Manual IB-CVB517M2
Safety informationSafety information
1. Packing content
1x IB-CVB517M2, 1x screw set, 1x quick installation guide
2. Key features
Converts 1x M.2 SATA to SATA III + 1x M.2 PCIe to Mini SAS HD
Supports M.2 size 22x 30/42/60/80 mm
Interface to PC: 1x SATA III + 1x Mini SAS HD (SFF-8643)
M.2 SATA SSD with B-Key or B+M-Key, M.2 PCIe SSD with M-Key
Data transfer rate up to 32 Gbit/s (PCIe) and 6 Gbit/s (SATA)
Compatible with Windows 7, macOS 10.0 or higher
3. Installation
3.1 Mount the M.2 SSD with a slight angle into the M.2 slot. (M.2 PCIe SSD with M-Key for PCIe slot.
M.2 SATA SSD with B-Key or B+M-Key for SATA III interface.)
3.2 Fasten the SSD module with the screws
3.3 Make sure the computer is turned off and all power cables are disconnected from the system.
3.4 Open the computer case and connect the IB-CVB517M2 via a Mini SAS HD cable to the available
slot for the M.2 PCIe SSD on the motherboard.
3.5 Connect the IB-CVB517M2 via a SATA data cable to the motherboard for the M.2 SATA SSD.
3.6 Secure the 3.5" converter on the housing of the PC.
3.7 Close the case and restart your PC.
Please read carefully the following information to prevent injuries, damage to material and device as
well as data loss:
Warning levels
Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of
occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.
Warns of a hazardous situation causing .directly death or serious injury
Warns of a hazardous situation that cause death or serious injury.potentially may
Warns of a hazardous situation that cause minor injury.potentially may
Warns of a situation that cause material or environmental damage and potential may
disrupt operative processes.
1. Risk of electrical shock
Contact with parts conducting electricity
Risk of death by electrical shock
Read the operating instructions prior to use
Make sure the device has been de-energised prior to working on it
Do not remove contact protection panels
Avoid contact with conducting parts
Do not bring plug contacts in contact with pointed and metal objects
Use in intended environments only
• Operate the device using a power unit meeting the specications of the type plate only!
Keep the device/power unit away from humidity, liquid, vapour and dust
Do not modify the device
Do not connect the device during thunderstorms
Approach specialist retailers if you require repairs
2. Hazards during assembly (if intended)
Sharp components
Potential injuries to fingers or hands during assembly (if intended)
Read the operating instructions prior to assembly
Avoid coming into contact with sharp edges or pointed components
Do not force components together
Use suitable tools
Use potentially enclosed accessories and tools only
3. Hazards caused by a development of heat
Insufficient device/power unit ventilation
Overheating and failure of the device/power unit
Prevent externally heating up components and ensure an exchange of air
Do not cover the fan outlet and passive cooling elements
DANGER
WARNING
CAUTION
IMPORTANT
WARNING
CAUTION
IMPORTANT
Avoid direct sunlight on the device/power unit
Guarantee sufficient ambient air for the device/power unit
Do not place objects on the device/power unit
4. Hazards caused by very small parts and packaging
Risk of suffocation
Risk of death by suffocation or swallowing
Keep small parts and accessories away from children
Store/dispose of plastic bags and packaging in an area that is inaccessible to children
Do not hand over small parts and packaging to children
5. Potential data loss
Data lost during commissioning
Potentially irreversible data loss
Always comply with the information in the operating instructions/quick installation guide
Exclusively use the product once the specifications have been met
Back up data prior to commissioning
Back up data prior to connecting new hardware
Use accessories enclosed with the product
6. Cleaning the device
Harmful cleaning agents
Scratches, discolouration, damage caused by moisture or short circuit in the device
Disconnect the device prior to cleaning
Aggressive or intense cleaning agents and solvents are unsuitable
Make sure there is no residual moisture after cleaning
We recommend cleaning devices using a dry, anti-static cloth
7. Disposing of the device
Environmental pollution, unsuitable for recycling
Potential environmental pollution caused by components, recycling circle interrupted
This icon on product and packaging indicates that this product must not be disposed of as part of domestic
waste. In compliance with the Waste Electrical and Electronic Equipment Directive ( ) this electrical deWEEE -
vice and potentially included batteries must not be disposed of in conventional, domestic waste or recycling
waste. If you would like to dispose of this product and potentially included batteries, please return it to the
retailer or your local waste disposal and recycling point.
If you have any questions, please do not hesitate to contact our support at
support@raidsonic.de www.raidsonic.de or visit our website at .
WARNING
IMPORTANT
IMPORTANT
IMPORTANT
© Copyright 2017 by RaidSonic Technology GmbH. All Rights Reserved
The information contained in this manual is believed to be accurate and reliable. RaidSonic Technology GmbH assumes
no responsibility for any errors contained in this manual. RaidSonic Technology GmbH reserves the right to make changes
in the specifications and/or design of the above mentioned product without prior notice. The diagrams contained in this
manual may also not fully represent the product that you are using and are there for illustration purposes only. RaidSonic
Technology GmbH assumes no responsibility for any differences between the product mentioned in this manual and the
product you may have.
