The HP ProLiant ML350e Gen8 is a dual processor tower platform, which is built on the latest Intel® Xeon® E5-2400 processors to

create unique system architecture. This unique architecture as well as flexible deployment options allow the businesses to scale as

needed so they can optimize their IT spending dollars. The HP ProLiant ML350e Gen8 delivers the industry's most powerful embedded

management technology with HP integrated Lights-Out 4 (iLO4), which allows businesses to manage the servers anytime and from

anywhere.

Front View:

Rear View:

SATA DVD ROM or DVD RW optical drive

One (1) standard 460W Non-Hot Plug Power supply

Two (2) removable media bays

Four (4) USB connectors

Two (2) standard system fans

iLO connector

One (1) standard 460W Non-Hot Plug Power Supply

Video connector

Six (6) PCIe expansion slots (4 PCIe 3.0 and 2 PCIe 2.0)

Serial connector

12 total DIMM slots: DDR3 Registered (RDIMM) or

Unbuffered (UDIMM) memory (6 DIMM slots per CPU)

NIC connector 2

Processor and processor heatsink

NIC connector 1

Quick removal access panel

UID LED button

Standard drive cage (4LFF or 6LFF or 8SFF)

PCIe slot 1 (for processor 1)

10.

Optional drive cage (6LFF or 8SFF)

10.

PCIe slot 2 (for processor 1)

11.

Power On/Standby button and system power LED button

11.

PCIe slot 3 (for processor 2)

12.

NIC status LED

12.

PCIe slot 4 (for processor 2)

13.

Health LED

13.

PCIe slot 5 (for processor 1)

14.

UID LED button

14.

PCIe slot 6 (for processor 1)

15.

Four (4) USB connectors

What's New

Added new 6G SATA ME Hot Plug Enterprise Mainstream Solid State Drive s

Supports new HP iLO Essentials license ideal for small and medium business customers

QuickSpecs

HP ProLiant ML350e Generation 8 (Gen8)

Overview

DA - 14340 Worldwide — Version 12 — March 1, 2013

Page 1

Produkt Specifikationer

Mærke:	HP
Kategori:	Server
Model:	ProLiant ML350e
Bredde:	218 mm
Dybde:	740 mm
Højde:	462 mm
Vægt:	26850 g
Opbevaringstemperatur (T-T):	-30 - 60 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	2
Ethernet LAN:	Ja
Processorkerner:	4
Driftstemperatur (T-T):	10 - 35 °C
Intern hukommelse:	4 GB
Kabelteknologi:	10/100/1000Base-T(X)
Intel® Wireless Display (Intel® WiDi):	Ingen
Strømforsyningens indgangsfrekvens:	50 - 60 Hz
Processorfrekvens:	2.2 GHz
Processorserie:	Intel® Xeon® E5 Family
Processortråde:	4
Processor-cache:	10 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	- Mhz
Maksimal intern hukommelse:	- GB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Hukommelsesstik:	12
Processorproducent:	Intel
Processormodel:	E5-2407
Ethernet-grænsefladetype:	Gigabit Ethernet
Optisk drevtype:	DVD-ROM
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
HDD-grænseflade:	Serial ATA III
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Tower (5U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Intel® Identity Protection Technology version:	0.00
Konfliktfri processor:	Ingen
HDD-størrelse:	3.5 "
Strømforsyning:	460 W
Processor sokkel:	LGA 1356 (stik B2)
Processor litografi:	32 nm
Stepping:	M1
Thermal Design Power (TDP):	80 W
Maksimalt antal PCI Express-kanaler:	24
PCI Express slots version:	3.0
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- Mhz
Systembus-hastighed:	6.4 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Sandy Bridge EN
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Identity Protection Teknologi (Intel® IPT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ja
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	45 x 42.5 mm
Processor kode:	SR0LR
Processor ARK ID:	64614
Understøttede instruktionssæt:	AVX
Intel® Smart Cache:	Ja
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	54 TB
Redundant strømforsyning:	Ingen
Bundkort chipsæt:	Intel C600
LAN Kontroller:	HP NC361i
Hot-swap:	Ja
Billedtypekort:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-18.gif" title="Block Diagram" /></div>
Maksimal intern hukommelse understøttet af processor:	375 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,1066 Mhz
Hukommelsesbåndbredde understøttet af processor (maks.):	25 GB/sek.
Skalerbarhed:	2S
Maksimalt antal SMP-processorer:	4
Antal QPI-lins:	1
Hukommelseskanaler understøttet af processor:	Tredobbelt
Antal af hovedstrømforsyninger:	1
