Side 1/2

8. USB-C data input port

Connect your phone to the hip dac 3 with a Lightning to USB

Camera Adapter (Apple) or USB-C to USB-C cable (Android).

When using other audio sources, please connect with a USB

cable. This USB-C port is intended for data transfe r only.

Tip: Fo r App le iOS a nd Android d evices, please u se ba ttery power on the hip dac 3,

otherwise you may receive error messages from your device.

Note: For use with PC it is necessary to d ownload drivers.

Tip: Fo r the required driver a nd all the latest firmware updates please refer to our

website: www.ifi-audio.com/download-hub/

9. USB-C (5V) battery charge input

For charging only. It will take ~3 hours for a high-powered USB

charger to fully charge hip dac 3. Use the enclosed USB 'Type A'

to 'Type C' cable, smart charger or a regular charger up to 6.3V.

10. LED for Battery Status

LED Status

White* > 75%

Green* 25% >

Red* 10% >

Red (flashing) 10% ≤

*B attery LED will flash when it is charging

ifi-audio.com Ver1.0

31 2 5 64

4. ON/OFF and Analogue Volume Control

The analogue volume control in hip dac 3 is superior to any digital

volume control.

Warning: Due to the hig h power of hip dac 3, always start off at a low volume level

so that there is no risk of damage to your headphones and your hearing. iFi audio is

not responsible for any hearing or equip ment da mage from misu se.

Power ON. Power OFF.

Tip: hip dac 3 will continue to use battery power even if the USB cable is connected

afterwards.

Tip: Fo r con nection to Apple devices, Apple Lightning to USB Camera Adapter is

required. For connecti on to Android devices, USB-C to USB -C cab le and

appropriate OS support are required.

For m ore information, please refer to www.ifi-aud io. com

5. Balanced 4.4mm headphone output

Connect balanced 4.4mm headphones.

6. S-Balanced 3.5mm headphone output

Connect 3.5mm headphones.

7. iEMatch switch

iEMatch reduces the output level, so that even the most

sensitive In-Ear-Monitors (IEMs) can be matched to the hip dac 3.

= 3.5mm he adphones

= of f

= 4.4mm he adphone

Tip: The hip da c 3 or the hea dphone w ill not be damaged if the i EMatch swit ch is adju sted inco rrectl y,

but the atte nuation level will not b e correct.

98 10

OFF

1. PowerMatch (on/off)

PowerMatch enables hip dac 3 to match headphones' impedance

and sensitivity in order to generate their highest operational

efficiency.

Tip: Fo r in-ear-moni tors (earbuds) try Powe rMatch off. For headphones try PowerMatch on,

When on, the gain increa ses by 10dB. If your IEMs a re very sensitive, tr y using the iEMatc h

feature (item 7 ).

2. XBass (on/off)

Many headphones lack the correct bass response. XBass is an

analogue circuit designed to 'add back' the lost bass response for a

more accurate reproduction of the original music.

3. Audio Format LED (kHz)

The LED colour scheme indicates the audio format and sampling

frequency received by hip dac 3 from the music source.

LED Mode

Yellow PCM 44.1/48kHz

White PCM 88.2/96/176.4/192/352.8/384kHz

Cyan DSD 64/128

Red DSD 256

Green MQA

Blue MQA Studio

Magenta Original Sample Rate*

*MQB

Warning: Installing GTO enabled firmware may res ult in the LED's on this device no longer

changing in accordan ce with th e above table

iE Ma tc h

of f

3. 5

4. 4

SPECIFICATIONS

Inp ut: USB-C

Formats supported : DSD256 / 11.3MHz

PCM 384kHz

full MQA Decoder

DAC: Bit-Perfect DSD & DXD DAC b y Burr Brown

Head phone Outputs:

Balanced 4.4mm

S-BAL 3.5mm

Power Output:

Balanced 400mW @ 32 ; 6.3V @ 600

Ω Ω

S-BAL 280mW @ 32 ; 3.2V @ 600Ω Ω

Output Impedance:

Balanced ≤1 , With iEMatch engaged: ≤4.5Ω Ω

S-BAL ≤1 , With iEMatch engaged: ≤4.5ΩΩ

SNR :

Balanced ≥109dB(A) @ 0dBFS

S-BAL ≥103dB(A) @ 0dBFS

DNR:

Balanced ≥109dB(A)

S-BAL ≥103dB(A

THD + N:

Balanced <0.006X% (360mW/2.0V @ 600Ω)

S-BAL <0.01% (100mW/1.27V @ 16Ω)

Frequency Response: 20Hz - 45kHz (-3dB)

Power Consumption: <2W idle, 4W max

Battery : Lithium-polymer 2200mAh approx.

8 hours

Power System: Charging via USB-C,BC V1.2 compliant up

to 1000mA charging current

Dimensions: 102 x 70 x 14 mm (4.0" x 2.8" x 0.6")

Net weight: 135 g (0.30 lbs)

Limited Warranty: 12 months*

*12 months typical or as permitted/required by local reseller laws.

**Specifications are subject to change witho ut notice.
