab. Follow the instructions.
9Configure audio output for the WinDVD Player. See “Configuring Audio for
WinDVD Player” on page 47.
Enabling digital audio output with Multi-channel
Sound Manager (optional)
Your PC must include a digital audio out connector on the back panel.
To enable digital audio output:
1Follow steps 1 through 5 of the previous procedure, “Configuring Audio Output
with Multi-channel Sound Manager.”
2Place a check next to Enable digital audio output. The Output digital and
analog option is automatically selected.
3Connect the digital audio output connector on the back of your PC to your
home audio system’s digital audio input.
4Select your stereo system’s digital audio input.
5Click OK.
6Test the speakers, by playing a CD, for example. (If you test using a DVD, you
need to configure WinDVD first. See “Configuring Audio for WinDVD Player”
on page 47.)
7Configure audio output for the WinDVD Player. See “Configuring Audio for
WinDVD Player” on page 47.
If you select Enable digital audio output, the microphone volume setting
becomes not muted, and the recording source is fixed in Stereo Mix. If you place the
microphone too close to the speakers, feedback can occur.
Configuring Audio Output with Sound
Effect Manager
Follow these steps after you have installed and connected your speakers, if your PC
model has type 6 connectors.
1Click Start on the taskbar.
2Click Control Panel.
3Click Sounds, and then Speech and Audio Devices (or Sounds and
Audio Devices).
NOTE: A connector with no descriptive text in the Connection Guide indicates that
the connector is not used for the selected speaker configuration.

Configuring Speaker and Sound Options 39
4Click Sound Effect Manager. The window opens.
5Click the Speaker Configuration tab.
6Select the option describing the number of speakers in your system in a range
from 2.1 Speaker to 7.1 Speaker.
7Click the Speaker Test button to test the speakers.
8Click OK.
9Configure audio output for the WinDVD Player. See “Configuring Audio for
WinDVD Player” on page 47.
The Sound Effect Manager control screens
• Sound Effect — selects the Environment and the Equalizer settings. You can
select an environment such as Under Water or Auditorium. To use the Equalizer,
click the Power button in the center of the circular equalizer control to turn it on.
You can click a preset button, such as Pop or Live, or manually adjust the
settings and then save them for easy selection later.
• Speaker Configuration — selects the number of speakers, shows the
Connection Guide, and has the Speaker Test button to test the speakers. A
connector with no descriptive text in the Connector Guide indicates that the
connector is not used for the selected speaker configuration.
• Digital Audio — selects the digital audio output and digital audio frequency
for the digital audio connectors on the PC.
• Audio Wizard — opens a window that shows the connector panel on the
front of the PC. To close the window without enabling the wizard, click OK.
To enable the Audio Wizard:
Make sure the Enable auto detection check box is selected to enable the wizard.
Click OK to close the window.
Using the Audio Wizard in the Sound Effect
Manager
The Sound Effect Manager Audio Wizard can help you connect front-panel audio.
To use the Audio Wizard:
1Turn on the PC.
2Click Start on the taskbar.
3Choose Control Panel.
4Click Sounds, then Speech and Audio Devices (or Sounds and Audio
Devices).
5Click Sound Effect Manager. The window opens.

40 Getting Started Guide
6Click Audio Wizard. A window opens that shows the connector panel on the
front of the PC.
7Place a check in the Enable jack detection check box to enable the wizard.
8Connect the speaker system audio cable plugs into the connectors on the front
of your PC. The panel display highlights a cable that is properly inserted in a
connector.
9Close the window.
Retasking front-panel connectors
With the Audio Wizard enabled, both the microphone connector and the
headphones connector on the front of the PC can be retasked to perform a different
audio function. These two connectors are universal audio jacks. When you plug in a
cable, the wizard asks you to select the function for the cable from a list, and then it
sets the universal audio jack to perform as the selected function. The functions are:
•Stereo Speaker (Out)
•Microphone (In)
•Headphone (In)
•Audio Line In
To retask front-panel connectors:
1Follow steps 1 through 7 of the procedure, “Using the Audio Wizard in the
Sound Effect Manager” on page 39.
2When you plug in a cable, the wizard asks you to select the device you
plugged in from a list.
3Close the window.
Disabling digital audio output with Sound Effect
Manager (optional)
To disable digital audio output:
1Open the Sound Effect Manager:
Click Start, Control Panel, Sounds, Speech, and Audio Devices, and
then Sound Effect Manager.
2Click Audio Wizard. A window opens displaying the connector panel on the
front of the PC.

42 Getting Started Guide
Configuring the Realtek HD Sound Effect
Manager
1Click the Audio I/O tab.
2Select the option describing the number of speakers in your system — for
example, 7.1 speakers.
3Only connectors being used are shown; if the connector is not shown it means
that it is not used for the selected speaker configuration.
4Click OK.
To hear DVD movies recorded with multi-channel audio from all speakers, change
the audio properties for the DVD player software program to match your speaker
configuration (if your DVD program supports more than two channels).
To use a microphone or set up the PC for recording, see “Configuring sound for
recording with the Realtek HD Sound Effect Manager” on page 42.
To use Multi-streaming Audio, see “Configuring Multi-streaming Audio” on page 43.
Configuring sound for recording with the
Realtek HD Sound Effect Manager
The microphone connector is ready to use for recording sound. If you want to use
another connector for recording, such as the Digital Audio In connector, use these
steps to select it.
1Click Start on the taskbar; then Control Panel, Sounds, Speech, and
Audio Devices, and then Realtek HD Sound Effect Manager.
2Click the Mixer tab.
3In Record click the drop-down list. Choose:
•RealTek HD Digital Input to use the digital audio in connector (select
models only).
•Line in/Mic in to use the Audio Line In (In) or the Microphone (Mic)
connectors.
4Click OK to close the window.
NOTE: The front pink and green connectors can be retasked to perform other audio
functions; refer to “Retasking front panel audio connectors” on page 43.

Configuring Speaker and Sound Options 43
Retasking front panel audio connectors
The pink and green connectors on the front of the PC connectors can be retasked as
needed.
1Click Start on the taskbar; then Control Panel, Sounds, Speech, and
Audio Devices, and then Realtek HD Sound Effect Manager.
2Click the Audio I/O tab.
3Click the tool icon in the Front Panel section. The connector settings
window displays.
4Select Enable Jack detection when device is plugged in, and click OK.
The front pink and green connectors can now be used as input or output devices.
Configuring Multi-streaming Audio
The Realtek HD Sound Effect Manager software allows you to listen to two different
audio sources on two different speaker sets.
For example, you hear one audio source through a rear-panel speaker connection
and a second source through a front-panel headphone or speaker connection. You
must configure Multi-streaming Audio for your system if you want to hear two audio
sources on separate speakers.
Audio output overview
The front-panel audio output is the stereo headphone (green) connector only.
The rear-panel outputs are the speaker connectors that can be set up as multi-
channel out from stereo (2.1) to 7.1 (select models only) configurations. Refer to
your user documentation for powered speakers or AV receiver setup information.

44 Getting Started Guide
Audio input overview
You can select two of the following audio sources to play through front-panel
headphone and rear-panel speaker connectors:
1From an externally connected device source, such as:
•A microphone with cable connected to Mic In (pink).
•An MP3 player cable connected to Line In (blue).
2From an internal source inside or directly connected to the PC, audio files may
reside on: hard disk drives, DVDs, CDs, USB drives, HP Personal Media Drives,
or any connected device. Play internal media files through programs such as:
•Windows Media Player
•WinDVD
•HP Tunes
•Other installed media player software
When to use multi-streaming audio
You may multi-stream two audio sources as described in the following typical
examples:
1For online gaming, where you hear 5.1 game sound on your AV receiver or
powered speakers, while you also hear gaming conversation on your headset.
See “Example 1: For Online Gaming” on page 45.
2For digital home entertainment, where you hear:
•DVD sound on your living room TV/display or AV receiver from the rear
speaker connections.
•While you also hear your PC headphone or powered speakers that are
connected to the front panel green headphone jack, from one of the
following external PC audio sources:
aFront panel Line In
bInternal source residing on: a hard disk drive, DVD, CD, USB Drive, or
other external device.
See “Example 2: For Digital Home Entertainment” on page 46.
NOTE: Digital Audio In cannot be multi-streamed.

Configuring Speaker and Sound Options 45
Setting up multi-streaming audio
Example 1: For Online Gaming
To configure multi-streaming audio output for online gaming with Realtek HD Sound
Effect Manager, you must enable Voice-Over-IP software (software used to converse
over the Internet). Other players hear your voice from the microphone via the
Internet and you hear the game audio from the rear speakers:
1Connect the audio input and output connectors to:
•A headphone set to the front Headphone Out (green) connector.
•A microphone to the front Mic In (pink) connector for online conversation.
•A set of powered stereo 5.1, or 7.1 speakers to the rear Speaker Out
connectors for gaming sound output.
2Click the Realtek HD Audio Manager icon on the system tray to
open the Realtek HD Audio Sound Effect Manager window.
3Choose the Mixer tab.
4Click the Multi-streaming setting audio button. The dialog box
opens.
5Select the Enable multi-streaming playback check box.
6Select one of the following options to determine how you would like to hear
your own voice:
•Check the Output Mic In/Line In to front panel check box, and
select OK.
•Check the Output Mic In/Line In to rear panel check box, and
select OK.
7Select Realtek HD Audio rear output from the drop-down list.
8Start the game that you are about to play. You should hear the gaming sound
on the rear stereo, 5.1, or 7.1 speakers.
9At the Mixer tab, select Realtek HD Audio front output to enable audio
conversation with your teammates.
NOTE: To ensure you have sound output, go to the Mixer window and check that
the setting of the front pink microphone is not on mute.

46 Getting Started Guide
Example 2: For Digital Home Entertainment
To configure multi-streaming audio output for digital home entertainment with Sound
Effect Manager:
1Connect the audio output connectors to:
•A headphone set or powered speakers connected to the front Headphone
Out (green) connector for stereo music playback.
•A set of powered stereo, 5.1, or 7.1 speakers connected to the rear
Speaker Out connectors for DVD playback sound output.
2Click the Realtek HD Audio Manager icon on the system tray to
open the Realtek HD Audio Sound Effect Manager window.
3Choose the Mixer tab.
4Click the Multi-streaming setting audio button. The dialog box
opens.
5Select the Enable multi-streaming playback check box, and
select OK.
6Select Realtek HD Audio rear output from the drop-down list.
7Open WinDVD to play a DVD movie. You should hear the DVD sound on the
rear speakers.
8Select Realtek HD Audio front output from the drop-down list.
9Open Windows Media Player to play music. You should hear the music sound
on the front headphone connection.
10 To hear an external device source from the Line In or Mic In connection:
aClick the Multi-streaming setting audio button. The dialog box
opens.
bCheck the Output Mic In/Line In to front panel check box in the
dialog box, and select OK.

Configuring Speaker and Sound Options 47
Configuring Audio for WinDVD Player
Follow these steps after you have installed, connected, and configured your
speakers.
The InterVideo WinDVD program (select models only) is set up for two-speaker
(stereo) output. To hear all speakers from DVD movies recorded with multichannel
audio, change the audio properties for WinDVD to match your speaker
configuration (if your InterVideo WinDVD program supports more than two
channels).
If you want to play a stereo DVD, you may change the audio properties of WinDVD
to match the recorded DVD audio output.
1Insert a DVD.
Or
Click Start, choose All Programs, InterVideo WinDVD, InterVideo
WinDVD Player, and then click InterVideo WinDVD. The WinDVD video
window opens.
2Right-click anywhere in the WinDVD video window, and then click Setup. The
Setup window opens.
3Click the Audio tab.
4Select Audio Output Configuration. Choose Analog or Digital
(S/PDIF). Click Apply.
5Select Audio Speaker Configuration. Click the option for the number of
speakers to match your multichannel speaker system.
6You can click the Test button to test the speakers. You should be able to hear
the speakers. Click Stop, and then click OK.
Using Headphones
Your PC comes with a headphones connector (lime-green) on the front of the
PC. The headphones connector is labeled with a headphones icon.
You can also connect headphones to the Line Out connector (lime-green) on
the back of your PC.
Using a 2.1 speaker system with headphones
For select models with the 2.1 speaker system, look for the headphones connector
on the right side of the main speaker. When headphones are plugged in, the sound
to the speakers and the subwoofer is muted.
OUT

48 Getting Started Guide
Using a 5.1 to 7.1 speaker system with
headphones
For select models that include a 5.1 or higher speaker system, a headphones
connector is located on the right side of the control tower.
If the control tower displays HP (for headphones), the headphones are enabled; the
sound to the speakers and the subwoofer is muted.
•Push and hold the On button on the control tower for several seconds to enable
sound from the speakers.
•Press the On button briefly to enable the headphones.
Selecting recording devices
(Type 6 connectors only)
To select a sound recording device:
1Click Start on the taskbar.
2Choose Control Panel.
3Click Sounds and Audio Devices (or Sounds, Speech, and Audio
Devices). The Sounds and Audio Devices window opens.
4Click the Audio tab. The window opens.
5In Sound Recording, select a recording device; for example, Realtek HD Front
Pink Jack.
6Click OK.
7Close the window.
Resolving Sound Issues
If you don’t have sound from your speakers, check the following:
•Check volume and mute settings. See “Using Headphones” on page 47.
•Use active, powered speakers, or speakers with an amplifier.
•Verify cable connections.
•Make sure the software program and sound software are configured.
•Some programs may result in low volume, even when the Volume knob is turned
to the maximum position. If this is the case, double-click the Volume icon on
the taskbar, and increase the volume.
•Reconfigure the sound software for surround sound.
•Reinstall the sound card drivers by using HP Application Recovery. See
“Application Recovery” in the PC Troubleshooting and Maintenance Guide.

Using the Memory Card Reader 49
Using the Memory Card Reader
Digital cameras and other digital imaging devices use memory cards, or media,
to store digital picture files. The optional memory card reader (select models only)
can read and write to a variety of types of memory cards and the IBM Microdrive
disk drive.
The card reader is accessible directly on the front of the PC or located inside a
cover. It has two or four horizontal card slots, which accept the memory cards and
the Microdrive disk drive.
You can place media in one or more of the card slots and use each media
independently. Place only one piece of media in a slot at one time.
Each card slot has its own drive letter and icon. When you insert media, the display
label may change to the title of the media, if the title is present.
If you open the Safely Remove Hardware window by mistake, click Close.
CAUTION: Do not click in the Safely Remove Hardware window Stop
with the USB Mass Storage Device selected. Doing so removes the
operating system recognition of the memory card reader from your
PC; you must restart the PC to see your memory card reader again.

50 Getting Started Guide
Using the Memory Card Reader
1Insert the media into the card slot until it stops.
The activity light (A) on the memory card reader lights, and the PC
automatically detects the media.
2The PC opens a window so you can use the media contents. You can copy files
from or to the media.
3When you are finished, right-click the drive icon, select Eject, check that the
activity light is on but not blinking, and then remove the media. A steady
activity light indicates that the PC is not reading or writing the media.
NOTE: Media must be inserted correctly. Note the direction of the notched
corner on the media. See the “Media Insertion Guide” on page 51.
CompactFlash and Microdrive are keyed and cannot be inserted incorrectly.
Insert the receptacle edge (holes) of this media into the slot.
WARNING: Do not try to remove media when the activity light is
blinking; doing so may cause loss of data.
Produkt Specifikationer
Mærke: | HP |
Kategori: | Skrivebord |
Model: | Pavilion a1010n |
Har du brug for hjælp?
Hvis du har brug for hjælp til HP Pavilion a1010n stil et spørgsmål nedenfor, og andre brugere vil svare dig
Skrivebord HP Manualer

3 Oktober 2024

29 September 2024

15 September 2024

9 September 2024

6 September 2024

3 September 2024

2 September 2024
